Fisher & Paykel DishDrawer DD60 Series User manual

DishDrawer
DD60, DD24
Phase 9
AA GB EU DK PF SG US CA TW
SERVICE MANUAL

1
FEATURED PRODUCT & CONTACT ADDRESSES
BRAND MODEL DESCRIPTION CA CA
NEW LOGO
CA NEW
STEEL
COLOUR
MARKET
Fisher & Paykel DD60DAW9 Double white model 81075 81584 AA
Fisher & Paykel DD60DAX9 Double stainless steel model 81076 81585 81585-B AA
Fisher & Paykel DD60DCW9 Double classic white model 81077 81586 AA
Fisher & Paykel DD60DCX9 Double classic stainless steel model 81078 81587 81587-B AA
Fisher & Paykel DD60SAW9 Single white model 81079 81588 AA
Fisher & Paykel DD60SAX9 Single stainless steel model 81080 81589 81589-B AA
Fisher & Paykel DD60SCW9 Single classic white model 81081 81590 AA
Fisher & Paykel DD60SCX9 Single classic stainless steel model 81082 81591 81591-B AA
Fisher & Paykel DD60SCTW9 Single classic tall tub white model 81083 81592 AA
Fisher & Paykel DD60SCTX9 Single classic tall tub stainless steel model 81084 81593 81593-B AA
Fisher & Paykel DD60DAHW9 Double water softener white model 81135 - GB
Fisher & Paykel DD60DAHB9 Double water softener black model 81136 - GB
Fisher & Paykel DD60DAHX9 Double water softener stainless steel model 81137 - GB
Fisher & Paykel DD60DCHW9 Double classic water softener white model 81138 - GB
Fisher & Paykel DD60DCHB9 Double classic water softener black model 81139 - GB
Fisher & Paykel DD60DCHX9 Double classic water softener stainess steel model 81140 - GB
Fisher & Paykel DD60SAHX9 Single water softener stainless steel model 81141 - GB
Fisher & Paykel DD60SCTHX9 Single classic tall tub water softener stainless steel model 81142 - GB
Fisher & Paykel DD60DCHX9 Double classic water softener stainless steel model 81162 - EU
Fisher & Paykel DD60SCHX9 Single classic water softener stainless steel model 81163 - EU
Fisher & Paykel DD60DCHW9 Double classic water softener white model 81158 - DK
Fisher & Paykel DD60DCHX9 Double classic water softener stainless steel model 81159 - DK
Fisher & Paykel DD60SCHW9 Single classic water softener white model 81160 - DK
Fisher & Paykel DD60SCHX9 Single classic water softener stainless steel model 81161 - DK
Fisher & Paykel DD60DCW9 Double classic white model 81147 81620 PF
Fisher & Paykel DD60DCX9 Double classis stainless steel model 81148 81621 81621-B PF
Fisher & Paykel DD60SCTW9 Single classic tall tub white model 81149 81622 PF
Fisher & Paykel DD60SCTX9 Single classic tall tub stainless steel model 81150 81623 81623-B PF
Fisher & Paykel DD60DCX9 Double classic stainless steel model 81170 81624 81624-B SG
Fisher & Paykel DD60SCTX9 Single classic tall tub stainless steel model 81171 81625 81625-B SG
Fisher & Paykel DD60SCX9 Single classic stainless steel model 81172 81626 81626-B SG
Fisher & Paykel DD24DAW9 Double white model 81085 81594 US
Fisher & Paykel DD24DAB9 Double black model 81086 81595 US
Fisher & Paykel DD24DAX9 Double stainless steel model 81087 81596 81596-B US
Fisher & Paykel DD24DCTW9 Double classic tall tub white model 81088 81597 US
Fisher & Paykel DD24DCTB9 Double classic tall tub black model 81089 81598 US
Fisher & Paykel DD24DCTX9 Double classic tall tub stainless steel model 81090 81599 81599-B US
Fisher & Paykel DD24DCHTX9 Double classic water softener tall tub stainless steel model 81091 81600 81600-B US
Fisher & Paykel DD24SAW9 Single white model 81092 81601 US
Fisher & Paykel DD24SAB9 Single black model 81093 81602 US
Fisher & Paykel DD24SAX9 Single stainless steel model 81094 81603 81603-B US
Fisher & Paykel DD24SCTW9 Single classic tall tub white model 81095 81604 US
Fisher & Paykel DD24SCTB9 Single classic tall tub black model 81096 81605 US

