EN
ROTARY PETROL LAWNMOWER USER’S MANUAL
3
Table of Contents
Petrol Lawnmower
INSTRUCTIONS FOR USE
Thank you for purchasing this rotary petrol lawnmower. Before you start using it, please,
carefully read this user's manual and save it for possible future use.
TABLE OF CONTENTS
1. GENERAL SAFETY REGULATIONS............................................................................................................................4
2. EXPLANATION OF INSTRUCTION LABELS ON THE MACHINE ....................................................................5
3. DESCRIPTION OF THE LAWNMOWER (Fig. 1) ..............................................................................................................7
4. ASSEMBLY/PREPARATION...........................................................................................................................................7
5. ASSEMBLING THE LAWNMOWER ...........................................................................................................................8
6. BEFORE STARTING THE LAWNMOWER.............................................................................................................. 10
7. CONTROLLING AND OPERATING THE LAWNMOWER...............................................................................11
8. SAFETY INSTRUCTIONS.............................................................................................................................................. 13
9. MAINTENANCE............................................................................................................................................................. 15
10. WHAT TO DO WHEN...................................................................................................................................................18
11. TECHNICAL SPECIFICATIONS................................................................................................................................. 19
12. DISPOSAL ........................................................................................................................................................................20
13. DECLARATION OF CONFORMITY ....................................................................................................................... 21

EN 4
FZR 5167-B
General safety regulations
1. GENERAL SAFETY REGULATIONS
IMPORTANT SAFETY NOTICE
Unpack the product carefully and do not throw away any of the packaging until you have found all the parts
of the product.
Store the machine in a dry place out of children’s reach.
Read all the warnings and instructions. Failure to comply with the warnings and instructions may lead to
electric shock, fire and/or serious injuries.
PACKAGING
The product’s packaging prevents damage during transport. This packaging is a resource and can be recycled.
USER MANUAL
Before starting to work with the machine, please read the following safety regulations and instructions for use.
Get familiar with the controls and correct use of the equipment. Keep the user’s manual in a safe place for easy
future reference. Save the original packaging, including the internal packing material, guarantee card and proof
of purchase receipt for at least the time of the guarantee. If you need to ship this machine, pack it in the original
cardboard box to ensure maximum protection during shipping or transport (e.g. when moving or when you need
to send this product for repair).
Note: If you hand over the appliance to somebody else, do so together with this user's manual. Make sure
you use the appliance properly by following the instructions in the included User manual. The user’s manual
also contains operating, maintenance, and repair instructions.
The manufacturer assumes no responsibility for accidents or damages arising from
failure to comply with these instructions.

EN
ROTARY PETROL LAWNMOWER USER’S MANUAL
5
Explanation of instruction labels on the machine
2. EXPLANATION OF THE INSTRUCTION LABELS
ON THE MACHINE
Before putting into operation, please carefully
read the user's manual.
Keep other persons away from the work area.
Attention, rotating blades! Protect yourself against
the danger of injury to limbs.
Emission of toxic gasses. Do not use the petrol
lawnmower in enclosed or unventilated areas.
Hot surfaces, risk of burns!
Before carrying out maintenance, turn off the
engine and disconnect the spark plug.
Never add fuel while the engine is running.

EN 6
FZR 5167-B
Explanation of instruction labels on the machine
Indicates that there is a risk of injury to persons, death or
damage to the machine if instructions are not followed.
Use ear protection.
Use eye protection.
Use breathing protection.
Always maintain a distance from moving parts.
Travel along the slope on contours, not up and down.
Conforms to all relevant European directives.
Petrol is extremely flammable and therefore allow the
engine to cool down for 2 minutes before adding more
fuel.

EN
ROTARY PETROL LAWNMOWER USER’S MANUAL
7
Description of the lawnmower | Assembly/Preparation
3. DESCRIPTION OF THE LAWNMOWER (Fig. 1)
1. Start/brake lever
2. Top part of the handle
3. Travel lever
4. Pull cord handle
5. Screws with quick couplers
6. Bottom part of the handle
7. Grass catcher cover - rear deflector
8. Mowing height adjustment lever
9. Lawnmower chassis
10. Side discharge deflector
11. Side discharge cover
12. Oil tank cap
Fig. 1
4. ASSEMBLY/PREPARATION
Before assembling and starting the petrol lawnmower, first carefully read the entire user's manual and the
instructions contained in it.
IMPORTANT INFORMATION: The lawnmower is supplied WITHOUT FUEL AND OIL in the engine.
Your new lawnmower was tested at the production plant meaning that a small amount of residual oil may
be in the engine.
TAKING THE LAWNMOWER OUT OF THE CARDBOARD PACKAGING
Take the lawnmower out of the cardboard packaging and check that no loose parts are left in the packaging.

