Finlux 22fld850 User manual

colour television
télévision couleur
owner’s manual
manuel de l'utilisateur
22FLD850

English - 1 -
Contents
Features ................................................................. 4
Accessories ............................................................ 4
Introduction............................................................. 5
Preparation............................................................. 5
Safety Precautions ................................................. 5
Power Source ..................................................... 5
Power Cord......................................................... 5
Moisture and Water ............................................ 5
Cleaning.............................................................. 5
Ventilation ........................................................... 6
Heat and Flames ................................................ 6
Lightning ............................................................. 6
Replacement Parts ............................................. 6
Servicing............................................................. 6
Waste Disposal................................................... 6
Information for Users in European Union
Countries ............................................................ 6
Information for Users on Disposal of Old
Equipment and Batteries .................................... 6
Disconnecting the Device ................................... 6
Headphone Volume ............................................ 6
Installation........................................................... 6
LCD Screen ........................................................ 7
Warning .............................................................. 7
Licence Notification ............................................ 7
Overview of the Remote Control ............................ 8
LCD TV and Operating Buttons (for 760 models)...... 9
LCD TV and Operating Buttons (for 850 models).... 10
LCD TV and Operating Buttons (for 875 models).....11
Viewing the Connections- Back Connectors (*).... 12
Viewing the Connections - Side Connectors (*) ... 14
Power Connection ................................................ 15
Aerial / Cable (*) Connection................................ 15
Using Side USB Input (*)...................................... 16
USB Memory Connection ................................. 16
Connecting the LCD TV to a PC (*)...................... 17
Connecting to a DVD Player (*)............................ 18
Using Side AV Connectors (*)............................... 19
Using Other Connectors (*) .................................. 20
Connecting Other Equipment via Scart (*) ........... 21
Inserting Batteries in the Remote Control
Handset ................................................................ 22
Operating Range for the Remote Control............. 22
Switching the TV On/Off ....................................... 22
To Switch the TV On......................................... 22
To Switch the TV Off......................................... 22
Input Selection...................................................... 22
Basic Operations .................................................. 23
Operation with the Buttons on the TV............... 23
Volume Setting.............................................. 23
Programme Selection ................................... 23
Viewing Main Menu....................................... 23
AV Mode ....................................................... 23
Operation with the Remote Control .................. 23
Volume Setting.............................................. 23
Programme Selection (Previous or Next
Programme).................................................. 23
Programme Selection (Direct Access) .......... 23
Initial Settings ....................................................... 23
General Operation................................................ 24
Information Banner ........................................... 24
Electronic Programme Guide (EPG) .................... 25
Displaying Subtitles .......................................... 26
Digital Teletext (** for UK broadcasts only)....... 26
Widescreen....................................................... 26
Digital TV Menu System....................................... 27
Channel List...................................................... 27
Navigating Entire Channel List ..................... 27
Moving the channels in the channel list ........ 27
Deleting Channels in the Channel List.......... 27
Renaming Channels ..................................... 28
Adding Locks to Channels ............................ 28
Setting Favourites......................................... 28
How to Add a Channel to a Favourites
List..........................................................29
Removing a Channel from Favourite List.....29
On Screen Help ........................................... 29
Program Guide ............................................. 29
Timers............................................................... 29
Conditional Access ........................................... 29
TV Setup........................................................... 30
Setup ................................................................ 30
Configuration ................................................ 30
AC3 Audio (**for continental Europe
country options only) ..............................30
Hard of Hearing (**for continental Europe
country options only) ..............................30
Favourite Mode.......................................30
Channel List ...........................................30
Active Antenna.................................................. 31
Scan Encrypted .....................................31
Receiver Upgrade ..................................31
Over Air Download (OAD) ......................31
Parental Control .....................................31
Time Settings (*) .......................................... 32
Audio Description (Optional)......................... 32
Audio Description (Optional) ..................32
Preferred Language (Optional)...............32
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 1A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 1 04.05.2009 13:58:2104.05.2009 13:58:21