2
Fisher & Paykel Appliances Ltd U.K
Turing House
Ortensia Drive
Milton Keynes
MK17 8LX
Buckinghamshire
England
tel: [phone]
fax: [phone]
email: customer.care@sherpaykel.co.uk
Fisher & Paykel Appliances
Unit D2
North Dublin Corporate Park
Swords
Co Dublin
Ireland
tel: [phone]
fax: [phone]
email: customer.care@sherpaykel.ie
Fisher & Paykel Appliances Ltd
PO Box 58-546
Botany, Manukau 2163
78 Springs Rd
East Tamaki
Manukau 2013
New Zealand
tel: [phone]
fax: [phone]
email: customer[email protected]o.nz
Fisher & Paykel Appliances
150 Ubi Avenue 4
#03-01A
Ubi Biz-Hub
408825
Singapore
tel: [phone]
Customer Care: [phone]
email: customer.care@sherpaykel.co.sg
FEATURED PRODUCT & CONTACT ADDRESSES
BRAND MODEL DESCRIPTION CA CA
NEW
LOGO
CA
NEW STEEL
COLOUR
MARKET
Fisher & Paykel DD24SCTX9 Single classic tall tub stainless steel model 81097 81606 81606-B US
Fisher & Paykel DD24SCHTX9 Single classic water softener tall tub stainless steel model 81098 81607 81607-B US
Fisher & Paykel DD60DCHX9 Double classic water softener stainless steel model 81174 81627 81627-B TW
Fisher & Paykel DD60SCTHX9 Single classic tall tub water softener stainless steel model 81175 81628 81628-B TW
Fisher & Paykel DD60SCHW9 Single classic water softener white model 81196 81629 TW
Fisher & Paykel DD60DCHX9 Double classic water softener stainless steel model 81323 81616 81616-B EU
Fisher & Paykel DD60DCHW9 Double classic water softener white model 81324 81617 EU
Fisher & Paykel DD60SCHX9 Single classic water softener stainless steel model 81325 81618 81618-B EU
Fisher & Paykel DD60SCHW9 Single classic water softener white model 81326 81619 EU
Fisher & Paykel DD60DAHW9 Double water softener white model 81327 81608 GB
Fisher & Paykel DD60DAHB9 Double water softener black model 81328 81609 GB
Fisher & Paykel DD60DAHX9 Double water softener stainless steel model 81329 81610 81610-B GB
Fisher & Paykel DD60DCHW9 Double classic water softener white model 81330 81611 GB
Fisher & Paykel DD60DCHB9 Double classic water softener black model 81331 81612 GB
Fisher & Paykel DD60DCHX9 Double classic water softener stainless steel model 81332 81613 81613-B GB
Fisher & Paykel DD60SAHX9 Single water softener stainless steel model 81333 81614 81614-B GB
Fisher & Paykel DD60SCTHX9 Single classic tall tub water softener stainless steel model 81334 81615 81615-B GB
Fisher & Paykel DD60SCHX9 Single classic water softener stainless steel 81944 GB
Fisher & Paykel Appliances Inc
695 Town Center Drive
Suite 180
Costa Mesa, CA 92626-1902
USA
Telephone: [phone]
Fisher & Paykel Customer Services Pty
Ltd
PO Box 798, Cleveland, QLD 4163
A.C.N. 003 3335 171
19 Enterprise Street Cleveland, QLD 4163
Australia
tel: [phone]
fax: [phone]

