INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
3
Invertor generator - four-stroke engine
USER'S MANUAL
Thank you for purchasing this four-stroke engine invertor generator. Before you start using
it, please carefully read this user's manual and save it for possible future use.
TABLE OF CONTENTS
1. SAFETY INFORMATION...............................................................................................................................................4
1.1 Safety label.............................................................................................................................................................4
2. LOCATION OF SAFETY LABELS...............................................................................................................................6
3. COMPONENT MARKING..........................................................................................................................................7
3.1 Control panel........................................................................................................................................................7
3.2 ECON. SW (Economical mode switch)...................................................................................................8
3.3 Reset...........................................................................................................................................................................8
4. PRE-OPERATIONAL CHECK.....................................................................................................................................9
4.1 Checking the oil level.......................................................................................................................................9
4.2 Checking the fuel level................................................................................................................................. 10
4.3 Checking the air filter .................................................................................................................................... 10
5. STARTING THE ENGINE............................................................................................................................................ 12
5.1 Starting the engine - Procedure............................................................................................................... 12
6. USING THE GENERATOR ........................................................................................................................................ 14
6.1 Using direct current......................................................................................................................................... 15
6.2 Alternating current appliances................................................................................................................ 15
6.3 AC and overload indicator........................................................................................................................ 16
6.4 Oil level warning system............................................................................................................................... 16
7. STOPPING THE ENGINE .......................................................................................................................................... 17
7.1 Stopping the engine - Procedure ........................................................................................................... 17
8. MAINTENANCE........................................................................................................................................................... 18
8.1 Oil exchange...................................................................................................................................................... 18
8.2 Servicing the air filter...................................................................................................................................... 19
8.3 Servicing the spark plug............................................................................................................................... 21
8.4 Spark gap maintenance............................................................................................................................. 22
9. TRANSPORT AND STORAGE ................................................................................................................................ 25
9.1 Generator transport........................................................................................................................................ 25
10. TECHNICAL SPECIFICATION ................................................................................................................................ 27
11. WIRING DIAGRAM ................................................................................................................................................... 28
12. ATTACHMENT.............................................................................................................................................................. 29
12.1Environment conditions ............................................................................................................................... 29
13. DISPOSAL...................................................................................................................................................................... 30
14. DECLARATION OF CONFORMITY..................................................................................................................... 31
Table of Contents

EN 4
FZI 4010 BI
Safety Information
1. SAFETY INFORMATION
Please read the following information carefully so that personal and property safety
can be guaranteed.
Before using your generator, please read and understand the user’s manual.
Engine emissions contain poisonous carbon monoxide. Operate the generation in a ventilated location.
During the generator operation and before it has cooled down, please don’t touch the hot exhaust silencer.
Under the specified conditions, the petrol is explosive and combustible. When replenishing the fuel, the
generator should be turned off and no smoking and no flame sources are allowed in its neighbourhood.
In order to prevent risk of electric shock or fire, don’t connect the equipment to the building’s grid or other
generator.
The running generator should be positioned at least one meter apart from frameworks and other electric
appliances.
Position the generator on flat surface to prevent overturning or fuel spilling.
Keep your children and pets away from the work area.
Don’t handle with wet hands.
Don’t expose the generator to rain, moisture and snow.
During operation, position the generator at least 1 m apart from buildings and other equipment.
Bigger repairs may only be performed by a professionally trained person.
Don’t use the generator for underground applications.
Don’t use the generator in a potentially explosive environment.
When operating or servicing your generator, use personal protective equipment: gloves, mask and ear plugs.
1.1 SAFETY LABEL
DANGER!
Using the generator indoors MAY CAUSE DEATH WITHIN A COUPLE OF MINUTES.
The generator’s exhaust fumes contain carbon monoxide.
This is a poisonous substance neither to be seen nor smelled.
NEVER operate the equipment in your house or garage, EVEN IF the doors and windows are open.
Use only OUTDOORS and away from windows, doors and vents.

