Fire Pants Fabrication SCORPION Manual

1
SET UP INSTRUCTIONS
SCORPION GRINDER
Serial Numbers 011+
FIRE PANTS FABRICATION
Website: www.firepantsfab.com.au
Email: [e-mail]
Phone: [phone]

2
TABLE OF CONTENTS
SECTION DESCRIPTION PAGE
1 Introduction 3
2 Specifications 3
3 Unpacking 4
4 Setting Up 4
5 Operating instructions 17
6 Safety 18
7 Troubleshooting 21

3
1. INTRODUCTION
The Scorpion known for its fast acting, effective sting; this grinder is no different. With more power,
more speed, big platen and small footprint; the Scorpion grinder is in a league of its own. Perfect for
both beginners and professionals.
Features include:
•2 x 72” or 2 x 48” Belt Capacity
•Solid 10mm steel frame, laser cut for accuracy
•Ceramic platen backrest
•6061 aluminium tracking and drive wheels
•Huge 250mm drive wheel coupled with 2hp and 3hp motors ultimate performance
•The only grinder in its class built to run the Cubitron II belts from 3M
•Extended length platen backrest for greater control
•Move from a 300mm flat platen to a 250mm slack belt without even stopping or making
adjustments
•150 –350mm contact wheel capability
•Australian designed and built
NOTE: PLEASE DO NOT OPERATE THE SCORPION GRINDER UNTIL YOU HAVE READ THESE
INSTRUCTIONS AND ARE FAMILIAR WITH ITS CONTROLS. THE SCORPION GRINDER IS INTENDED
FOR USE ONLY BY TRAINED PERSONNEL.
2. SPECIFICATIONS
Model
SC72 Frame
SC72 2hp
SC72 3hp
SC72 VSD
Dimension of
Frame (LxWxH)
250 x 400 x
850mm
250 x 400 x
850mm
250 x 400 x
850mm
250 x 400 x
850mm
Weight
Approx. 20kg
Approx. 35kg
Approx. 35kg
Approx. 40kg
Electrical
Specifications
-
240v 10a
240v 15a
240v 10a
Belt Size
2 x 72”
2 x 72”
2 x 72”
2 x 72”
Belt Speed
-
7500sfm fixed
7500sfm fixed
750 –7500sfm
Environment
-
IP55
IP55
IP55 (indoor only)
Motor
No Motor
2 hp, 2 pole
3hp, 2 pole
2hp, 4pole
Switchgear
-
DOL Starter
DOL Starter
VSD control

4
3. UNPACKING
Carefully inspect the exterior of the packing box. Any visible damage should immediately be
reported to Fire Pants Fabrication. Remove all packing documents from the interior of the box and
file in your records. Remove the shipping box, the foam packaging material, and the Scorpion
Grinder. Open the top flaps of the packing box to remove the Scorpion Grinder from the base of the
box. Grasp the Scorpion Grinder on both sides, using proper lifting techniques, and place it on a
stable bench top. Visually check the Scorpion Grinder to ensure that no damage occurred during
shipping.
4. SETTING UP
Tools required:
5mm Allen key
6mm Allen key
10mm spanner (or socket) x2
13mm spanner (or socket)
16mm spanner (or socket)
17mm spanner (or socket)
18mm spanner (or socket)
Combination square or small spirit level
Torque wrench (recommended)

5
Step 1
Unpack the contents of all packages.
One package will contain the grinder frame
and parts, the other will have the motor
and VSD / Switchgear (if applicable).
First find the bag of bolts and confirm the
contents.
Refer to contents list on bag for correct
hardware.
Step 2
Unpack motor onto bench, flip it onto its
back, use a 13mm socket to remove the
motor feet. Retain feet and hardware.
Step 3
Place motor in position shown in picture,
Reinstall the feet using the original
hardware on the side facing up. The feet
will be on the same side as the data plate.
Tighten to 15 ft/lb

6
*You may have to clean the paint on the
bolt head if it does not seat fully into its
position.
Step 3.1
To allow the base to bolt down properly,
use a #2 Philips screwdriver to:
For Fixed speed machines: swap bolts A
and B.
For Variable speed machines: remove bolt
A and place in the empty position B.
Step 4
While in this position, locate the base
plate, and the 4 x M8*40mm countersunk
bolts, washers and nuts. Use a 6mm allen
key and 13mm spanner and 5mm Allen key
to install the base plate. (If installing on a
pedestal, you may need to preinstall the
bolts).

