FIP FLS M9.03 User manual

1
FLS M9.03
DUAL PARAMETER FLOW
MONITOR & TRANSMITTER
SAFETY INSTRUCTIONS
PACKING LIST
General Statements
• Do not install and service the product without following the Instruction
Manual.
• This item is designed to be connected to other instruments which can be
hazardous if used improperly. Read and follow all associated instrument
manuals before using with it.
• Product installation and wiring connections should only be performed by
qualied sta󰀨.
• Do not modify product construction.
Installation and Commissioning Statements
• Remove power to the instrument before wiring input and output connections.
• Do not exceed maximum specications using the instrument.
• To clean the unit, use only chemical compatible products.
Please verify that the product is complete and without any damage.
The following items must be included:
• M9.03 Dual Parameter Flow Monitor & Transmitter
• Instruction Manual for M9.03 Dual Parameter Flow Monitor & Transmitter.

2
DESCRIPTION
CONNECTIONS TO INSTRUMENTS
The new FLS M9.03 is a powerful dual ow monitor designed to convert the
frequency signals of FLS ow sensors into ow rates. M9.03 is equipped
with a 4” wide full graphic display which shows measured values clearly and
a lot of other useful information. Moreover, due to a multicolor display plus a
powerful backlight, measurement status can be determined easily from afar
also. A tutorial software guarantees a mistake-proof and fast set up of every
parameters. Calibrations can be performed just xing installation features
or using a reference value through a new “in-line calibration”. Two 4-20mA
output are available to remote each ow rate to an external device. A proper
combination of digital outputs allows customized setups for any process to be
controlled.
F3.00 F3.20 F6.30 F3.10 F3.05 F6.60 F6.61 F111
M9.03 x x - X - X X X
ULF F3.80 pH/
ORP200
pH/
ORP400
pH/
ORP800
C150/
200
C100/
C300 C6.30
M9.03 X X - - - - - -
TECHNICAL DATA
General
• Associated sensors: 2 X FLS hall e󰀨ect ow sensors with frequency output
or FLS F6.60 ow magmeter family
• Materials:
- case: ABS
- display window: PC
- panel & wall gasket: silicone rubber
- keypad: 5-button silicone rubber
• Display:
- LC full graphic display
- backlight version: 3-colours
- backlight activation: User adjustable with 5 levels of timing
- update rate: 1 second
- enclosure: IP65 front
• Flow input range (frequency): 0÷1500Hz
• Flow input accuracy (frequency): 0,5%

3
Electrical
• Supply Voltage: 12 to 24 VDC ± 10% regulated
• Maximum current consumption: 300 mA
• FLS hall e󰀨ect ow Sensor power:
- 5 VDC @ < 20 mA
- optically isolated from current loop
- short circuit protected
• 2 x Current output:
- 4-20 mA, isolated, fully adjustable and reversible
- max loop impedance: 800 Ω @ 24 VDC - 250 Ω @ 12 VDC
• 2 x Solid State Relay output:
- user selectable as MIN alarm, MAX alarm, Pulse
Out, Window IN Alarm, Window OUT Alarm, O󰀨
- optically isolated, 50 mA MAX sink, 24 VDC MAX pull-up voltage
- max pulse/min: 300
- hysteresis: user selectable
• 2 x Relay output:
- user selectable as MIN alarm, MAX alarm, Pulse Out, Window IN Alarm,
Window OUT Alarm, O󰀨
- mechanical SPDT contact
- expected mechanical life (min. operations): 107
- expected electrical life (min. operations): 105N.O./ N.C.switching capacity
5A/240VAC
- max pulse/min: 60
- hysteresis: User selectable
Environmental
• Operating temperature: -20 to +70°C (-4 to 158°F)
• Storage temperature: -30 to +80°C (-22 to 176°F)
• Relative humidity: 0 to 95% not condensing
Standards & Approvals
• Manufactured under ISO 9001
• Manufactured under ISO 14001
• CE
• RoHS Compliant
• EAC

4
DIMENSIONS
PANEL MOUNTING
WALL MOUNTING

5
INSTALLATION
Mechanical installation
The M9.03 Dual-Parameter Flow Monitor & Transmitter is available just in one
packaging for panel or wall installation. The panel version is installed using
the panel mounting kit (M9.SN1), while the wall mounting version is got xing
the panel mounting version on the wall mounting kit (M9.KWX). The mounting
kits can be ordered directly connected to the monitor or separately and then
simply installed on it.
Panel installation
Fix instrument on the panel rotating by hand the xing snails (M9.SN1).

