FireScapes 501 Mounting instructions

INSTALLER/CONSUMER SAFETY
INFORMATION
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND USING APPLIANCE
IMPORTANT: Installation and service of
natural gas should be completed by a
qualified installer, service agency or
gas supplier.
WARNING: Lift unit from underside of
frame only. Lifting from decorative stone
caps may cause damage.
WARNING: If the information in
this manual is not followed exactly,
a fire or explosion may result
causing property damage, personal
injury or loss of life.
FOR YOUR SAFETY
•Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other
appliance.
FOR YOUR SAFETY
--------IF YOU SMELL GAS:
•Do not touch any electrical switches.
•Do not try to light any appliance.
Extinguish any open flame.
•Do not use the phone in your
building.
•Immediately call your gas supplier
from a neighbor s phone.
•Follow your gas supplier s
instructions.
•If you cannot reach your gas
supplier, call the fire department.
WARNING:
FOR OUTDOOR USE ONLY!
DO NOT USE FOR COOKING!
U.S. Patent US 6,354,288 B1
MODELS #501 - #702
Homeowner’s Installation and
Operating Manual
INSTALLER: Do Not Discard this
Manual
Leave for Homeowner

General Information
IMPORTANT: Read all instructions and warnings
carefully before starting installation. Failure to
follow these instructions may result in a possible
fire hazard and will void the warranty.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause injury
or property damage. Read the installation,
operating and maintenance instructions thoroughly
before installing or servicing this appliance.
WARNING: This appliance shall be used only
outdoors in a well-ventilated space and shall NOT
be used inside a building, garage or any other
enclosed area.
WARNING: This unit is NOT for use with solid
fuel.
NOTE: All new LP cylinders (and in many cases
used cylinders) may contain water, air or other
contaminants. It is essential that those be removed
before filling the cylinder and placing into service.
Water vapor present in the gas vapor may cause the
regulator to “freeze up” and cause an interruption to
the gas flow. This interruption will cause the unit to
shut down. To prevent this from occurring, it is
essential that a qualified individual ALWAYS
purge a new tank thoroughly before placing it into
service. It is recommended that cylinders that have
not been used for extended periods of time also be
purged before use.
The installation must conform with Local Codes or,
in the absence of local codes, with the National Fuel
Gas Code ANSI Z223.1 or CSA-B140.1 installation
code.
The appliance and its individual shut off valve must
be disconnected from the gas supply piping system
during any pressure testing or the system at test
pressure in excess of ½ psig (3.5kPa).
This appliance must be isolated from the gas supply
piping system by closing its individual manual shut
off valve during any pressure testing of the gas
supply piping system at test pressures equal to or
less than ½ psig (3kPa).
Always keep the appliance area clear and free from
combustible materials, gasoline and other
flammable vapors and liquids.
Children and adults should be alerted to the hazards
of high surface temperatures and should stay away to
avoid burns or clothing ignition.
Young children should be carefully supervised when
they are in the area of the appliance.
Never leave the unit unattended during operation.
Clothing or other flammable materials should not be
hung from the appliance, or placed on or near the
appliance.
Installation and repair should be done by a qualified
service person. The appliance should be inspected
before use and at least annually by a qualified service
person. More frequent cleaning may be required as
necessary. It is imperative the control compartment
burners and circulation air passageways of the
appliance be kept clean and free of debris.
Inspect the fuel supply connection (including the
hose for LP models) before each use of the appliance.
If it is evident there is excessive abrasion or wear, or
the hose is cut, it must be replaced prior to the
appliance being put into operation.
The pressure regulator and hose assembly supplied
with LP models must be used. Replacement pressure
regulators and hose assemblies must be those
specified in this manual.
The LP gas supply cylinder used with LP models
must be constructed and marked in accordance with
the specifications for LP gas cylinders of the U.S.
Department of Transportation (DOT) or the
specifications in the National Standard of Canada,
CAN/CSA B330, Cylinder, Spheres and Tube for
Transportation of Dangerous Goods as applicable.
Cylinders must be stored outdoors in a well-
ventilated area out of reach of children.
Disconnected cylinders must have threaded valve
plugs tightly installed and must not be stored in a
building, or any other enclosed area.
Storage of this appliance indoors is permissible only
if it has been disconnected from its fuel supply
(natural gas line or LP gas cylinder).
The LP gas cylinder supply system must be arranged
for vapor withdrawal.
The LP gas cylinder used must include a collar to
protect the cylinder valve.
When an LP model is not in use, the LP gas must be
turned off at the supply cylinder.

