Fisher & Paykel DD601 User manual

DishDrawer
Models
DD601 DD601I
DS601 DS601I
599022

Contents
1.0 SERVICE REQUIREMENTS 1
1.1 Health & Safety 1
1.2 Specialised Tools 3
2.0 DIMENSIONS & SPECIFICATIONS 4
3.0 TECHNICAL OVERVIEW 5
3.1 Electronics 5
3.2 Motor 5
3.3 Cabinet 5
3.4 Filling 6
3.5 Dispensing Detergent 7
3.6 Lid Seal 7
3.7 Wash Cycle 8
3.8 Heating 8
3.9 Filter Plate 9
3.10 Drain Cycle 9
3.11 Drying Cycle 10
3.12 Deflating 10
3.13 Lockring Nut 10
3.14 Wiring Cover 11
4.0 DIAGNOSTICS 12
4.1 Setup & Diagnostics 12
4.2 Fault Modes 12
4.3 Diagnostic Modes 13
4.4 Diagnostics Quick Reference Flow Chart 18
4.5 Fault Codes 20
5.0 WIRING DIAGRAM 33

6.0 SERVICE PROCEDURES 34
6.1 Drawer Front Removal 34
6.2 Handle and LCD Display Removal 34
6.3 Drying Fan Removal 34
6.4 Detergent Dispenser 35
6.5 Electronic Controller 35
6.6 Top Kick Strip Removal 35
6.7 Lower Kick Strip Removal 36
6.8 Wiring Cover Removal 36
6.9 Filter Plate Removal 36
6.10 Rotor Assembly Removal 36
6.11 Tub Removal 37
6.12 Locking Ring, Element Plate & Motor Assembly Removal 37
6.13 Lid Assembly Removal 38
6.14 Lid Seal Replacement 38
6.15 Slide Runner Replacement 39
6.16 Front Trim Replacement 39
6.17 Sound Gasket Replacement 39
6.18 Link Assembly Removal 40
6.19 Air Pump Removal 40
6.20 Exhaust Valve Removal 41
6.21 Water Valve Removal 41
6.22 Flood Switch Removal 41
6.23 EMI Filter Removal 42
6.24 Tub Microswitch Removal 42

- 4 -
1.0 SERVICE REQUIREMENTS
1.1 Health & Safety
Note: When servicing the dishdrawer, health and safety issues must be considered at all
times. Specific safety issues are listed below with their appropriate icon. These are
illustrated throughout the service information to remind service people of the issues.
1.1.1 Electrical Safety
Ensure the mains power has been disconnected before servicing the
DishDrawer. If the mains supply is required to be on to service the
DishDrawer, make sure it is turned off when removing any electrical
component or connection to avoid
electrical shock.
1.1.2 Electrostatic Discharge
An anti-static strap is to be used as electrical static discharge (ESD)
protection when servicing electronic components.
1.1.3 Good Working Practices
Ensure the work area is in a tidy and orderly condition at all times so as not
to cause a hazard while service work is being completed. Always clean and
tidy the DishDrawer and work area after service is completed.
1.1.4 Isolate Water Supply
Turn off the water connection tap before servicing.
1.1.5 Water Leak Check
Check for water leaks as part of the testing after the service has been
completed.

- 5 -
1.1.6 Insulation Test
Megger test to check insulation.
Warning: Short together the phase and neutral pins on the plug so as not to
damage any electronic circuitry.
1.1.7 Solvent and Excessive Heat Damage
Plastic surfaces can be damaged by solvents and excessive heat.
1.1.8 Sheet Metal Edges
When working around cut sheet metal edges use appropriate gloves or protection to
eliminate the chance of receivinga laceration.
1.1.9 Diagnostics
While in diagnostics some safety devices are bypassed.
Ensure you do not run components unattended. They may overheat, flood,
burnout or cause water damage.
D

