Fine offset WH2810 User manual

Color Screen Multi-channel Weather Station User Manual
1
1. Introduction
Thank you for purchasing the color screen weather station with temperature,
humidity, barometric, moon phase and advanced forecasting. This device
can receive signals up to 3 sensors. All the sensors measure temperature
and humidity then transmit to the console and displayed on Outdoor
segment.
The following use guide provides step by step instructions for installation,
operation and troubleshooting.
2. Product Features:
Figure 1

Color Screen Multi-channel Weather Station User Manual
2
1) Wireless outdoor temperature (°F or °C) and humidity (%RH)
2) Indoor temperature (°F or °C) and humidity (%RH)
3) Support 3 outdoor sensors measures temperature and humidity in
different spots.
4) Records min. and max. Temperature and humidity
5) Barometric pressure (inHg, mmHg or hPa)
6) Weather forecast
7) Time and date by manual setting or DCF Radio controlled time and date.
8) 12 or 24-hour time display
9) Perpetual calendar
10) Time alarm with snooze
11) Moon phase
12) LED backlight
13) Wall hanging or free standing
14) Included transmitter (Outdoor sensor)
15) Synchronized instant reception
3. Getting started
Note: The power up sequence must be performed in the order shown in this
section (remote transmitter(s) first, display console second) to avoid the
console synchronization time out.
This weather station consists of a console (receiver), thermo-hygrometer(s)
(remote transmitter(s))，and a power adapter.
3.1 Parts list
QTY
ITEM
1
Display console
Frame Dimensions (LxWxH): 161.5*86*21.5mm
*
Thermo-hygrometer transmitter
Dimensions (LxWxH): 122*40*18mm
1
Power adapter
*:1, 2 or 3 transmitters for user’s option.

Color Screen Multi-channel Weather Station User Manual
3
Console
Figure 2
Remote sensor
Figure 3
LIGHT/SNOOZE Key
Hanging hole
Power jack
Folding bracket

Color Screen Multi-channel Weather Station User Manual
4
3.2 Thermo-Hygrometer Sensor Set Up
Note: To avoid operating problems, please take note of battery polarity
before/when inserting any Alkaline Batteries (permanent damaged could be
introduced by inserting the battery in wrong direction). Do not use
rechargeable batteries. We recommend fresh alkaline batteries for outdoor
temperature range between -20°Cand 60°C and fresh lithium batteries for
outdoor temperature range between -40°C and 60°C.
1. Move the transmitter(s) about 2 to 3m away from the display console
(if the transmitters are too close, they may not be received by the
display console). With multiple transmitters, make sure all transmitters
are powered up and displaying different channels on the display.
2. Remove the battery door on the back of the thermo-hygrometer sensor
by sliding down the battery door.
Figure 4
3. BEFORE inserting the batteries, locate the slide switches on the inside
cover of the lid of the transmitter(Figure 4).

Color Screen Multi-channel Weather Station User Manual
5
4. Channel Number: the weather station support up to three sensors. To
set each channel number, slide the button to according number.
5. Temperature unit of Measure: To change the sensor display units of
measure (°For °C),Press the round button C/F.
6. Insert two AA batteries
7. Wait for seconds until temperature and humidity displayed on the LCD
screen of sensors.
8. Verify the correct channel number (CH) and temperature units of
measure are on the display, as shown in Figure 5.
Figure 5
(1) Temperature
(2) Temperature units ((°F or °C)
(3) Channel number
(4) Relative humidity
9. Close the battery door.
10. Repeat for the additional remote sensor, verifying each remote is on a
different channel.
3.3 Sensor Operation Verification
Verify the humidity sensors match closely with all of the sensors in the same
location (about 2 to 3m apart). The sensors should agree within 10% (the
accuracy is ± 5%). Allow about 30 minutes for all sensors to stabilize. The
humidity can be adjusted or calibrated later to match each other a known
source.

