Finish Thompson PF SERIES User manual

PF SERIES PUMPS
PFM, PFP, PFV
OPERATION, INSTALLATION & PARTS MANUAL
Serial Number 178923 & lower

(8'HFODUDWLRQRI&RQIRUPLW\


)LQLVK7KRPSVRQ,QFKHUHE\GHFODUHVWKDWWKHIROORZLQJPDFKLQHVIXOO\FRPSO\ZLWKWKH
DSSOLFDEOHKHDOWKDQGVDIHW\UHTXLUHPHQWVDVVSHFLILHGEHWKH(&'LUHFWLYHVOLVWHG
7KHSURGXFWPD\QRWEHWDNHQLQWRVHUYLFHXQWLOLWKDVEHHQHVWDEOLVKHGWKDWWKHGULYHPRWRU
IRUWKH'UXPDQG&RQWDLQHU3XPSFRPSOLHVZLWKWKHSURYLVLRQVRIDOOUHOHYDQW(&'LUHFWLYHV
7KHFRPSOHWHSURGXFWFRPSOLHVZLWKWKHSURYLVLRQVRIWKH(&'LUHFWLYHRQPDFKLQHU\VDIHW\
SURYLGHGPRWRUVPDQXIDFWXUHGE\)LQLVK7KRPSVRQ,QFDUHXVHG
7KLVGHFODUDWLRQLVYDOLGSURYLGHGWKDWWKHGHYLFHVDUHIXOO\DVVHPEOHGDQGQRPRGLILFDWLRQV
DUHPDGHWRWKHVHGHYLFHV
7\SHRI'HYLFH
'UXPDQG&RQWDLQHU3XPS7XEHV

0RGHOV
%76±    (33,(336  ()3()9()6
+9'3/5  +9'3+5  3)0 
 3)3  3)6  3)9
 7%3 7%6  77&776 
 6776  706
(&'LUHFWLYHV
0DFKLQHU\6DIHW\(&

$SSOLHG+DUPRQL]HG6WDQGDUGV
(1,623DUW
(1,623DUW
(1

0DQXIDFWXUHU
)LQLVK7KRPSVRQ,QF
*UHHQJDUGHQ5RDG
(ULH3HQQV\OYDQLD86$

6LJQHG
B
3UHVLGHQW

-DQXDU\

3HUVRQV$XWKRUL]HGWR&RPSLOH7HFKQLFDO)LOH0LFKDHO6PLWK(QJLQHHUV/LPLWHG
2DNV5RDG:RNLQJ6XUUH\
 *83+8.
   7HOHSKRQH


Introduction
This manual pertains to the PF Series, specifically the PFP, PFM, and PFV plastic drum pumps. Finish Thompson Inc.
thanks you for choosing our products. We believe the use of our products will be fully satisfactory. When properly
installed and operated, your Finish Thompson motor and pump will provide long, trouble-free service; therefore,
please read this manual carefully before carrying out any operations on the pump/motor unit. Any use other than that
described herein is considered incorrect; and, consequently, Finish Thompson Inc. shall not be held responsible for
any damages to people or property. In case of doubt or enquiries, please reply to our Technical Service department
directly at the following address:
Finish Thompson, Inc.
921 Greengarden Rd.
Erie, PA 16501 U.S.A.
Index
Introduction ............................................................................................................................. 1
Warranty, General Terms & Conditions...................................................................................... 2
Safety...................................................................................................................................... 3
Pump Specifications ................................................................................................................ 4
Installation............................................................................................................................... 5
Maintenance
Disassembly ....................................................................................................................... 5
Inspection........................................................................................................................... 6
Reassembly........................................................................................................................ 6
Exploded View ......................................................................................................................... 7
Design Change ........................................................................................................................ 8
Pump Tube Spare Parts List ..................................................................................................... 9-10
1