English - 2 -
Relative Volume (Optional).....................32
Standby Search (****) ................................... 32
Language...................................................... 32
Preferred.................................................33
Current....................................................33
Language Settings .................................33
Installation..................................................... 33
Automatic Channel Scan........................33
Manual Channel Scan ............................34
Clear Service List (****) ..........................34
First Time Installation..............................34
Media Browser (*)...................................35
Playing MP3 Files............................................. 36
Viewing JPG Files............................................. 36
Video Playback (*) ............................................ 36
Slideshow Options............................................ 36
Navigating the Analogue TV Menu System.......... 37
First Time Installation (*)....................................... 37
Analogue TV Menu System.................................. 37
Picture Menu..................................................... 37
Mode............................................................. 37
Brightness/Contrast/Colour/Sharpness/Hue.... 38
Colour Temp.................................................. 38
Noise Reduction ........................................... 38
Film Mode ..................................................... 38
Game Mode (optional) .................................. 38
Picture Zoom ................................................ 38
Reset ............................................................ 38
Store ............................................................. 38
Sound Menu ..................................................... 38
Volume.......................................................... 38
Equalizer....................................................... 38
Balance......................................................... 39
Headphone ................................................... 39
Volume....................................................39
Sound Mode (optional) ...........................39
AVL ............................................................... 39
Spdif Out....................................................... 39
SRS TruSurr XT (optional)............................ 39
Effect............................................................. 39
Store ............................................................. 39
Sleep Timer................................................... 40
Child Lock ..................................................... 40
Language...................................................... 40
Default Zoom ................................................ 40
Blue Background .......................................... 40
Menu Background......................................... 40
Backlight ....................................................... 40
Menu Timeout ............................................... 40
Teletext Language ........................................ 40
Ext Out.......................................................... 40
Install Menu ...................................................... 41
Program ........................................................ 41
Band ............................................................. 41
Channel ........................................................ 41
Colour System .............................................. 41
Sound System .............................................. 41
Fine Tune...................................................... 41
Search .......................................................... 41
Store ............................................................. 41
Install Menu in AV Modes.............................. 41
Colour System........................................41
Store ............................................................. 41
Program Table............................................... 41
Name......................................................42
Move.......................................................42
Delete .....................................................42
APS (Auto Programming System)..........42
Source Menu (*)................................................ 42
PC Mode Menu System........................................ 43
PC Position Menu............................................. 43
Autoposition .................................................. 43
H (Horizontal) Position.................................. 43
V (Vertical) Position ...................................... 43
Phase............................................................ 43
Dot Clock ...................................................... 43
PC Picture Menu........................................... 43
Sound Menu ................................................. 43
Feature Menu ............................................... 43
Source Menu ................................................ 43
Media Browser Menu.................................... 43
Displaying TV Information .................................... 44
Mute Function....................................................... 44
Picture Mode Selection......................................... 44
Freezing Picture ................................................... 44
Zoom Modes......................................................... 44
16:9................................................................... 44
4:3..................................................................... 44
Panoramic......................................................... 44
14:9................................................................... 44
Cinema ............................................................. 44
Subtitle.............................................................. 45
Zoom................................................................. 45
Teletext ................................................................. 45
Tips....................................................................... 46
Screen Care...................................................... 46
Image Persistence............................................ 46
No Power.......................................................... 46
Poor Picture...................................................... 46
No Picture......................................................... 46
Sound ............................................................... 46
Remote Control................................................. 46
Input Sources.................................................... 46
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 2A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 2 04.05.2009 13:58:2204.05.2009 13:58:22

English - 3 -
Appendix A: PC Input Typical Display Modes....... 47
Appendix B: AV and HDMI Signal Compatibility
(Input Signal Types) ............................................. 48
Appendix C: Pin Specifications (*)........................ 49
SCART connector pin specifications ................ 49
HDMI connector pin specifications ................... 49
Signal Input....................................................... 49
PC RGB Terminal (D-sub 15-pin connector).... 49
S-input connector pin specifications ................. 49
Appendix D: Supported File Formats for USB
Mode (*)................................................................ 50
Specifications ..............................................................51
Digital Specifications (*)........................................ 51
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 3A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 3 04.05.2009 13:58:2204.05.2009 13:58:22