Color Screen Multi-channel Weather Station User Manual
6
Verify the temperature sensors match closely with all of the sensors in the
same location (about 2 to 3m apart). The sensors should be within 2°C (the
accuracy is ± 1°C). Allow about 30 minutes for all sensors to stabilize. The
temperature can be adjusted or calibrated later to match each other or a
known source.
3.4 Radio Controlled Clock (RCC)
After the remote sensor is powered up, the sensor will transmit weather
data for 30 seconds, and then the sensor will begin radio controlled clock
(RCC) reception. During the RCC time reception period (maximum 5
minutes), no weather data will be transmitted to avoid interference. Once
the radio controlled time is received the RCC signal received successfully,
the RCC reception icon will turn on in the outdoor sensor LCD display.
Then outdoor sensor sends the RCC signal to display console, Once the
radio controlled time is received, RCC reception icon will turn on in the
display console. (reference Figure 8).
If the signal reception is not successful within 3 minute, the signal search
will be cancelled and will automatically resume every six hours until the
signal is successfully captured. The regular RF link will resume once RCC
reception routine is finished. In some locations, RCC reception may take a
couple of days to receive the signal.
3.5 Remote Sensor Installation
Before mount the units, ensuring that the receiver can still pick up the signal
from transmitters. It is recommended to mount the sensors on a north facing
wall, in a shaded area. Direct sunlight and radiant heat sources will result in
inaccurate temperature readings. Although the sensors are water resistant,
it is best to mount in a well protected area, such as under an eve.
1. Use a screw or nail to affix the remote sensor to the wall, as shown in
Figure 6
2. Hang the remote sensor up on string, as shown in Figure 7.

Color Screen Multi-channel Weather Station User Manual
7
Figure 6
Figure 7
3.6 Display Console Set Up
Place the remote thermo-hygrometer about 5 to 10 meters away from the
display console (if the sensor is too close, it may not be received by the
display console).
1. Insert the power adapter into the power jack of the console, and plug in
the adapter. The LCD display will beep once and then light up. The
brightness selection is set to high when plugged into the adapter. Press
the LIGHT/SNOOZE key can adjust among HIGH/MIDDLE/OFF level
according to your preference.
2. Remove the battery door on the back of the display. Insert three AAA
(alkaline or lithium, avoid rechargeable) batteries in the back of the
display console. Looking at the back of the unit (left to right), the
polarity is (+) (-) for the top battery, (-) (+) for the middle battery and (+)
(-) for the bottom battery.
Note: To avoid permanent damage, please take note of the battery
polarity before inserting the batteries.

Color Screen Multi-channel Weather Station User Manual
8
3. Replace the battery door, and fold out the desk stand and place the
console in the upright position.
Note: The batteries are intended for back-up power only. The backlight will
remain on for 5 seconds when on back up battery power only. Only when
you use power adapter it will the back-light be continuously on.
4. The console will instantly display indoor temperature, humidity,
barometer, moon phase, date and time. The remote search icon will
turn on：
3.6.1 Display Console Layout
Note: The following illustration shows the full segments of the LCD for
description purposes only and will not appear like this during normal
operation.
Figure 8

Color Screen Multi-channel Weather Station User Manual
9
1. Time
12. Max outdoor temperature
2. Moon phase
13. Min outdoor temperature
3. Weather forecast icon
14. Outdoor humidity
4. Radio controlled clock
15. Min Outdoor humidity
5. Week day
16. Max outdoor humidity
6. Date
17. Indoor temperature
7. Absolute/relative barometric
pressure selection
18. Max indoor temperature
19. Min indoor temperature
8. Barometric pressure
20. Indoor humidity
9. Outdoor sensor signal
21. Min indoor humidity
10. Channel number
22. Max indoor humidity
11. Outdoor temperature
23. MAX/MIN DAILY icon
4. Console Operation
Note: The console has four keys for easy operation: TEMP./+ key, ALM key,
BARO./- key and SET/CH key. There are four program modes: Set Mode,
Alarm Mode, calibration mode and Min/Max Mode.
Any program mode can be exited at any time by either pressing the
SNOOZE/LIGHT key (on the top of the display console), or waiting for the
30-second time-out to take effect.
4.1 Set Mode
4.1.1 Set Mode Quick Reference Guide

Color Screen Multi-channel Weather Station User Manual
10
Command
Mode
Settings
SET/CH + 2
seconds
Enter Set Mode, Beep
Press TEMP./+ or BARO./- to
toggle OFF and ON
SET/CH
RST-reset max/min at 0:00
Press TEMP./+ or BARO./- to
toggle OFF and ON
SET/CH
Time Zone (TZ)
Press TEMP./+ to increase.
BARO./- to decrease
SET/CH
12/24 Hour Format
Press TEMP./+ or BARO./- to
toggle between 12 hour (12h)
and 24 hour (24h) format
SET/CH
Hour of Day
Press TEMP./+ to increase.
BARO./- to decrease
SET/CH
Minute of Day
Press TEMP./+ to increase.
BARO./- to decrease
SET/CH
D-M/M-D Format
Press TEMP./+ or BARO./- to
toggle between D-M and M-D
format
SET/CH
Year
Press TEMP./+ to increase.
BARO./- to decrease
SET/CH
Month of Year
Press TEMP./+ to increase.
BARO./- to decrease
SET/CH
Day of Month
Press TEMP./+ to increase.
BARO./- to decrease
SET/CH
Temperature Units of
Measure
Press TEMP./+ to toggle
between degF and degC
SET/CH
Barometric Pressure Units
of Measure
Press TEMP./+ to toggle
between inHg, mmHg and hPa
SET/CH
Northern Hemisphere
(NTH) or southern
Hemisphere (STH) select
Press TEMP./+ to toggle
between Northern and
southern Hemisphere
SET/CH
Exit Set Mode

