FilterStream D4200 User manual

ADVANCED CLEANING APPLIANCES
™
®
INSTRUCTION
MANUAL

INDEX
2
IMPORTANT SAFEGUARDS 4
ABOUT YOUR DUSTTAMER DELUXE®6
DUSTTAMER DELUXE®DESCRIPTION 7
BATTERY CHARGING PROCEDURE 8
2-STAGE FILTRATION SYSTEM 10
LAMBSWOOL DUSTER 11
DUSTING 11
CLEANING LAMBSWOOL DUSTER WITH VACUUM CHAMBER 12
LAMBSWOOL DUSTER STORAGE 14
MAINTENANCE 15
Emptying/Cleaning Stainless Steel Pre-Filter Screen
Cleaning/Replacing the HEPA Filter
Cleaning the DustTamer Deluxe®
BATTERY REMOVAL/DISPOSAL 18
ACCESSORIES 19
WARRANTY Back Cover
PG

3
Congratulations!
You now own a top-quality
FilterStream®DustTamer Deluxe®
Cordless Vacuum Powered Duster.
To ensure maximum satisfaction,
please take a few moments to
review the following important
information before using this item.
Thank You!

IMPORTANT SAFEGUARDS
4
When using electrical appliances,
always follow basic precautions,
including the following:
PLEASE READ ALL
INSTRUCTIONS CAREFULLY
BEFORE USING THIS
APPLIANCE
WARNING:
To reduce the risk of fire,
electrical shock or injury:
• Close supervision is necessary
when any appliance is used
by or near children. Do not
allow this appliance to be
used as a toy.
• Do not use without pre-filter
screen and HEPA filter in
place. Replace a damaged
filter promptly.
• To protect against risk of
electrical shock: (i) do not put
vacuum chamber or charger in
water or other liquid, and (ii)
do not insert a wet duster into
the vacuum chamber
• Do not put anything that is
burning or smoking, such as
cigarettes, matches, or hot
ashes into the vacuum chamber.
• Avoid putting hard, sharp
objects in the vacuum chamber.
They may damage the vacuum
chamber and the filters.
• Do not use this product to pick
up toxic substances,
flammable or combustible
liquids such as gasoline or
operate in the presence of
explosive or flammable fumes.
Do not immerse the vacuum
chamber in any liquid.
• Do not operate in the
presence of explosives and/or
flammable fumes or liquids.
• Do not unplug the charger by
pulling on the cord. Never
carry the charger or vacuum
chamber by the cord or yank
to disconnect from an outlet;
instead, grasp the charger
and pull to disconnect. Do not
pull cord around sharp edges
or corners.
• Do not allow the cord to hang
over the edge of a table or
counter or touch hot surfaces.
The vacuum chamber should
be placed away from sinks and
hot surfaces.
• The use of an extension cord
is not recommended. Only
plug the charger into a
standard electrical outlet
(120V/60 Hz).
• Use only the charger supplied
with this unit to recharge the
vacuum chamber.

5
• Do not attempt to use the
charger with any other product.
• Never handle the plug or vacuum
chamber with wet hands.
• Do not operate with a
damaged cord or charger.
If the vacuum chamber has
been dropped into water or
if it malfunctions, return the
unit to the store where it
was purchased.
• Unplug the charger from
outlet before any routine
cleaning or maintenance of the
vacuum chamber.
• Do not put any object into
openings. Do not use with any
opening blocked; keep free of
dust, lint, hair, or anything that
may reduce airflow.
• Do not use on or near hot
surfaces.
• Use extra care when cleaning
on stairs.
• This vacuum chamber is
intended for household use
only and not for commercial or
industrial use.
• Use only as described in this
manual. Use only
FilterStream®DustTamer®
accessories and filters.
• The vacuum chamber should
be unplugged before you
begin vacuuming.
• This product contains nickel
cadmium (Ni-cad) batteries.
Do not incinerate the batteries
as they will explode at high
temperatures. Always dispose
of the batteries in accordance
with your state’s laws Please
call 1-800-822-8837 for
disposal instructions and drop
off locations in your area.
• Leaks from a battery cell can
occur under extreme
conditions. If the battery
liquid gets on skin: (i) wash
immediately with water. If it
gets in your eyes,
immediately flush your eyes
with a mild solution of baking
soda and water and seek
medical attention.
SAVE THESE
INSTRUCTIONS

