MODEL 110
RADIO COMMUNICATION SYSTEM
INSTALLATION & OPERATION MANUAL

TABLE OF CONTENTS
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
System Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CA Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Headset Module Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Foot Switch (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Radio Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Options and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Appendix A-Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Appendix B-RJ-12 Connector Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1

2
OVERVIEW
Firecom’s 110 radio interface is designed for use in rugged, demanding environments. When used with Firecom
noise attenuating headsets, the system provides protection from hearing loss that occurs from exposure to high
noise levels while offering a 2-way radio communication interface. The 110 radio interface is a durable solution
for vehicles and other high-noise environments requiring radio communications.
When properly installed, the user will hear radio traffic and transmit over the radio when the Push-To-Talk (PTT)
button is activated.

Modular Jack
The modular jack is the connection point for the CA cable leading from the 110 radio interface to the headset
module.
Radio Interface Jack
The 9-pin D-Sub connector is an attachment point for the included mobile radio (MR) interface cable.
Power Connector
The 3-pin connector is the attachment point for vehicle power. A power connection cable is provided.
Receive Audio Adjust
A rotational adjustment for setting the level of audio received to the intercom from a mobile radio.
Transmit Audio Gain Jump/Intercom Audio Gain Jump
Two dip switches are provided for incremental gain increases of both the radio transmit audio and the
intercom audio.
Transmit Audio Adjust
A rotational adjustment for setting the level of audio transmitted to an appropriate level for a mobile radio.
3
HEADSET
FEATURES
RADIO POWER
Rx T/G Tx
Modular Jack
Radio Interface Jack
Power Connector
Receive Audio Adjust Transmit Audio Adjust
Transmit Audio Gain Jump
Intercom Audio Gain Jump
Front View
Back View
Side View

4
INSTALLATION
Mounting the Radio Interface Unit
Mount the interface unit to a flat surface by drilling four mounting holes and installing the enclosed #6 fasteners.
Mounting hole and intercom dimensions are shown below. The unit is designed for vehicle interiors and indoor
use. Do not mount outdoors.
Assembly Shown without Jacks
Units: Inches [millimeters]
Scale: None

5
SYSTEM WIRING
Overview
Once the radio interface unit is installed, the system is ready for wiring. A headset module can be connected to
the headset port using a RJ-12 connector and CA cable as shown in the figure below. See “CA Cable Routing”
in the Installation section of this manual before wiring. The 2-way radio is added using the 9-pin D-Sub connector.

6
SYSTEM WIRING
Power Connections
Power is wired to the unit using the power supply cable with in-line fuse (included). When routing the power
cable, the in-line fuse should be easy to access.
Warning
Before making power connections, make sure the power source is turned off.
Important
Use a dedicated ground for the (-) power connection. Do not ground to the chassis.
Important
We recommend connecting the intercom power to the same power busses as the 2-way radio.
CA Cable Routing
There are several important considerations when routing the CA cable:
• Do not bundle extra cable. The cable should be cut to length at installation, especially when radios
are used.
• Route CA cables away from hot surfaces including vehicle exhaust systems.
• When routing CA cables through bulkheads or other sheet metal, use a grommet in the hole to
prevent damage to the cable.
Headset Module Installation
The following steps are recommended for installing a HM-10 or PP-20 headset module.
• Identify where the headset module is to be mounted and use the module as a template to locate the
two mounting holes as shown in figure above. Drill two holes for the #6 hardware provided.
• If you are installing a PP-20 module, route the CA cable as outlined in “CA Cable Routing” on this
page and install an RJ-12 connector at the intercom end of the cable as outlined in Appendix B “RJ-12
Connector Assembly.”Always make sure the printed side of the cable is facing the release tab
on the RJ-12 modular plug. If you are installing an HM-10 module, continue with the following steps.
HM-10 PP-20

