Firegear DBS-12 User manual

IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
Warning: For Outdoor Use Only
Burning
Spur Only
Description Burning
Spur Kit
Description Input Rating
DBS-12 12-inch Spur Burner DBS-12K 12-inch Spur Burner Kit 50,000 Btu’s
DBS-16 16-inch Spur Burner DBS-16K 16-inch Spur Burner Kit 75,000 Btu’s
DBS-22 22-inch Spur Burner DBS-22K 22-inch Spur Burner Kit 100,000 Btu’s
DBS-31 31-inch Spur Burner DBS-31K 31-inch Spur Burner Kit 175,000 Btu’s
DBS-36 36-inch Spur Burner DBS-36K 36-inch Spur Burner Kit 225,000 Btu’s
Installation and Operating Instructions
Outdoor Fire Pit Burning Spurs & Kits
INSTALLATION PRECAUTION:
This system requires a minimum 18 square inches (per side) of cross ventilation.
Failure to provide proper ventilation will void the warranty.
PN#9077

REV. B Page 2
Burning Spur Kit
Fuels used in gas red appliances, and the products of combustion such as fuels, contain
chemicals known to cause cancer, birth defects and/or other reproductive harm.
This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed area can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
WARNING
Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or other appliance.
An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
WARNING
Do not leave unattended during use.
Do not use for cooking.
Follow all gas leak procedures in this
manual prior to operation.
WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage,
personal injury of loss of life
Read the owner’s information manual
provided with this appliance.
Installation and service must be
performed by a qualied installer,
service agency, or the gas supplier.
WARNING
If the information in this manual is not
followed exactly, a re or explosion
may result causing property damage,
personal injury, or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or other appliances.
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open ame.
3. If odor continues, leave the area
immediately.
4. After leaving the area, call your gas
supplier or re department.
DANGER
FIRE OR EXPLOSION
HAZARD

REV. B Page 3
Burning Spur Kit
Specications 4
Preparation for Non-Combustible Structure 5
Hard Piping to Fire Pit 5
High Elevation 5
Cross Ventilation Requirements 5
Pipe Sizing Chart 6
Installation into an Approved Enclosure 7
Burning Spur Information 7
Burning Spur Assembly 8
Installing Key Valve 8
Typical Installation Drawings 9
Operation 10
Lighting Instructions 10
Replacement Parts 11
Replacement Parts List 12
Burning Spur Contents 13
Converting to Liquid Propane (LP) Gas 14
Fire Pit Maintenance/ Trouble Shooting 15
Optional Accessories 16
TABLE OF CONTENTS
All media (i.e. lava rock, lava stones, lava boulders and fire glass) has the potential of
thermal spalling. This is a process that may occur when media is wet and moisture gets
trapped inside of the material due to rapid temperature differences. When this happens
the media has the potential to crack or “pop” outside the fire feature.
WE HIGHLY RECOMMEND COVERING ALL FIRE FEATURES WHEN NOT IN USE
The use of a cover can lessen the impact of thermal spalling; however, heavy rains, high
humidity and the presence of moisture may still cause the media to pop.
ALWAYS USE CAUTION WHEN USING THE FIRE FEATURE
Extra caution should be taken when lighting a fire feature when heavy rains, high humidity
and moisture are present. Light the fire feature; leave the area allowing any moisture in
the media to dissipate. We strongly recommend that during this drying out time that you
monitor the fire feature from a distance. This drying out period should be no less than 30
minutes. Continue monitoring the flame from distance to ensure that all popping has
ceased before fully enjoying the fire.
CAUTION
CALIFORNIA PROPOSITION 65
WARNING
This product can expose you to Chromium, which is
known to the state of California to cause cancer
and birth defects or other reproductive harm.
(For more information, go to www.p65warnings.ca.gov)