7
Step 5
Place motor on its feet as shown, at this
point you should secure the grinder on a
bench or pedestal where it will be used. Do
NOT connect the motor to a power until
the assembly is completed.
Step 6
locate the 4 x M8*25mm bolts, Large
washers, Scorpion frame.
Step 7
Place the frame on the motor face mount
in an upright position, install the 4 bolts by
hand into the slotted holes into the motor
face. Use a spirit level on the front vertical
face of the frame and adjust plumb before
tightening to 20 ft/lb with 13mm socket.

8
Step 8
Use the 6 x M6x40 bolts, washers, flange
nuts, and nyloc nut to assemble the tool
holder.
Assemble as shown, with the nyloc nut
closest to the M12 threaded hole in the
frame. Align the flats of the nut
horizontally to allow the platen bracket to
slide over it.
Step 8.1
Install one of the locking handles to the
tool holder.
Use an Allen key in the back, while pulling
the lever back to allow you to rotate the
centre easily.
Step 9
Locate the platen, angle brackets, 2 x
10*16mm bolts & washers, 2 x M12*20mm
bolts & washers.
Install angle brackets to platen by hand,
then the assembly to the frame. Lightly nip
up the bolts using a 16mm and 18mm
spanner to hold in place, final adjustment
will come later.
The platen mount holes are offset, the
default position is to have the ‘Long’ end
down (as shown), but it can be reversed to
give more platen above the work rest, and
a shorter ‘Slack’ belt area.

9
Step 10
Next assemble the work rest to the tool
arm using 1 x M12*35mm bolt and washer
and 1 locking handle with a washer.
Tighten the bolt just enough to allow some
movement when the locking handle has
been released.

10
Step
10.1
Install tool arm to the frame by sliding the
tool arm into the slot. Tighten with the
locking handle on the side.
*The angle of the locking handles can be
adjusted by pulling the handle out and
rotating to another position. The spring will
lock them in the new position.
Step 11
Locate the tensioner handle, hinge
assembly, tracking adjuster, tracking wheel
(125mm), 2 x M8*25mm Socket head bolt,
1 x M8*20mm socket head bolt.
Step 12
Place the two (2) 25mm long bolts through
the holes shown, and place through the
holes on the tracking arm, then secure the
hinge assembly to the other side. Tighten
to 20 ft/lb.

11
Step 13
Install the M10 Nut on the T handle thread,
then install the tracking adjuster T handle
until it contacts the back of the hinge.
*the nut is there to help lock the handle in
place, it should not need a spanner to
tighten it enough to lock the adjuster in
place.

12
Step 14
Locate the gas strut, Install the balls onto
the frame and tensioner as shown, with a
M8 washer under each.
Remove the locking clip from the gas strut
(if required) and press the ends firmly onto
the mounts on the frame. The rod should
be facing down. Replace clips.
Step 15
Then slide the tracking wheel over the axle
on the hinge assembly. You may need to
use a small screwdriver to lift the bearing
spacer inside the wheel to get it to slide on.
Secure using the 20mm long socket head
bolt and washer, tighten to 20ft/lb.