7
SYSTEM WIRING
Headset Module Installation
• With the CA cable routed from the intercom, cut the cable to length at the headset module and slide
the bend relief grommet over the end of the CA cable as shown in the figure above.
• Attach a RJ-12 connector to the end of the cable –see Appendix B “RJ-12 Connector Assembly.”
Always make sure the printed side of the cable is facing the release tab on the RJ-12
modular plug.
• Open the headset module assembly by removing the screws labeled “A” in the figure on page 6.
Install the plug and bend relief grommet as shown in the figure above. If the CA cable is going
from the intercom to the headset module it MUST be inserted on the same side of the
HM-10 as the “Firecom” label. Replace the headset module cover and mount the assembly with
the hardware provided.
Foot Switch (optional)
A radio Push-to-Talk (PTT) foot switch option is available from Firecom when a headset radio PTT is not desired.
Depressing the foot switch will initiate radio transmissions of the headset plugged into the headset module
where the foot switch is installed.
The foot switch is installed to the headset module using a CA cable and RJ-12 connector. You will need to open
the headset module and remove the plastic tab which covers the access hole to the second modular jack.
Warning
The CA cable from the intercom should always be plugged into the headset module on the
“Firecom” label side.

8
SYSTEM WIRING
SETTINGS
Side View
Rx T/G Tx
Radio Connections
The mobile radio is connected to the intercom by using the radio port on the back of the unit. A MR interface
cable, with an un-terminated end, is supplied with the intercom. For independent wire descriptions, see
Appendix A.
Warning
To ensure proper operation, the connection to the radio should be performed by a qualified
radio technician.
Some radio specific interface cables are available for common model radios. For a list of interface cables, please
visit www.firecom.com and click on the Product Support section of our web site or contact our service department
at 800-527-0555.
When installing an MR cable, tighten the two screws on the plug of the cable.
Warning
If the screws are not properly tightened, the 9-pin plug may vibrate and cause problems with
transmission, reception, or other radio functionality.
Receive Audio Adjust Transmit Audio Adjust
Transmit Audio Gain Jump Intercom Audio Gain Jump
Several adjustments to the 110 Radio Interface are required. When connecting to the mobile radio, it will be
necessary to make both transmit and receive audio adjustments.
Warning
These adjustments must be performed by a qualified radio technician. Failure to perform
these adjustments may result in problems hearing or transmitting radio signals when using
the intercom system.

9
SETTINGS
RX
The receive audio adjustment is a rotational adjustment of the audio gain from the radio. When making this
adjustment, set your mobile radio volume to the normal volume level used without the 110 interface installed.
The audio level should be adjusted with the headset user for quality audio mixing.
Transmit Audio Gain Jump
The transmit audio gain jump switch is an incremental gain increase of the audio broadcast through the radio.
The gain is increased when the switch is in the “up” position and decreased in the “down” position. The transmit
audio “TX” should be used initially for adjustment and the transmit audio gain jump used only if required.
Headset Audio Gain Jump
The headset audio gain jump switch is an incremental gain increase of the headset sound level. The headset
is also equipped with an independent volume control. If an overall higher headset sound level is desired, the
headset audio gain jump switch may be used. The gain is increased when the switch is in the “up” position
and decreased in the “down” position.
TX
The transmit audio adjustment is a rotational adjustment of the audio broadcast through the radio. Adjust the
radio transmit sound level to eliminate clipping and provide quality audio mixing.
After these adjustments are made, the holes may be sealed using plugs (provided).
OPERATION
The 110 radio interface is designed to offer clear communications to a mobile radio using a noise-canceling
headset.
Before testing the unit, make sure the power supplied to the unit and the radio is turned on. To begin using the
radio interface, plug your Firecom headset into the headset module. For proper headset fitting instructions, as
well as care and maintenance, see your headset manual.
Firecom offers both over-the-head and under-the-helmet styles of headsets for use with the 110 radio interface.
These radio transmit headsets are identified by a red momentary PTT button on the headset. To transmit out the
radio, press and hold the red PTT button. You will hear your voice in the headset only when you transmit. You
will always hear radio traffic on your headset. Volume is adjusted on the ear dome.
Foot Switch (optional)
If an optional foot switch is installed, the headset plugged into the headset module will transmit over the radio
when the foot switch is activated. See System Wiring section, “Foot Switch (optional)” in this manual.