6
Wall installation
Use the panel mounting kit (M9.SN1) to x the M9.03 on the dedicated frontal
cutout of the wall mounting kit (M9.KWX).
Tighten front screws of box and waterproof connectors of cables, internally
mount caps on screw sites to get a IP65 watertight installation.

7
WIRING
REAR TERMINAL VIEW
General recommendation
Always ensure the power supply is switched o󰀨 before working on the device.
Make wiring connections according to wiring diagrams.
• Terminals accept 26 to 12 AWG (0.08 to 2.5 mm2)
• Strip around 10 mm (0.4”) of insulation from the wire tips and tin bare ends to
avoid fraying.
• Ferrules are suggested when connecting more than one wire to a single
terminal.
• Remove the upper part of the terminals for an easy cabling.
• Insert wire tip or ferrule completely into the terminal and x with the screw
until nger tight.
• Do not route the sensor, DC power, or 4-20mA cables in conduit containing
AC power wiring. Electrical noise may interfere with sensor signal.
• Routing the sensor cable in grounded metal conduit can help prevent
electrical noise and mechanical damage.
• Seal the cable entry points to prevent moisture damage.
Wall Installation
Pull the electrical cables through liquid tight connectors.
Use electrical cables with the proper external diameter for the liquid tight
connector.
PG11/PG9: external diameter between 2-7 mm (0.079-0.276”)
Refer to dedicated sensor manual for its wiring.

8
POWER/LOOP WIRING DIAGRAM
Stand-alone application,
no current loop used
Connection to a PLC/Instrument with a separate power supply
or
Connection to a PLC with built-in
power supply
Power Supply
12 - 24 VDC
12 - 24 VDC
+ VDC
- VDC
2
1
Power Supply
12 - 24 VDC
4 - 20 mA
Input 2
PLC Terminals
4 - 20 mA
Input 1
+ VDC
- VDC
2
1
- LOOP 2
+ LOOP 1
+ LOOP 2
- LOOP 1
21
22
23
24
Power Supply
12 - 24 VDC
12 - 24 VDC
PLC
4 - 20 mA
Input 2
4 - 20 mA
Input 1
+ VDC
- VDC
2
1
- LOOP 2
+ LOOP 1
+ LOOP 2
- LOOP 1
21
22
23
24
Power Supply
12 - 24 VDC
12 - 24 VDC
PLC
4 - 20 mA
Input 2
4 - 20 mA
Input 1
+ VDC
- VDC
2
1
- LOOP 2
+ LOOP 1
+ LOOP 2
- LOOP 1
21
22
23
24
Power Supply
12 - 24 VDC
12 - 24 VDC
PLC
4 - 20 mA
Input 2
4 - 20 mA
Input 1
+ VDC
- VDC
2
1
- LOOP 2
+ LOOP 1
+ LOOP 2
- LOOP 1
21
22
23
24
Power Supply
12 - 24 VDC
12 - 24 VDC
PLC
4 - 20 mA
Input 2
4 - 20 mA
Input 1
+ VDC
- VDC
2
1
- LOOP 2
+ LOOP 1
+ LOOP 2
- LOOP 1
21
22
23
24
Internal PLC
connection
N.O.
COM
4
3
PLC
Imax = 50 mA
Power sup.
Power sup.
O.C. IN
O.C. IN
SOLID-STATE RELAY WIRING DIAGRAM
(FOR SSR1 AND SSR2)
Connection to a PLC with NPN input Connection to a PLC with PNP input
N.O.
COM
4
3
PLC
Imax = 50 mA
Power sup.
Power sup.
O.C. IN
O.C. IN
Internal PLC
connection
lmax = 50mA lmax = 50mA
USB PORT
A USB port (type B) is available on the M9.03 PCB.
The USB connection allows the updating of device software.
To update the software you need: USB cable (M9.KUSB), the interface
software "FLS Calibration System” and the new updating software for M9.03
which are both downloadable from www.snet.it freely on product page.