2
Warranty, General Terms & Conditions
1. The following terms and conditions apply to the sale of machinery, components and related services and products, of Finish
Thompson Inc. (hereinafter “the products”)
2. Finish Thompson Inc. (the manufacturer) warrants only that:
a) its products are free of defects in material, design and workmanship at the time of original purchase;
b) its products will function in accordance with Finish Thompson Inc. operation manuals; Finish Thompson Inc. does not
guarantee that the product will meet the precise needs of the Customer, except for those purposes set out in any invitation
to render documents or other documents specifically made available to Finish Thompson Inc. before entering into this
agreement;
c) high quality materials are used in the construction of the pumps and that machining and assembly are carried out to the
highest standards. Except as expressly stated above, Finish Thompson Inc. makes no warranties, express or implied,
concerning the products, including all warranties of fitness for a particular purpose.
This warranty shall not be applicable in circumstances other than defects in material, design, and workmanship. In particular
warranty shall not cover the following:
d) Periodic checks, maintenance, repair and replacement of parts due to normal wear and tear;
e) Damage to the product resulting from:
i. Tampering with, abuse or misuse, including but not limited to failure to use the product for its normal purposes as
stated at the time of purchase or in accordance with Finish Thompson, Inc. instructions for use and maintenance of the
product, or the installation or improper ventilation or use of the product in a manner inconsistent with the technical or
safety standard in force;
ii. Repairs performed by non-authorized service workshop, or opening of the unit by non-authorized personnel, or use of
non genuine Finish Thompson Inc. parts;
iii. Accidents, force majeure or any cause beyond the control of Finish Thompson Inc., including but not limited to light-
ning, water, fire, earthquake, and public disturbances, etc.
3. The warranty shall cover the replacement or repair of any part, which is documented to be faulty due to construction or as-
sembling, with new or repaired parts free of charge delivered by Finish Thompson, Inc. Parts subjected to normal wear and
tear shall not be covered by the warranty. Finish Thompson, Inc. shall decide as to whether the defective or faulty part shall be
replaced or repaired. Transportation charges are prepaid to Finish Thompson.
4. The warranty of the products shall be valid for a period of 12 months from the date of delivery, under the condition that notice
of the alleged defect to the products or parts thereof be given to Finish Thompson, Inc. within the term of 8 days from the
discovery.
5. Repair or replacement under the terms of this warranty shall not give a right to an extension to, or a new commencement of,
the period of warranty. Repair or replacement under the terms of this warranty may be fulfilled with functionally equivalent re-
conditioned units. Finish Thompson Inc. qualified personnel shall be solely entitled to carry out repair or replacement of faulty
parts after careful examination of the motor. Faulty parts or components when replaced by Finish Thompson Inc. will become
the property of Finish Thompson Inc. If this warranty does not apply, the purchaser shall bear all cost for labor, material and
transportation.
6. Finish Thompson Inc. will not be liable on any claim, whether in contact, tort, or otherwise, for any indirect, special, incidental,
or consequential damages, caused to the customer or to third parties, including loss of profits, process down time, transpor-
tation costs, costs associated with replacement or substitution products, labor costs, installation or removal costs. In any and
all events, manufacturer’s liability shall not exceed the purchase price of the product and/or accessories.
7. Return Policy. Should you have any problems with this product, please contact the distributor in your area. The distributor
will determine if a return to the factory is necessary and will contact the factory for a Return Authorization Number.

3
Safety
1. Introduction
This manual contains all the information needed for the correct installation, use and maintenance of your new Finish Thompson
pump. It should be read and understood by all the personnel involved in installation, operating and servicing of the pump before
it is started.
2. Operator Qualification and Training
The personnel in charge of the installation, the operation, and the maintenance of the pump must be qualified and able to per-
form the operations described in this manual. Finish Thompson, Inc. shall not be held responsible for the training level of
personnel and for the fact that they are not fully aware of the contents of this manual.
3. Safety Instructions
FOR YOUR OWN SAFETY
BEFORE using or servicing your pump, please make sure to wear the proper clothing, eye protection and follow standard safety
procedures when handling corrosive or personally harmful materials.
GENERAL DANGER
NEVER use a plastic pump or an open, splash-proof, TEFC or non-ATEX motor when pumping or mixing flammable or combus-
tible material.
ALWAYS use and store the pump and motor in an upright position.
DANGER: POWER SUPPLY
Refer to instructions in the appropriate motor Operation & Installation Manual.
4. Noise Level
Refer to specifications in the appropriate motor Operation & Installation Manual.
5. Modifications and Spare Parts
Any changes concerning the service of the pump as originally purchased can be executed only after written approval from
Finish Thompson Inc. It is recommended to use only genuine Finish Thompson Inc. spare parts and approved accessories. The
use of non-original spare parts or non-approved accessories will void warranty and removes any responsibility on the manufac-
turer’s behalf for any damage caused to people or things.