ABOUT YOUR DUSTTAMER DELUXE®
6
The revolutionary DustTamer
Deluxe®,the world’s first dusting
appliance, makes dusting faster,
easier and cleaner!
With DustTamer Deluxe®,
there’s no more brushing of
allergy causing dust back and
forth and into the air, and no
more wasted time with slow,
messy dusting cloths.
To use, you simply dust your
home with the professional
quality Australian lambswool
duster and conveniently suction
off the dust on-the-spot with
the cordless, rechargeable
vacuum chamber!
To ensure that only clean, dust
and allergen free air re-enters
your home, DustTamer Deluxe®
utilizes a 2-stage HEPA filtration
system that captures 99.97% of
dust and allergens.
Your DustTamer Deluxe®D4200
comes complete with a handy 22”
duster, a washable/ reusable
stainless steel pre-filter, and a
certified HEPA filter.
Please follow this manual for the
proper set-up, use, and care of this
revolutionary cleaning product.
Your DustTamer Deluxe®Vacuum
Powered Duster contains the
following parts:
Upper Vacuum Chamber
Housing
Lower Vacuum Chamber
Housing
Housing Release Latch
AC Adapter Jack
Lambswool Duster (22”)
Duster Hanging Hook
Dust Agitation Ring
Dust View Window
Stainless Steel Pre-Filter
Screen
HEPA Filter
Infrared Dust Wand Sensor
Carrying Handle
Battery/AC Adapter
Compartment
Battery/AC Adapter
Compartment Latch
AC Adapter and Cord
Motor and Fan
Air Exhaust
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

7
DUSTTAMER DELUXE®DESCRIPTION
1
2
3
4
5
10
12
13
14
15
16
6
7
8
9
9
10
11
17

BATTERY CHARGING PROCEDURE
8
Your DustTamer Deluxe®uses a
cordless, rechargeable vacuum
chamber to suction dust off your
DustTamer®Duster. When fully
charged, your vacuum chamber
will have enough power to clean
your Duster approximately 50
times.
To charge your DustTamer
Deluxe®, please follow these steps:
1. Open the Battery/AC Adapter
Compartment by depressing
the purple Compartment Latch
at the rear of the unit and
sliding the Battery/AC Adapter
Compartment out of the
Vacuum Chamber. (see figure 1)
2. Upon first use of the
DustTamer Deluxe®, remove
the white plastic tab marked
“Remove Before Use”.
3. Remove the supplied AC
Adapter from the Battery/AC
Adapter Compartment and
connect it to the AC Adapter
Jack located at the rear bottom
of the Vacuum Chamber and
plug the AC Adapter into a wall
outlet. (See figure 2)
1
2
Fig.
Fig.

9
Important: Before first use,
charge your DustTamer
Deluxe®for at least 24 hours.
Note 1: To maintain a charge
keep the AC Adapter and
Vacuum Chamber plugged into
a standard wall outlet at all
times. When charging, the AC
Adapter may be warm to the
touch. This is normal.
Note 2: The Battery/AC
Adapter compartment can be
removed from the unit and
charged separately for added
convenience.
The Vacuum Chamber can be
left in one location during
dusting, (bringing the Duster
back to it for cleaning) or you
can carry the Vacuum
Chamber with you from room
to room for extra convenience.
Note 3: As with many
rechargeable products, we
recommend that the AC
Adapter not be plugged into
the wall outlet when the unit is
in use (i.e. while cleaning the
Duster with suction action).
TM
3Fig.

2-STAGE FILTRATION SYSTEM
10
Traditional dusting tools push
allergy causing dust from one
spot to another or into the air.
With its 2-stage HEPA filtration
system, DustTamer Deluxe®
overcomes this problem.
Stage 1: A reusable, washable
Stainless Steel Pre-Filter
Screen traps larger dust
particles for clean and
easy removal when full
(see “Maintenance”
section of this manual for
emptying instructions).
Stage 2: An included
FilterStream®certified
HEPA Filter captures
99.97% of microscopic
dust particles, pollen,
bacteria and other
allergens down to 0.3
microns in size. 1
2
4
Fig.

11
Your DustTamer Deluxe®includes
a professional quality 100%
Lambswool Duster made in
Australia.
Lambswool dusters are the choice
of cleaning professionals because
they are:
Fast - the large head covers large
areas quickly
Superior at Dust Pick Up -
lambswool has natural dust
grabbing fibers, electrostatic
action and lanolin oil that attracts
and holds dust like a magnet
Incredibly Soft & Versatile -
won’t scratch delicate items; great
for small figurines or
large tables
Reusable - saves time and money!
LAMBSWOOL DUSTER • DUSTING
DUSTING
The included Lambswool Duster
is ideal for cleaning any areas
where dust accumulates:
• Venetian blinds
• lamps
• louvered doors
• fine furniture
• collectibles
• televisions/stereo equipment
• plant leaves
• computer monitors/keyboards
• automobile dashboards
For helpful dusting & cleaning
tips, see our handy DustTamer®
Cleaning Tips booklet included
with your DustTamer Deluxe®.