9
RELAY WIRING DIAGRAM (FOR RELAY 1 & RELAY 2)
The alarm is OFF during normal
operation and goes ON according to
Relay settings
The alarm is ON during normal
operation and goes OFF according to
Relay settings
Connection to a PLC / Instrument
digital input with separate Power
Supply
The alarm is o󰀨 during normal
operation and goes ON according to
Relay setting.
If Imax > 50 mA use external Relay
Connection to a PLC / Instrument
digital input for Voltage Free Contacts
(REED)
Connection to an User
N.O.
COM
3
4
Power Supply
12 - 24 VDC
12 - 24 VDC
PLC / Instrument
Digital INPUT
Digital INPUT
Imax = 50mA
NO
10
11
12
RELAY 2
NC
COM
Alarm
AC or DC
Power NO
10
11
12
RELAY 2
NC
COM
Alarm
AC or DC
Power
lmax = 50mA
PLC
DIGITAL INPUT N
DIGITAL INPUT 2
DIGITAL INPUT 1
REF PLC
N.O.
Imax = 50 mA
Imax
COM
3
4
N.O.3
4 COM
AC or DC
Power
User
Imax = 50mA
N.O.3
4 COM
AC or DC
Power User
Imax = 50mA
lmax = 50mA
lmax = 50mA
N.O.3
4 COM
AC or DC
Power
User
Imax = 50mA
N.O.3
4 COM
AC or DC
Power User Imax = 50mA
lmax = 50mA
N.O.
N.O.
N.C.
COM
4
3
COM
External Relay
V= 12-24 VAC/VDC
Imax = 50 mA
Imax
Imax
+V
-V lmax = 50mA

10
* Delta visualization can be activated in Options Menù.
** Both Analog Outputs can be set for remoting
the same Flow Rate.
*** In case Bi-directional measurement is activated,
Delta Flow indication cannot be shown.
****Resettable totalizers can be reset using on view level
***** for more info about Outputs
↓
↓
OPERATIONAL
OVERVIEW
The M9.03 Dual Parameter Flow Monitor
and Transmitterfeatures a full graphic
display and a ve-button keypad for
system set-up, calibration and operation.
Full graphic display has a white backlight
during standard conditions, a red backlight
in case a set alarm is activated (MAX,
MIN, WINDOW IN, WINDOW OUT MODE:
always with priority), a green backlight in
case a external device control is activated
(PULSE MODE).
VIEW LEVEL
Flow Rate 1
Flow Rate 2
(Delta Flow Rate)*
Flow Rate 1
Innite Totalizer(S) 1
Resettable Totalizer(S) 1 ****
Flow Rate 2
Innite Totalizer(S) 2
Resettable Totalizer(S) 2 ****
Output Settings *****
Flow Rate 1 or 2 - Analog Output 1**
Flow Rate 2 or 1 - Analog Output 2**
Item Code - Software Release
MENU DIRECTORY
Settings 1
Calibration 1
Calibration 2
Settings 2
Outputs
Options
Setting View 1
Setting View 2

11
↓
↓
↓
↓
MENU LEVEL
Setting View 1
K-Factor
Internal Diameter
Sensor Type
Pipe Parameter
Standard Pipe
Pipe Diameter
Setting View 2
K-Factor
Internal Diameter
Sensor Type
Pipe Parameter
Pipe Diameter
Options
Language
Backlight
Filter
Asec Upgrade Firmware
Flow Rate Decimal Point
Default Data
Outputs Activation
Password
Custom Calibration1
Custom Calibration2
Contrast
Bi-Directional***
Delta Flow ***
Outputs
1 SSR
2 SSR
3 RELAY
Output Test
4-20mA
Calibration 2
Correction Factor
Signal Intensity BLE
Auto Calibration
Calibration 1
Correction Factor Signal Intensity BLE
Auto Calibration
Settings 2
Installation Data Volume Unit
Flow Unit
Settings 1
Installation Data
Flow Unit
Volume Unit

12
OUTPUT MODE
The M9.03 Dual Parameter Flow Monitor and Transmitter features 2 solid
state relays and 2 mechanical relays in addition to 2 analog outputs 4-20mA.
PROCEDURE FOR OUTPUTS SETTING
• go to the “Options” menu
• enter into the “Outputs activation” sub menu
• enable output(s)
• go to the “Outputs” menu
• set the operating mode for each enabled output
Monitor without digital
output activated
In case a digital output
is enabled, a icon will
appear
In case a digital output
is set, icon reports the
operating mode
In case set digital
output is activated, the
icon will turn to black
(display turns green in
case output is set to
manage an external
device, red to indicate
a activated output as
alarm)
EDIT LEVEL
PUSH BUTTON
to modify an item
to scroll right
to return to Menu without saving
to save new settings
↓
↓