10
TROUBLESHOOTING
If the radio interface system does not operate as expected, check the following items:
• Check for power at the unit and confirm that the fuse is not blown or the circuit breaker is not tripped.
• Confirm that a dedicated ground is used for the interface power and not a chassis ground.
• Check for corrosion on headset plug.
• Check that the headset is plugged in all the way.
• Check headset controls.
If these steps do not correct the problem, review the chart below for symptoms and recommendations.
SYMPTOM RECOMMENDED SOLUTION
Intermittent crackling in headset • Check the headset plug. Make sure it is clean for good electrical
speakers contact.
• Check wire connections at the headset module.
• Check wire connections at the radio interface unit.
• Check the CA cable and RJ-12 connectors.
Tip: Determine if the problem is with the headset or the system by
plugging a different headset (if available) into the headset module
and retesting.
Alternator whine and other • Connect both the radio interface and radio to the cleanest power
source distracting noises source possible, without sirens, strobes, flashers, and motors (i.e.
wipers, heater, etc.).
• Check the power and ground connections for both the radio inter-
face and the radio. Make sure they are clean and tight.
• Ensure that power and ground wires for the radio and radio interface
are no smaller than 18 AWG.
• Check MR cable for proper wiring connections.
• Make sure that all battery connections are clean and free from dirt
and corrosion.
• Use separate noise filters on radio and/or radio interface power as
needed.
• Use a robust common ground for both the radio and the radio
interface.
Tip: Check the power to the unit for an AC signal. There should be
less than 300mVAC present on power lines
No sound in headset speakers • Check the volume control on the headset.
• Confirm the radio is operating properly.
• Check the headset plug. Make sure it is clean for the best electrical
contact.
• Confirm that the radio interface has adequate power.
• Check wire connections at the headset module.
• Check the MR cable between the radio and interface unit. Make
sure the screws on the 9-pin D-sub connector are tight. See
Appendix A for wiring.
• Check the CA cable and RJ-12 connector installation.
Tip: Determine if the problem is with the headset or the system by
plugging a different headset (if available) into the headset module
and retesting.

11
TROUBLESHOOTING
The radio transmitted audio is weak • Confirm that you have the headset microphone close to your
or mouth, within 1/8 inch is recommended.
The radio keys but no audio is • Adjust the transmit audio setting –see Settings.
transmitted • Confirm that you have a radio transmit headset with a red PTT
or button.
You can hear the radio, but radio • Check the MR cable between the radio and the interface unit.
users cannot hear you Make sure the screws on the 9-pin D-sub connector are tight.
See Appendix A for wire connection details.
• Check the headset plug. Make sure it is clean for the best electrical
contact.
• Check wire connections at the headset module.
• Check wire connections at the interface unit.
• Check the CA cable and RJ-12 connector installation.
Tip: Determine if the problem is with the headset or the system by
plugging a different headset (if available) into the headset module and
retesting.
Tip: Substituting suspect components in the system may be helpful in
tracking down problems.
Radio receive audio is weak • Check the radio volume.
or • Adjust the receive audio setting. See the Settings section in this
You can’t hear the radio, but radio manual.
users can hear you • Verify that receive audio is present by listening to the radio’s speaker.
• Check the headset volume control setting.
• Check the headset plug. Make sure it is clean for the best electrical
contact.
• Check wire connections at the headset module.
• Check wire connections at the interface unit.
• Check the CA cable and RJ-12 connector installation.
• Check the MR cable between the radio and the interface unit.
Make sure the screws on the 9-pin D-sub connector are tight.
See Appendix A for wire connection details.
Tip: Determine if the problem is with the headset or the system by
plugging a different headset (if available) into the headset module
and retesting.
Tip: Substituting suspect components in the system may be helpful in
tracking down problems.
The radio doesn’t key • Confirm that you have a radio transmit headset with a red PTT
button.
• Check the CA cable and RJ-12 connector installation.
• Check the MR cable between the radio and the interface unit.
Make sure the screws on the 9-pin D-sub connector are tight.
See Appendix A for wire connection details.
Tip: Determine if the problem is with the headset or the system by
plugging a different headset (if available) into the headset module
and retesting.
Tip: Substituting suspect components in the system may be helpful in
tracking down problems.
If a problem persists in a headset or intercom unit, contact Firecom for a Return Merchandise Authorization
(RMA) number. Return the headset or intercom for replacement or repair.
Contact: Firecom Corporation
7340 SW Durham Road
Portland, OR 97224 USA
800-527-0555 OR 503-684-6647