English - 4 -
Features
• Remote controlled colour LCD TV.
• Fully integrated digital TV (DVB-T) (*).
• HDMI connector(s) for digital video and audio.
This connection is also designed to accept
high definition signals.
• USB connection (*).
• 200 programmes from VHF, UHF (analogue).
• 300 programmes for digital TV (IDTV)
• OSD menu system.
• Teletext, fastext, TOP text.
• SRS TruSurround XT virtual surround
sound(optional).
• A scart socket for external devices (such as
video, video games, audio set, etc.).
• Stereo sound system. (German+Nicam)
• Headphone connection.
• Audio line out via SPDIF.
• Automatic programming system.
• Forward or backward manual tuning.
• PLL (Frequency Search).
• Sleep timer.
• Child lock.
• NTSC playback.
• AVL (Automatic Volume Limiting).
• Automatic sound mute when no transmission.
• Auto switching to standby mode if no valid
signal detected for five minutes.
• PC input (optional).
• Plug&Play for Windows 98, ME, 2000, XP,
Vista
1
• Game Mode (optional).
• 3D comb filter.
• Active antenna power (*).
(*) Optional: It is possible that this function is not
included in your TV.
Accessories
-/--
P/CH
GUIDE
//
P<P/SWAP
//
PP
OK
SELECT
MENU
DTV
TV
ABC DEF GHI
JKL MNO PQR
STU VWX YZ
SOURCE EXIT
123
456
789
0
AV
I-II
WIDE
INFO
Remote Controller
CR2025
3V
+
Batteries
Instruction Book
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 4A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 4 04.05.2009 13:58:2204.05.2009 13:58:22

English - 5 -
Introduction
Thank you for choosing this Finlux LCD TV. This
manual will guide you for the proper
operation of your TV. Before operating
the TV, please read this manual
thoroughly.
This instruction manual
includes all options of the
Finlux LCD TVs. It is possible that
some functions are not available in
your TV.
Please do keep this manual in a safe place for
future references.
Preparation
For ventilation, leave a free space of at least
10 cm all around the set. To prevent any fault
and unsafe situations, please do not place any
objects on top of the set.
Use this device in moderate climates.
Safety Precautions
Please read the following recommended
safety precautions carefully for your
safety.
Power Source
The TV set should be operated only from a
220-240 V AC, 50 Hz outlet. Ensure that you
select the correct voltage setting for your
convenience.
Power Cord
Do not place the set, a piece of furniture, etc.
on the power cord (mains lead) or pinch the
cord. Handle the power cord by the plug. Do
not unplug the appliance by pulling from the
power cord and never touch the power cord with
wet hands as this could cause a short circuit or
electric shock. Never make a knot in the cord or
tie it with other cords. The power cords should
be placed in such a way that they are not likely
to be stepped on. A damaged power cord can
cause fire or give you an electric shock. When it
is damaged and needs to be replaced, it should
be done by qualified personnel.
Moisture and Water
Do not use this device in a
humid and damp place (avoid
the bathroom, the sink in the
kitchen, and near the washing
machine). Do not expose this
device to rain or water, as this
may be dangerous and do
not place objects filled with
liquids, such as flower vases,
on top. Avoid from dripping
or splashing.
If any solid object or liquid falls into the cabinet,
unplug the TV and have it checked by qualified
personnel before operating it any further.
Cleaning
Before cleaning, unplug the TV
set from the wall outlet. Do not
use liquid or aerosol cleaners.
Use soft and dry cloth.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 5A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 5 04.05.2009 13:58:2304.05.2009 13:58:23

English - 6 -
Ventilation
The slots and openings on the TV set are
intended for ventilation and to ensure reliable
operation. To prevent overheating, these
openings must not be blocked or covered in
anyway.
Heat and Flames
The set should not be placed
near to open flames and
sources of intense heat such
as an electric heater. Ensure
that no open flame sources,
such as lighted candles,
are placed on top of the TV.
Batteries should not be exposed to excessive
heat such as sunshine, fire or the like.
Lightning
In case of storm and lightning
or when going on holiday,
disconnect the power cord
from the wall outlet.
Replacement Parts
When replacement parts are required, make
sure that the service technician has used
replacement parts, which are specified by the
manufacturer or have the same specifications as
the original one. Unauthorized substitutions may
result in fire, electrical shock or other hazards.
Servicing
Please refer all servicing to
qualified personnel. Do not
remove the cover yourself as
this may result in an electric
shock.
Waste Disposal
Instructions for waste disposal:
• Packaging and packaging aids are recyclable
and should principally be recycled. Packaging
materials, such as foil bag, must be kept away
from children.
• Batteries, including those which are heavy
metal-free, should not be disposed of with
household waste. Please dispose of used
battery in an environment friendly manner.
Find out about the legal regulations which
apply in your area.
• Cold cathode fluorescent lamp in LCD
PANEL contains a small amount of mercury;
please follow the local laws or regulations for
disposal.
Information for Users in European
Union Countries
This symbol on the product
or on its packaging means
that your electrical and
electronic device should
be disposed at the
end of its service life
separately from your
household wastes. There
are separate collection
systems for recycling in EU.
For more information, please contact the local
authority or the dealer where you purchased
the product.
Information for Users on Disposal of
Old Equipment and Batteries
[European Union only]
These symbols indicate that equipment with
these symbols should not be disposed of as
general household waste. If you want to dispose
of the product or battery, please consider the
collection systems or facilities for appropriate
recycling.
Notice: The sign Pb below the symbol for batteries
indicates that this battery contains lead.
Disconnecting the Device
The mains plug is used to disconnect TV set
from the mains and therefore it must remain
readily operable.
Headphone Volume
Excessive sound pressure from
earphones and headphones
can cause hearing loss.
Installation
To prevent injury, this device
must be securely attached to the wall in
accordance with the installation instructions
when mounted to the wall (if the option is
available).
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 6A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 6 04.05.2009 13:58:2304.05.2009 13:58:23

