Landmann Fraser Quick setup guide

VER.1, 3/26/2019
Assembly and Use
Instructions for Model:
25964
25965
PLEASE READ ALL RULES FOR SAFE OPERATION
AND HELPFUL HINTS BEFORE USING.
!
!WARNING: FUELS USED IN WOOD OR CHARCOAL BURNING
APPLIANCES, AND THE PRODUCTS OF COMBUSTION OF SUCH FUELS,
CAN EXPOSE YOU TO CHEMICALS INCLUDING CARBON BLACK,
WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE
CANCER, AND CARBON MONOXIDE, WHICH IS KNOWN TO THE
STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM.
For more information go to: www.P65Warnings.ca.gov
®

• THIS FIRE PIT IS FOR OUTDOOR USE ONLY!
• USE ONLY ON BRICK, CONCRETE, STONE OR OTHER MASONRY
SURFACES!
• DO NOT USE ON LAWNS, WOODEN DECKS, COMPOSITE
DECKS, ASPHALT OR ANY COMBUSTIBLE SURFACE.
• KEEP THE FIRE PIT A MINIMUM OF 10 FT. AWAY FROM
BUILDINGS, STRUCTURES, ANY FLAMMABLE ITEMS AND
VEHICLES.
• NEVER USE UNDER LOW HANGING TREE BRANCHES, TRELLIS,
OVERHANGS OF ANY KIND INCLUDING COVERED PORCHES.
• WARNING! NEVER USE GASOLINE, ALCOHOL OR VOLATILE
FLUIDS TO START OR RESTART FIRES.
• DO NOT USE THE OUTDOOR FIRE PIT WHILE IMPAIRED BY
ALCOHOL OR ANY OTHER SUBSTANCE.
• FOR LONGER PRODUCT LIFE, KEEP FIRES TO A RESPECTABLE
SIZE, DO NOT OVERLOAD.
• DO NOT THROW FIREWOOD INTO THE FIRE PIT, ADD
FIREWOOD BY CAREFULLY PLACING INTO THE FIREBOWL.
• THE OUTDOOR FIRE PIT IS FOR ADULT USE ONLY.
• ADULTS NEED TO KEEP WATCH AND SUPERVISE CHILDREN
AND PETS WHEN AROUND THE FIRE PIT DURING USE.
• AVOID BEHAVIOR THAT COULD CAUSE THE FIRE PIT TO TIP
OVER.
• KEEP LOOSE CLOTHING AWAY.
• DO NOT LEAVE UNATTENDED AT ANY TIME WHILE IN USE.
• DO NOT MOVE THE FIRE PIT DURING USE.
• DO NOT USE IN WINDY CONDITIONS!
• DO NOT OVERLOAD OR USE FOR BURNING GARBAGE.
• USE CAUTION WHEN TENDING THE FIRE, AS SURFACES WILL
BECOME VERY HOT WHILE IN USE.
• ALWAYS USE THE SPARK GUARD DURING USE.
• USE MITTENS OR GLOVES WITH THE POKER TO REMOVE THE
SPARK GUARD, THE SPARK GUARD WILL BECOME VERY HOT!
• USE CAUTION WHEN REMOVING THE SPARK GUARD, AS
HOT STEAM OR A FLARE UP COULD CAUSE BURNS.
• BEFORE EACH USE MAKE SURE THE FIRE PIT IS IN GOOD
WORKING CONDITION.
• USE CAUTION AFTER THE FIRE HAS BEEN EXTINGUISHED,
SURFACES WILL REMAIN HOT FOR SOME TIME.
• THE FIRE PIT MUST BE COMPLETELY COOLED OFF AND
ALL EMBERS MUST BE EXTINGUISHED BEFORE ANY COVER
CAN BE USED.
• CHECK LOCAL LAWS AND CODES BEFORE USING.
CARBON MONOXIDE HAZARD!
BURNING WOOD OR CHARCOAL
PRODUCES CARBON MONOXIDE, WHICH
HAS NO ODOR AND CAN CAUSE DEATH IF
BURNED IN ENCLOSED AREAS. NEVER
BURN WOOD OR CHARCOAL INSIDE
HOMES, VEHICLES, TENTS OR ANY OTHER
ENCLOSED AREAS.
WARNING!
!
PAGE 2
READ FIRST! RULES FOR THE
FRASER OUTDOOR FIRE PIT SAFE
OPERATION.
!
®

PAGE 3
When unpacking the Fraser from the carton, make sure you find and become familiar with all the parts listed
below. Use caution as some parts may have sharp edges.
PARTS LIST
HARDWARE LIST
Assembly time: 15 minutes
A Phillips or plain screwdriver and
an adjustable wrench are needed
for assembly.
TOOLS REQUIRED
T
(1) SPARK
GUARD HOOK
®
A
(1) FIREBOWL
B
(1) SPARK GUARD
F
(1) POKER
C
(1) BASE
D
(4) BASE ARMS
E
(1) SUPPORT RING
x4
(12) M6 x 12MM
BOLT
AA
x 12
(1) M6 x 16MM
BOLT
BB
(8) M6 x 20MM
COUNTERSUNK
BOLT
CC
(21) M6 HEXNUT
DD
(1) SPARK GUARD
WASHER
GG
x1 x8 x 21 x 1