12
OPTIONS AND ACCESSORIES
See www.firecom.com for options and accessories.
SPECIFICATIONS
Dimensions:
L x H x W: 4.16 [106] x 2.75 [70] x 1.29 [33] inches [millimeters]
Weight::
5.9 oz [170 g] (without cables)
Power Requirements:
Minimum: 9.5 VDC @ 83mA
Maximum: 28.0 VDC @120mA
Fuse: 2 amp
See the headset manual for headset specifications.
Appendix A - Wiring Diagrams
5 Conductor Plug HM-10 Headset Module

13
Appendix A - Wiring Diagrams
PP-20
CA Cable
Mobile Radio Interface Cable

14
Appendix B - RJ-12 Connector Assembly
RJ Connector, 6 Position Plug Installation
To install the RJ-12 connector plug onto the flat CA cable:
1. Using the cutter blade on the crimping tool (labeled A, in figure 1), cut the CA
cable so the cut is clean and at a 90-degree angle to the side of the cable.
2. Fully insert one end of the CA cable between the stripping blades (labeled C,
in figure 1) until the end of the cable hits the stop (labeled B, in figure 1).
3. Squeeze the handles of the crimping tool together until the tool bottoms out.
4. While holding the handles together, pull the cable out of the tool.
5. The stripped insulation should expose approximately 3/16” of wire (figure 2).
6. Push a RJ-12 connector into the plug holder on the crimping tool (labeled D,
in figure 1) until the release tab on the plug locks into position.
7. Holding the cable so that the printed side of the cable is toward the release
tab on the plug, push the cable into the plug as far as it will go.
Note: Always make sure the printed side of the cable is facing the release
tab on the RJ-12 connector plug (figure 3). This ensures proper orientation
of the plug on each end of the cable.
8. Squeeze the tool handles completely together. You may feel the crimper
finish punching the contacts through the insulation on the wires.
9. Let the handles spring open.
10.Push down on RJ-12 connector release tab (figure 3) and remove the RJ-12
connector from the crimping tool.
11. Inspect the plug to ensure that the cable is held securely in place.
12. Repeat this procedure as necessary to install a RJ-12 connector plug on each
end of each CA cable.
Figure 1
RJ-12 Connector Plug
Crimping Tool
Figure 2
Stripped
CA Cable
Figure 3
RJ-12 Connector
Plug

15
WARRANTY
Two-Year Limited Warranty to the Original Purchaser
Sonetics Corporation warrants to the original purchaser of its products, that they will be free from defects in
materials and workmanship, under normal and proper use, for the period of two years from date of purchase.
Sonetics Corporation will repair or replace, at its option, any parts showing factory defects during this warranty
period, subject to the following provisions. This warranty applies only to a new product which has been sold
through authorized channels of distribution. All work under warranty must be performed by Sonetics Corporation.
All returned products must be shipped to our address, freight prepaid, accompanied by a dated proof of purchase.
The purchaser voids this warranty if he, she or others attempt to repair, service or alter the product in any way. This
warranty does not apply in the event of accident, abuse, improper installation, unauthorized repair, tampering,
modification, fire, flood, collision, or other damage from external sources, including damage which is caused by
user replaceable parts (leaking batteries, etc.). This warranty does not extend to any other equipment or apparatus
to which this product may be attached or connected. The foregoing is your sole remedy for failure in service or
defects. Sonetics Corporation shall not be liable under this or any implied warranty for incidental or consequential
damages, nor for any installation or removal costs or other service fees. This warranty is in lieu of all other
warranties, express or implied, including the warranty of merchantability or fitness of use, which are hereby
excluded. To the extent that this exclusion is not legally enforceable, the duration of such implied warranties shall
be limited to two years from date of purchase. No suit for breach of express or implied warranty may be brought
after two years from date of purchase.

FIRECOM IS A DIVISION OF SONETICS CORPORATION
17600 SW 65th Ave, Lake Oswego, OR 97035 USA
800-527-0555 • [email protected] • firecom.com
Copyright ©2019 Sonetics Corporation. All rights reserved.
The information in this document is subject to change without notice.
No part of this document may be reproduced in any form
without prior written consent of Sonetics Corporation.
600-0073-00 Rev C