- 6 -
1.2 Specialised Tools
For servicing this product Specialised tools are required.
1.2.1 Static Strap:
To be used as ESD protection when replacing or handling electronic components.
1.2.2 Down Load Pen Connection: P/N 425930C.
To be used to retrieve data from the electronic controller along with the diagnostic
program on your laptop.
1.2.3 Down Load Serial Connection: P/N 425376C.
To be used to retrieve and download data from the electronic controller along with
the diagnostic program on your laptop.
1.2.4 Perspex Test Lid: P/N 525826.
To be used on the drawer while extended to observe water fill,
wash and drain operations.
1.2.5 Air Gauge and Plumbing. P/N 525819.
To be used to measure the air pressure in the lid seal and plumbing.

- 7 -
2.0 DIMENSIONS & SPECIFICATIONS
Product Size (mm) Minimum Cavity Size
Height 817-877mm 820-880mm
Width 595mm 600mm
Depth 570mm 580mm
Drawer Open (incl cab) 1080mm
Electrical 230-240V AC 50Hz 10amp max.
Specifications
Lid Seal
P/N525878
Exhaust Valve
P/N525415
Lid Seal Air Pump
P/N525430
Water Inlet Valves
P/N525113 Dual
P/N525842 Single
Flood Switch
P/N525941
EMI Filter
P/N525908P
Motor
Drain
Wash
Stator
P/N525933
Rotor
P/N525736
30-40 Kpa
12 Volt ac
70 ±5 Ohms
5 Volt ac
16 ±2 Ohms
24Volt dc
70 ±5 Ohms
5 Lt/min
24Volt dc
Double Pole
240Volt ac
40 Volt dc 3 Phase
4200RPM
2300-2850RPM
2.5 ±0.2 Ohms
per winding
Detergent
Dispenser
P/N525675
Rinse Aid
Dispenser
Electronic P.C.B.
P/N525832P
Control Panel Std
P/N525192P
Control Panel
Integrated
P/N525185P
24 volt dc
70 ±5 Ohms
5 grams
10 grams
15 grams
5 gram pre-rinse
24 Volt dc
70 ±5 Ohms
50 mls
25 reg. Washes
approx
230-240 Volt Input
Outputs: -
230 Volt ac
40 Volt dc
24 Volt dc
24 Volt dc
24 Volt dc
Temperature Sensor
(Part of Heater
Plate)
Inlet Hose
P/N525151
Drain Hose
P/N525435
P/N525495
962-Ohms @ 20°C
1000-Ohms@ 30°C
1202-Ohms @ 60°C
1.7m
960Kpa
2.0m from rear of
cabinet
2.5m bottom tub
2.9m top tub
Heater Plate
P/N525169 240 Volt ac
55 ±5 Ohms

- 8 -
3.0 TECHNICAL OVERVIEW
3.1 Electronics
The DD601 electronic controller has two separate micro controllers on the main printed circuit
board. One is for motor control and output switching and the other is for controlling interface and
console functions.
The user interface comprises a printed circuit board for front controls and a touch switch panel for
internal controls.
The electronics can connect to a computer service tool via a serial communications port for fault
finding and product information.
All output peripherals (solenoids, fans etc), except the heating element, are run on low voltage
(24v).
The power for all low voltage devices comes from a 100w switchmode power supply, which is
cooled by a heatsink and when necessary the drying fan.
The element is switched by a relay and protected by a fail safe relay.
3.2 Motor
The motor is a fully electronically controlled 40V 60w 3 phase 6 pole brushless DC motor,
running at approximately 2300-2850 depending on wash cycle selected, 2500 rpm on Normal, Fast,
and Rinse cycles, 2300 on Delicate and 2850 on Heavy Wash, 4200 rpm on Drain.
3.3 Cabinet
3.3.1 Chassis
On the double drawer the double chassis is one complete assembly composed of 5 steel
metal components locked together by a proprietry riveting process. The chassis exterior is
made of white prepaint, while other components are made of electrogalvanised material.
On the single drawer four bolts and washers are used to secure the chassis to the shelf using
the steel inserts.
Unlike most other dishwashers, the chassis assembly is a load carrying structure designed to
impart stiffness to the product and to ensure deflection is minimised.
The feet of the cabinet are assembled into the chassis by means of four steel inserts which
are clinched in place to form a permanent threaded connection.
The tub extends 510mm out of the cabinet by travelling along two rigidly attached slides on
either side of the tub.