Color Screen Multi-channel Weather Station User Manual
11
4.1.2 Set Mode Operation
While in Normal Mode, press and hold SET/CH key 2 seconds enter setting
mode. The first setting will begin flashing. You can press the SET/CH key
again to skip any step, as defined below.
1. Beep on/off. The BEEP (ON or OFF) setting will begin flashing. Press
the TEMP./+ key to toggle between BEEP ON and BEEP OFF.
2. MAX/MIN record reset ON/OFF. Press SET/CH key again, RST (ON
or OFF) will begin flashing. This function is to switch off/on the
automatically reset of MAX/MIN record at 0:00 every day, which is
default turned on. Press TEMP./+ key to toggle between RST ON and
RST OFF.
3. Time Zone Settings. Press the SET/CH key again to adjust the Time
Zone (TZ) setting.
Press the TEMP./+ key or BARO./- key to adjust the time zone from
-12 to 12, based on the number of hours from Coordinated Universal
Time, or Greenwich Mean Time (GMT).
4. 12/24 Hour Format. Press the SET/CH key again to adjust the 12/24
hour format setting. Press the TEMP./+ key to change between 12
hour and 24 hour format.
5. Change Hour. Press the SET/CH key again to set the hour. Press the
TEMP./+ key or BARO./- key to adjust the hour up or down.
6. Change Minute. Press the SET/CH key again to set the minute. Press
the TEMP./+ key or BARO./- key to adjust the minute.
7. D-M/M-D Format. ress the SET/CH key again to adjust the D-M/M-D
format setting. Press the TEMP./+ key to change between D-M and
M-D format.
8. Change Year. Press the SET/CH key again to set the calendar year.

Color Screen Multi-channel Weather Station User Manual
12
Press the TEMP./+ key or BARO./- key to adjust the calendar year.
9. Change Month. Press the SET/CH key again to set the calendar
month. Press the TEMP./+ key or BARO./- key to adjust the
calendar month.
10. Change Day. Press the SET/CH key again to set the calendar day.
Press the TEMP./+ key or BARO./- key to adjust the calendar day.
11. Temperature Units (Celsius or Fahrenheit). Press the TEMP./+ key
again to toggle the temperature units from Celsius to Fahrenheit.
12. Barometric Pressure Display Units (hPa, mmHg or inHg). Press the
SET/CH key again to toggle the pressure units between hPa, mmHg or
inHg.
13. Northern Hemisphere (NTH) or southern Hemisphere (STH) select.
Press the SET/CH key again to toggle the pressure units between
NTH or STH.
Note: In the Set mode, press the TEMP./+ key or BARO./- key to change
or scroll the value. Hold the TEMP./+ key or BARO./- key for 3 seconds to
increase/decrease rapidly.
Note: Press the LIGHT/SNOOZE key (or wait 30 seconds for the
programming mode to timeout), and the Set Mode will return to Normal
Mode.
4.2 Check different channels when multiple sensors included
If the device comes with multiple sensors, channel number can be set up as
3.2 Thermo- Hygrometer Sensor Set Up. While in normal mode, press
SET/CH key repeatedly to view data of different channels. Temperature,
humidity, max./min. records of according channel will be displayed on
outdoor segment.