3
CONTENTS
1HEALTH & SAFETY 5
2 SPECIFICATIONS 7
2.1 Product Dimensions 7
2.1.1 AA, GB, EU, IE, DK Double Models 7
2.1.2 AA, GB, EU, IE, DK Single Models 8
2.1.3 US Double Models 9
2.1.4 US Single Models 10
2.2 Clearances & Dimensions 11
2.2.1 AA, GB, EU, IE, DK Double Models 11
2.2.2 AA, GB, EU, IE, DK Single Models 12
2.2.3 US Double Models 13
2.2.4 US Single Models 14
2.3 Plumbing Requirements 15
2.3.1 AA, GB, EU, IE, DK Double Models 15
2.3.2 AA, GB, IE, EU, DK Single Models 16
2.3.3 US Double Models 17
2.3.4 US Single Models 18
2.4 Electrical Specifications 20
2.5 Component Specifications 20
2.6 Wash Profiles 21
3MODEL NUMBER LOCATION & IDENTIFICATION 24
4TECHNICAL OVERVIEW 25
5 OPERATION 33
6 DIAGNOSTICS 41
6.1 Entering Diagnostics 41
7FAULT DIAGNOSTICS 43
7.1 Troubleshooting 43
7.2 Fault Codes 46
7.3 Component testing 50
8SERVICING THE COMPONENTS 51
8.1 Removing the drawer front 51
8.2 Dissassembly of the Inner door panel 51
8.3 Removal of the UI display 52
8.4 Removal of the top cap 53
8.5 Removing the wash controller 54
8.6 Removing the dispenser 54
8.7 Removing the drying fan and flap valve 54
8.8 Removing the water softener 55
8.9 Removing the strainer 55
8.10 Removing the filter plate 56

4
CONTENTS
8.11 Removing the motor rotor 56
8.12 Removing the pump cap cover 56
8.13 Removing the tub 57
8.14 Removing the kickstrip 57
8.15 Removing the lower cowling 57
8.16 Removing the wiring cover 58
8.17 Removing the heater 59
8.18 Replacing the motor 60
8.19 Replacing a fill hose, drain hose or wiring harness 61
8.20 Replacing the motor controller 64
8.21 Replacing the flood sensor harness 65
8.22 Replacing the water inlet valve 65
8.23 Replacing the lid actuator 66
8.24 Replacing the lid assembly 66
8.25 Replacing the yoke assembly 67
8.26 Replacing the side rail 68
8.27 Replacing the chassis trim 68
8.28 Replacing the temp sensor 68
9WIRING DIAGRAM 69
10 NOTES 70

5
1 HEALTH & SAFETY
IMPORTANT !
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.
When servicing the Dishwasher, health and safety issues must be considered at all times.
D
1.1 Health & Safety
Note: Specific safety issues are listed below with their appropriate icon. These are illustrated throughout
the service information.
1.1.1 Electrical Safety
Ensure the mains power has been disconnected before servicing the DishDrawer™. If the
mains supply is required to be on to service the DishDrawer™, make sure it is turned off
when removing any electrical component or connection to avoid electrical shock.
1.1.2 Electrostatic Discharge
An anti-static strap is to be used as electrical static discharge (ESD) protection when servicing
electronic components.
1.1.3 Good Working Practices
Ensure the work area is in a tidy and orderly condition at all times so as not to cause a hazard
while service work is being completed. Always clean and tidy the DishDrawer™ and work area
after service is completed.
1.1.4 Isolate Water Supply
Turn o the water connection tap before servicing.
1.1.5 Water Leak Check
Check for water leaks as part of the testing after the service has been completed.
1.1.6 Insulation Test
Megger test to check insulation.
Warning: Short together the phase and neutral pins on the plug so as not to damage any
electronic circuitry.
1.1.7 Solvent and Excessive Heat Damage
Solvents and excessive heat can damage plastic surfaces.
1.1.8 Sheet Metal Edges
When working around cut sheet metal edges use appropriate gloves or protection to eliminate
the chance of receiving a laceration.
D
D
D
D
D
D
D

6
1.2 Specialised Tools
1.1.9 Diagnostics
While in diagnostics some safety devices are bypassed. Ensure you do
not run components unattended.
They may overheat, flood or burn out or cause water damage.
D
1.2.1 Static Strap
For servicing this product, some specialist tools are required.
An anti static strap is required to prevent ESD (electrocstatic discharge) when handling electronic
components.
1.3 Training Videos
In section 8, Service Procedures, you will find web links to take you through to training videos on
specific service procedures. These training videos are also available on the service website Cool Blue
World.
1 HEALTH & SAFETY