13
Step
15.1
Locate the guard, M10 x 35mm bolt, 2 x
M10 washers, and M10 Nyloc Nut.
Install guard on tensioner arm as shown.
Tighten nut and bolt enough to be able to
rotate the guard by hand, but not so loose
that is moves on its own.
The guard can be lifted up out of the way
for belt changes, but should always be in
the down position while the grinder is in
use.
(Guard is not shown in the following steps)
Step 16
Locate the drive wheel, and M8*40mm
bolt. Remove the protective cover from the
motor shaft, line up the keyway on the
shaft and the wheel, carefully slide the
drive wheel onto the shaft.
The wheel should be snug, but not require
any more than some light taps with a
rubber hammer to slide it on.
If it does not slide on, remove the key from
the shaft, and using some fine emery
gently work around the shaft to remove
any high spots. If it still does not slide on,
contact Fire Pants Fab for further
instructions.

14
Step 17
Once the wheel is seated on the shaft,
secure with the bolt, tighten to 20ft/lb.
Step 18
Locate the supplied belt and hang it over
the top wheel. Pull down on the tensioner
handle to hook it under the drive wheel.
Pay attention to the belt orientation, some
can only be used in one direction.

15
Step 19
Rotate the belt by hand in an anticlockwise
direction (viewed from the drive wheel
end), while using the tracking adjuster
handle to align the belt as close to centre
as possible on both wheels.
Step 20
Once the belt is aligned, adjust the platen
fore/aft position by loosening the M12
bolts on the frame, the platen should
protrude into the belt by 1-2mm. Use a
spirit level or measure off the frame to get
it even. Tighten adjuster bolts.
Adjust the platen left or right to be centred
on the belt by loosening the M10 bolts on
the back of the platen. Tighten adjuster
bolts.
Adjust the platen left or right to be centred
on the belt by loosening the M10 bolts on
the back of the platen. Tighten adjuster
bolts.

16
Step 21
Use a square to adjust the worktable, set it
to 90° to the platen. Remember to tighten
both work rest locks before loosening or
tightening the worktable.
Step 22
Mount the VSD / DOL Starter securely.
Follow the instructions in the VSD manual
for air gap and other mounting
requirements.
Mounting hardware not included.
Step 23
Your Scorpion grinder is now assembled
and ready to use. Plug it in to a suitable
power source and refer to the Operating
instruction section.

17
IMPORTANT: THE BOLTS AND WASHERS SUPPLIED WITH THE SCORPION GRINDER MUST BE USED.
For Variable speed model grinders only
If your motor and drive has come prewired:
•Plug the 3-pin electrical cord into a
240v power source.
•Turn isolating switch on.
•Ensure the forward light is flashing.
•Use the potentiometer next to the
keypad to adjust motor to its lowest
speed, it should display approx. 700
feet per minute.
•Push the run button to start the
motor.
•Check tracking of belt on the
Scorpion Grinder.
•See instruction manual for use on
the Variable Speed Drive.
If your motor and drive has not come prewired:
Contact a qualified electrician to wire up the
motor and variable speed drive.
•Plug the 3-pin electrical cord into a 240v
power source.
•Turn isolating switch on.
•Ensure the forward light is flashing.
•Use the potentiometer next to the
keypad to adjust motor to its lowest
speed, it should display approx. 700 feet
per minute.
•Push the run button to start the motor.
•Check tracking of belt on the Scorpion
Grinder.
•See instruction manual for use on the
Variable Speed Drive.
NOTE: ALL VARIABLE SPEED DRIVES SUPPLIED BY FIRE PANTS FABRICATION; WIRED OR NOT; HAVE
BEEN PROGRAMMED TO SUIT THE SCORPION GRINDER.
Operation Instructions:
1. Inspect machine prior to and during use for loose bolts, worn parts, noisy bearings, damage
to electrical cables.
2. Install the belt by pulling down on the tensioner handle and carefully slipping it around both
wheels.
3. Rotate slowly by hand to confirm the tracking.
4. Adjust tracking using the adjuster handle on the top.
5. Set up the worktable to the desired angle / position
6. Stand back from the belt
7. If variable speed, set to desired speed.
8. Press the Start (green) button.
9. Confirm the belt tracking again.
10. Wait until the belt is up to speed before grinding.
11. When finished press the Stop (Red) button and wait while the belt slows down to a stop, do
not continue to grind as the belt is slowing as you will prematurely wear the belt.
12. When finished, turn off Isolator switch (variable speed only), remove belt. Turn off power
source.
13. Inspect machine for loose bolts, worn parts, noisy bearings, damage to electrical cables after
use.