PUMP SPECIFICATIONS
MODEL PFM MODEL PFP MODEL PFV
Outer Tube Diameter 2” (51 mm) 2” (51 mm) 2” (51 mm)
Discharge Spout Variable orifice barb fitting Variable orifice barb fitting Variable orifice barb fitting
Discharge Thread 1-1/4” NPSM 1-1/4” NPSM 1-1/4” NPSM
Max. Specific Gravity 1.83 1.83 1.83
Max. Viscosity 2000 cP 2000 cP 2000 cP
Min./ Max. Fluid
Temperature
35°F Minimum to 160°F Maximum 35°F Minimum to 160°F Maximum 35°F Mininum to 120°F Maximum*
(1.6°C Minimum to 71°C Maximum) (1.6°C Minimum to 71°C Maximum) (1.6°C Minimum to 49°C Maximum)
Wetted Materials Polypro, FKM, PTFE, ETFE, 316 SS Polypro, FKM, PTFE, ETFE, Alloy 625 (PFP) Unfilled Polypro, PVDF, FKM, PTFE, ETFE, Alloy 625
*PFV-72: 35°F Min. to 115°F Max. (2°C Min. to 49°C Max.)
4

INSTALLATION & MAINTENANCE INSTRUCTIONS
Installation
1. Remove the drum pump from its packaging and inspect for shipping damage.
2. Turn the pump coupling to verify there is no binding.
3. Verify the housing cover (item 21) is on tight (it has a left hand thread).
4. Adjust the coupling so that the empty slots in the insert are at 3 and 9 o’clock with the pump dis-
charge at 12 o’clock.
5. Install the motor onto the drum pump per the installation instructions from the Operation & Installation
Manual of the specific motor model.
Note: Pumps with the standard 1” barb spout include a variable orifice fitting, which initially limits the flow of the
pump to 10 gpm. As it is cut away, flow will increase from 10 gpm up to maximum flow (to increase flow,
simply trim back orifice). Orifice steps control flow as follows: Step 1 = 10 gpm, Step 2 = 20 gpm, Step 3 = 30
gpm, Step 4 (maximum opening) = maximum flow (see Fig. 1).
Note: ALWAYS use a 1” I.D. hose properly secured to the barb spout using a hose clamp.
Maintenance
Disassembly
1. Remove the housing cover (item 21) by turning it clockwise (left hand thread) while gripping the impeller
housing (item 18).
2. Turn the impeller until a hole in the shaft can be seen through the square slot in the impeller housing (item
18), and insert 3/32 pin into the hole. Holding the pin, turn the impeller (item 20) counterclockwise (right-
hand thread) and remove it.
3. Remove the impeller housing (item 18) by gripping the intake tube and spinning the housing clockwise
(left hand thread). Re-insert the 3/32 pin and while gripping the pump coupling unthread (counterclock-
wise) and remove the shaft (item 19) from the bearing assembly (item 3).
4. Place the pump head (item 5) in a vise (do not crush) and remove the intake tube (item 9) by unthreading
clockwise (left hand thread). Remove the inner upper (item 11) and lower (item 15) tubes from the head.
Remove the bearing assembly (item 3) and the FKM lip seal (item 4) from the head.
5. Remove the center bearing (item 13) from the upper (item 11) and lower (item 15) tubes.
6WHS
6WHS 6WHS 6WHS
)LJ
5

Inspection
1. Check the housing cover (item 21), the impeller (item 20), and the impeller housing (item 18) for wear, rub-
bing, or damage from foreign objects. Replace if damaged.
Note: The double impeller design of this pump is dependant on the impeller working correctly. Any damage
to the impeller can cause pump failure.
2. Inspect the pump shaft (item 19) for wear in the bottom (item 16), center bearing (item 13) and the FKM lip
seal (item 4) areas. Replace the shaft if needed.
3. Inspect the bottom bearing (item 16), center bearing (item 13), and the bearing guide (item 14) for internal
wear. Inspect all o-rings (items 17,12, & 10) for nicks or chemical attack. Replace as needed.
4. Inspect the bearing assembly (item 3) for rust or corrosion. Never reuse the lip seal.
Reassembly
1. Install new lip seal (item 4) into the pump head with the grooved side facing the bottom of the pump.
2. Thread the shaft (item 19) into the bearing assembly (item 3) with the 3/32 hole in the shaft on the other
end. Carefully insert the shaft straight through the vapor seal (to avoid seal damage) from the top and seat
the bearing assembly (item 3) into the pump head.
3. If o-rings are replaced -- install 2 center bearing o-rings (items 12) in the grooves, then slide the bearing
guide on and then the remaining 2 o-rings. Install 2 upper inner tube o-rings (items 10), and install the im-
peller housing o-ring (item 17) inside the top of the housing. Apply a small amount of Vaseline to the o-rings
to aid in assembly. Assemble the center bearing (item 13) into the upper (item 11) and lower (item 15) inner
tubes.
4. Slide the inner tube assembly up the shaft and into the counter bore in the bottom of the head. Slide the
intake tube up from the bottom, centering the bearing guide, and thread it into the head (left hand thread).
5. Gripping the coupling at the top of the pump, thread the impeller on (right hand thread). Install the housing
cover (left hand thread). Turn the coupling to verify there is no binding inside the pump.
6