REV. B Page 4
Burning Spur Kit
SPECIFICATIONS
Table 1 Installation specications
Fig. 1 Burning Spur Dimensions; refer to Table 1.
Models: Orice NG Btu’s Orice LP
DBS-12/ DBS-12K OAS-NG34 50,000
(14.65kW)
OAS-LP47
DBS-16/ DBS-16K OAS-NG29 75,000
(21.98kW)
OAS-LP41
DBS-22/ DBS-22K OAS-NG22 100,000
(29.31kW)
OAS-LP35
DBS-31/ DBS-31K OAS-NG05 175,000
(51.29kW)
OAS-LP26
DBS-36/ DBS-36K OAS-NG01 225,000
(65.94kW)
OAS-LP19
Table 2 Btu Specications
Burner ModelS
Spur Burner Only/ Spur Burner Kit Pan/Disc
Depth
A
Outer
Diameter
Min. Inside
Opening
Dimension
B
Combustible
Side Wall
C
Combustible
Ceiling
D
Combustible
Floor
DBS-12/ DBS-12K 2 ½” - 3” 12” 15” 36” 96” 18”
DBS-16/ DBS-16K 2 ½” - 3” 16” 19” 36” 96” 18”
DBS22/ DBS-22K 2 ½” - 3” 22” 25” 36” 96” 18”
DBS-31/ DBS-31K 2 ½” - 3” 31” 34” 36” 120” 18”
DBS-36/ DBS-36K 2 ½” - 3” 36” 39” 36” 120” 18”
Disclaimer: Btu listings are based on 7.0”WC for Natural Gas
and 11.0”WC for Liquid Propane (LP) at the burner orice. Flex
line size and proper gas pipe sizing will also affect Btu’s. As a
result your Btu’s may vary slightly from Table 2 specications.
Fig. 2 Clearance to Combustibles
(Not to be used in an enclosed space)
BEFORE INSTALLING A BURNING SPUR DETERMINE WHAT PAN WILL BE USED:
The Spur Burner models above are not provided with pans for installation. We suggest you provide an appropriate non-
combustible burner pan to install the Burning Spur. Burner pans sizes listed in Table 1 are suggested sizes based on the
burning spur model size. The pans can be round, square or a at metal. NOTE: It is recommended to use 304
Stainless Steel. Burner pans should have ¼” drainage holes to prevent standing water in pan and the center hole for the
burner nipple should be ⅞” in diameter. A recommended material thickness for any burner pan or disc is 16 gauge. Once
the Burning Spur is installed into a burner pan then proceed with this manual to complete the installation.
CAUTION: DO NOT use stiff screen or perforated metal as a burner pan. Some gases are heavier than air and
screen or perforated metal can enable the gas to ow down inside an enclosure which could cause delayed
ignitions or explosions.
A
C
B
D
C
L
24”
Max
Overhang
(Center Line)
Description: Spur Burners are provided with a burner and Natural gas (NG) orice only (i.e. DBS-12) and Spur Burner
Kits are provided with Spur Burner, Natural gas (NG) orice, key valve assembly and ex line (i.e. DBS-12K).
Note: An LP conversion kit must be ordered seperate.
Pressure NG LP
Min. Inlet 5.0” WC (1.24 kPa) 10.5” WC (2.61kPa)
Max. Inlet 10.5” WC (2.61kPa) 13.0” WC (3.23kPa)
Normal Inlet 7.0” WC (1.74kPa) 11.0” WC (2.73kPa)
Table 3 Gas Pressures

REV. B Page 5
Burning Spur Kit
PREPARING A NON-COMBUSTIBLE STRUCTURE
The re pit can be installed on a at, stable surface, away from any combustible materials. Install Fire pit on any level,
outdoor non-combustible, at stable surface or a combustible oor according to the clearances specied in this manual.
NOTE: Do not place re pit directly on grass, dirt, or rocks this may prevent proper ventilation. Ensure proper water
drainage is also incorporated into the re pit enclosure.
HARD PIPING TO FIRE PIT WITHOUT GAS PROXIMITY
NOTE: Refer to the NFPA54 (National Fuel Gas Code) for proper pipe sizing. See gas line sizing chart on page 6 as a
reference.
1. Turn OFF gas supply system. NOTE: All gas connections (except for brass to brass) require the following. Clean pipe
threads using either a wire brush or steel wool. Apply pipe sealant to the ttings before making any connection.
2. Ensure all gas connections are snug, but do not over tighten! BE CAREFUL!
3. Install necessary pipe for the distance required and a manual shut-off valve at the exterior house wall. Check with
local codes for proper procedures. If pipe is to pass through a foundation or house wall, make sure to seal the area
around the pipe with weather sealant. Consult a plumber for proper installation to ensure you are providing adequate
gas supply for your application.
4. The primary gas shut-off (not supplied) will require a ½” male ared tting to enable connection of the stainless steel
ex gas line supplied with the re pit (see Fig. 5 page 9).
5. Do not place an LP tank inside any re pit enclosure. Locate all Liquid Propane (LP) tanks outside the enclosure.
6. To prevent performance problems with LP gas re pits, do not use a LP tank less than 100lbs. capacity.
IMPORTANT
Installation of Natural or LP gas should be done by a qualied installer, service agency or gas supplier.
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures equal to or less than ½” psi (3.5kPa)
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE
Fire pits are subjected to many outdoor elements such as rain,
snow, wind, heat or cold. A minimum of 18 square inches
(opposite sides) of cross ventilation is required to keep the
components in good working order. Use gure 3 as guide to
assist to incorporate proper ventilation.
Fire Pit
Enclousure
(2) 6”x12”
Fire Pit
Examples of Cross Ventilation
3 - 2”x3” Slots Per Side or
2- 1” x 9” Slots Per Side or
2- Firegear 6 x12 vents
Cross Flow Ventilation
(Min. 18 Sq. In. Per Side)
Fig. 3 Cross Ventilation Example
HIGH ELEVATION INSTALLATION
This appliance is listed for elevations from 0- 4500 feet in Canada
and the U.S. If elevation exceeds 4500 feet it may be necessary
to decrease the input rating by changing the existing burner orice
to a smaller size. Input should be reduced 4% for each 1000 feet
beyond the 4500 feet above sea level. Check with your local gas
utility for assistance in determining the proper orice in your
location. In some cases the heating value may already be
reduced and downsizing the orice may not be necessary.
WARNING: Proper clearances from combustible materials must be maintained from all sides, top and bottom of this
appliance. Use the specications listed on this page for proper clearance to combustibles (See Table 1 and Fig. 2).