7
2 SPECIFICATIONS
2.1 Product Dimensions
2.1.1 AA, GB, EU, DK, PF, SG Double Models
4
3 PRODUCT DIMENSIONS
N
F
C
L
M
A
G
B
E
D
O
I
H
J
K
L
PLAN
PROFILE PROFILE
DD60DC MODELSDD60DA MODELS
FRONT
DD60DA DD60DC
PRODUCT DIMENSIONS MM MM
A
Overall height of product
1
820-880
2
820-880
2
B
Overall width of product 599 599
C
Overall depth of product 573 573
D
Depth of chassis (to back of front drawer panel) 553 553
E
Depth of drawer front panel 20 20
F
Height of chassis
1
811 811
G
Height of drawer front panels 712 712
H
Height of upper drawer front panel 393 393
I
Height of lower drawer front panel 312 312
J
Height from top of drawer front panel to top of chassis 88
K
Ventilation gap between drawer front panels 77
L
Height of toekick (customisable) 70-120 72-127
M
Depth from front of drawer panel to front of toekick (adjustable)
3
NA 38-54
N
Height of levelling feet (adjustable) 9-69
2
9-69
2
O
Maximum extension of drawer 547 547
1 includes 2mm high bracket slots 2 depending on adjustment of levelling feet
3 adjustable to match toekick recess on adjoining cabinetry
4
3 PRODUCT DIMENSIONS
N
F
C
L
M
A
G
B
E
D
O
I
H
J
K
L
PLAN
PROFILE PROFILE
DD60DC MODELSDD60DA MODELS
FRONT
DD60DA DD60DC
PRODUCT DIMENSIONS MM MM
A
Overall height of product1820-8802820-8802
B
Overall width of product 599 599
C
Overall depth of product 573 573
D
Depth of chassis (to back of front drawer panel) 553 553
E
Depth of drawer front panel 20 20
F
Height of chassis1811 811
G
Height of drawer front panels 712 712
H
Height of upper drawer front panel 393 393
I
Height of lower drawer front panel 312 312
J
Height from top of drawer front panel to top of chassis 88
K
Ventilation gap between drawer front panels 77
L
Height of toekick (customisable) 70-120 72-127
M
Depth from front of drawer panel to front of toekick (adjustable)
3NA 38-54
N
Height of levelling feet (adjustable) 9-6929-692
O
Maximum extension of drawer 547 547
1
includes 2mm high bracket slots
2
depending on adjustment of levelling feet
3
adjustable to match toekick recess on adjoining cabinetry

8
2.1.2 AA, GB, EU, DK, PF, SG Single Models
2 SPECIFICATIONS
4
3 PRODUCT DIMENSIONS
D
J
G
H
I
E
B
F
C
A
PLAN
PROFILE
FRONT
DD60SA DD60SCT
PRODUCT DIMENSIONS MM MM
AOverall height of product
1
410 454
BOverall width of product 599 599
COverall depth of product 573 573
DDepth of chassis (to back of front drawer panel) 553 553
EDepth of drawer front panel 20 20
FHeight of drawer front panel 393 437
GHeight of chassis
1
410 454
HHeight from top of drawer front panel to top of chassis 88
IVentilation gap below drawer front panel 77
JMaximum extension of drawer 547 547
1
includes 2mm high bracket slots
4
3 PRODUCT DIMENSIONS
D
J
G
H
I
E
B
F
C
A
PLAN
PROFILE
FRONT
DD60SA DD60SCT
PRODUCT DIMENSIONS MM MM
AOverall height of product
1
410 454
BOverall width of product 599 599
COverall depth of product 573 573
DDepth of chassis (to back of front drawer panel) 553 553
EDepth of drawer front panel 20 20
FHeight of drawer front panel 393 437
GHeight of chassis
1
410 454
HHeight from top of drawer front panel to top of chassis 88
IVentilation gap below drawer front panel 77
JMaximum extension of drawer 547 547
1
includes 2mm high bracket slots