- 9 -
3.3.2 Drawer Fronts
Prefinished drawer fronts are formed from a prepainted blank of steel. The drawer fronts
are attached to the tub by means of formed hooks and two pins which are inserted through
either side of the tub.
On the integrated model, the front panel supplied on each drawer is the mounting panel for
the joinery finished drawer front. The joinery finished drawer front is supplied by the
customer.
3.4 Filling
3.4.1 Cold Inlet
The tub of the dishwasher fills by a cold water inlet hose only. From the connection to the
cold water pipe in the kitchen, the inlet hose enters the cabinet of the dishwasher at the
base, onto a dual water valve. Each tub is supplied water independently via one of the dual
valve coils and a fill hose that runs through customised link assemblies at the back of the
tub and travels along the base of the tub under the wiring cover to the front. At the front of
the tub, the fill hose connects to the detergent dispenser which allows water to enter the
tub, firstly through the pre rinse section of the dispenser for the pre rinse cycle and
secondly through the main wash section for all other cycles.
3.4.2 Mixing the Detergent
Filling cold water enters the detergent dispenser, flushing the detergent from the cup,
through the dispenser into the tub.
3.4.3 Amount of Water
The tub fills with approximately 2.2 litres of water, level with the base of the spray arm
attachment. Once this level is reached, the wash pump (which has sensed the fill at 30
second intervals during the fill), becomes primed and pumps the water through the spray
arm which will then rotate.
The water level is monitored by sensing the motor load through the electronics.

- 10 -
3.5 Dispensing Detergent
The dispenser is mounted in the front wall of the wash tub.
The detergent dispenser consists of two detergent chambers, one for pre wash and the other for the
main wash.
The detergent dispenser door is opened manually for detergent loading and then manually closed
ready for the detergent to be transported to the wash tub by the inlet water. To enable each
detergent chamber to be dispensed separately, an inlet water diverter valve controlled by the
electronics is necessary.
Additionally a positive displacement pump unit and storage tank are incorporated within the
dispenser to supply rinse aid. The rinse aid dispensed volume is adjusted utilising the dishwasher
electronic controller. A glowing red light on the tank filler cap indicates an empty rinse aid tank.
3.6 Lid Seal
3.6.1 When Activated
At the beginning of each wash cycle, the lid seal inflates while the pre wash drain cycle
removes any residue water from the tub. This runs for approximately 60 seconds, then the
tub fills.
3.6.2 What is the Lid Seal
The lid seal is a static plastic moulding retained in the lid which provides a dynamic seal to
the tub. The dynamic seal is created by a bellows section gasket bridging between the top
flange of the tub and the lid. The dynamic seal also locks the tub/drawer during washing.
3.6.3 During Wash
The bellows section gasket is inflated by a solenoid activated diaphragm air pump. This
cycles during the complete cycle at timed intervals to maintain a 35kpa sealing pressure.