English - 7 -
LCD Screen
The LCD panel is a very high technology product
with about a million thin film transistors, giving
you fine picture details. Occasionally, a few
non-active pixels may appear on the screen
as a fixed blue, green or red point. Please note
that this does not affect the performance of
your product.
Warning
Do not leave your TV in standby or operating
mode when you leave your house.
Licence Notification
is a trademark of SRS Labs,
Inc. TruSurround technology is incorporated
under license from SRS Labs, Inc.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 7A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 7 04.05.2009 13:58:2304.05.2009 13:58:23

English - 8 -
Overview of the Remote Control
-/--
P/CH
GUIDE
//
P<P/SWAP
//
PP
OK
SELECT
MENU
DTV
TV
ABC DEF GHI
JKL MNO PQR
STU VWX YZ
SOURCE EXIT
123
456
789
0
AV
I-II
WIDE
INFO
1
2
3
4
5
6
7
8
9
11
1
0
1
2
1
3
1
4
1
51
6
8
1
71
1
9
12
2
0
5
2
24
23
2
2
29
26
8
2
7
2
30
Standby1.
Numeric buttons2.
Source Selection3.
Swap / Previous Programme4.
Mono/Stereo - Dual I-II5.
Cursor left6.
Cursor down7.
Menu8.
Programme up -9. Page down (*) /
Programme down - Page up (*)
Green button / Picture /10. Subtitle on-off (*) (**)
Red / Sound menu /11. Channel list (*) (**)
Time /12. Subtitle on-off (*) (***)
Teletext13.
Mix (in TXT mode) /14. No function
Expand (in TXT mode) / Image Size15.
Reveal (in TXT mode) / Switch from TV to PC16.
Index Page /17. Guide (*) (**)
Update (in TXT mode) /18. No function
Hold (in TXT mode) /19. No function
Blue / Install /20. Favourite Mode Selection (*) (**)
Yellow / Feature /21. Current Language (*) (**)
Volume Up / Volume down22.
Mute23.
TV /24. Digital TV (*) / Quit menu
Cursor right25.
Cursor up26.
Okay (store) /27. Select (*) / Freeze picture
Info28.
Picture mode selection29.
Exit (*)30. (*) Bold printed functions are only available for
DIGITAL TV models.
(**) For continental Europe country options
only.
(***)For UK only.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 8A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 8 04.05.2009 13:58:2304.05.2009 13:58:23

English - 9 -
LCD TV and Operating Buttons (for 760 models)
FRONT VIEW
REAR VIEW
TOP VIEW
Standby button1.
TV/AV button2.
Programme Up/Down3.
buttons
Volume Up/Down buttons4.
Note: Press V+/V- buttons at the
same time to view main menu.
/
TV AV
/PCH
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 9A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 9 04.05.2009 13:58:2404.05.2009 13:58:24

English - 10 -
LCD TV and Operating Buttons (for 850 models)
FRONT VIEW
REAR VIEW
Standby button1.
TV/AV button2.
Programme Up/Down3.
buttons
Volume Up/Down buttons4.
Note: Press V+/V- buttons at the
same time to view main menu.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 10A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 10 04.05.2009 13:58:2404.05.2009 13:58:24

English - 11 -
LCD TV and Operating Buttons (for 875 models)
FRONT VIEW
REAR VIEW
Standby button1.
TV/AV button2.
Programme Up/Down buttons3.
Volume Up/Down buttons4.
Note: Press “ ” or “ ” buttons at
the same time to view main menu.
TV/AV
MENU
P\CH
TOP VIEW
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 11A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 11 04.05.2009 13:58:2504.05.2009 13:58:25