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
5
Safety Information
ATTENTION Failure to read and adhere to the instructions in the user’s manuals may lead to death,
personal injury or property damage.
The running engines emit carbon monoxide, poisonous gas without smell and colour. Inhaling
carbon monoxide may lead to nausea, fainting or death. DON’T START the equipment in
enclosed spaces even if the windows and doors are open.
The generator poses a risk of potential electric shock. Don’t expose the equipment to moisture,
rain or snow. Don’t operate with wet hands of feet.
Petrol and its vapours are combustible and explosive. Prior to replenishing the fuel, turn the
engine off and let it cool down for at least 2 minutes.
Failure to provide a proper grounding of the generator may lead to death as a consequence of
electric shock especially in the generator is equipped with trundles.
FOR MAINTENANCE SCHEDULE, PLEASE REFER TO THE USER’S MANUAL
CHANGE OIL AFTER NO LONGER THAN 50 HOURS
Detach the panel on the invertor rear side to access the oil cap.
Failure to observe the specified service intervals leads to shortening the engine lifetime.
DON’T REMOVE THIS MARK

EN 6
FZI 4010 BI
Location of safety labels
2. LOCATION OF SAFETY LABELS

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
7
Component marking
3. COMPONENT MARKING
1. Choke lever
2. Left service cover
3. Start-up handle
4. Engine switch
5. Control panel
6. Fuel tank cap
7. Fuel tank cap’s bleeding lever
8. Spark plug’s service cover
9. Exhaust silencer
1
2
3
4
7
6
5
89
3.1 CONTROL PANEL
1. 12 V DC
2. AC socket
3. AC indicator (green)
4. Overload indicator (red)
5. Oil level warning indicator (red)
6. Parallel outputs ON
7. Economical mode switch
8. Ground terminal
9. USB slot
5
4
3
2
86
7
9
1

EN 8
FZI 4010 BI
Component marking
3.2 ECON. SW (ECONOMICAL MODE SWITCH)
If the engine ECON switch is in the “ON” position, the economical mode control unit will automatically set the
generator motor to an appropriate speed based on the connected electric load. This will result in higher fuel
savings and lower noise level.
If the engine ECON switch is in the “OFF” position, the engine will run at the rated speed of 4850 rpm.
Note: When working with electric equipment having a high inrush current, such as a compressor, the ECON
switch must be set in the “OFF” position.
ON
OFF
OFF
ON
ECON SW.
Note:
When an appliance with a high current consumption is connected instantaneously, please set the
economical mode switch to the “OFF”( ) position in order to soften the voltage change.
When working with DC, set the economical mode switch to the “OFF” ( ) position.
Note:
In the protection state, the power indicator (green) is off and the overload indicator (red) lights.
At each engine start, the RESET button is available five times. Otherwise the engine needs to be restarted.
3.3 RESET
In the protection state, the overload indicator (red) lights. To restore the generator power without necessity to
fully restart the engine, press RESET.
Hold down “RESET” button for one second until the overload indicator (red) goes out and the power indicator
(red) lights.
RESET has no effect in the no-load state.

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
9
Pre-operational check
4. PRE-OPERATIONAL CHECK
Make sure that the generator is placed on a flat surface and is turned off.
4.1 CHECKING THE OIL LEVEL
Remove the oil filler cap and clean it with a cloth. Mount it back on the crankcase and proceed to check the oil
level:
If the oil level at the filler cap bottom drops, refill the motor oil.
1. Upper level
2. Dipstick
3. Oil filler cap
Oil tank capacity: 0.25 l
(Model FZI 4010 BI)
1
2
3
Note:
Using non-detergent or two-stroke oil may lead to shortening the engine lifetime.
Use quality motor oil with strong detergents.
Use four-stroke motor oil meeting or exceeding the API standards: SG, SF, SAE viscosity value:
-30 -20 -10 0 10 20 30 40℃
-20 0 20 40 60 80 100F
5W-30
10
10W
15W-40
W-40
-30
Take care when using and storing the motor oil and prevent debris or dust from entering the oil.
Mixing different oils is forbidden.