7
PFM/PFP/PFV SPARE PARTS EXPLODED VIEW
1RWH,WHPV
KDYHEHHQDIIHFWHG
E\GHVLJQFKDQJHV,I
DUHSDLULQYROYHVDQ\RI
WKHVHLWHPVSOHDVHUHIHU
WRLQIRUPDWLRQIRXQGRQ
SDJHRIWKLVPDQXDO

8
Head and Vapor Seal Change - PFM, PFP, PFV Series
,Q2FWREHU)LQLVK7KRPSVRQPDGHDFKDQJHWRWKHKHDG
LWHPDQGWKHYDSRUVHDOLWHPRQWKHSODVWLF3)6HULHV
SXPSV7KH¿UVWVHULDOQXPEHUZLWKWKHQHZKHDGDQGYDSRUVHDO
LV;;;;;-0DNHVXUHWKHFRUUHFWSDUWVDUHRUGHUHGZKHQ
UHSDLULQJDSXPS
Vapor Seal
7KHSULPDU\SDUWDIIHFWHGE\WKHFKDQJHWRWKHKHDGLVWKHYDSRU
VHDOLWHP2OGVW\OHYDSRUVHDOVZLOOFRQWLQXHWREHDYDLODEOHWR
¿WROGVW\OHKHDGV
'HWHUPLQDWLRQRIQHZYHUVXVROGVW\OHYDSRUVHDOLVHDV\6LPSO\
ORRNDWWKHKHDGGHVLJQ
Impeller Housing change - PFM, PFP, PFV Series
%HJLQQLQJ$XJXVW)LQLVK7KRPSVRQPDGHDFKDQJHWR
WKHLPSHOOHUKRXVLQJLWHPRQWKHSODVWLF3)6HULHVPRG
HOV3)03)33)97KHFKDQJHZDVSKDVHGLQRYHUVHYHUDO
PRQWKVDQGFRYHUVDOOWKHYDULRXVWXEHOHQJWKVZLWKLQWKHVH
PRGHOV
7KHFKDQJHDIIHFWVWKHVHSDUWV
,QWDNHWXEHDVVHPEO\LWHP
8SSHULQQHUWXEHLWHP
,PSHOOHUKRXVLQJLWHP
:KHQUHSDLULQJDSXPSLQYROYLQJWKHSDUWVOLVWHGDERYH\RX
PXVW DVVXUHWKDWWKHFRUUHFWSDUWVDUHRUGHUHG
)LUVWFKHFNWKHVHULDOQXPEHU,IWKHSXPSVHULDOQXPEHU
HQGVLQ/RUROGHUSXPSVPDQXIDFWXUHGEHIRUH-DQXDU\
LWLVQHFHVVDU\WRGHWHUPLQHZKLFKLPSHOOHUKRXVLQJLV
LQVWDOOHGLQWKHSXPS,IWKHVHULDOQXPEHULVQRWOHJLEOHWKH
LQIRUPDWLRQEHORZFDQEHXVHGWRGHWHUPLQHZKLFKLPSHOOHU
KRXVLQJ\RXUSXPSFRQWDLQV
127($OOSXPSVHULDOQXPEHUVHQGZLWKDOHWWHUDQGWZRGLJLW
QXPEHU7KHOHWWHUV$WKURXJK/UHIHUWRWKHPRQWKHJ$ 
-DQXDU\7KHWZRQXPHULFDOGLJLWVUHIHUWR\HDU6RDSXPSVH
