Fimco TC-15-HP User manual
Warranty/Parts/Service
For home usage, products are warranted for one year from date
of purchase against manufacturer or workmanship defects.
Commercial users have a 90 day warranty.
Your authorized dealer is the best source of replacement parts
and service. To obtain prompt, efficient service, always
remember to give the following information...
- Correct Part Description and/or part number.
- Model number/Serial number of your sprayer.
Part descriptions and part numbers can be obtained from the
illustrated parts list section(s) of this manual.
Whenever you need parts or repair service, contact your
distributor/dealer first. For warranty work, always take your
original sales slip, or other evidence of purchase date, to your
distributor/dealer.
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your trailer
cart. Please read it carefully, as it furnishes information which
will help you achieve years of trouble-free operation.
To Dump:
Step on foot plate located in the middle of the tongue.
Step and lean towards the rear of the cart. The cart will tilt back to
the dump position.
To Return to Pulling Position:
Push down on the front of the
cart body until the latch engages and locks to the tow bar.
Your pulling vechicle's speed should be governed by the weight of
the load. The heavier the load, the slower the speed for safe
operation.
Form No. 2063 [5008338 (03/14)] Printed in the U.S.A.
Owner's Manual
(15 Cubic Ft. Poly Trailer Cart)
Using Your Dump Cart
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
www.fimcoindustries.com
Model: TC-15-HP (5302027)
Assembly
Most of your cart will be pre-assembled at the factory. Finish
assembly by following the next steps:
- Bolt the hopper to the tubular frame, with the 12 truss head
screws. Secure to the frame with 5/16" whiz locknuts.
- Bolt the tongue assembly (which should be pre-assembled)
around the tubular frame directly under the hopper. This will
'sandwich' around the bolted-together tubes under the hopper.
- Slide a machinery bushing (Item 8) onto the axle pin.
- Slide the pin with the machinery bushing through the axle hole,
feeding it from the outside of the wheel, towards the center of
your cart.
- Place another machinery bushing over the pin, after fed through
the wheel, then slide complete wheel/axle assembly into the axle
receiver tube on the frame. Secure in place with the provided
cotter pin.
(Repeat for other wheel)
16
12
16
5 20
19
17.16
17.17 17.6
17.13
17.5
41
8
76
14
2
13
9
2
15
18
3
3
3
10
10
11
15
11
18
5
16
17.3
17.11
17.14
17.7
17.12
17.1
17.4
17.2
17.10
17.2
17.4
17.15
17.9
17.11
17.8
17.10
17.2
Page 2
Exploded View/Parts List:
TC-15-HP (5302027)
Check tire pressure at regular intervals. Proper inflation will
prolong the life of the tires.
NOTE:
700 lbs. maximum capacity
Approximate weight of (1 Cu. Ft.)
Dirt: 150 lbs.
Sand: 125 lbs.
Gravel: 110 lbs.
Max. Speed: 4 MPH
This unit is intended for use only with riding mowers or tractors. It
is definitely NOT for highway use, being pulled at high speeds, or
transporting passengers of any sort. Such use could result in
injuries for which we cannot be held responsible.
___________________________________________________
Please do not return this merchandise to the store. Call us
and we will take care of any problem you may have with this
product.
___________________________________________________
How to order parts:
When ordering parts, always give model number, part number,
part description, and inspector number.
Returns can be sent to:
FIMCO Inc.
1000 FIMCO Lane
North Sioux City, SD 57049
Warning: Danger of Improper Use of Cart:
Item
No
Part
Number
Qty
Description
1 5006092 1
3/8"-16 Hex Locknut
2 5006307 16
5/16-18nc Hex Flanged Whiz Nut Gr. 5
3 5006366 3
3/8-16nc Hex Flanged Toplock Nut Gr. 8
4 5006367 1
5/16-18nc Hex Flanged Toplock Nut Gr. 5
5 5021089 2
Wheel, 16 x 6.50-8, Turf Tread
6 5034079 1
H.H.C.S. 3/8"-16nc x 1" Long
7 5034154 1
H.H.C.S. 5/16"-18nc x 5/8" Long
8 5034171 1
H.H.C.S. 3/8"-16nc x 3 1/2" Long
9 5034640 4
H.H.C.S. Flanged 5/16"-18nc x 2" Long
10 5034670 2
H.H.C.S. Flanged 3/8"-16nc x 3 1/4" Long
11 5041094 4
Machinery Bushing, 3/4" ID x 1-1/4" OD
12 5083009 1
15 Cu. Ft. Poly Cart Hopper
13 5090015 1
Dump Cart Latch
14 5095267 1
Hitch Pivot Mount
15 5101230 2
Cotter Pin, 3/16" x 2"
16 5117321 12
Truss Head Machine Screw 5/16"-18 x 2"
17 5277348 1
Tongue Assembly Dump Cart
17.1 5006035 1
5/16"-18 Hex Locknut
17.2 5006092 3
3/8"-16 Hex Locknut
17.3 5006259 2
3/8-16nc Hex Flanged Whiz Nut Gr. 5
17.4 5019138 2
Extension Spring
17.5 5034078 1
H.H.C.S. 3/8"-16nc x 3" Long
17.6 5034099 2
H.H.C.S. 3/8"-16nc x 3/4" Long
17.7 5034154 1
H.H.C.S. 5/16"-18nc x 5/8" Long
17.8 5034171 1
H.H.C.S. 3/8"-16nc x 3 1/2" Long
17.9 5034326 1
H.H.C.S, 3/8"-16 x 3 1/4"
17.10 5041167 2
Flanged Bronze Bushing
17.11 5013638 1
Dump Cart Hitch
17.12 5023115 1
4 1/2" Link Arm
17.13 5038722 1
10 Cu. Ft. Dump Cart Hitch
17.14 5090014 1
Foot Latch
17.15 5092026 1
Foot Lever, 60 degree
17.16 5101065 1
#211 Hitch Pin Clip (Zinc Plated)
17.17 5101268 1
1/2" x 1 1/2" Clevis Pin
18 5277349 2
3/4" Axle Pin Weldment
19 5277350 1
ATV 15 cu ft. Frame Weldment (L.H.)
20 5277351 1
ATV 15 cu ft. Frame Weldment (R.H.)