EN 10
FZI 4010 BI
Pre-operational check
Note:
Before the motor oil volume has dropped below the safety reserve level, the motor will be automatically
stopped by the low oil level warning system and the oil warning indicator (red) will light.
In order to avoid difficulties due to a sudden stop, it is recommended to regularly check the motor oil level.
Before the motor oil volume has dropped below the safety reserve level, the motor will be automatically
stopped by the low oil level warning system and the oil warning indicator (red) will light.
In order to avoid difficulties due to a sudden stop, it is recommended to regularly check the motor oil level.
4.2 CHECKING THE FUEL LEVEL
Recommended fuel: please use unleaded petrol (octane number at least 95 by research method).
Never use disintegrating or contaminated petrol or a mixture of oil end petrol.
Prevent any dirt or water from entering the tank.
Don’t use a petrol mixture with ethanol or methanol content as this may lead to a serious damage to the engine.
1. Fuel tank cap
2. Open
3. Upper limit mark
Fuel tank capacity: 3.0 l
(Model FZI 4010 BI)
1
2
3
Petrol is extremely explosive and flammable.
It is forbidden to smoke and make fire at the location of fuel replenishment or storage area.
Do not overfill the fuel tank (the fuel must not reach over the upper level red mark).
Once replenished, make sure to properly and safely close the fuel tank.
Prevent the fuel from spilling from the tank. (Before the engine start-up, there must be no excessive fuel
around the tank filler).
Avoid the fuel contact with skin and inhaling its vapours.
4.3 CHECKING THE AIR FILTER
Check if the air filter element is clean and in good condition.
Loosen the air filter service cover screw and remove the cover.
Press the latch on the air filter top.
Take off the air filter cover.
Check the filter element and clean or replace it as needed.

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
11
Pre-operational check
1. Cover screw
2. Air filter service cover
1
2
1. Latch
2. Latch
3. Air filter housing
4. Air filter element
5. Air filter cover
6. Lower latch
1
2
3
4
5
6
Note:
Don’t start the engine without the air filter element, otherwise a seizure might occur.

EN 12
FZI 4010 BI
Starting the engine
5. STARTING THE ENGINE
Note:
Before starting the engine, remove the load from the AC socket.
When filling the fuel for the first time, replenishing the fuel or storing the equipment for a longer period of time,
it is necessary to open the motor switch for ten to twenty seconds first and then pull 10 to 20 times in order to
feed the carburettor with enough fuel.
5.1 STARTING THE ENGINE - PROCEDURE
5.1.1 Turn the fuel tank cap’s bleeding lever to the „ON“ position.
1. Fuel tank cap’s
bleeding lever
OFF
ON
1
Note:
During the generator transport, make sure that the fuel tank cap’s bleeding lever is turned in the „OFF“
position.
5.1.2 Turn the engine switch to the “ON” position.
Engine switch
ON
ON
OF
F
5.1.3 Turn the choke lever to the "CLOSED” position.
1. Choke lever
2. Closed
1
2 2

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
13
Starting the engine
Note:
Don’t move the choke lever to the “CLOSED” position if the engine is hot or the surrounding temperature is
high.
5.1.4 Pull the start-up handle softly until you feel resistance and then pull it quickly in the arrow direction as
shown on the picture below.
1. Start-up handle
1
Note:
Slowly return the start -up handle to its original position by hand. Don’t let it bump back.
5.1.5 When the engine has started and warmed up, turn the choke lever to the “OPEN” position.
1. Choke lever
2. Opening
1
2
2
Note:
If the generator stops and cannot he started again, check the oil level first.
Adjusting the carburettor for operation in high altitudes
In high altitudes, the standard air-fuel mixture is too rich for the carburettor. This will decrease the output and
increase the fuel consumption. Also, very rich mixture leads to spark plug contamination and causes start-up
problems. If the generator works in a high altitude, replace the main jet or adjust the carburettor idle screw.
If the generator is to be constantly operated at altitudes of more than 1,000m, please ask your authorized service
to adjust the carburettor. The generator output power should be adjusted according to the altitude and ambient
temperature. For correction factor, please refer to 13-2.