18
General Machinery Safety Instructions
Fire Pants Fabrication requires all users of their machines to read, understand and comply
with this entire manual before using this machine.
1. Read the entire Manual before starting
machinery. Machinery may cause serious injury
if not correctly used.
2. Use correct amperage extension cords.
Undersized extension cords overheat and lose
power. Replace extension cords if they become
damaged.
3. Always use correct hearing protection when
operating machinery. Machinery noise may
cause permanent hearing damage.
4. Keep machine well maintained. Keep blades
sharp and clean for best and safest
performance. Follow instructions when
lubricating and changing accessories.
5. Machinery must never be used when tired, or
under the influence of drugs or alcohol. When
running machinery, you must always be alert
6. Keep machine well-guarded. Make sure guards
on machine are in place and are all working
correctly.
7. Wear correct Clothing. At all times remove all
loose clothing, necklaces, rings, jewellery, etc.
Long hair must be contained in a hair net. Non-
slip protective footwear must be worn.
8. Do not overreach. Always keep proper footing
and balance
9. Always wear correct respirators around fumes
or dust when operating machinery. Machinery
fumes & dust can cause serious respiratory
illness. Dust extractors must be used where
applicable.
10. Secure workpiece. Use clamps or a vice to hold
the workpiece where practical. Keeping the
workpiece secure will free up your hand to
operate the machine and will protect hand from
injury.
11. Always wear correct safety glasses. When
machining you must use the correct eye
protection to prevent injuring your eyes.
12. Check machine over before operating. Check
machine for damaged parts, loose bolts, Keys
and wrenches left on machine and any other
conditions that may affect the machines
operation. Repair and replace damaged parts.
13. Keep work clean and make sure you have good
lighting. Cluttered and dark shadows may cause
accidents.
14. Use recommended accessories. Refer to
instruction manual or ask manufacturer when
using accessories. The use of improper
accessories may cause the risk of injury.
15. Personnel must be properly trained or well
supervised when operating machinery. Make
sure you have clear and safe understanding of
the machine you are operating.
16. Do not force machinery. Work at the speed and
capacity at which the machine or accessory was
designed.
17. Keep children and visitors away. Make sure
children and visitors are at a safe distance for
you work area.
18. Use correct lifting practice. Always use the
correct lifting methods when using machinery.
Incorrect lifting methods can cause serious
injury.
19. Keep your workshop childproof. Use padlocks,
turn off master power switches and remove
start switch keys.
20. Lock mobile bases. Make sure any mobile bases
are locked before using machine
21. Never leave machine unattended. Turn power
off and wait till machine has come to a complete
stop before leaving the machine unattended.
22. Allergic reactions. Certain metal shavings and
cutting fluids may cause an allergic reaction in
people and animals, especially when cutting as
the fumes can be inhaled. Make sure you know
what type of metal and cutting fluid you will be
exposed to and how to avoid contamination.
23. Make a safe working environment. Do not use
machine in a damp, wet area, or where
flammable or noxious fumes may exist.
24. Call for help. If at any time you experience
difficulties, stop the machine and call you
nearest branch service department for help.
25. Disconnect main power before service machine.
Make sure power switch is in the off position
before re-connecting.

