Firex CUCIMIX UCBTE008 V1 Series User manual

INSTALLATION AND
OPERATION MANUAL
“CUCIMIX”
ROUND BRATT PANS WITH MIXER, ELECTRIC TYPE
MODD. UCBTE008_V1 ; UCBTE008C_V1
WARNING:
Improper installation, operation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operating and maintenance instructions
thoroughly before installing, operating or servicing this equipment.

04
-
UCBTE008_
V1
-
DIMU
-
00
-
EN
INTRODUCTION
2
IN CASE OF TECHNICAL ASSISTANCE, INDICATE:
MODEL : ______________________________________________________
NR. SERIAL : ______________________________________________________
The model and serial number are indicated on the rating plate
Firex srl, Z.I.Gresal, 28
32036 Sedico
BELLUNO ITALIA
TELEPHONE: [phone] ; FAX: [phone]
The manual is available upon request to:
[email protected]
specifying model and serial number
(The model and serial number data are indicated on the rating plate).
.
