Fimco TC-17 User manual

Warranty/Parts/Service
For home usage, products are warranted for one year from date
of purchase against manufacturer or workmanship defects.
Commercial users have a 90 day warranty.
Your authorized dealer is the best source of replacement parts
and service. To obtain prompt, efficient service, always
remember to give the following information...
- Correct Part Description and/or part number.
- Model number/Serial number of your sprayer.
Part descriptions and part numbers can be obtained from the
illustrated parts list section(s) of this manual.
Whenever you need parts or repair service, contact your
distributor/dealer first. For warranty work, always take your
original sales slip, or other evidence of purchase date, to your
distributor/dealer.
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your trailer
cart. Please read it carefully, as it furnishes information which
will help you achieve years of trouble-free operation.
Form No. 1030 [5004673 (03/14)] Printed in the U.S.A.
Owner's Manual
(17 Cubic Foot, 2-Wheel Trailer Cart w/Bolt-On Features)
Check tire pressure at regular intervals. Proper inflation will
prolong the life of the tires.
NOTE:
1700 lbs. maximum capacity
Approximate weight of (1 Cu. Ft.)
Dirt: 150 lbs.
Sand: 125 lbs.
Gravel: 110 lbs.
Max. Speed: 4 MPH
Maintenance Instructions
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: [phone] : Toll Free Fax: [phone]
www.fimcoindustries.com
Model: TC-17
(5301397)
Model: TC-17-BOM
(5301483)
Assembly
Remove tailgate and turn cart upside down for ease of assembly.
1. Bolt axle housing (Item 8) to cart weldment (Item 9), using 3/8"
x 1" slotted screws (Item 7). Secure in place with 3/8" whiz lock
nuts (Item 1).
2. Affix yoke brace (Item 4) to cart body (Item 9) in a similar
manner.
3. Slide axle (Item 3) through axle housing (Item 8) and tongue
assembly (Item 11).
4. Center the axle and place wheel (Item 2) over axle, followed by
machine bushing (Item 5) on the outside of the wheel.
5. Secure with Cotter Pin (Item 6). Repeat procedure for the other
side.

11.11
23
6
1
4
1
1
5
2
1
7
9
7
7
7
10
7
8
11.2
11.11
11.5
11.1
11.6
11.7
11.10 1
4
11.3
11.9
11.4
11.8
11.11
Page 2
Warning: Danger of Improper Use of Cart:
This unit is intended for use only with riding mowers or tractors.
It is definitely NOT for highway use, being pulled at high speeds,
or transporting passengers of any sort. Such use could result in
injuries for which we cannot be held responsible.
___________________________________________________
Please do not return this merchandise to the store. Call us
and we will take care of any problem you may have with this
product.
___________________________________________________
How to order parts:
When ordering parts, always give model number, part number,
part description, and inspector number.
Returns can be sent to:
FIMCO Inc.
1000 FIMCO Lane
North Sioux City, SD 57049
Exploded View/Parts List for Models:
TC-17 (5301397)
TC-17-BOM (5301483)
To Dump: Pull latch toward your pulling vehicle. The cart will tilt
back to the dump position.
To Return to Pulling Position: Push down on the front of the
cart body until the latch engages and pedestal secures to the tow
bar.
Your pulling vechicle's speed should be governed by the weight
of the load. The heavier the load, the slower the speed for safe
operation.
Using Your Dump Cart
Item
No
Part
Number
Qty Description
1 5006259 16 3/8-16nc Hex Flanged Whiz Nut Gr. 5
2 5021089 2 Wheel, 16 x 6.50-8, Turf Tread
3 5024100 1 Axle ( 15 & 17 Cu. Ft. Dump Trailers)
4 5037617 1 Yoke Brace
5 5041094 2 Machinery Bushing, 3/4" ID x 1-1/4" OD
6 5101086 2 Cotter Pin, 3/16" x 1 1/2" (Zinc-Plated)
7 5117306 16 3/8"-16 Slotted Round Head Machine Screw x 1"
8 5275048 1 Axle Housing Weldment (15 & 17 Cu. Ft. Carts)
9 5275049 1 17 Cu. Ft. Cart Weldment
10 5275059 1 Tailgate
11 5275116 1 Tongue Assembly (TC-17)
11.1 5034099 2 H.H.C.S. 3/8"-16nc x 3/4" Long
11.2 5006259 2 3/8-16nc Hex Flanged Whiz Nut Gr. 5
11.3 5006160 1 1/4"-20 Hex Locknut
11.4 5034321 1 H.H.C.S., 1/4"-20 x 3 1/2"
11.5 5038722 1 10 Cu. Ft. Dump Cart Hitch
11.6 5101268 1 1/2" x 1 1/2" Clevis Pin
11.7 5101065 1 #211 Hitch Pin Clip (Zinc Plated)
11.8 5019262 1 Tongue Spring, Zinc-Plated
11.9 5041141 1 Tongue Latch Bushing
11.10 5090008 1 Dump Cart Latch
11.11 5096103 1 Tongue (17 Cu. Ft. Dump Cart)