Color Screen Multi-channel Weather Station User Manual
13
4.3 Check Barometric Pressure
4.3.1 Barometric Pressure History
While in normal mode, press BARO./- to check the barometric pressure.
Press the BARO./- button to switch to past 12hr/24hr/48hr/72hr average
pressure. To exit the barometric pressure history mode, press the
SNOOZE/LIGHT key (on the top of the display console), or wait 30 seconds
for the timeout to take effect.
4.3.2 Relative Pressure Calaibration
You will want to calculate your barometric pressure to an official reporting
station in your area. Since barometric pressure does not drastically
change in a 50 mile radius (unless the weather is rapidly changing), this
method of calibration is acceptable.
To determine the relative pressure for your location, locate an official
reporting station near you (the internet is the best source for real time
barometer conditions, such as Weather.com or Wunderground.com), and
set your weather station to match the official reporting station.
4.3.3 Relative vs. Absolute Pressure
While in normal mode, Press and hold the BARO./- button for 2 seconds
you can switch between absolute (ABS) pressure and relative (REL)
pressure.
The display console displays two different pressures: absolute (measured)
and relative (corrected to sea-level).
To compare pressure conditions from one location to another,
meteorologists correct pressure to sea-level conditions. Because the air
pressure decreases as you rise in altitude, the sea-level corrected pressure
(the pressure your location would be at if located at sea-level) is generally
higher than your measured pressure.
Thus, your absolute pressure may read 28.62 inHg (969 mb) at an altitude

Color Screen Multi-channel Weather Station User Manual
14
of 1000 feet (305 m), but the relative pressure is 30.00 inHg (1016 mb).
The standard sea-level pressure is 29.92 in Hg (1013 mb). This is the
average sea-level pressure around the world. Relative pressure
measurements greater than 29.92 inHg (1013 mb) are considered high
pressure and relative pressure measurements less than 29.92 inHg are
considered low pressure.
To determine the relative pressure for your location, locate an official
reporting station near you (the internet is the best source for real time
barometer conditions, such as Weather.com or Wunderground.com), and
set your weather station to match the official reporting station.
4.4 Dew point
While in normal mode, Press the TEMP/+ key to view the Dew Point of
current channel in the outdoor temperature Segment. If key idle 30 seconds,
the display will return to normal mode.
To exit the Dew Point display mode, press the SNOOZE/LIGHT key (on the
top of the display console), or wait 30 seconds for the timeout to take effect.
4.5 ALARM Mode
While in normal mode, press the ALARM key to view the alarm time. The
alarm icon will be displayed in the time field.
4.5.1 Time ALARM
Press ALARM button once, you will see the ALARM time.
Press and hold the ALARM button for 2 seconds, you will enter the ALARM
setting interface. Please follow the below sequence to operate settings:
1. Press the TEMP./+ and BARO/- button to change the hour.
2. Press SET/CH to confirm the hour and skip to minute setting. And press
the TEMP./+ and BARO/- button to change the minute.

Color Screen Multi-channel Weather Station User Manual
15
3. Press SET/CH to confirm the minute and skip to Alarm on/off setting.
Press TEMP./+ and BARO/- button to switch on/off the time ALARM.
4. Press SET/CH to skip to Ice ALARM on/off setting. Press TEMP./+ and
BARO/- button to switch on/off the low temperature ALARM(Refer to 4.5.2).
5. Returns to the normal display mode.
4.5.2 Low temperature ALARM
Low temperature ALARM is an ALARM happens when outdoor temperature
falls into (or goes up to) -3~2 c range. Once there is outdoor temperature of
any sensor falls into this temperature range, the low temperature alarm
would be triggered. The LO temperature icon will appear and flash
on the console. If the BEEP is switched on, a sound ALARM would be also
activated when Low temperature ALARM occurs.
4.5.3 Cancelling the ALARM
When time ALARM or Low temperature ALARM is triggered, press any key
to close the sound alarm. During time ALARM, press LIGHT/SNOOZE key
can enter snooze mode.
The Low temperature ALARM will reset automatically once the value has
fallen into the Low temperature ALARM range.
4.6 Calibration Mode
While in normal node, press and hold the SET/CH and BARO./- buttons 5
seconds to enter calibration mode(note: the SET mode will appear after
three seconds. Continue pressing the two keys until you see the CAL icon

Color Screen Multi-channel Weather Station User Manual
16
appear in the upper right hand corner of the display).
The calibration sequence would be as below:
1. CH1 Outdoor temperature calibration.
2. CH1 Outdoor humidity calibration.
3. CH2 Outdoor temperature calibration.
4. CH2 Outdoor humidity calibration.
5. CH3 Outdoor temperature calibration.
6. CH3 Outdoor humidity calibration.
7. Indoor temperature calibration.
8. Indoor humidity calibration.
9. Absolute pressure calibration.
In calibration mode, press + and - buttons to adjust offset values, then press
SET/CH to confirm and proceed to next parameter. Press the ALARM
button to cancel offset values.
Example 1:
The calibrated temperature from a red spirit thermometer, or actual
temperature is 30.0 °C
The uncalibrated or measured temperature is 28.7 °C.
Offset = Calibrated Temperature – Uncalibrated Temperature = 30.0 – 28.7
= 1.3 °C.
Enter the temperature offset +1.3 °C.
Example 2:
The calibrated absolute pressure from a calibrated pressure sensor, or
actual absolute pressure is 28.61 inHg.
The uncalibrated or measured absolute pressure measured by the weather
station is 28.66 inHg.
Offset = 28.66 – 28.61 = -0.05 inHg
Enter the absolute pressure offset -0.05 inHg
Note: The absolute pressure offset will also affect the relative pressure.
To adjust the relative pressure, only (independent of the absolute
pressure), reference Section 5.1.