REV. B Page 6
Burning Spur Kit
REFERENCE
GAS PIPE SIZING
Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4”
10 275 567 1071 2205 3307 6221 10140 17990 35710
20 189 393 732 1496 2299 4331 7046 12510 25520
30 152 315 590 1212 1858 3465 5695 10110 20620
40 129 267 504 1039 1559 2992 4778 8481 17300
50 114 237 448 913 1417 2646 4343 7708 15730
60 103 217 409 834 1275 2394 3908 6936 14150
70 89 185 346 724 1086 2047 3329 5908 12050
80 78 162 307 630 976 1811 2991 5309 10830
90 69 146 275 567 866 1606 2654 4711 9613
100 63 132 252 511 787 1496 2412 4281 8736
125 54 112 209 439 665 1282 2083 3618 7382
150 48 100 185 390 590 1138 1808 3210 6549
175 43 90 168 353 534 1030 1637 2905 5927
200 40 83 155 325 491 947 1505 2671 5450
300 37 77 144 303 458 887 1404 2492 5084
NATURAL GAS : PIPE SIZING CHART
•Natural Gas (NG) flow is given in
thousands of BTU/hr. = 1cubic
foot of NG gas - 1000 BTU
•Nominal pressure at the burner
for Natural Gas is 3.5” of water
column. (Typical machine supply
5”-7”)
•Pipe length must include
additional length for all fittings.
Add approximately 5 feet of pipe
per fitting.
•Natural Gas Example: A machine
with a burner that requires
440,000 BTU would need a 1 -1/4”
pipe for a 20” long run.
LIQUID PROPANE : PIPE SIZING CHART
NOTE: The sizing charts above list the specific pipe sizes required for the amount of BTU’s for a new gas line installations. If you
are using an existing gas line you must take into consideration the existing gas line capacities to ensure you will have proper
pressure. This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel
Gas Code - current edition) for more details.
Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4”
10 108 230 387 793 1237 2259 3640 6434 -
20 75 160 280 569 877 1610 2613 5236 9521
30 61 129 224 471 719 1335 2165 4107 7859
40 52 110 196 401 635 1143 1867 3258 6795
50 46 98 177 364 560 1041 1680 2936 6142
60 42 89 159 336 513 957 1559 2684 5647
70 38 82 149 317 476 896 1447 2492 5250
80 36 76 140 239 443 840 1353 2315 4900
90 33 71 133 275 420 793 1288 2203 4667
100 32 68 126 266 411 775 1246 2128 4518
125 28 60 117 243 369 700 1143 1904 4065
150 25 54 105 215 327 625 1008 1689 3645
175 23 50 93 196 303 583 993 1554 3370
200 22 47 84 182 280 541 877 1437 3160
300 17 37 70 145 224 439 686 1139 2539
•Liquid Propane (LP) Gas flow is
given in thousands of BTU/hr. =
1cubic foot of LP gas - 2500 BTU.
•This chart refers to low pressure LP,
after regulation, Standard nominal
pressure at the burner for Liquid
Propane Gas is 11” of water column.
•Pipe length must include additional
length for all fittings. Add
approximately 5 feet of pipe per
fitting.
•LP Example: A machine with a
burner that requires 440,000 BTU
would need a 1” pipefor a 20’ long
run.
GAS PIPE SIZING CHART
Table 4 Gas Pipe Sizing Chart

