First Light PLB Series Configuration guide

INSTALL INSTRUCTIONS
PLB SERIES - SOLAR LED BOLLARD
First Light Technologies
Document 70-0004 21.NOV.18
©Copyright First Light Technologies
www.firstlighttechnologies.com
[e-mail]
Toll free: 1 [phone]
Path
Anchor Bolts
PRIOR TO INSTALL
Ensure install location receives at least 2-3 hours
of midday sun on average. Please handle bollard with
care as scratches will affect appearance and powder
coat durability.
TOOLS REQUIRED
•5/32 inch hex key
•3/4 inch wrench or deep socket
TO INSTALL
1. INSTALL ANCHOR BOLTS. With a one to two foot setback from the path or area to be
illuminated, install concrete footing with supplied anchor bolts. Align anchor bolts to path as
shown below using the supplied cardboard template to hold the bolts in position.
Head
Post
Baseplate
Footing

INSTALL INSTRUCTIONS
PLB SERIES - SOLAR LED BOLLARD
First Light Technologies
Document 70-0004 21.NOV.18
©Copyright First Light Technologies
www.firstlighttechnologies.com
[e-mail]
Toll free: 1 [phone]
2. INSTALL BASEPLATE.Remove the baseplate from the bottom of the bollard and install it on the
footing. Ensure the base plate is aligned to the path as shown and tighten to 45 ft-lbs.
*Supplied levelling nuts can be placed below the baseplate but are optional.
3. MOUNT BOLLARD.Mount the bollard onto the baseplate, with the supplied ¼-20 screws and
tighten to 65 in-lbs.
4. CONNECT BATTERY.Remove the head of the bollard from the post and connect the battery
cables. Observe the light to ensure it illuminates for approximately 20 seconds after connecting
the battery. If the light does not illuminate after connecting the battery, please call us at 1 (844)
279-8754.
Note: There is a small cable that is not connected to anything which is for factory use and can be
ignored.
5. PUT BACK HEAD.Place the head back on the post and fasten with the supplied ¼-20 screws and
tighten to 65 in-lbs.
6. INSTALL COMPLETE.
Path
Footing
Baseplate
Nuts
Battery Cables
Battery
Head