Duster in and out of the
Vacuum Chamber a few times
(see Figure 6). The
combination of the Dust
Agitation Ring (which loosens
dust with a twisting action) and
suction will most effectively
remove dust from the
Lambswool Duster. The
Vacuum Chamber suction will
run for approximately 8
seconds, then will
automatically turn off to
conserve battery power.
During the above cleaning
cycle, dust and allergens are
being suctioned away and
captured in the Stainless Steel
Pre-Filter and the HEPA Filter
(see figure 7). Only clean,
allergen free air is recirculated
into your home.
If you want to clean the Duster
again, simply remove the
Lambswool Duster from the
Vacuum Chamber and reinsert it,
thereby activating the Infrared
Dust Wand Sensor and turning
the suction on again.
Your Lambswool Duster is now
clean and ready to dust another
room in your house.
CLEANING LAMBSWOOL DUSTER WITH VACUUM CHAMBER
12
1. Your DustTamer Deluxe®
Vacuum Chamber can be
conveniently carried from
room to room operating on
battery power.
2. The number of times you
clean your Lambswool Duster
in the Vacuum Chamber will
be determined by the amount
of dust you pick up. Rooms
with heavy dust accumulation
may require several cleanings,
whereas small rooms or quick
touch-up dusting may only
require one cleaning.
Note: To keep your Lambswool
Duster free of dust and allergens,
we recommend periodic cleaning
of your Lambswool Duster in
the Vacuum Chamber, even if
dust isn’t visible on the
Lambswool Duster.
To clean your Lambswool
Duster in the Vacuum Chamber,
simply follow these steps:
a. Slowly insert the Lambswool
Duster into the Vacuum
Chamber. The Infrared Dust
Wand Sensor will detect the
Lambswool Duster and
automatically start the suction
action. (see figure 5)
b. Once the suction has started,
slowly move the Lambswool

13
TM
TM
5
67
Fig.
Fig. Fig.

LAMBSWOOL DUSTER STORAGE
14
Your Lambswool Duster can be
stored inside the Vacuum
Chamber or hung from a hook,
nail, etc. with the built-in
hanging hook.
Figure 8 & 9
TM
TM
8
9
Fig.
Fig.
Duster
Stored
Separately
Duster
Stored
Inside
Vacuum
Chamber

15
Dust, dirt and debris suctioned
off by your Vacuum Chamber will
collect in the Stainless Steel Pre-
Filter Screen and HEPA Filter. To
empty/clean these parts, please
follow these steps:
1.Open Vacuum Chamber
Holding the Upper Vacuum
Chamber Housing with one
hand and the Lower Vacuum
Chamber Housing with the
other, depress the Housing
Release Latch on the front of
the unit just above the Air
Exhaust and separate the two
parts from each other.
(see figure 10)
2.Cleaning Stainless Steel Pre-
Filter Screen
To clean the Stainless Steel
Pre-Filter Screen, remove the
Stainless Steel Pre-Filter
Screen from the bottom of the
Upper Vacuum Chamber by
inserting your thumb and fore
fingers into the wide oval
notches and pulling the Steel
Pre-Filter Screen away from
the unit.(See Figure 11)
MAINTENANCE
10
11
Fig.
Fig.
12
Fig.

MAINTENANCE
16
The Stainless Steel Pre-Filter
Screen can be cleaned by
emptying the dust in the trash, or
preferably, in the sink under
running water (see figure 12) to
ensure that dust particles are not
reintroduced to the household.
Thoroughly dry the Pre-filter after
cleaning to prevent moisture from
getting on the HEPA Filter.
3.Cleaning HEPA Filter
To remove the HEPA Filter
from the Lower Vacuum
Chamber Housing, insert your
thumb and middle finger into
the semi circular depressions
on either side of the filter and
pull outward. Use your finger
to lightly clean the paper
surface of the HEPA Filter,
clearing off any dirt, dust, and
hair. You can also gently tap
the HEPA Filter on the edge of
the garbage can or sink face
down for additional cleaning.
(see figure 13)
Note: Do not wash the HEPA
filter. Water will permanently
damage the filter.
13
Fig.
4.Cleaning Vacuum Chamber
Cleaning Interior: Remove any
dust that may build up inside
the Vacuum Chamber with a dry
cloth.
Cleaning Exterior: Clean the
Vacuum Chamber’s exterior
with a damp cloth
Warning: Never immerse the
Vacuum Chamber in water
This may damage the electrical
contacts and circuitry in the
Upper Vacuum Housing.