REV. B Page 7
Burning Spur Kit
REQUIREMENTS
1. Only non-combustible materials should come in direct contact with any part of the re pit. Underneath area should
be non-combustible or a at level combustible surface according to the clearances specied in this manual.
2. Refer to the NFPA54 (National Fuel Gas Code) for proper pipe sizing. Determine the size of the re pit you are
preparing to install (Refer to page 6).
3. Determine the size of the round or square re pit you are preparing to install (Refer to page 4).
4. You must provide a round or square opening to place the re pit into the non-combustible enclosure. A
minimum burner pan dimension is listed in Table 1.
5. Follow the local code requirements for the gas type being used. This re pit should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fire pits create high temperatures, it is very important to have any combustibles at a safe distance.
7. Do not ll the enclosure cavity with gravel, rock or sand. The enclosure requires free owing air underneath to
keep it cool and provide ventilation to prevent moisture, and additional provided an outlet for gas to escape if a leak
occurs.
8. CAUTION: A minimum of 18 square inches of cross ventilation (per opposite sides) is required to keep the
enclosure dry.
9. These products are designed for outdoor use only. Not approved for any indoor use or any enclosed space.
10. This re pit is designed to have Firegear Outdoors lava rock or glass media completely covering the burner tube,
so that the burner is not visible. Do not cover more than 1” above the top of burner. Use lava rock a minimum of 1”
diameter as a base to ll the burner pan. DO NOT USE STONE OR RIVER ROCK.
11. Gas lines and ttings must be installed in to the non-combustible structure. All gas connections must be leak tested
before installation of the re pit. Soapy water leak detection is required before regular use of the re pit.
12. Do not use material that will absorb moisture over time and will not release this moisture quickly. Moisture can boil in
this material and can rapidly break apart and cause damage or personal injury.
13. Never leave any combustible material on top of the re pit. This could cause unsafe operation of this system
and damage to the component that will not be covered under our warranty.
14. Ensure proper water drainage is also incorporated into the re pit enclosure.
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE
BURNING SPUR INFORMATION
All Burning Spurs come ready to install and have a ½” male center nipple. The Burning spur must be installed as shown in
Fig. 4 with center nipple facing downward. Ensure to seal each NPT tting with thread tape or pipe compound.
NOTE: Flared ttings do not require tape or compound.
Burning Spur Kit: Included Burning Spur, orice, ared tting, manual key valve with 12-inch key and 46” ex connector.

REV. B Page 8
Burning Spur Kit
INSTALLING KEY VALVE
The key valve contents: 1- key valve, 1- key and 1- ange. (See Fig. 6). The valve requires a 1¼” round clearance hole
in the non-combustible enclosure wall. See the instructions supplied with the key valve for more specic details.
Note: Be sure to leak test all tting before operation. Fig. 7 shows an example of a typical installation on page 8.
Primary Gas
Supply
ON
OFF
Fig. 6 Key valve components.
Note: It is recommended to use the key valve assembly provided in the Burning Spur kit. Otherwise, you will need to
provide a key valve for the installation.
GAS FLOW
Burner Pan OAS#
U3-8D-S
BURNING SPUR ASSEMBLY
Fig. 5. Natural Gas Burning Spur parts
Minimum 7/8” Center Hole
The burner panfor the Burning Spur needs a center hole a minimum of ⅞ -inch in diameter. We strongly recommend
using a pan for any Propane or LP Gas installations. Once the Burning Spur is placed into the center hole of your re pit
pan then install the orice (OAS) and tting (U3-8D-S) as shown in Fig. 5. Note: Use Teon tape or compound rated for
gas to seal the threads.
Fig. 4 Installing burning spur into pan.

REV. B Page 9
Burning Spur Kit
Key Valve Flange
Non-
Combustible
Wall Material
Non-
Combustible
Wall Material
Key Valve
Primary Gas
Supply
K
e
y
V
a
l
v
e
S
i
d
e
V
i
e
w
D
e
t
a
i
l
Fig. 7 Typical installation.
NOTE: Key valve and exible gas lines are
supplied. Gas shut-off is not supplied.
Note: A 1¼” x 2” black iron or galvanized
coupler/nipple (not supplied) can be used
as a spacer between the manual valve
and the valve ange to add additional
support to hold the manual key valve in
place.
Key Valve Flange
Non-
Combustible
Wall Material
Non-
Combustible
Wall Material
Key Valve
Black Iron
Nipple
TYPICAL INSTALLATION DRAWINGS
Key Valve
Gas Supply
Fire Pit Pan
Non-Combustible
Fire Pit Enclousure
Shut-O
Spur Burner

REV. B Page 10
Burning Spur Kit
CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the re pit unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or Propane gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
Key
Fig. 9 Inserting Key into Valve
ON
OFF
Fig. 8 Key Valve Face
Butane Lighter
Fig. 10 Lighting re pit with lighter
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE
ATTEMPTING TO LIGHT FIRE PIT
CAUTION: Ensure you have leak tested the re pit before operating.
TURNING ON FIRE PIT
1. Insert key into shut-off valve and secure into square end (See Figs. 8 & 9).
2. Light a long match or butane lighter and hold it near the burner (See Fig. 10).
3. Turn the key slowly counter-clockwise in key valve (ON position) to allow gas to ow
and simultaneously apply the long burning match or Butane lighter as close to the end
burner as possible to light the re pit.
4. Gas should ignite within 10 seconds or less. If re pit does not light within 10 seconds
turn key clockwise to turn OFF the gas supply. Ensure there is not too much media on
top of the burner that might inhibit gas ow and try again in 5 minutes.
TURNING OFF FIRE PIT
1. Insert key into shut-off valve and secure into square end.
2. Turn key clockwise until it stops.
3. After cooling off install cover.