EN 14
FZI 4010 BI
Using the generator
If the carburettor has been adjusted for operation in high altitudes, the air-fuel
mixture will be too lean to be used in low altitudes. Operation in low altitude may
case overheating and lead to serious engine damage. The carburettor must be set
back according to the original specifications.
6. USING THE GENERATOR
Remember to ground the generator if the connected appliance is also grounded.
In order to prevent risk of electric shock or fire, don’t connect the equipment to
the building’s grid.
1. Ground terminal
2. Earth mark 1
2
In order to ensure consistent operation, do not exceed the generator output
power.
Do not make parallel connections to other generators.
Do not fix any attachments to the exhaust.
If an extension lead is needed, use only flexible cable with solid rubber jacket
(according to IEC245 or equivalent standards).
Length of extension lead: 60 m for a 1,5 mm2 cross-section cable;
100 m for 2,5 mm² cross-section.
Keep away from other electric cables and wires.
Note:
The AC socket can be also used during DC power supply. When using simultaneously, make sure not to
exceed the total AC and DC power. (AC: 0.9 kVA, DC: 5 A)
Most motor appliances draw more than their rated power during start-up.

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
15
Using the generator
6.1 USING DIRECT CURRENT
The DC socket can be also used during AC power supply.
If the DC circuit protection trips as a result of DC circuit overload, remove the load first and reset the protection
after severall minutes.
1. DC circuit protection
ON OFF
1
6.2 ALTERNATING CURRENT APPLIANCES
6.2.1 Start the engine and make sure that the green power indicator is on.
6.2.2 Make sure that all appliances are turned off and insert the appliance’s plug in the generator socket.
Note:
To achieve the best performance and the longest possible generator lifetime, the new generator should be
running at 50% of its rated power for 20 hours.
1. Overload indicator (red)
2. AC current indicator (green)
3. Power socket
1
3
2
Note:
Before connecting to the generator, make sure that all electric appliances are in good condition. If an electric
appliance shows unusual behaviour, sluggish performance or stops suddenly, turn the generator motor off
immediately and disconnect the appliance.

EN 16
FZI 4010 BI
Using the generator
6.3 AC AND OVERLOAD INDICATOR
During normal operation, the AC indicator (green) remains lit.
If there is overload of the generator (over 0.9kVA) or short-circuit in the connected appliance, the green AC
indicator goes out and the overload indicator (red) lights. The AC power supply turns off but the engine continues
running.
If the overload indicator lights, disconnect the electric appliances first and then press the Reset button for
1 s. If the red overload indicator goes out and the green AC indicator is still lit, you can reconnect your electric
appliances. Otherwise, stop the engine and check the generator.
6.4 OIL LEVEL WARNING SYSTEM
The oil level warning system protects the engine from damaging due to low oil in the crankcase. Before the
crankcase oil level drops below the safety limit, the oil level warning system will automatically turn the engine off
(the engine switch will remain in the “ON” position).
When the oil level warning system turns the engine off and the oil level warning indicator (red) lights, please
checking the engine oil level.
123
1. Overload indicator (red)
2. AC current indicator (green)
3. Oil level warning indicator (red)

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
17
Stopping the engine
7. STOPPING THE ENGINE
If it’s necessary to stop the engine in an emergency, turn the motor switch in the “OFF” position.
7.1STOPPING THE ENGINE - PROCEDURE
7.1.1 Turn off the connected electric appliances and unplug their cords from the mains.
1. Engine switch
ON
OF
1
7.1.2 Turn the fuel tank cap’s bleeding lever to the “OFF” position.
1. Fuel tank cap’s bleeding lever
OFF
OFF
1
Note:
Make sure that the fuel tank cap’s bleeding lever and the motor switch are in the “OFF” position during
stopping, transporting and storing the generator.

