First Light SCL2 Series Configuration guide

INSTALL INSTRUCTIONS
SCL2 SERIES - SOLAR LED COMMERCIAL LIGHT
First Light Technologies www.firstlighttechnologies.com
Document 70-0030 10.September.2018 [email protected]
© Copyright First Light Technologies Ltd. 1-844-279-8754 Toll Free
PRIOR TO INSTALLATION
Install footing and pole as per specifications. Ensure install location has a minimum of 2
to 3 hours of direct midday sun exposure for best performance. Please handle fixture
with care as scratches will affect appearance and powder coat durability.
TOOLS REQUIRED
•1/8 inch hex key
•7/16 inch socket with torque wrench
•Side cutters
•Torque wrench
TO INSTALL
1. Remove light from box using the cardboard handles and place onto cardboard liner with solar module
facing down. Use 1/8” hex key to loosen fastener.
2. Open door. Remove packaging material, mounting kit and batteries from the interior of the light. The
batteries are attached to the battery shelf with velcro and may need to be pulled lightly. The mounting kit
is zip-tied to the battery shelf.
3. If pole is not pre-drilled, drill holes in pole as shown in diagram 3. (Note: drawing is not to scale).
4. Insert the backing plate into the pole and thread the threaded rods fully into backing plate. Place
mounting arm on the pole sliding the threaded rods through holes. Ensure the tab is on the right side as
shown.
1
2
3
4
Threaded Rod
Mounting Kit
Batteries
PushNut
Mounting Arm
Backing Plate
Fastener
Handle
Handle
Tab
Door

INSTALL INSTRUCTIONS
SCL2 SERIES - SOLAR LED COMMERCIAL LIGHT
First Light Technologies www.firstlighttechnologies.com
Document 70-0030 10.September.2018 [email protected]
© Copyright First Light Technologies Ltd. 1-844-279-8754 Toll Free
5. Place light onto mounting arm, install mounting plate and nuts with wrench, torque to 70in-lbs (8N-m).
6. Install batteries onto the door as shown in diagram 6. Press to connect the velcro. The text on the batteries
should be facing you. For grounding, use the provided stud by removing nut on the grounding lug and
installing ground wire.
7. Connect the battery harnessesas shown in diagram 7, ensuring to latch the connectors. After a brief
pause, the light will turn on for 20-30 seconds when connected correctly. If this does not happen, there are
troubleshooting suggestions below.
8. Close door and tighten fastener with hex key.
9. Install complete.
TROUBLESHOOTING
If light does not turn on when batteries are connected:
•Check the battery harness polarity –red wire must be connected to positive (+) terminal and black wire to
negative (-).
•During storage, batteries do slowly discharge but will remain sufficiently charged for at least a year. Our
lights’adaptive capability will recharge discharged batteries in most circumstances by simply installing the
light in a sunny location. If the light does not illuminate at all when the batteries are connected, they are
likely very low and may need charging. In this case, please email [e-mail] or call 1-
844-279-8754 for assistance.
Pole
Backing
Plate
Mounting
Plate
Hex Nut
Mounting
Arm
Install
Batteries
With
Terminals
As Shown
7
Connect Both
Batteries, Ensuring
The Connectors Latch
Correctly.
Grounding
Lug
6
5