REV. B Page 11
Burning Spur Kit
REPLACEMENT PARTS
1
2
5
4
Drawings not to scale.
89
3
ON
OFF
6
7

REV. B Page 12
Burning Spur Kit
1DBS-12/ DBS-12K (Burner only) 1 B-SPUR12
1DBS-16/ DBS-16K (Burner only) 1 B-SPUR16
1DBS-22/ DBS-22K (Burner only) 1 B-SPUR22
1DBS-31/ DBS-31K (Burner only) 1 B-SPUR31
1DBS-36/ DBS-36K (Burner only) 1 B-SPUR36
2OAS# (Orice air shutter) for Natural Gas Gas Fire Pits 1Refer to page 4 of
manual for specic
orice sizes/model
numbers.
3OAS# (Orice air shutter) for LP Gas Fire Pits 1Refer to page 4 of
manual for specic
orice sizes/model
numbers.
41/2” Flex Gas Line (46-inch Length) (used with all kits) 1 T200-9898-46
5 Key Valve 1 BVL2S
6 Chrome Plated Flange Cover CVR-BVL2CP
7 12-inch Chrome Key (used with all key valves) 1 KEY-PC-12
8 ½” Flare to ½” MIP Fitting (used with all DBS & DBS Kits) 1 U1-8D-S
9 ½” Flare to ½” FIP Fitting (used with all DBS & DBS Kits) 1 U3-8D-S
Item Description Qty. Part Number
BURNING SPUR REPLACEMENT PARTS

REV. B Page 13
Burning Spur Kit
GAS FLOW
B-Spur
OAS#
U3-8D-S
Burning Spur Only Contents
Models
DBS-12
DBS-16
DBS-22
DBS-31
DBS-36
GAS FLOW
12-inch Key
T200-9898-46
Key Valve
U1-8D-S
B-Spur
Flange
OAS#
U3-8D-S
Burning Spur Kit Contents
Models
DBS-12K
DBS-16K
DBS-22K
DBS-31K
DBS-36K

REV. B Page 14
Burning Spur Kit
CONVERTING BURNING SPUR TO LP GAS
Fig. 1 LP conversion illustration.
Fig. 2 Optional LP conversion illustration.
GAS FLOW
Burner Pan
OAS#
U3-8D-S
½” Brass
Coupler #99-8
½” x 5-inch Black
Iron Nipple
#113BS-D5
Burner Pan ½” Brass
Coupler #99-8
½” x 5-inch Black
Iron Nipple
#113BS-D5
½” OAS-LP Orice
½” Flared Fitting
#U3-8D-S
GAS FLOW
CAUTION: Ensure there is ventilation under the burner to
provide fresh air for air shutter.
Converstion Kit Common Parts Btu Ratings LP Orice Models
OAS-LPK47 S499-8; 113-SS4-D5;
U3-8D-S
50,000
(14.65kW)
OAS-LP47 DBS-12
DBS-12K
OAS-LPK41 S499-8; 113-SS4-D5;
U3-8D-S
75,000
(21.98kW)
OAS-LP41 DBS-16
DBS-16K
OAS-LPK35 S499-8; 113-SS4-D5;
U3-8D-S
100,000
(29.30kW)
OAS-LP35 DBS-22
DBS-22K
OAS-LPK26 S499-8; 113-SS4-D5;
U3-8D-S
175,000
(51.28kW)
OAS-LP26 DBS-31
DBS-31K
OAS-LPK19 S499-8; 113-SS4-D5;
U3-8D-S
225,000
(65.94kW)
OAS-LP19 DBS-36
DBS-36K
When converting Burners to LP gas the main burner orice must be kept a minimum of 6-inches away from the burner
connection (nipple) to prevent any back pressure at the LP orice. See Fig. 1 below for details. Note: It is acceptable to
install a 90° elbow, if necessary, to run the gas line the opposite direction (see Fig 2 or 3). A 90° elbow or close nipple are
not provided with the kit.
All NPT pipe threads must be sealed with approved gas Teon tape or pipe compound.
Check for any gas leaks before presuming normal operation after conversion is complete.
CAUTION: Ensure there is ventilation under the burner to provide fresh air for air shutter/orice.
Table 5 LP conversion chart.
Burner Pan
½” x 5-inch Nipple
(113-SS4-D5)
½” OAS-LP Orifice
½” Flared Fitting
(U3-8D-S)
½” x ½” Coupling
(S499-8)
GAS FLOW
½” 90º Elbow
(not supplied)
½” Close Nipple
(not supplied)
Fig. 3 Optional LP conversion illustration.