- 11 -
3.7 Wash Cycle
3.7.1 Tub
The tub is the main cavity where all the wash activity occurs. The tub is a plastic recepticle
which has a wash pump and sprayarm at the base. The tub also has guide vanes around its
walls which direct falling water from the wash cycle in a clockwise direction around the
filter plate. This clears the filter plate of food particles into the sump where they can be
trapped or pumped out during the drain cycle.
3.7.2 Rotor
The rotor is a four pole permanent magnet rotor with a graphite bearing at each end of the
vertical shaft. At the lower end of the rotor shaft is the drain impellor and at the upper end
is the wash impellor.
3.7.3 Spray Arm
The spray arm is shaped for most efficient waterflow. The holes are positioned for best
penetration into the washload, with the water jets angled to ensure the sprayarm rotates at
the most efficient speed.
3.8 Heating
3.8.1 The Element
The heater plate is an element consisting of a porcelain enamelled steel plate with a thick
film resistive circuit written onto the dry side. The element is clamped in place by a
lockring nut and supports the motor at the base of the tub.
3.8.2 Heating the Water
The heater plate lies beneath the filter plate. This creates a flow through water heating
system during the wash cycle by allowing water to flow through the filter plate, over the
surface of the element and into the wash pump.
3.8.3 Maintaining the Temperature
Attached to the element is a sub printed circuit board with a temperature sensitive
thermistor . This connects by means of a RAST 2.5 connector system to the wiring harness
of the element. Sensor components are unservicable.

- 12 -
3.8.4 Overheating Control
The heater plate is only activated during the wash cycles. It is not used for drying. The
temperature is maintained by the thermistor. The element circuit is continuously monitored
by the electronic controller and will switch a fail safe relay if a fault is detected in the
heater circuit. The element is thermally monitored by the thermistor on the element
through the electronic controller.
3.9 Filter Plate
The filter plate is a stainless steel disk which lies below the dishrack and sprayarm and completely
encompasses the base of the tub.
3.9.1 The Filter System
The tub is designed with vanes which swirl the water around and over the filter plate. At
the front of the tub, located as part of the filter plate, is the drain filter. Large soils collect
in the drain filter and only 1.5mm or smaller soils flow through its micro mesh filter,
eliminating re-depositing of soil during the wash. Only soils up to 6mm pass through the
drain filter during the drain cycle. This requires the drain filter to be regularly emptied and
cleaned.
3.9.2 Removing and Cleaning the Filter Plate
The drain filter can be emptied with the dishrack in place by removing the cutlery basket
and opening the plastic section of the dishrack. The filter plate is removable for cleaning
by removing the dishrack and sprayarm and unlocking the lockring nut anti-clockwise.
3.10 Drain Cycle
The drain pump is a self priming centrifugal pump which only pumps when the motor is rotating in
the drain direction (anti-clockwise). It has a five bladed impellor made from acetal pushed into a
spline on the end of the rotor shaft. The drain cycle is a 60 second timed drain period.
The drain pump housing, which incorporates an inlet and outlet pipe, is welded to the motor
housing, hence captivating the motor.
The inlet pipe plugs straight into the sump and is sealed there by a small ‘o’ ring.
The outlet pipe has a non return flap valve to prevent soiled water returning to the tub.
The drain hose is an extruded blow mould hose which is routed over the link assembly and exits out
of the base of the product and is connected to a domestic drain.

- 13 -
3.11 Drying Cycle
Immediately after water from the final hot rinse has been drained from the tub, the drying system
begins operation.
The fan draws air through the tub, where it absorbs water from the dishload. The moisture laden air
is then mixed with a larger quantity of ambient air (from the kitchen), to minimise the amount of
vapour visible when exiting from the drawer front.
The fan runs continuously during the drying cycle and will restart if the tub is opened and closed
again. After the drying cycle is complete, the fan continues to run for 30 minutes, but will not
restart if the tub is opened.
The fan is pulsed when needed throughout the entire wash cycle. This draws ambient air through
the electronics heatsink to maintain the electronics components within their specified operating
temperatures.
3.12 Deflating
3.12.1 Lid Seal
The lid seal is a static plastic moulding retained in the lid which provides a dynamic seal to
the tub during the washing cycles.
3.12.2 When the Lid Seal Deflates
At the end of the dishwasher programme, or a pause in the programme, an exhaust valve
releases the air pressure from the bellows section gasket. This deflates the seal and unlocks
the tub and drawer.
3.13 Lockring Nut
The lockring nut holds the heater plate into the base of the tub and motor housing assembly to form
a watertight seal. It does this by compressing two large ‘o’ rings between the heater plate and tub
and between the heater plate and the motor assembly.
It has clips which hold the drain hose, fill hoses and the wiring loom in place.
Another function of the lockring nut is to support the wiring cover with three clips.