FRASER ASSEMBLY INSTRUCTIONS
PAGE 4
ASSEMBLE BASE ARMS
Take each of the (4) base arms
[D ] and assemble to the base
[C ] using (12) 12MM bolts [ AA ]
and (12) hexnuts [ DD ]. Tighten
securely.
1
STEP
ASSEMBLE SUPPORT RING
Assemble the support ring [ E ]
to the top of the base arms [ D ]
using (8) 20MM bolts [ CC ] and
(8) hexnuts [ DD ]. Tighten
securely.
2
STEP
DO NOT RETURN PRODUCT TO THE
STORE. IF YOU HAVE QUESTIONS
OR HAVE TROUBLE WITH
ASSEMBLY, PLEASE CALL
1-800-321-3473 FOR ASSISTANCE.
®
F
T
A
B
E
BB
GG
DD
C
DD
CC
D
AA
DD
PLACE THE FIREBOWL
Place the firebowl [ A ] on the
support ring [ E ].
3
STEP
ASSEMBLE THE SPARK
GUARD HOOK
Assemble the spark guard hook
[T ] to the spark guard [ B ]
using (1) 16MM bolt [ BB ], (1)
washer [ GG ] and (1) hexnut
[ DD ]. Tighten securely.
4
STEP
PLACE THE SPARK GUARD
Place the spark guard [ B ] onto
the firebowl.
5
STEP

FRASER USE INSTRUCTIONS
PAGE 5
ADD SAND
Before using, add a 1-1.5 in.
layer of sand or about 5 lbs.
(size wise, its the same amount
as a 5 lb. bag of sugar) to the
bottom of the firebowl. This
will help neutralize the
corrosive nature of the ashes
and help radiate the heat
upwards.
1
STEP
ADD FUEL
Add up to 5 lbs. of kindling and
firewood to the firebowl. Use
paper or firestarter under the
kindling and light with a match.
Add more firewood as needed.
The capacity of the fire pit is 5
lbs. of fuel.
2
STEP
SAND
®
KINDLING
FIREWOOD

!
ALL SURFACES BECOME
HOT DURING USE!
PAGE 6
NEVER USE GASOLINE,
ALCOHOL OR VOLATILE
FLUIDS TO START OR
RESTART FIRES.
WARNING!
!
HOT SURFACES DURING
USE! USE MITTENS, POKER
OR GLOVES ON THESE
PARTS.
WARNING!
!
HOT!
!
• KEEP THE FIRE PIT OUT OF THE WEATHER AND
ELEMENTS.
• STORE THE FIRE PIT IN A DRY LOCATION
OUT OF THE WEATHER.
• DO NOT DUMP ASHES WHERE A FIRE CAN BE
STARTED.
• DISPOSE OF ASHES IN PROPER RECEPTACLE ONLY
AFTER ASHES HAVE COOLED.
• USE ANY COVER ONLY AFTER THE FIRE PIT IS
COMPLETELY COOL TO THE TOUCH.
• STORE THE FIRE PIT IN AN AREA SO THAT IT
WON'T BE PRONE TO TIPPING OVER AND BEING
A HAZARD.
HELPFUL HINTS:
Congratulations on your purchase of the Fraser
Fire Pit! At Landmann USA, we strive to provide
you with an easy to use, easy to assemble product.
However,in the unlikely event your package
should have a missing or defective part, please
contact us at:
[e-mail]
-OR-
1-800-321-3473 M-F 8-5 ET.
Proof of purchase may be required. Thank you!
For best results, the fire pit should be cleaned
after every use. Make sure fire pit is cool and all
embers are extinguished before cleaning.
If any remaining firewood needs to be removed,
use poker or shovel to remove. Any sand can be
reused.
Dispose of ashes in proper receptacle only after
ashes have cooled. Do not dump ashes where a
fire can be started.
If the fire pit needs to be cleaned, use a mild
soap and water with a soft rag. Dry thoroughly
to prevent rust.
Occasionally, the fire pit finish will need to be
refinished. Use a high quality, high heat paint to
renew the finish.
CLEANING
AVAILABLE
ACCESSORIES
Please visit our website at:
www.landmann.com/us
-OR-
Call customer service toll free at:
1-800-321-3473
These custom made accessories are made just
for the Fraser Fire Pit.
Landmann® Limited
Distributed by Landmann® USA
Fairburn, GA 30213
www.landmann.com/us
Made in China
© 2019 Landmann® USA
Landmann® and the Landmann Firebird are
registered trademarks of Landmann USA.
Fraser™
COVER
MODEL 29300
®
!
!
!
!
!
!
!
!
!
!
!