Color Screen Multi-channel Weather Station User Manual
17
Normally, you would not calibrate the absolute pressure because it is
difficult to obtain a calibrated source. The preferred method is to calculate
relative pressure to an official source near you, as described in Section
4.3.2.
During calibration mode, press LIGHT/SNOOZE to exit calibration mode.
Please note Offset values range as below:
Temperature offset calibrated (range +/-9F, default: 0 degrees).
Humidity offset calibrated (range +/-9%)
Pressure offset calibrated (range +/-10hpa)
4.7 MAX/MIN Mode
The Max/Min weather data are displayed on the bottom of each parameter
segment. Left one in red color is MAX record, right one in blue or yellow is
MIN record. All the MAX/MIN records are based on since last reset time
after turned on.
Max temperature Min temperature Max humidity Min humidity
All MAX/MIN records of all sensors can be cleared if you press and hold the
TEMP button for 2 seconds.
MAX/MIN records are cleared on 0:00 every day default. And below
MAX/MIN DAILY icon would be displayed on console. You can switch off
this automatically clearing function in setting mode (Refer to 4.1.2 2.RST
ON/OFF in Set Mode Quick Reference Guide), and this icon would
disappear.

Color Screen Multi-channel Weather Station User Manual
18
4.8 Other Console Features
4.8.1 Color Weather Forecasting
This station learns. Please allow 30 days for barometric calibration. This will
ensure an accurate personal forecast for your location.
Six color forecast icons use changing atmospheric pressure to predict
weather conditions for the next 12-hours .
Note: The weather forecast or pressure tendency is based on the rate of
change of barometric pressure. In general, when the pressure increases,
the weather improves (sunny to partly cloudy) and when the pressure
decreases, the weather degrades (cloudy to rain).
Sunny Partly Cloudy Cloudy
Rainy Stormy Snowy

Color Screen Multi-channel Weather Station User Manual
19
Note: Snowy icon will appear in place of rainy and stormy icons when the
outdoor temperature is below 0 °C /32°F.
4.8.2 Moon phase
The following moon phases are displayed based on the calendar date.
New
Waxing
Crescent
First
Quarter
Waxing
Gibbous
Full
Waning
Gibbous
Third
Quarter
Waning
New
Note: Above icons are for Northern Hemisphere areas. For Southern
Hemisphere the icons are as below:
New
Waxing
Crescent
First
Quarter
Waxing
Gibbous
Full
Waning
Gibbous
Third
Quarter
Waning
New
4.8.3 Temperature/Humidity Trend Arrows
The temperature (2°F/1°C) and humidity (3%) trend indicators update every
30 minutes. The trend reflects changes over the past 3 hours. E.G.: At 3:00
— compares to 12:00 data; at 3:30 — compares to 12:30.
Temperature or Humidity
increased in past 3 hours
Temperature or Humidity
did not change in past 3
hours
Temperature or
Humidity decreased in
past 3 hours
4.8.4 Pressure Tendency Arrows
The forecast trend indicators update every 30 minutes. The trend reflects
changes in pressure (1 hPa) over the past 3 hours.E.G.: At 3:00 —
compares to 12:00 data; at 3:30 — compares to 12:30.

Color Screen Multi-channel Weather Station User Manual
20
Pressure is rising, weather
expected to improve
Pressure is unchanged
Pressure is falling,
weather expected
to worsen
4.8.5 Restoring Lost Outdoor Temperature and Humidity Sensor
If the signal is lost between the remote sensor (or transmitter) and the
display console (or the receiver), to resynchronize, while in normal mode,
Press and hold SET/CH and TEMP button for 5 seconds, to register the
outdoor transmitter.
Please wait several minutes for the remote sensor reports in. Do not touch
any buttons until synchronization is complete.
If the synchronization fails, reset the console by removing one battery from
the display console, wait 10 seconds, and reinsert the battery, as specified
in the console set up part.