- 14 -
3.14 Wiring Cover
The wiring cover protects the customer from the 240V mains supply which passes over the link
assembly and under the lockring to the front of the tub. It also serves to protect the motor assembly,
drain and fill hoses from damage when opening and closing drawers. The wiring cover acts as a
cosmetic part of the product.
4.0 DIAGNOSTICS
4.1 Setup & Diagnostics
The DishDrawer comes with comprehensive fault codes and built in diagnostics, to save the user &
service person time and worry, if the dishwasher ever exhibits a fault.
4.2 Fault Modes
The faults are displayed in the LCD as one of 8 F (fatal) faults or one of 3 U (user) faults. A Fatal
fault will usually require the assistance of a qualified service person, while many User a faults are
simply blockages or installation errors, easily fixed by the user. In the Integrated models, an LCD
is not available, and faults are indicated by a Red center LED, with the fault number indicated on
the touch switch panel with Red LED’s. The indication below for the Touch Switch Panel is from
left to right, with ‘_’ meaning the LED is Off, and ‘#’ meaning the LED is On. A fatal fault is
accompanied by a continuous pulsating beep, while a user fault is accompanied by a more pleasant
continuous pulsating tone pattern. The last two faults are logged into EE memory, with 8 bytes of
information logged to aid location of the fault. These bytes are available for interrogation by a PC if
required. The fault codes shown on Pages 20/21 have been implemented in the DishDrawer.
To clear any fault press the Power button. It the fault is still present then it cannot be cleared.

- 15 -
4.3 Diagnostic Modes
4.3.1 Temperature Display Mode
During a wash cycle, the current water temperature can be displayed on the LCD instead
of the time remaining. To enter temperature display mode, start a wash cycle as normal.
Initiate a keylock by pushing and holding the Keylock button for 4 seconds.
Once in keylock mode push and hold Start/Pause for 8 seconds to enter temperature
display mode. The temperature is now displayed and the MIN symbol is switched off.
Keylock mode can now be exited.
To cancel temperature display mode, either repeat the above procedure or enter power off
mode by pressing Power. Temperature display mode is automatically cancelled at the end
of a wash program (even in CC mode).
4.3.2 Rinse Aid / Tub-Open Beep Water Pressure Setup Mode
To enter this setup mode, hold the Programme and Eco touch switches simultaneously for
5 seconds. Once the setup mode is entered a beep is emitted and the LCD is red with ‘HP’
displayed.
Push Power at any time to exit this setup mode.
4.3.3 Rinse Aid Setup
The current rinse aid setting is shown using orange LED’s on the touch switch panel.
The amount of rinse aid dispensed into a rinse cycle can be varied to suit the level of
hardness of the local water supply. It is adjusted for 1 - 5 dispenser levels
(1 = approx 1ml of rinse aid , 5 = approx. 5mls of rinse aid).
Push Programme to advance the rinse aid setting. Once the desired setting is achieved,
push Power to exit. The rinse aid index is stored in EE memory, so even with the power
removed, the rinse aid level is retained.
4.3.4 Tub-Open Beep Setup
The beep sequence that occurs when the tub is opened can be turned on or off using the
Keylock button. If the Smily Face on the LCD is On then the beep sequence will occur
when the tub is Opened. If the Smiley face is Off then no beeps will occur when the tub is
Opened. Push Power to exit when the desired setting has been selected.
The Integrated Model will sound a single beep when turning this option off, while the
actual beep sequence is sounded when turning this option on. The DishDrawer will default
to 'beeps on' if the mains power is removed.

