Cooper Lighting XF Falcon User manual

FLOODLIGHTING
555
COOPER LIGHTING
COOPER LIGHTING - LUMARK®
COOPER LIGHTING
• Tempered glass lens is
impact- and thermal
shock-resistant. Four
point door connection
provides positive seal to
housing
• Die-cast aluminum
housing is finished in
weather- and abrasion-
resistant dark bronze
polyester powder coat
• Full-circumference
silicone gasket seals out
external contaminants
• 5KV pulse-rated
mogul-base porcelain
lamp socket for HID
lamps
• Mogul-base lamp
included and available
up to 400W HPS or MH
• Formed-aluminum
reflector optimizes beam
efficiency and control
• Polyester powder coated
steel trunnion mount
provides stability and
adjustable aiming.
Optional slipfitter
available (order
separately)
• Approximate net weight:
33 lbs. (15 kgs.)
XF
FALCON
250-400W
High Pressure Sodium
Metal Halide
FLOODLIGHT
DIMENSIONS DESCRIPTION
The compact die-cast aluminum
Falcon floodlight blends well in
almost any setting. It features an
adjustable trunnion which allows
exceptional mounting flexibility
and light control. U.L. listed and
labeled for wet locations.
CSA certified.
The Falcon floodlight can be wall
or pole mounted, making it perfect
for all commercial, industrial
and residential low wattage
floodlighting applications.
Accessories 2
XF/WG=Wire Guard
XF/GS=Replacement Door (Bronze)
XF/FC=Side and Top Visor (Bronze)
XF/SF=Slipfitter (Bronze)
10 1/8"
[265mm]
14 6/8" [377mm] 13 5/8" [340mm]
1" [25mm]
1 1/2"
[38mm]
TRUNNION-MOUNT DRILL PATTERN
ORDERING INFORMATION
SAMPLE NUMBER: HPXF40T
Lamp Type
MH=Metal
Halide
HP=High
Pressure
Sodium
Fixture Type 1
XF=Falcon
Lamp Wattage
25=250W
40=400W
Mounting Type
T=Trunnion
Accessories
(See Below)
NOTES: 1 Add “W” to the end of catalog number for white finish. 2Order separately. Add “WHT” to the end of accessory number for white
finish (Example: XF/WG-WHT). 3Specifications and dimensions subject to change without notice.
LAMP TYPE WATTAGE
Metal Halide 250, 400W
High Pressure Sodium 250, 400W
EPA-Effective Projected Area: .876 Square Feet
