Fiilex P360 GEen II Series User manual

P360 &P360EX
Portable LED Light
User Manual

What’s In The Box
Getting To Know The Light
Set Up And Basic Operation
Optional Accessories
Specifications
For Your Safety
1
2
4
7
8
9
Table of Contents

1
What’s In The Box
• 4 Leaf Barndoor• P360 or P360EX Light
• Power Adapter

2
Getting To Know
The Light
D
C
E
F
G
H
I
J
K
L
M
N
O

3
4 Leaf Barndoor
Barndoor Slot
Barndoor Holder
Barndoor Fix Ball
Side Air Vents
Yoke Knob
Back Air Vents
Light Intensity Knob
Light Control Output Jack (P360EX Only)
DC Power Input Jack
On/ Off Switch
CCT Tuning Knob (3000K - 5600K)
Light Control Input Jack (P360EX Only)
Yoke
Light Stand Adapter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O

4
Set Up And
Basic Operation
2
3
6
7
5
11

5
8
9
10
13
12
11

6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
When using light for the first time, remove the plastic
protective membranes and discard.
Mount Light Stand Adapter(O) to 5/8 Stud on light stand or
tripod.
Insert the DC power plug from the power adapter into the DC
Power Input Jack (J).
Connect the Power Adapter to AC Power.
Press On/Off button (K) to turn on P360/EX.
Adjust the color temperature with CCT Tuning Knob (L).
Adjust the Intensity with the Light Intensity Knob (H).
Slide Barndoor into the Barndoor Slot (B) until it clicks into
place.
Following Steps for P360EX model only.
Mount the DMX Connection Box with the Power Adapter
Holder to the light stand or tripod. Secure with the Stand
Fastener Knob.
Slide the Power Adapter into the cradle of the Power
Adapter Holder and tighten the Velcro Strap.
Insert Connection Plug into Light Control Input Jack on the
P360EX (M).
Connect to DMX controller via XLR5 (D) or RJ45 (C) ports in
the DMX Connection Box.
Rapidly push the thumbwheel (F) two times to unlock.
Seven-segment Display (B) will start to flash, you can now set
the DMX Address.
To set the DMX address, slide the thumbwheel (F) up to
increase the number, and down to decrease.
Once set, push the thumbwheel (F) once in to lock.

7
For additional accessories go to www.fiilex.com
Optional Accessories
When using light for the first time, remove the plastic
protective membranes and discard.
Mount Light Stand Adapter(O) to 5/8 Stud on light stand or
tripod.
Insert the DC power plug from the power adapter into the DC
Power Input Jack (J).
Connect the Power Adapter to AC Power.
Press On/Off button (K) to turn on P360/EX.
Adjust the color temperature with CCT Tuning Knob (L).
Adjust the Intensity with the Light Intensity Knob (H).
Slide Barndoor into the Barndoor Slot (B) until it clicks into
place.
Following Steps for P360EX model only.
Mount the DMX Connection Box with the Power Adapter
Holder to the light stand or tripod. Secure with the Stand
Fastener Knob.
Slide the Power Adapter into the cradle of the Power
Adapter Holder and tighten the Velcro Strap.
Insert Connection Plug into Light Control Input Jack on the
P360EX (M).
Connect to DMX controller via XLR5 (D) or RJ45 (C) ports in
the DMX Connection Box.
Rapidly push the thumbwheel (F) two times to unlock.
Seven-segment Display (B) will start to flash, you can now set
the DMX Address.
To set the DMX address, slide the thumbwheel (F) up to
increase the number, and down to decrease.
Once set, push the thumbwheel (F) once in to lock.
D-tap Cable
Dome DiffuserFresnel Lens
Power Adapter Holder DMX Connection Box
Softbox
For P360EX Only

8
Specifications
Size (without Barndoor)
4” (Diameter) x 4.7” (Length) /
102mm (Diameter) x 119mm (Length)
Weight (Includes Yoke)
1.6 lb / 0.74 kg
LED
Dense Matrix LED
Thermal Design
Advanced Vapor Cooling System
CCT Range
Continuous from 3000K to 5600K
CRI
>92
Power Consumption
90W Max.
Power Input
12 to 28 V DC
AC Adapter
100-240VAC, 50/60Hz (In) / 24V DC,90Wmax.(Out)
Operating Temperature
0º to 40ºC / 32º to 104º F
P360EX Only
IP-24 Rating
For P360EX Only

9
Information and Specifications in this document are subject to change without notice. DiCon
Lighting, Inc. assumes no responsibility or liability for any error or inaccuracies that may
appear in this manual. Unlawful reproduction or distribution in any manner without the
written permission of DiCon Lighting, is strictly prohibited.
© DiCon Lighting 1996-2014 All Rights Reserved
Fiilex.com
1689 Regatta Blvd. Richmond, CA 94804
[phone] . [e-mail]
For Your Safety
• Do not attempt to disassemble the body of the P360
or P360EX, doing so will immediately void the factory
warranty.
• Do not install the P360 in a damp or wet area.
• Do not submerge P360/P360EX in water.
• Do not cover the side or back air vents.
• Only use the included power adapter, failure to do so
may cause damage to the LED light.
• Only use a soft, dry towel to gently clean the exterior
of the light.
• Before using the light for the first time, remove the
protective membranes.

Fiilex.com
3
4 Leaf Barndoor
Barndoor Slot
Barndoor Holder
Barndoor Fix Ball
Side Air Vents
Yoke Knob
Back Air Vents
Light Intensity Knob
Light Control Output Jack (P360EX Only)
DC Power Input Jack
On/ Off Switch
CCT Tuning Knob (3000K - 5600K)
Light Control Input Jack (P360EX Only)
Yoke
Light Stand Adapter