- 16 -
4.3.5. Water Pressure Set Up
The DishDrawer can be set to either High(Standard) or Low inlet water pressure. The LCD
displays the current water pressure setting.
If “HP” is displayed then the settingis High Pressure.
If “LP” is displayed then the setting is Low Pressure. Low pressure is generally less than
50kPa or equivalent to that supplied by a ceiling tank.
Push the Start/Pause button to alternate between HP and LP.
Integrated: A high beep is sounded when changing the HP, and a low beep is sounded
when changing to LP. Push Power to exit when the desired setting has been selected.
4.3.6 Dishwasher Diagnostics
Dishwasher Diagnostics can only be entered in Power Off mode, ie. When there is no
display on the LCD or the badge LED’s are off. Diagnostics is entered by holding the
Keylock and Start/Pause buttons simultaneously for 6 seconds. Ensure that Keylock is
pushed first to prevent the dishwasher from starting a wash, from a Start/Pause keypress.
There are currently four levels of diagnostics. To move to next level push Power. Once a
mode has been entered, pushing Power will exit diagnostics completely (except Display &
Show Off modes). If no mode is entered then the display will cycle through the four levels
and exit after the last. On entering diagnostic mode the first level is Download Mode.
4.3.7 Display / Download Mode
In this mode all LED’s (except Rinse program) and LCD segments (except keylock) are
illuminated.
4.3.8 Optical LED Download / Fault Display
An optical data download is available here to download all EE data to a PC via the Rinse
Program Red LED. Hold the reader pen over the Rinse Program LED and press Start /
Pause to initiate the download. A short beep indicates the start and finish of download.
The last two faults are displayed on the LCD during the optical download, with the
Current Fault code displayed first followed by the Previous Fault Code.

- 17 -
4.3.9 Clearing Fault Logs
To Clear the current Fault press the Keylock button until a beep is sounded. This action
moves the Current Fault into the Previous Fault while clearing the Current Fault. To Clear
the Previous Fault press Keylock once more until the beep is sounded. Warning:
Once a fault has been cleared it is permanently removed from Memory and cannot be
recovered.
Press Power to advance to the next mode.
4.3.10 Show Off Mode
This mode initiates a shop show off display and operation demonstration. The LCD display
is Red backlight ‘Ad’. The touch switch LED’s are - Grn Grn __ Grn Grn.
Press Power to skip show off mode and move onto the next mode.
Press Start/Pause to initiate show off mode:
A short series of tones indicates that Show Off mode has been entered. The Show Off
display cycles through every LED, & LCD segment. If any front panel key is pressed the
dishwasher will re-initiate a series of short tones.
Once Show Off mode has been initiated, the mains power must be removed to exit out of
Show Off mode.
4.3.11 Hardware Output Diagnostic Test Mode
This mode tests all the hardware outputs and inputs. The LCD display is Red backlight and
‘HO’.
Press Power to skip hardware diagnostics and advance to the next mode.
Press Start/Pause to enter hardware diagnostics.
Once hardware diagnostics has been entered the current hardware output being tested is
indicated in green on the touch switch panel, using binary encoding, and also on the LCD
as shown below.
Any combination of outputs can be switched on or off. Load sensing is enabled when the
motor is running.
Press Start/Pause to advance to next hardware output.
Press Keylock to turn the currently displayed output On or Off. If the currently displayed
output has a green backlight then that output has been switched on, and if the backlight is
red then that output is off.
Press Power to Exit at any time (All outputs will be switched off on exit).
The LCD display and touch switch panel green LED’s are illuminated to correspond to a
particular hardware device. The following table details the display order of the test.