REV. B Page 15
Burning Spur Kit
FIRE PIT MAINTENANCE
1. The re pit should be inspected and cleaned before initial use at least annually by a qualied eld service person.
2. Any component that is found faulty must be replaced with an approved component.
3. Any tampering or modifying with the re pit is dangerous and voids all warranties.
4. During winter months in cold climates and various seasons operation the re pit may be affected by weather
conditions. It is recommended to use a ventilated cover overtop of your re pit to protect it from humid/rainy weather
conditions when not in use. Heavy rains/downpours could affect the re pit operation if not covered; if this occurs
ensure you allow the re pit time to dry out before attempting to operate. NOTE: If a combustible type cover is used
over the re pit when not in use be sure to remove it before operation to prevent a severe safety hazard.
5. Over time stainless steel parts can discolor when heated, usually a golden or brown hue. This discoloration is normal
and does not affect the performance of the appliance.
TROUBLE SHOOTING
Symptom Remedy
Fire pit won’t light 1. Bleed gas line.
2. Ensure all gas supply lines are turned ON.
3. Ensure there is not too much media overtop of burner; it can inhibit gas from owing.
4. Check gas pressure.
Low ame 1. Ensure the base media is at least 1-inch in diameter and top media is no more than 1-inch over
top of burner.
2. Ensure all shut-off valves and key valve is fully open. See page 7; gure 6
3. Check gas pressure.
Water in my re pit 1. Excess dust/sand material from media may be blocking the weep holes to relieve water.
Remove all media and unplug weep holes. Clean or install new media free of dust and dirt.
2. Ensure re pit enclosure has proper drainage for water and proper ventilation to dry out.

REV. B Page 16
Burning Spur Kit
Round Flat Disc
Model: Fits Spur Model
PAN-SS26D DBS-16K
PAN-SS29D DBS-22K
PAN-SS34D DBS-31K
PAN-SS44D DBS-36K
Square Pans
Model: Fits Spur
PAN-SS20S DBS-16K
Round Pans
Model: Fits Spur Model
PAN-SS16R DBS-12K
PAN-SS19R DBS-16K
PAN-SS25R DBS-22K
PAN-SS29R2 DBS-31K
PAN-SS33R2 DBS-36K
Square Flat Disc
Model: Fits Spur Model
PAN-SS25SF DBS-16K
PAN-SS25SF DBS-22K
PAN-SS30SF DBS-22K
PAN-SS34SF DBS-31K
PAN-SS40SF DBS-36K
PAN-SS46SF DBS-36K
Manual Spark Ignition
Model: MSI-BSMTI
Piezo ignitor system for use with
Firegear Outdoors pans only. Not for
use with custom built pans.
Round Lids/Covers
Model: Fits Pan
LID-16R PAN-SS16R
LID-19R PAN-SS19R
LID-25R PAN-SS25R
LID-29R2* PAN-SS29R
LID-33R2* PAN-SS33R
* Lids not recommended for at discs
Square Lids/Covers
Model: Fits Pan
LID-20S PAN-SS20S
LID-26S PAN-SS26S
LID-32S PAN-SS32S
LID-38S PAN-SS38S
* Lids not recommended for square
ats
Lava Stones
Model: FG-LS50 - 50lb.bag; 1” to 2”
diameter
Lava Rock
Model: FG-LAVA10 (10lb bag.)
FG-LAVA50 (50lb bag.)
1” to 2” diameter
Fireglass/Liquid Glass/
Reective Glass
Sold in 5lb bags in various colors.
See your Firegear dealer for various
options.
Paver System
Model: PAVER-CP-MT
Paver bracket, key valve & parts for
match throw system
Model: PAVER-CP-MSI
Paver bracket, key valve, battery
paver ignition & parts
Paver Vents
Model: PAVER-VENT-4-LNTS
2 - paver brackets, parts and 2 - 4”
vents. Provides 18 sq. in. of ventilation
Model: PAVER-VENT-6-LNTS
2 - paver brackets, parts and 2 - 6”
vents. Provides 18 sq. in. of ventilation
Model: PAVER-VENT-6X12SS
2 - 6”x12” vents and screws.
Provides 18 sq. in. of ventilation
Flexframe
Universal brackets to support a re pit
disc when using paver or other non-
combustible enclosures.
Models: FLEXFRAME-SS (2-piece)
Models: FLEXFRAME-SS3 (3-piece)
E-STOP
Gas shut-off valve with mechanical
timer and emergency shut-off.
Models:
ESTOP1-OH 1-hour timer
ESTOP2-5H 2.5 hour timer
See Firegear Outdoors catalog for other accessories.
ACCESSORIES
The following accessories are available from your local Firegear Outdoors dealer/distributor.
Manual changes often occur, ensure to check the Firegear Outdoor
website for any recent updates and warranty information.
FOR TECHNICAL SERVICE, CALL:
Firegear Outdoors
17322 Gothard St
Huntington Beach, CA 92647
Web Site: www.regearoutdoors.com
[phone]