General Information
Enclosures for LP Gas Supply Systems
If you build enclosures for an LP gas cylinder,
follow these recommended specifications. You
must also follow local codes.
Enclosures for LP gas supply cylinders shall be
ventilated by openings at the level of the cylinder
valve and at floor level. The effectiveness of the
openings(s) for purposes of ventilation shall be
determined with the LP gas supply cylinder(s) in
place. This shall be accomplished by one of the
following:
1. One side of the enclosure shall be
completely open; or
2. For an enclosure having four sides, a top and
bottom:
a. At least (2) ventilation openings at
cylinder valve level shall be
provided in the side wall, equally
sized, spaced at 180 degrees (3.14
rad.) and unobstructed. Each
opening shall have a total free area
of not less than ½ square inch per
pound (3.2 sq. cm/kg) of stored fuel
capacity and not less than a total free
area of 10 square inches (64.5sq.cm)
b. Ventilation openings(s) shall be
provided at floor level and shall have
a total free area of not less than ½
inch per pound (3.2 sq/ cm/kg) of
stored fuel capacity and not less than
a total free area of 10 square inches
(64.5 sq.cm). If ventilation openings
at floor level are in a side wall, there
shall be at least two openings. The
bottom of the openings shall be at
floor level and the upper edge no
more than 5 inches (127mm) above
the floor. The openings shall be
equally sized, spaced at 180 degrees
(3.14 rad) and unobstructed.
c. Every opening shall have minimum
dimensions so as to permit the
entrance of a 1/8 inch (3.2mm)
diameter rod.
3. Cylinder values shall be readily accessible
for hand operation. A door on the enclosure
to gain access to the cylinder valve is
acceptable, provided it is nonlocking and
can be opened without the use of tools.
4. There shall be a minimum clearance of 2
inches (50.8mm) between the lower surface
of the floor of the LP gas supply cylinder
enclosure and the ground.
5. The design of the enclosure shall be such
that the LP gas supply cylinders(s) can be
connected, disconnected and the connections
inspected and tested outside the cylinder
enclosure; and those connections which
could be disturbed when installing the
cylinder(s) in the enclosure can be leak
tested inside the enclosure.
6. Be certain to mount or set the LP gas
cylinder on a flat surface and restrain it to
prevent it from tipping.
Purge the gas supply line of any trapped air prior to
the first firing of the unit.
WARNING: During the initial purging and
subsequent lightings, NEVER allow gas valve to
remain in the “Open” position without first
placing a burning match on top of the burner.
Cylinder Enclosures available to match portable
outdoor fireplace models