17
Note: Make sure that all parts
are dry before putting them
back together.
5. After cleaning, insert the
HEPA Filter back into the
Lower Vacuum Chamber
Housing, and the Stainless
Steel Pre-Filter back into the
Upper Vacuum Housing. A light
“click” is heard when firmly
seated. (see figure 14)
6. The Vacuum Chamber is put
back together by connecting
the rectangular slot on the rear
of the Upper Vacuum
Chamber to the rear
protruding tab on the Lower
Vacuum Chamber Housing
Then lower the Upper Vacuum
Chamber Housing onto the
Lower Vacuum Chamber
Housing until an an audible
“click” is heard.
(see figure 15)
15
Fig.
14
Fig.

BATTERY REMOVAL/DISPOSAL
18
Your DirtTamer Deluxe® Vacuum
Chamber uses 6 nickel cadmium
(Ni-Cad) batteries which are
factory installed in the Battery/
AC Adapter Compartment.
When the battery life has been
exceeded, the entire Battery/AC
Adapter Compartment should be
removed from the Vacuum
Chamber and recycled in
accordance with state, and/or
national laws.
To remove/replace the
Battery/AC Adapter
Compartment, follow these
steps:
a. Open the Battery/AC
Adapter Compartment by
depressing the Battery/AC
Adapter Compartment Latch
at the rear of the unit and
sliding the Battery/AC
Adapter Compartment out of
the Vacuum Chamber
(see figure 1)
b. Recycle according to State,
and/or National Laws. Please
call 1-800-822-8837 for
disposal instructions and drop
off locations in your area.
c. A new Battery/AC Adapter
Compartment, which contains
fresh batteries, can be
ordered from the
FilterStream Customer
Service Center at 800-211-
9607.
Note: Please call 1-800-822-
8837 for disposal instructions
and drop off locations in your
area. The batteries must not be
incinerated or composted.

19
Handy Duster Accessories:
A variety of 100% Lambswool Dusters are available to make your
dusting chores easier:
Standard 22” DustTamer® Duster (Model# D-100)
Extendable 31” DustTamer® Duster (Model# EX-100)
Bendable & Extendable 31” DustTamer® Duster (Model# B-100)
Mini 10” DustTamer® Duster (Model# M-100)
All of these Duster accessories are available from FilterStream at
1-800-211-9607 or by mailing the enclosed order form to FilterStream
with payment.
Replacement Filters, and Battery/AC Adapter Compartments:
Replacement Filters, and Battery/AC Adapter Compartments are
available from FilterStream at 1-800-211-9607. Please reference the
following numbers:
DustTamer®/FilterStream® HEPA Filter (Model # H-100)
[Fits DirtTamer Cordless Hand Vacs & DustTamer Vacuum
Powered Dusters]
DustTamer® Stainless Steel Pre-Filter Screen (Model # S-100)
DustTamer® Battery/AC Adapter Compartment (Model # RBP-100)
Please visit us at www.filterstream.com for more information.
ACCESSORIES

FilterStream Company warrants that this product is free from defects in
materials or workmanship for a period on two (2) years from the date
of original purchase.
It the product fails to operate in accordance with the manufacturer’s
specifications, simply return the product to the retail location where
you purchased it (or send it postage prepaid to the address below)
within two (2) years of the date of purchase. Proof of date of purchase
is required.
Upon receipt, FilterStream Company will, at its option, repair or
replace the product at no charge to you.
This warranty does not cover damage resulting from accident, misuse
or abuse, lack of reasonable care, the affixing of any attachment not
provided with the product, or loss of parts, or subjecting the product to
anything but the specified voltage or batteries.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS
OR IMPLIED. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO TWO (2)
YEARS FROM THE DATE OF ORIGINAL PURCHASE. IN NO EVENT
WILL FILTERSTREAM COMPANY BE RESPONSIBLE FOR INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT.
Some states do no allow limitation on how long an implied warranty
last and/or the exclusion or limitation of incidental or consequential
damages, so the above limitation may not apply to you. This warranty
gives you specific rights which vary from state to state.
To speak with a FilterStream representative, please call:
(781)-769-3959
Artwork#: 02-A200-03
FilterStream Company Service Center
P.O. Box 481, Westwood, MA, USA 02090-0481
TWO YEAR LIMITED WARRANTY