- 18 -
LCD Heavy Norm Fast Deli Hardware Output
-------------------------------------------------------------------------------------------
EU Off Off Off On Exhaust Valve
FU Off Off On Off Fill Water Valve
dd Off Off On On Detergent Diverter Valve
LS Off On Off Off Lid Seal Pump
rd Off On Off On Rinse Aid Dispenser (dispenses
current setting)
P1 Off On On Off Motor Wash direction
(2300-2850 rpm)
P2 Off On On On Motor Drain direction
(4200 rpm)
dF On Off Off Off DC drying fan (On
100% duty)
Er On Off Off On Element Relay
‘temp’ On Off On Off Displays current water
temperature.
WARNING : As there is no protection in this mode it is possible to turn the element on with no
water in the tub. It is advisable to avoid turning on the element without water in the tub.
NB : No Fault codes will come up while in diagnostics mode.
Tub Open Microswitch Test: At any time during HO test mode the Rinse red LED indicates the tub
position. On = Open, Off = Closed.
Note : There maybe a short delay (up to 0.5sec) from when the tub has changed state to the position
that is indicated on the LED. This is due the communication delays between the two micro-
controllers.
4.3.12 Continuous Cycle Life Test Mode
In this mode the dishwasher can be run continuously in any wash cycle. Once the cycle
has finished, the dishwasher automatically restarts the same wash cycle.
The LCD is Red backlight and display CC. The touchswitch panel is -
Red Red __ Red Red.
To exit diagnostic mode push Power.
To initiate a continuous cycle press Start/Pause. The dishwasher will enter standby mode.
Choose the required cycle and operate the dishwasher as normal. Continuous cycling can
be canceled at any time by pushing the Power button, or removing the mains power.
Continuous cycling is indicated by the backlight alternating between green and orange.
In continuous cycle a delay occurs when a cycle has finished before the next cycle starts.
This delay is currently 1 min. During this time the LCD displays a finish cycle display, and
the backlight alternates between RED and OFF.

- 19 -
Cycle Count Retrieval
To display the cycle count on the LCD screen, Pause the dishwasher while running a Continuous
Cycle. The two bytes of the cycle count will be displayed alternately, in syncronisation with
the changing backlight.
The Low byte is displayed when the backlight is Green.
The High byte is displayed when the backlight is Orange.
To calculate the Total diswasher cycle count use the formula below.....
Cycle_Count = ((200 x High_byte) + Low_byte).
Eg. Low_byte = 156
High_byte = 21
Cycle_count = ((200 x 21) + 156) = 4,356.

- 20 -
4.4 Diagnostics Quick Reference Flow Chart
To clear the current
fault code press the
Keylock once. Note if
you press Keylock
again you will remove
the previous fault.
Pressand hold
Keylock, then
Start/Pause buttons
for 6 seconds
Press
Start/Pause
button
Press Power
button
Press
Start/Pause
button
Press Power
Button
Press
Start/Pause
button
Press Keylock
button to turn
output On/Off
All LED’s &
LCD segments
except Keylock
are illuminated Initiate Pen upload via
Rinse program LED.
At the same time, first
the current, then the
previous fault code will
be displayed in the
LCD
Cycles
through every
LED &LCD
segment
Hardware
output
diagnostic
test mode
Disconnect
power supply to
exit Show Off
mode
EU = Exhaust valve
FU = WaterInlet Valve
dd = Detergentdiverter valve
Er = Element relay
LS= Lid seal pump
rd = Rinse aid dispenser
P1 = Wash pump motor
P2 = Drain pump motor
dF= Drying fan
temp = currentwater temperature
Note: Display green = output on
Display red = output off
Tub microswitch can be tested at
any time. Rinse LED on = Open
Rinse LED off =Closed
LED Heavy Normal Light Delicate
EU Off Off Off On
FU Off Off On Off
dd Off Off On On
LS Off On Off Off
rd Off On Off On
P1 Off On On Off
P2 Off On On On
dF On Off Off Off
Er On Off Off On
temp On Off On Off
#1 Display
#2 Show Off/Demo Mode
#3 Hardwre Output Test
See Next