ULDOQXPEHUHQGLQJLQ&ZDVPDQXIDFWXUHGLQ0DUFK
6HFRQGGHWHUPLQHLPSHOOHUKRXVLQJUHTXLUHG7KHHDVLHVW
ZD\WRGHWHUPLQHQHZYHUVXVROGLVWRPHDVXUHRQHRIWKHWZR
ZLQGRZVLQWKHVLGHRIWKHLPSHOOHUKRXVLQJ0HDVXUHIURP
WKHWRSWRWKHERWWRP2OGVW\OHLPSHOOHUKRXVLQJVKDYHDZLQ
GRZKHLJKWRIDSSUR[LPDWHO\PP1HZVW\OHLPSHOOHU
KRXVLQJVKDYHDZLQGRZKHLJKWRIDSSUR[LPDWHO\PP
PP PP
2OG6W\OH 1HZ6W\OH
,PSHOOHU+RXVLQJV
,IWKHSXPSKDVDQROGVW\OHLPSHOOHUDQGRQHRUDOORIWKH 
 WKUHHDIIHFWHGSDUWVDUHUHTXLUHGIRUUHSDLU¿QGWKHFRUUHFW
 SDUWQXPEHULQWKHIROORZLQJSDUWVOLVW
:KHQRUGHULQJDOORWKHUSDUWVUHIHUHQFHWKHSDUWVOLVWRQ 
 SDJHRIWKLVPDQXDO
Old Style Impeller
Item Description PFM/PFP
(Polypropylene)
PFV
(PVDF)
9 PF27 intake tube M100005-1 M100005-5
9 PF40 intake tube M100005-3 M100005-6
9 PF48 intake tube M100005-4 M100005-7
9 PF60 intake tube M100005-8 M100005-12
9 PF72 intake tube M100005-11 M100005-10
11 PF27 upper inner tube M100050-1 M100050-5
11 PF40 upper inner tube M100050-3 M100050-6
11 PF48 upper inner tube M100050-4 M100050-7
11 PF60 & PF72 upper inner tube M100050-3 M100050-6
18 PF impeller housing M100018-1 M100018-2
1HZ6W\OH 2OG6W\OH
7RUHSODFHDQROGVW\OHKHDGYDSRUVHDORUGHU31 0
2UGHU31WRUHSODFHDQHZVW\OHKHDGYDSRUVHDO7KH
WZRYDSRUVHDOVDUHQRWLQWHUFKDQJHDEOHVRLWLVLPSRUWDQWWR
RUGHUWKHFRUUHFWSDUWQXPEHU
Head
1HZVW\OHKHDGVLWHPDUHEDFNZDUGVFRPSDWLEOH%HFDXVH
WKHYDSRUVHDOVDUHGLIIHUHQWEHWZHHQWKHWZRKHDGVWKHKHDG
LVVROGDVDNLWWKDWLQFOXGHVERWKWKHKHDGDQGWKHYDSRUVHDO
8VHKHDGSDUWQXPEHUVVKRZQLQWKHSDUWVOLVWRQSDJHRIWKLV
PDQXDO
+HDGV