EN 18
FZI 4010 BI
Maintenance
8. MAINTENANCE
The aim of the maintenance and adjustment schedule is to keep the generator in as good operating condition as
possible.
Turn the engine off before each time you perform the maintenance. If the engine
must be running, make sure the area is well ventilated. Exhaust fumes contain
poisonous carbon monoxide.
When replacing the worn parts, always use original Fieldmann components or
those of equal quality.
Maintenance schedule
Regular service interval (3) At each use First month
or 10h
Once in
3 months
or 50h
Once in
6 months
or 100h
Once in
2 years or
300h
Item
Engine oil Level check 
Replacement 
Air filter Inspection 
Cleaning + (1)
Spark plug Check - adjustment 
Spark plug Replacement 
Spark gap 
Valve movement Check - adjustment + (2)
Combustion chamber Cleaning After every 300 h (2)
Fuel tank and filter Cleaning Annually (2)
Fuel lines Once in 2 years (replacement if necessary) (2)
Note:
If the equipment is operated in dusty environment, service more frequently.
If you lack necessary tools and mechanical skills, these items should be repaired by a service organization.
For the service procedures, please refer to HEYA user’s manual.
In case of commercial use, determine correct maintenance intervals according to actual operating hours.
8.1 OIL EXCHANGE
Drain the oil quickly and fully while the engine is still hot. We recommend you to ask your Fieldmann service
centre to perform the service jobs.
8.1.1 Loosen the air filter service cover screw and remove the cover.
8.1.2 Remove the oil filler cap.
8.1.3 Drain the contaminated oil thoroughly in appropriate container.
8.1.4 Refill with recommended oil and check the level.

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
19
Maintenance
8.1.5 Replace the oil filler cap.
8.1.6 Replace the service cover and tighten its screw.
1. Cover screw
2. Air filter service cover
Oil tank capacity: 0.25 l
1
2
1. Dipstick
2. Oil filler cap
Oil tank capacity: 0.25 l
After the oil exchange, wash your hands with soap.
Note:
In conformity with the environmental protection requirement, the used oil must be collected in a sealed container
and handed over to a service centre for recycling. Do not discard in a dustbin or spill out on the ground.
8.2 SERVICING THE AIR FILTER
A contaminated air filter leads to restricting the air flow into the carburettor. Clean and maintain the air filter
regularly especially in extremely dusty environment. We recommend you to ask your Fieldmann service centre to
perform the service jobs.

EN 20
FZI 4010 BI
Maintenance
Never use petrol or solvents with low ignition temperature for cleaning.
Under certain conditions, these are flammable and explosive substances.
Note:
Never start the generator without the air filter as this may lead to a quick motor seizure.
8.2.1 Loosen the air filter service cover screw and remove the cover.
1. Cover screw
2. Air filter service cover
1
2
8.2.2 Press the latch on the air filter top and open the air filter cover.
1. Latch
2. Air filter housing
3. Air filter element
4. Air filter cover
5. Lower latch
1
1
2
3
4
5

EN
INVERTOR GENERATOR - FOUR-STROKE ENGINE USER'S MANUAL
21
Maintenance
8.2.3 Remove the air filter element, clean it with non-flammable solvent or solvent with high ignition temperature
and then dry out.
8.2.4 Soak the air filter element in clean motor oil and displace the excess oil.
1. Filter element
1
8.2.5 Replace the filter element and cover.
8.2.6 Replace the service cover and tighten the screws.
8.3 SERVICING THE SPARK PLUG
Recommended spark plug: CR7HSA
Check the spark plug electrode distance and clean the carbon deposits at the spark plug’s bottom.
We recommend you to ask your Fieldmann service centre to perform the service jobs.
8.3.1 Remove the spark plug’s service cover.
1. Spark plug’s service cover 1
8.3.2 Remove the spark plug’s cap.
8.3.3 Clean the carbon deposits at the spark plug’s bottom.
1. Handle
2. Spark plug’s cap
2
1