English - 12 -
Viewing the Connections- Back Connectors (*)
All listed connections below may not be supported together. Some connections are
optional and it is possible that some connections are not available in your TV.
SCART socket1. inputs or outputs for external devices.
Connect the SCART cable between SCART socket on TV and SCART socket on your
external device (such as a decoder, a VCR or a DVD player).
Note: If an external device is connected via the SCART socket, the TV will automatically
switch to AV mode.
Component Video Inputs (YPbPr)2. are used for connecting component video.
You can connect the component video and audio sockets with a device that has component
output. Connect the component video cables between the COMPONENT VIDEO INPUTS
on on the TV and the component video outputs of your device. While connecting, be sure
that the letters on your TV, “Y”, “Pb”, “Pr” correspond with your device’s connectors.
PC/YPbPr Audio Inputs3. are used for connecting audio signals of a PC or a device that
connects to the TV via YPbPr.
Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output of
your PC to enable PC audio.
Connect the audio cable between AUDIO INPUTS on the TV and audio outputs of your
device to enable component audio.
S/PDIF Out4. outputs digital audio signals of the source currently being watched..
Use an S/PDIF coaxial cable to transfer audio signals to a device that has S/PDIF input.
You should also set SPDIF Out option in the Sound Menu as On.
RF Input5. connects to an aerial antenna or cable TV network.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 12A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 12 04.05.2009 13:58:2604.05.2009 13:58:26

English - 13 -
Note that if you use a decoder or a media recorder, you should connect the aerial cable
through the device to the television with an appropriate antenna cable, as shown in the
illustrationin the following pages.
Audio Line Outs6. output audio signals to an external device such as an optional sound
system.
To connect the external speakers to your TV, use AUDIO LINE OUTS of the TV with an
audio cable. Note: Line out feature cannot be used while in HDMI source. You can use
SPDIF instead.
PC Input7. is for connecting a personal computer to the TV set.
Connect the PC VGA cable between the PC INPUT on the TV and the PC VGA output on
your PC.
HDMI 1:8. HDMI input
HDMI 2 :9. HDMI input
HDMI Inputs are for connecting a device that has an HDMI socket.
Your LCD Television is capable of displaying High Definition pictures from devices such
as a High Definition Satellite Receiver or DVD Player. These devices must be connected
via the HDMI sockets or Component Socket. These sockets can accept either 480i, 480p,
576p, 576i, 720p, 1080i, 1080p signals.HDMI connection also carries the audio signal, no
separate sound connection is needed for an HDMI to HDMI connection.
(*) Optional: It is possible that some connectors are not available in your TV.
When you use the wall mount kit with the LCD TV, we would definitely recommend to plug all your
cables into the back of the LCD before mounting to the wall.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 13A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 13 04.05.2009 13:58:2604.05.2009 13:58:26

English - 14 -
Viewing the Connections - Side Connectors (*)
All listed connections below may not be supported together.
(*) Optional: It is possible that this function is not
included in your TV
CI (Common Interface) slot is used for inserting a CI1.
card. A CI card allows you to view all the channels that
you subscribe to. For more information, see “Conditional
Access” section.
USB Input (functional in DTV mode only)2.
Headphone jack is used for connecting an external3.
headphone to the system. Connect to the HEADPHONE
jack to listen to the TV from headphones (optional).
Video Input is used for connecting video signals of external4.
devices.Connect the video cable between the VIDEO IN
socket on the TV and the VIDEO OUT jack on your device.
Audio Inputs are used for connecting audio signals of5.
external devices. Connect the audio cable between the
AUDIO INPUTS on the TV and the AUDIO OUTPUT jacks
on your device.
Note: If you connect a device to the TV via the VIDEO
INPUT, you should also connect your device with an audio
cable to the AUDIO INPUTS of the TV to enable audio.
S-Video Input is used for connecting an S-Video signal6.
(e.g. from a camcorder or VCR). For using S-VIDEO input;
connect the video cable between the S-VIDEO input on the
TV and the S-Video output on your device. Connect the audio cable between the AUDIO
INPUTS (indicated with number 5 in the illustration) on the TV and the audio jacks on your
device..
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 14A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 14 04.05.2009 13:58:2604.05.2009 13:58:26