9
2 SPECIFICATIONS
2.1.3 US, TW Double Models
5
4 PRODUCT DIMENSIONS
DD24DA DD24DCT
PRODUCT DIMENSIONS MM MM
A
Overall height of product132 5/16 - 34 5/8” (820-880)
2
34 - 36 3/8” (864-924)
2
B
Overall width of product 23 9/16” (599) 23 9/16” (599)
C
Overall depth of product 22 9/16” (573) 22 9/16” (573)
D
Depth of chassis (to back of front drawer panel) 21 3/4” (553) 21 3/4” (553)
E
Depth of drawer front panel 13/16” (20) 13/16” (20)
F
Height of chassis131 15/16” (811) 33 11/16” (855)
G
Height of drawer front panels 29 3/4” (756) 29 3/4” (756)
H
Height of upper drawer front panel 15 1/2” (393) 17 3/16” (437)
I
Height of lower drawer front panel 14” (356) 12 1/4” (312)
J
Height from top of drawer front panel to top of chassis 5/16” (8) 5/16” (8)
K
Ventilation gap between drawer front panels 1/4” (7) 1/4” (7)
L
Height of toekick (customisable) 2 13/16 - 5” (72-127) 2 13/16 - 5” (72-127)
M
Depth from front of drawer panel to front of toekick (adjustable)31 1/2 - 4” (38-102) 1 1/2 - 4” (38-102)
N
Height of leveling feet (adjustable) 3/8 - 2 11/16” (9-69)
2
3/8 - 2 11/16” (9-69)
2
O
Maximum extension of drawer 21 9/16” (547) 21 9/16” (547)
1
includes 1/16” (2mm) high bracket slots
2
depending on adjustment of leveling feet
3
adjustable to match toekick recess on adjoining cabinetry
N
F
C
L
M
A
G
B
E
D
O
I
H
J
K
PLAN
PROFILE
FRONT
5
4 PRODUCT DIMENSIONS
DD24DA DD24DCT
PRODUCT DIMENSIONS MM MM
AOverall height of product132 5/16 - 34 5/8” (820-880)
2
34 - 36 3/8” (864-924)
2
BOverall width of product 23 9/16” (599) 23 9/16” (599)
COverall depth of product 22 9/16” (573) 22 9/16” (573)
DDepth of chassis (to back of front drawer panel) 21 3/4” (553) 21 3/4” (553)
EDepth of drawer front panel 13/16” (20) 13/16” (20)
FHeight of chassis131 15/16” (811) 33 11/16” (855)
GHeight of drawer front panels 29 3/4” (756) 29 3/4” (756)
HHeight of upper drawer front panel 15 1/2” (393) 17 3/16” (437)
IHeight of lower drawer front panel 14” (356) 12 1/4” (312)
JHeight from top of drawer front panel to top of chassis 5/16” (8) 5/16” (8)
KVentilation gap between drawer front panels 1/4” (7) 1/4” (7)
LHeight of toekick (customisable) 2 13/16 - 5” (72-127) 2 13/16 - 5” (72-127)
MDepth from front of drawer panel to front of toekick (adjustable)31 1/2 - 4” (38-102) 1 1/2 - 4” (38-102)
NHeight of leveling feet (adjustable) 3/8 - 2 11/16” (9-69)
2
3/8 - 2 11/16” (9-69)
2
OMaximum extension of drawer 21 9/16” (547) 21 9/16” (547)
1
includes 1/16” (2mm) high bracket slots
2
depending on adjustment of leveling feet
3
adjustable to match toekick recess on adjoining cabinetry
N
F
C
L
M
A
G
B
E
D
O
I
H
J
K
PLAN
PROFILE
FRONT
5
4 PRODUCT DIMENSIONS
DD24DA DD24DCT
PRODUCT DIMENSIONS MM MM
AOverall height of product
1
32 5/16 - 34 5/8” (820-880)
2
34 - 36 3/8” (864-924)
2
BOverall width of product 23 9/16” (599) 23 9/16” (599)
COverall depth of product 22 9/16” (573) 22 9/16” (573)
DDepth of chassis (to back of front drawer panel) 21 3/4” (553) 21 3/4” (553)
EDepth of drawer front panel 13/16” (20) 13/16” (20)
FHeight of chassis
1
31 15/16” (811) 33 11/16” (855)
GHeight of drawer front panels 29 3/4” (756) 29 3/4” (756)
HHeight of upper drawer front panel 15 1/2” (393) 17 3/16” (437)
IHeight of lower drawer front panel 14” (356) 12 1/4” (312)
JHeight from top of drawer front panel to top of chassis 5/16” (8) 5/16” (8)
KVentilation gap between drawer front panels 1/4” (7) 1/4” (7)
LHeight of toekick (customisable) 2 13/16 - 5” (72-127) 2 13/16 - 5” (72-127)
MDepth from front of drawer panel to front of toekick (adjustable)
3
1 1/2 - 4” (38-102) 1 1/2 - 4” (38-102)
NHeight of leveling feet (adjustable) 3/8 - 2 11/16” (9-69)
2
3/8 - 2 11/16” (9-69)
2
OMaximum extension of drawer 21 9/16” (547) 21 9/16” (547)
1 includes 1/16” (2mm) high bracket slots 2 depending on adjustment of leveling feet
3 adjustable to match toekick recess on adjoining cabinetry
N
F
C
L
M
A
G
B
E
D
O
I
H
J
K
PLAN
PROFILE
FRONT
Inches & MM Inches & MM