13
Digital outputs can be set in the following way:
MIN MODE (icon reports MIN)
WINDOW IN MODE
(icon reports WIN)
MAX MODE (icon reports MAX)
PULSE MODE (icon reports PLS)
Flow
Time
Hysteresis
Output relaxed
Output energized
Setpoint
Flow
Time
Hysteresis
Output relaxed
Output energized
Setpoint
Pulse duration
Volume Volume Volume
Pulse duration Pulse duration
Output relaxed
Output energized
Flow
Time
Hysteresis
Output relaxed
Output energized
Setpoint
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
WINDOW OUT MODE
(icon reports WOT)
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Flow
Time
Hysteresis
Output relaxed
Output energized
Setpoint
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
Output relaxed
Output energized
Time
Flow
Hysteresis
Setpoint
Setpoint
Hysteresis
In case bidirectional function is
activated, ICONS reports also a
reference to the ow direction:
+ for main direction, - for opposite
direction.

14
OUTPUT FOR F3.00.W
In case of combination with F3.00.W, LOW BATTERY status and NO SIGNAL
condition can be remoted by two di󰀨erent digital outputs or by one for both
indications.
SOFTWARE UPDATING
In order to update the Instrument Software with a New Firmware Release
follow the suggested procedures
TO UPDATE INSTALLED UNITS
- Download the interface software “FLS Calibration System”
and the Updated Software on www.snet.it
- Launch the software "FLS Calibration System" on the laptop
- Select OPTION and then UPGRADE FIRMWARE
- Conrm the "Firmware Upgrade" procedure by ENTER
- Connect M9.03 to the laptop by the USB cable
- Select the item (M9.03) which appears on NAVIGATION area
on the "FLS Calibration System" software
- Conrm FW UPGRADE and select the Updated Software
NOTE: At the end of the procedure restart the instruments in order to refresh
M9.03 software (It takes 90 seconds to refresh the SW. Please do not interrupt
the restarting process).
TO UPDATE NEW UNITS
- Download the interface software “FLS Calibration System”
and the updated software on www.snet.it
- Launch the software "FLS Calibration System" on the laptop
- Push together ENTER and ESC powering the monitor
- Connect M9.03 to the laptop by the USB cable
- Select the item (M9.03) which appears on the NAVIGATION
area on the software "FLS Calibration System"
- Conrm FW UPGRADE and select the Updated Software
NOTE: At the end of the procedure restart the instruments in order to refresh
M9.03 software (It takes 90 seconds to refresh the SW. Please do not interrupt
the restarting process).

15
ORDERING DATA
Part No. Description
/Name
Power
supply
Wire power
Technology
Sensor
Input Output
M9.03.P1
Panel mount
Dual
Parameter
Flow
Monitor and
Transmitter
12 - 24 VDC 3/4 wire 2* Flow
(Frequency)
2*(4-20mA),
2*(S.S.R.),
2*(mech. relay)
M9.03.W1
Wall mount
Flow Monitor
Dual
Parameter
Flow
Monitor and
Transmitter
12 - 24 VDC 3/4 wire 2* Flow
(Frequency)
2*(4-20mA),
2*(S.S.R.),
2*(mech. relay)
M9.03.W2
Wall mount
Flow Monitor
Dual
Parameter
Flow
Monitor and
Transmitter
110 - 230 VAC 3/4 wire 2* Flow
(Frequency)
2*(4-20mA),
2*(S.S.R.),
2*(mech. relay)
ACCESSORIES
SPARE PARTS
Part No. Name Description
M9.KW1 Wall mounting kit 144x144mm plastic box for wall installation
of all panel mount monitors
M9.KW2 Wall mounting kit with
power supply
144x144mm plastic box and 110/230VAC to 24 VDC power
supply for wall installation of all panel mount monitors
M9.KUSB USB cable for device
interfacing USB cable dedicated to FLS products, 1,5 meter long
Part No. Name Description
M9.SN1 Fixing snails 2 xing snails for panel installation of FLS monitors

FIP - Formatura Iniezione Polimeri S.p.A.
Loc. Pian di Parata
16015 Casella
Genova - Italy
Tel. [phone]
Fax [phone]
www.flsnet.it
I2458 - IMM903E REV-02 02/2020