REV. B Page 17
Burning Spur Kit
FIREGEAR LIMITED WARRANTY - 2020
Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship
defects that prevent safe and correct operation of the product. The warranty commences from date of sale to
the end user for the following period:
CONSUMER RESIDENTIAL APPLICATIONS –MANUFACTURED AFTER 12/02/2019
BURNER SYSTEMS, BURNERS, COMPONENTS AND ACCESSORIES
• LIFETIME WARRANTY ON CONSTRUCTION AND MANUFACTURER DEFECTS
• LIFETIME WARRANTY - STAINLESS STEEL BURNERS AND PANS
• LIFETIME WARRANTY - BRASS BURNERS
• FIVE (5) YEAR WARRANTY - GAS VALVE, SPARK IGNITER, PILOT ASSEMBLIES
• FIVE (5) YEAR WARRANTY - AWS ELECONITC IGNITION SYSTEMS (24VAC, 30 VDC)
• FIVE (5) YEAR WARRANTY - TFS/TMSI ELECTRONIC COMPONENTS
• FIVE (5) YEAR WARRANTY –MT COMPONENTS (KEY VALVE)
• FIVE (5) YEAR WARRANTY - REFRACTORY GAS LOG SETS
• FIVE (5) YEAR WARRANTY - READY TO FINISH/ANF FIRE PIT ENCLOSURES
• FIVE (5) YEAR WARRANTY –SKYTECH MANUACFTURED OPTIONAL CONTROLS
OUTDOOR FIREPLACE –KALEA BAY
• LIFETIME WARRANTY - CONSTRUCTION AND MANUFACTURER DEFECTS
• LIFETIME WARRANTY - STAINLESS STEEL COMPONENTS
• FIVE (5) YEAR WARRANTY - GAS VALVE, PILOT ASSEMBLY, POWER SUPPLY, CONTROLS
• FIVE (5) YEAR WARRANTY –SKYTECH MANUACFTURED OPTIONAL CONTROLS
SANCTUARY SERIES –GFRC FIRE FEATURES
• THREE (3) YEAR WARRANTY - GFRC STRUCTURE
• REFER TO THE APPROPRIATE BURNER SYSTEM FOR WARRANTY
WARRANTY COVERS MANUFACTURING DEFECTS OR STRUCTURAL FAILURE. SMALL STRESS CRACKS AND SURFACE
CRAZING ARE A NATURAL OCCURRENCE IN GFRC PRODUCTS AND NOT COVERED BY WARRANTY.
READY TO FINISH/ANF ENCLOSURES
• FRAME –LIFETIME WARRANTY ON CONSTRUCTION AND MANUFACTURER DEFECTS
ACCESSORIES
• LIFETIME WARRANTY - CONSTRUCTION AND MANUFACTURER DEFECTS
• LIFETIME WARRANTY - STAINLESS STEEL COMPONENTS (LIDS, STAINLESS STEEL COVERS)
• ONE (1) YEAR WARRANTY –ESTOP1-OH, ESTOP2-5H WINDSHIELDS, HOSES AND REGULATORS