10
2 SPECIFICATIONS
2.1.4 US, TW Single Models
5
4 PRODUCT DIMENSIONS
DD24SA DD24SCT
PRODUCT DIMENSIONS MM MM
AOverall height of product
1
16 1/8” (410) 17 7/8” (454)
BOverall width of product
23 9/16” (599) 23 9/16” (599)
COverall depth of product
22 9/16” (573) 22 9/16” (573)
DDepth of chassis (to back of front drawer panel)
21 3/4” (553) 21 3/4” (553)
EDepth of drawer front panel
13/16” (20) 13/16” (20)
FHeight of chassis
1
16 1/8” (410) 17 7/8” (454)
GHeight of drawer front panel
15 1/2” (393) 17 3/16” (437)
HHeight from top of drawer front panel to top of chassis
5/16” (8) 5/16” (8)
IVentilation gap below drawer front panel
1/4” (7) 1/4” (7)
JMaximum extension of drawer
21 9/16” (547) 21 9/16” (547)
1 includes 1/16” (2mm) high bracket slots
D
J
G
H
I
E
B
F
C
A
PLAN
PROFILE
FRONT
5
4 PRODUCT DIMENSIONS
DD24SA DD24SCT
PRODUCT DIMENSIONS MM MM
AOverall height of product
1
16 1/8” (410) 17 7/8” (454)
BOverall width of product 23 9/16” (599) 23 9/16” (599)
COverall depth of product 22 9/16” (573) 22 9/16” (573)
DDepth of chassis (to back of front drawer panel) 21 3/4” (553) 21 3/4” (553)
EDepth of drawer front panel 13/16” (20) 13/16” (20)
FHeight of chassis
1
16 1/8” (410) 17 7/8” (454)
GHeight of drawer front panel 15 1/2” (393) 17 3/16” (437)
HHeight from top of drawer front panel to top of chassis 5/16” (8) 5/16” (8)
IVentilation gap below drawer front panel 1/4” (7) 1/4” (7)
JMaximum extension of drawer 21 9/16” (547) 21 9/16” (547)
1
includes 1/16” (2mm) high bracket slots
D
J
G
H
I
E
B
F
C
A
PLAN
PROFILE
FRONT
Inches & MM Inches & MM

11
2 SPECIFICATIONS
2.2 Clearances & Dimensions
2.2.1 AA, GB, EU, DK, PF, SG Double Models
5
4 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 13 mm
clearance
from a corner
cupboard
Bracket slots
min. 2 mm
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD60DA DD60DC
CABINETRY DIMENSIONS MM MM
P
Inside height of cavity* min. 820 min. 820
Q
Inside width of cavity 600 600
R
Inside depth of cavity min. 560 min. 560
S
Recommended height of adjacent cabinet space 720 720
T
Height of toekick space* 100-160 100-160
* depending on adjustment of levelling feet
5
4 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 13 mm
clearance
from a corner
cupboard
Bracket slots
min. 2 mm
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD60DA DD60DC
CABINETRY DIMENSIONS MM MM
P
Inside height of cavity* min. 820 min. 820
Q
Inside width of cavity 600 600
R
Inside depth of cavity min. 560 min. 560
S
Recommended height of adjacent cabinet space 720 720
T
Height of toekick space* 100-160 100-160
* depending on adjustment of levelling feet
5
4 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 13 mm
clearance
from a corner
cupboard
Bracket slots
min. 2 mm
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD60DA DD60DC
CABINETRY DIMENSIONS MM MM
PInside height of cavity* min. 820 min. 820
QInside width of cavity 600 600
RInside depth of cavity min. 560 min. 560
SRecommended height of adjacent cabinet space 720 720
THeight of toekick space* 100-160 100-160
* depending on adjustment of levelling feet