English - 15 -
Power Connection
IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.
• After unpacking, allow the TV set to reach the ambient room temperature before you connect
the set to the mains.
• Plug the power cable to the mains socket outlet.
Aerial / Cable (*) Connection
• Connect the aerial or cable (* optional) TV plug to the AERIAL / CABLE socket located at the
rear of the TV.
Aerial or Cable
REAR VIEW
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 15A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 15 04.05.2009 13:58:2804.05.2009 13:58:28

English - 16 -
Using Side USB Input (*)
• You can connect USB devices to your TV by using the USB input of the TV. This feature allows
you to display/play JPG and MP3 files stored in a USB stick.
• It is possible that certain types of USB devices (MP3 Players) may not be compatible with this
TV.
• You may back up your files before making any connections to the TV set in order to avoid any
possible data loss. Note that manufacturer will not be responsible for any file damage or data
loss.
• Do not pull out USB module while playing a file.
CAUTION: Quickly plugging and unplugging USB devices, is a very hazardous operation.
Especially, do not repeatedly quickly plug and unplug the drive. This may cause physical
damage to the USB player and especially the USB device itself.
SIDE VIEW USB MEMORY
USB Memory Connection
• Plug your USB device to the USB input of the TV.
Note: Some USB hard disk drives may not be supported by USB Memory connection. Only USB hard disk
drives with FAT32 file system format is supported, NTFS file system format is not supported.
Note: If the plugged USB disk is not recognised, please reinsert the disk.
• It is recommended that you connect your USB device directly to the USB input of the TV. Some
compatibility problems may occur if you use a separate cable connection.
1
(*) Optional: It is possible that this function is not included in your TV.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 16A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 16 04.05.2009 13:58:2804.05.2009 13:58:28

English - 17 -
Connecting the LCD TV to a PC (*)
For displaying your computer’s screen image on your LCD TV, you can connect your computer
to the TV set.
• Power off both computer and display before making any connections.
• Use 15-pin D-sub display cable to connect a PC to the LCD TV.
• When the connection is made, switch to PC source. See “Input selection” section.
• Set the resolution that suits your viewing requirements. Resolution information can be found in
the appendix parts.
REAR VIEW
PC audio cable
(not supplied)
to AUDIO INPUTS
on the TV
PC RGB cable
(not supplied)
to PC input
Audio
Inputs
PC Input
2
(*) Optional: It is possible that this function is not included in your TV.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 17A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 17 04.05.2009 13:58:2804.05.2009 13:58:28

English - 18 -
Connecting to a DVD Player (*)
If you want to connect a DVD player to your LCD TV, you can use connectors of the TV set. DVD
players may have different connectors. Please refer to your DVD player’s instruction book for
additional information. Power off both the TV and the device before making any connections.
Note: Cables shown in the illustration are not supplied.
• If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD
player as illustrated below, switch to HDMI source. See, “Input Selection” section.
• Most DVD players are connected through COMPONENT SOCKETS. Use a component video
cable to connect video input. For enabling audio, use a component audio cable as illustrated
below. When the connection is made, switch to YPbPr source. See, “Input selection” section.
• You may also connect through the SCART socket. Use a SCART cable as shown below.
Note: These three methods of connection perform the same function but in different levels of quality. It is not
necessary to connect by all three methods.
HDMI
inputs
Scart sockets
Component
video
inputs
Component
audio
inputs
DVD Player
REAR VIEW
(*) Optional: It is possible that this function is not included in your TV.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 18A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 18 04.05.2009 13:58:2904.05.2009 13:58:29

English - 19 -
Using Side AV Connectors (*)
You can connect a range of optional equipment to your LCD TV. Possible connections are shown
below. Note that cables shown in the illustration are not supplied.
• For connecting a camcorder, connect to the S-VIDEO or VIDEO IN socket and the AUDIO
SOCKETS. Do not connect the camcoder to S-VIDEO and VIDEO IN socket at the same time
since it can cause noise in the picture. For selecting the related source, see the section “Input
selection” in the following parts.
• To listen the TV sound from headphones, connect to the HEADPHONE jack of theTV.
Camcorder
Headphone
SIDE VIEW
(*) Optional: It is possible that this function is not included in your TV.
A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 19A01-[GB]-MB25_FINLUX (22FLD850)_DVB_TC_ORTAK_(WO DVD)_1186UK_50148028.indd 19 04.05.2009 13:58:3004.05.2009 13:58:30
