Feniex FS-0416 User manual

Fusion S 400 Lightstick Instruction Manual
1.800.615.8350 / feniex.com
Feniex Product Copyrights This price List and the mentioned Feniex products include or describe copyrighted Feniex material. Laws in the
United States and other countries preserve for Feniex Industries and its licensors certain exclusive rights for copyrighted material, including the
exclusive right to copy, reproduce in any form, distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted
material of Feniex and its licensors contained herein or in the Feniex products described in this Price List may not be copied, reproduced,
distributed, merged or modied,transmitted, transcribed, stored in retrieval system or translated into any language or computer language, in any
form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S.
Patent & Trademark Oce.
FUSION-S 400
LIGHTSTICK
FS-0416
Equipment Dimensions
pp. 03
Specifications
pp.04
Wiring Diagram
pp.04
Quad Converter
pp.05
Feniex University
feniexuniversity.com

If the product needs to be returned for repair
or replacement, call our customer support line
to receive a return merchandise authorization
number.
Operational times are from 10 a.m. to 5 p.m.
central time, Monday through Friday. Please
do not send in product without contacting
support rst for a RMA number.
Service After Expiration
Feniex Industries will still provide service for
all products after expiration of the warranty.
For any issues, call the customer support
line. In some instances it may be necessary
for the product to be shipped, freight prepaid
and insured for loss or damage to Feniex
headquarters.
Copyright
This instruction manual and the Feniex
products described in this instruction manual
may include or describe copyrighted Feniex
material. Laws in the United States and other
countries preserve for Feniex Industries
and its licensors certain exclusive rights for
copyrighted material, including the exclusive
right to copy, reproduce in any form, distribute
and make derivative works of the copyrighted
material. Accordingly, any copyrighted
material of Feniex and its licensors contained
herein or in the Feniex products described in
this instruction manual may not be copied,
reproduced, distributed, merged or modied
in any manner without the express written
permission of Feniex Industries, Inc.
Feniex Product Copyrights
The products described in this document
are the property of Feniex Industries, Inc. It is
furnished by express license agreement only
and may be used only in accordance with the
terms of such an agreement. Products and
documentation are copyrighted materials.
Making unauthorized copies is prohibited by
law. No part of the product or documentation
may be reproduced, transmitted, transcribed,
stored in retrieval system or translated into any
language or computer language, in any form or
by any means, without prior permission from
Feniex Industries, Inc.
Safety Regulations
The following provides all the information
necessary to safely operate the previously
listed products of Feniex Industries, Inc. Please
read this manual thoroughly before installing or
operating your new product in order to prevent
any damage or injury. Failure to follow the
listed instructions in this manual may result in
damage to your products or personal injury.
• Proper installation of this product requires
good knowledge of automotive systems,
electronics and procedures.
• Please guarantee all vital components
of the vehicle are not in danger of being
damaged by drilling holes necessary for
installation. Check all sides of the mounting
surface before drilling any holes into the
vehicle.
• Do not install this product in any way
that interferes with the deployment of
the air bag. Doing so may damage the
eectiveness of the air bag and can lead
to serious personal and vehicle injury. The
installer will assume full responsibility of
proper installation of the new unit.
• Please clean the mounting surface before
installation of the unit when using tape,
brackets, magnet, Velcro or suction cups.
• The product's ground wire must be
connected directly to the Negative (-)
battery post for eective use of the unit.
Please follow all wiring guidelines provided
to guarantee long lifespan and productivity.
Failing to follow these instructions may
result in damage to the product.
Warranty
Feniex Industries, Inc. warranties to the original
purchaser that all our products shall be free
from defects in material and workmanship.
Feniex Industries' speakers, sirens, rocker
panels, AM600 Beacons, Torch Lights, AI
lightbars, AI Cubes, AM900 Work Lights, 8.5”
Dome Lights, ashlights, Remote Spot Lights
and controllers are warrantied for 2 years from
the manufacturing date. In addition, all other
products are warrantied for 5 years from the
manufacturing date.
If a warranty problem occurs, please contact
customer support at 1.800.615.8350 or visit
the web site at www.Feniex.com.
Warning! Utilizing non-factory screws and mounting
brackets may result in loss of warranty coverage.
Feniex Industries, Inc.
1.800.615.8350 / feniex.com
2
SAFETY REGULATIONS & WARRANTY

Feniex Industries, Inc.
1.800.615.8350 / feniex.com
3
EQUIPMENT DIMENSIONS
Feniex University
Before installing the Fusion®
S Lightstick, watch our
instructional video series,
Feniex University. Get an in-
depth look at the Fusion-S
Lightsticks, Quad Converter
and much more.
Use the link below:
feniexuniversity.com
18.8"
2.25"
1.3"

Feniex Industries, Inc.
1.800.615.8350 / feniex.com
4
Wire: Function:
Green Data Wire A
White Data Wire B
PATTERNS
SPECIFICATIONS
Voltage
10-18 Volts DC
Current Draw
Warranty 5 years
1Attack
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Cluster
Cluster Mix
Combo Single
Combo Triple
Vehicle Park
Half-Half Single
Half-Half Triple
1-1 Single
1-1 Triple
2-2 Single
2-2 Triple
All-on Single
All-on Triple
End + Corner
WIRING DIAGRAM
15A Fuse
4 Amps
2A Fuse

Feniex Industries, Inc.
1.800.615.8350 / feniex.com
5
15 Left Signal
16
17
18
19
20
21
22
23
24
25
26
27
28
Right Signal
Tail
Brake
Front Flood x
Rear Flood
Alley Right Flood x
Alley Left Flood x
California Red x
Cruise Left
Cruise Right
Dim 10%
Dim 50%
Arrow Position
1Front Mode 1 x
2
3
4
5
6
7
8
9
10
11
12
13
14
Front Mode 2 x
Front Mode 3 x
Driver Color
Rear Mode 1
Rear Mode 2
Rear Mode 3
Passenger Color
Driver Cut x
Passenger Cut x
Front Cut x
Rear Cut
Left Arrow
Right Arrow
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬¬
¬
¬
STANDARD REAR: QUAD CONVERTER
¬