Assembly and Installation
The log set is packaged and shipped separately.
Follow log manufacturer’s instructions for
installation.
1. Remove the gas log set and burner assembly
and check for damage. DO NOT install
damaged components. The logs are fragile –
handle with care. NOTE: Do not lift unit
from decorative stone caps as this may cause
damage. Lift unit from underside of frame.
2. Place the burner assembly on a flat, stable
surface in an outdoor location such as a
patio or a deck. This location must be
adjacent to the gas supply line (natural gas)
or LP gas supply cylinder. NOTE:
Minimum clearances to combustibles must
be maintained.
Remember, you must have easy access to the gas
valve control knob AFTER the appliance is
installed and connected to the gas supply.
The ON/OFF Gas Valve is used to turn gas to the
burner on and off.
Natural Gas Models
Connect the incoming gas supply line to the on/off
gas valve of the appliance. (Fig.1) Make certain
ALL gas connections are tight. Test for leaks. Use
a 50/50 solution of liquid soap and water to test for
leaks at gas fittings and joints. Apply water/soap
solution with a brush only – do not over apply.
NEVER test with an open flame.
LP Gas Models
1. Place cylinder base on a level surface.
2. Be sure to place cylinder in ring on base.
3. Make sure tank valve is in its full OFF
position. (Turn clockwise to stop.)
4. Check tank valve features to ensure it has
proper external mating threads. (Tank valve
marked: USE WITH TYPE 1)
5. Never attempt to use damaged or plugged
equipment. See your local LP Gas Dealer
for repairs.
6. After inspecting the LP hose connect the end
with the female fitting on the hose to the
male fitting on the on/off gas valve at the
end of the flex tube and make sure it is tight.
7. When connecting regulator assembly to the
tank valve, hand tighten nut clockwise to a
positive stop. DO NOT use a wrench to
tighten. Use of a wrench may damage quick
closing coupling nut and result in a
hazardous condition.
8. Locate the hose out of pathways where
people may trip over it or in areas where the
hose may be subject to accidental damage.
9. Open tank valve fully (counterclockwise).
Turn the on/off valve at the unit slowly to
the on position and use a 50/50 solution of
liquid soap and water to test for leaks at gas
fitting and joints. Apply water/soap solution
with a brush only – do not over apply.
NEVER test with an open flame. If leak is
found, turn tank valve off and do not use the
appliance until repairs can be make by a
local LP Gas Dealer. DO NOT attempt to
make repairs yourself.
10. Never attempt to use the appliance or any
components that have been damaged or
exposed to an accidental fire.

Assembly and Installation
Upon completing the gas line connection, a small
amount of air will be in the lines. When first
lighting the burner, it will take a few seconds for the
lines to purge themselves of this air. Once the
purging is complete the burner will light and
operate as indicated in the instruction manual.
Subsequent lighting of the appliance will not
require such purging.
Lighting and Operating Instructions
Lighting and Operating InstructionsLighting and Operating Instructions
Lighting and Operating Instructions
FOR YOUR SAFETY, READ BEFORE LIGHTING
WARNING: If you do not follow those instructions
exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
A. The appliance must be lit manually. When
lighting follow these instructions exactly.
B. BEFORE LIGHTING smell all around the
appliance area for gas. Be sure to smell
next to the floor because some gas is
heavier than air and will settle on the floor.
C. Use only your hand to turn the gas control
key. Never use tools. If the key will not
turn by hand do not try to repair it. Call a
qualified service technician. Applying force
or any attempted repair may result in a fire
or explosion.
D. Do not use this appliance if any part has
been under water. Immediately call a
qualified service technician to inspect the
appliance and to replace any part of the gas
control which has been under water.
WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance
•Do not touch any electric switch
•Do not use any phone in your building
•Immediately call you gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
Lighting Instructions
Lighting InstructionsLighting Instructions
Lighting Instructions
1. ST0P! Read the safety information above.
2. Remove the cover.
3. Insert the “TEE” handle in the valve.
4. Hold the log lighter towards the center of the
burner.
•For natural Gas unit, turn the “TEE”
handle slowly counterclockwise.
•For LP unit, turn the valve on the LP tank
counterclockwise all the way and then
turn the “TEE” handle on the valve slowly
counterclockwise.
5. If the burner does not light immediately turn
the gas valve to “OFF”.
6. Wait at least five (5) minutes to clear out
any gas. Then smell for gas, including near
the floor. If you smell gas, STOP! Follow
the safety information above WHAT TO
DO IF YOU SMELL GAS. If you do not
smell gas, repeat steps.
To Turn Off Gas to Appliance
To Turn Off Gas to ApplianceTo Turn Off Gas to Appliance
To Turn Off Gas to Appliance
1. Turn the “TEE” handle to the “OFF”
position fully clockwise at the unit, then turn
the valve on the LP tank to the “OFF”
position, fully clockwise. Remove “TEE”
handle.
2. Replace cover when until has completely
cooled.