2OG6W\OH,PSHOOHU+RXVLQJ3DUWV/LVW
,WHP 'HVFULSWLRQ 3)03)3 3)9
 9DSRU6HDO 0 0
 ´,QWDNH7XEH 0 0
 ´,QWDNH7XEH 0 0
 ´,QWDNH7XEH 0 0
 ´,QWDNH7XEH 0 0
 ´,QWDNH7XEH 0 0
 ´8SSHU,QQHU7XEH 0 0
 ´8SSHU,QQHU7XEH 0 0
 ´8SSHU,QQHU7XEH 0 0
 ´´8SSHU,QQHU7XEH 0 0
 ,PSHOOHU+RXVLQJ 0 0
9DSRUVHDOFDQDOVREHSXUFKDVHGDVDNLWZLWKWKHEHDULQJDVVHPEO\XVLQJSDUW
QXPEHU

ITEM QTY DESCRIPTION PART NUMBER
MODEL PFM MODEL PFP MODEL PFV
11
COUPLING INSERT
J100014 J100014 J100014
21
COUPLING HALF
J100012 J100012 J100012
3* 1 BEARING ASSEMBLY
A101110 A101110 A101110
4* 1 LIP SEAL
1/4” FKM 107592 107592 107592
51
NEW STYLE PUMP HEAD
POLYPROPYLENE 107755-1 107755-1 N/A
PVDF N/A N/A 107755-2
91
INTAKE TUBE (PFM/PFP = POLYPROPYLENE, PFV = PVDF)
27” MODELS 107475-2 107475-2 107475-7
40” MODELS 107475-3 107475-3 107475-8
48” MODELS 107475-4 107475-4 107475-9
60” MODELS 107475-5 107475-5 107475-10
72” MODELS 107475-6 107475-6 107475-11
10* 2
UPPER INNER TUBE O-RING
FKM J100249 J100249 J100249
EPDM 106519 106519 106519
PERLAST 105621 105621 105621
11 1
UPPER INNER TUBE (PFM/PFP = POLYPROPYLENE, PFV = PVDF)
27” MODELS 107660-2 107660-2 107660-5
40” MODELS 107660-3 107660-3 107660-6
48” MODELS 107660-4 107660-4 107660-7
60” MODELS 107660-3 107660-3 107660-6
72” MODELS 107660-3 107660-3 107660-6
12*
4 (27-48”)
8 (60”)
12 (72”)
CENTER BEARING O-RING
FKM J100018 J100018 J100018
EPDM 106798 106798 106798
PERLAST 105620 105620 105620
13 1 (27-48”)
2 (60”), 3 (72”)
CENTER BEARING
PTFE M100010 M100010 M100010
14
1 (27”-48”)
2 (60”)
3 (72”)
BEARING GUIDE
POLYPROPYLENE M101603-2 M101603-2 N/A
PVDF N/A N/A M101603-1
15 1
LOWER INNER TUBE
27” MODELS M100003-1 M100003-1 M100003-5
40” MODELS M100003-3 M100003-3 M100003-6
48” MODELS M100003-4 M100003-4 M100003-7
60” MODELS M100003-3 M100003-3 M100003-6
72” MODELS M100003-3 M100003-3 M100003-6
16 1 BOTTOM BEARING
PTFE M100007 M100007 M100007
17* 1
IMPELLER HOUSING O-RING
FKM J100019 J100019 J100019
EPDM 106799 106799 106799
PERLAST 105622 105622 105622
18* 1
IMPELLER HOUSING
POLYPROPYLENE 107316-1 107316-1 N/A
PVDF N/A N/A 107316-2
19 1
MAIN SHAFT
27” MODELS M100004-5 M100004-1 M100004-1
40” MODELS M100004-7 M100004-3 M100004-3
48” MODELS M100004-8 M100004-4 M100004-4
60” MODELS M100004-12 M100004-9 M100004-9
72” MODELS M100004-13 M100004-11 M100004-11
20* 1 IMPELLER ASSEMBLY
PVDF A100002-2 A100002-2 A100002-2
21* 1 HOUSING COVER
M101612-1 M101612-1 M101612-2
PUMP SPARE PARTS LIST
9
N/A = Not Applicable

ITEM QTY DESCRIPTION PART NUMBER
MODEL PFM MODEL PFP MODEL PFV
22 1
DISCHARGE O-RING
FKM J100991 J100991 J100991
EPDM J102378 J102378 J102378
PERLAST 107017 107017 107017
23 1
SPOUT
1” BARB (STANDARD) M100028-1 M100028-1 M100028-2
3/4” BARB (OPTIONAL) 105439-1 105439-1 105439
1” MNPT (OPTIONAL) 106599 106599 106599-1
24 1
DISCHARGE NUT
FOR USE WITH 1” OR 3/4” BARB SPOUT M101610-1 M101610-1 M101610-2
FOR USE WITH 1” MNPT SPOUT ONLY 106622 106622 106622-1
25
(not
pictured)
1
MIDDLE INNER TUBE (PFM/PFP = POLYPROPYLENE, PFV = PVDF)
27” MODELS N/A N/A N/A
40” MODELS N/A N/A N/A
48” MODELS N/A N/A N/A
60” MODELS M100003-3 M100003-3 M100003-6
72” MODELS M100003-3 M100003-3 M100003-6
26
(not
pictured)
1
LOWER MIDDLE INNER TUBE (PFM/PFP = POLYPROPYLENE, PFV = PVDF)
27” MODELS N/A N/A N/A
40” MODELS N/A N/A N/A
48” MODELS N/A N/A N/A
60” MODELS N/A N/A N/A
72” MODELS M100003-1 M100003-1 M100003-5
*Recommended Spare Parts
Note: Bearing assembly and lip seal can be purchased as a kit using part number 108110.