19
Belt Grinder Safety Instructions
Fire Pants Fabrication requires all users of their machines to read, understand and comply
with this entire manual before using this machine.
1. Maintenance. Make sure the grinder is turned
off and disconnect from the main power supply
and make sure all moving parts have come to a
complete stop before any inspection,
adjustment or maintenance is carried out.
2. Hearing protection and hazards. Always wear
hearing protection as noise generated from
grinder and workpiece vibration can cause
permanent hearing loss over time.
3. Grinder Condition. Grinder must be maintained
for a proper working condition. Never operate a
grinder that has damaged or worn parts.
Scheduled routine maintenance should
performed on a scheduled basis.
4. Dust hazards. Always wear dust mask or
respirator and eye protection when sanding. Use
a dust collector as well to keep dust to a
minimum.
5. Disc/Belt Condition. Never operate a grinder
with a damaged or badly worn disc or belt.
Replace if required.
6. Feeding material. Always feed material evenly
and smoothly against the direction of rotation.
Never use excessive force when sanding or
serious injury can occur.
7. Disc/Belt Rotation. Be aware of the Disc and Belt
rotation when sanding.
8. Job Material. Check material prior to sanding for
nails, staple and other objects that make cause
any danger when sanding.
9. Hand Hazard. Keep hands and fingers clear from
moving parts. Serious injury can occur.
10. Starting position/speed. Never turn the grinder
on when the workpiece is resting on the disc or
belt. Allow disc and belt to reach full speed
before sanding.
11. Leaving a grinder Unattended. Always turn the
grinder off and make sure all moving parts have
come to a complete stop before leaving the
grinder. Do not leave grinder running
unattended for any reason.
12. Disc sanding. Keep workpiece down toward the
table whilst sanding. Workpiece may cause
serious injury if not held correctly.
13. Avoiding Entanglement. Grinder guards must
always be used. Remove loose clothing, belts, or
jewellery items. Never wear gloves while
machine is in operation. Tie up long hair and use
the correct hair nets to avoid any entanglement
with the grinder moving parts.
14. Guards. Do not operate grinder without the
correct guards in place, If applicable.
15. Understand the machines controls. Make sure
you understand the use and operation of all
controls.
16. Stopping the Disc/Belt. Do not stop or slow the
Disc or Belt with your hand or workpiece. Allow
the machine to stop on its own.
17. Power outage. In the event of a power failure
during use of the Linisher, turn off all switches
to avoid possible sudden start up once power is
restored.
18. Wood dust may cause allergic reactions. Make
sure you know what type of dust you are
exposed to as it may cause you an allergic
reaction. Always wear an approved respirator.
19. Work area hazards. Keep the area around the
grinder clean from oil, tools, chips. Pay attention
to other persons in the area and know what is
going on around the area to ensure unintended
accidents.
20. Call for help. If at any time you experience
difficulties, stop the machine and call you
nearest branch service department for help.
21. Workpiece Handling. Never hold small
workpieces with your fingers during a cut.
Always support/feed the workpiece with push
stick, table support, vice, or some sort of
clamping fixture.

20
Plant Risk Assessment
NEW MACHINERY HAZARD IDENTIFICATION, ASSESSMENT & CONTROL
Belt Grinder / Disk grinder
This program is based upon the Safe Work Australia, Code of Practice - Managing Risks of Plant in the Workplace (WHSA 2011 No10)
Item
Number
Hazard Identification
Hazard
assessment
Risk Control Strategies
(Recommended for Purchase / Buyer / User
A
Entanglement
High
Eliminate, avoid loose clothing / Long hair etc.
C
D
Cutting, Stabbing,
Puncturing, Shearing
Medium
Medium
Isolate power to machine prior to any checks or maintenance being carried out
Do not adjust or clean machine until the machine has fully stopped.
Always keep gap between table and disc to a minimum.
Make sure all guard are secured shut when machine is on.
E
Friction
Medium
Keep hands and body clear from sanding disc/belt.
F
Striking
Medium
Wear appropriate protective clothing.
Wear safety glasses.
Stand clear of moving parts on machine.
Remove all loose objects around moving parts.
Ensure belts are in good condition and at correct tension.
Always sand on the down stroke of the disc's rotation.
H
Electrical
Medium
All electrical enclosures should only be opened with a tool that is not to be kept with the
machine.
O
Other Hazards,
Noise, Dust
Low
Wear hearing protection as required.
Should be connected to a dust extraction.
Respirator or PAPR system to be used.
Plant Safety Program to be read in conjunction with manufactures instructions