EN 8
FZR 5167-B
Assembling the lawnmower
5. ASSEMBLING THE LAWNMOWER
IMPORTANT INFORMATION: Carefully unfold the lawnmower handle careful not to pinch your finger or
damage the lawnmower's control cables.
1. ASSEMBLING THE HANDLE
1. Attach the lower part of the handle to the lawnmower chassis and secure with screws with quick coupler (Fig.
2.1)
2. Attach the top part of the handle to the bottom part of the handle using the included screws with quick coupler
and wing nuts (Fig. 2.2).
IMPORTANT: The handle can be adjusted to 3 different positions according to the user's needs (Fig. 2.3)
Fig. 2.1
Fig. 2.2 Fig. 2.3
2. SECURING CABLES
Secure the cables on both sides of the handles with plastic brackets (Fig. 3)
Fig. 3

EN
ROTARY PETROL LAWNMOWER USER’S MANUAL
9
Assembling the lawnmower
3. ASSEMBLING THE GRASS CATCHER
Secure the plastic hooks ending the textile part of the grass catcher into the steel structure (Fig. 4.1)
Fig. 4.1
IMPORTANT: The grass catcher is equipped with a full indicator. It is a plastic flap at the rear of the grass
catcher. When the grass catcher is not full, the flap is raised. When it closes, it is necessary to tip out the
grass catcher.
4. INSTALLING THE GRASS CATCHER AND SECURING THE STARTER CABLE
Attach the grass catcher to the lawnmower (Fig. 4.2)
Secure the starter cable (Fig. 4.3)
Fig. 4.2
Fig. 4.3

EN 10
FZR 5167-B
Before starting the lawnmower
6. BEFORE STARTING THE LAWNMOWER
ADDING OIL
The lawnmower is supplied without motor oil.
Before first start up, add motor oil SAE30 or 15W-
40 (approx 470 ml) according to the following
instructions.
1. When pouring in the oil, place the lawnmower on a level
surface.
2. Remove the plug with oil dipstick from the oil filler hole (Fig.
5).
3. After adding oil, put the dipstick back into the hole and
tighten it.
4. The oil level must be within the hatched section of the
dipstick, at the maximum level of the arrow marked on the dipstick (Fig. 5.).
Caution! DO NOT OVERFILL the oil tank, otherwise a large amount of smoke will come out of the exhaust
when the lawnmower is started up.
IMPORTANT INFORMATION: Check the oil level before every use of the lawnmower. Add oil if
necessary. Add oil up to the MAX level mark on the oil dipstick.
IMPORTANT INFORMATION: Change the oil after the first 5 hours of operation and
every 25 hours of operation thereafter
ADDING FUEL
The suitable type of fuel for this engine is NATURAL 95
After unscrewing the fuel tank cap, add the fuel, pouring it in all the way up to the collar of the fuel tank but do not
overfill it.
Always fill up with fresh, clean and approved unleaded petrol with an octane rating of at least 95.
Caution! If you splash the lawnmower when refuelling the oil or fuel, wipe it off immediately. Do not store,
refuel or handle fuel near an open flame
Caution! Fuels mixed with alcohol or fuels with ethanol or methane additives may bind moisture to
themselves, which may result in separation during storage and the formation of acids. Subsequently during
storage the acid vapours may damage the fuel system of the lawnmower engine. These fuels must not be
used in the lawnmower.
IMPORTANT INFORMATION: When not using the lawnmower for longer than 30 days, drain the fuel
tank, start the engine and let it run until the fuel lines and the carburettor are empty (the engine will stop on
its own). This will prevent future engine problems.
Before using it again, add fresh fuel into the fuel tank. For more information, see chapter Storage
instructions.
Fig. 5