REV. B Page 18
Burning Spur Kit
COMMERCIAL APPLICATIONS –MANUFACTURED AFTER 12/02/2019
BURNER SYSTEMS, BURNERS, COMPONENTS AND ACCESSORIES
• TWO (2) YEAR WARRANTY ON CONSTRUCTION AND MANUFACTURER DEFECTS
• TWO (2) YEAR WARRANTY - STAINLESS STEEL BURNERS AND PANS
• TWO (2) YEAR WARRANTY - BRASS BURNERS
• TWO (2) YEAR WARRANTY - GAS VALVE, SPARK IGNITER, PILOT ASSEMBLIES
• TWO (2) YEAR WARRANTY - AWS ELECONITC IGNITION SYSTEMS (24VAC, 30 VDC)
• TWO (2) YEAR WARRANTY –MT COMPONENTS (KEY VALVE)
• TWO (2) YEAR WARRANTY - REFRACTORY GAS LOG SETS
• FIVE (5) YEAR WARRANTY - READY TO FINISH/ANF FIRE PIT ENCLOSURES
• TWO (2) YEAR WARRANTY –SKYTECH MANUACFTURED OPTIONAL CONTROLS
OUTDOOR FIREPLACE –KALEA BAY
• LIFETIME WARRANTY - CONSTRUCTION AND MANUFACTURER DEFECTS
• LIFETIME WARRANTY - STAINLESS STEEL COMPONENTS
• TWO (2) YEAR WARRANTY - GAS VALVE, PILOT ASSEMBLY, POWER SUPPLY, CONTROLS
• TWO (2) YEAR WARRANTY –SKYTECH MANUACFTURED OPTIONAL CONTROLS
SANCTUARY SERIES –GFRC FIRE FEATURES
• THREE (3) YEAR WARRANTY - GFRC STRUCTURE
• REFER TO THE APPROPRIATE BURNER SYSTEM FOR WARRANTY
WARRANTY COVERS MANUFACTURING DEFECTS OR STRUCTURAL FAILURE. SMALL STRESS CRACKS AND SURFACE
CRAZING ARE A NATURAL OCCURRENCE IN GFRC PRODUCTS AND NOT COVERED BY WARRANTY.
READY TO FINISH/ANF ENCLOSURES
• FRAME –LIFETIME WARRANTY ON CONSTRUCTION AND MANUFACTURER DEFECTS
ACCESSORIES
• LIFETIME WARRANTY - CONSTRUCTION AND MANUFACTURER DEFECTS
• LIFETIME WARRANTY - STAINLESS STEEL COMPONENTS (LIDS, STAINLESS STEEL COVERS)
• ONE (1) YEAR WARRANTY –ESTOP1-OH, ESTOP2-5H WINDSHIELDS, HOSES AND REGULATORS

REV. B Page 19
Burning Spur Kit
The end-user must provide a bill of sale, canceled check, or payment record to verify the purchase date and to
establish the warranty period. This Limited Warranty shall be valid and limited to the original purchaser only.
WARNING Any modification to the product will void the warranty.
This Limited Warranty shall be limited to the repair and/or replacement of parts that have been proven to be
defective under normal use and service. All warranty claims must be made by the OEM/Distributor/Dealer
account on behalf of the end-user. You may contact Technical Support at 800-966-8126.
Our Technical Service Department must confirm all approved defects. If a defect is confirmed and we approve
the claim, we will replace such parts without charge. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
The manufacturer may request defective products returned with an RMA (Return Merchandise Authorization)
issued by Firegear Outdoors for specific products, which is considered to be the nature of the defect and or
warranty claim. Product to be returned should; be packed so as not to incur damages during transportation.
Firegear is not responsible for damages on returned items. RMA is valid for thirty (30) days from the date
issued. The RMA must be clearly marked on the outside of the package.
Please check with your local building code department or governing agency for proper approvals before
purchasing. Firegear Outdoors is not responsible for any violation of local codes.
Travel, diagnostic cost, service labor to repair the defect on warranty parts to and from the factory will be the
responsibility of the owner. We will not be responsible for labor charges and/or damage incurred in
installation, repair, and replacement. Firegear is not responsible for Issues related to gas or electrical
installation.
The Limited Warranty is voided if not assembled, installed, and operated as intended. This Limited Warranty
does not cover any defects due to accident, abuse, misuse, alteration, misapplication, vandalism, improper
installation or improper maintenance or service, removal from the original location, or re-installation into
another location, or failure to perform normal and routine maintenance.
Damage due to severe weather conditions such as hail, hurricanes, earthquakes, tornadoes, discoloration due
to overheating, exposure to chemicals (including chlorine and salt), either directly or in the atmosphere, or
very high humidity, is not covered by this Limited Warranty. Costal, humid and/or salt environments are
subject to manufacturer review. All out-of-box claims must be made within 30 days of purchase and must be
made prior to installation. Any product installed damaged will be considered damaged during installation and
not covered under warranty.
There are no other express warranties except as set forth herein. For consumer applications, any applicable
implied warranties of merchantability and fitness are limited induration to the period of coverage of this
Limited Warranty. Some states do not allow limitation on how long an implied warranty lasts, so this limitation
may not apply to you.
For Commercial Applications, the liability of Firegear Outdoors is limited to the express terms of this warranty.
We expressly disclaim any and all implied warranties, including any warranties of fitness for a particular
purpose or merchantability.

REV. B Page 20
Burning Spur Kit
We are not liable for any special, indirect or consequential damages. Our maximum liability is limited to the
purchase price of the purchased units. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so this limitation or exclusion may not apply to you.
We do not authorize any person or company to assume for it any other obligation or liability in connection
with the sale, installation, use, removal, return, or replacement of its equipment, and or such representation
are binding.
Firegear Outdoors
17322 Gothard Street, Huntington Beach, CA 92647
www.firegearoutdoors.com
Phone: [phone]
Email: [email protected]