12
2 SPECIFICATIONS
2.2.2 AA, GB, EU, DK, PF, SG Single Models
5
4 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 13 mm
clearance
from a corner
cupboard
min. 2 mm
clearance
to adjacent
cupboard door
M
L
K
PROFILE
PLAN
DD60SA DD60SCT
CABINETRY DIMENSIONS MM MM
K
Inside height of cavity min. 412 min. 456
L
Inside width of cavity 600 600
M
Inside depth of cavity min. 560 min. 560
()
min.
412mm
min.
456mm
KK
Dishwasher Dishwasher
DD60SA
(Standard height models)
DD60SCT
(Tall height models)
Oven
Cavity height options allow you to match dishwasher with your cabinetry or companion products
Bracket slots
5
4 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 13 mm
clearance
from a corner
cupboard
min. 2 mm
clearance
to adjacent
cupboard door
M
L
K
PROFILE
PLAN
DD60SA DD60SCT
CABINETRY DIMENSIONS MM MM
KInside height of cavity min. 412 min. 456
LInside width of cavity 600 600
MInside depth of cavity min. 560 min. 560
()
min.
412mm
min.
456mm
KK
Dishwasher Dishwasher
DD60SA
(Standard height models)
DD60SCT
(Tall height models)
Oven
Cavity height options allow you to match dishwasher with your cabinetry or companion products
Bracket slots
5
4 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 13 mm
clearance
from a corner
cupboard
min. 2 mm
clearance
to adjacent
cupboard door
M
L
K
PROFILE
PLAN
DD60SA DD60SCT
CABINETRY DIMENSIONS MM MM
K
Inside height of cavity min. 412 min. 456
L
Inside width of cavity 600 600
M
Inside depth of cavity min. 560 min. 560
()
min.
412mm
min.
456mm
KK
Dishwasher Dishwasher
DD60SA
(Standard height models)
DD60SCT
(Tall height models)
Oven
Cavity height options allow you to match dishwasher with your cabinetry or companion products
Bracket slots

13
2 SPECIFICATIONS
2.2.3 US, TW Double Models
6
5 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 1/2” (13 mm)
clearance from a
corner cupboard
min. 1/16” (2 mm)
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD24DA DD24DCT
CABINETRY DIMENSIONS MM MM
PInside height of cavity* min. 32 5/16”
(820) min. 34” (864)
QInside width of cavity 23 5/8”
(600) 23 5/8” (600)
RInside depth of cavity min. 22 1/16”
(560) min. 22 1/16” (560)
SRecommended height of adjacent cabinet space 30”
(762) 30” (762)
THeight of toekick space*
2 3/8 - 4 3/4” (60-120) 3 15/16” - 6 5/16” (100-160)
* depending on adjustment of leveling feet
6
5 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 1/2” (13 mm)
clearance from a
corner cupboard
min. 1/16” (2 mm)
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD24DA DD24DCT
CABINETRY DIMENSIONS MM MM
P
Inside height of cavity* min. 32 5/16” (820) min. 34” (864)
Q
Inside width of cavity 23 5/8” (600) 23 5/8” (600)
R
Inside depth of cavity min. 22 1/16” (560) min. 22 1/16” (560)
S
Recommended height of adjacent cabinet space 30” (762) 30” (762)
T
Height of toekick space*
2 3/8 - 4 3/4” (60-120) 3 15/16” - 6 5/16” (100-160)
* depending on adjustment of leveling feet
6
5 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 1/2” (13 mm)
clearance from a
corner cupboard
min. 1/16” (2 mm)
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD24DA DD24DCT
CABINETRY DIMENSIONS MM MM
P
Inside height of cavity* min. 32 5/16” (820) min. 34” (864)
Q
Inside width of cavity 23 5/8” (600) 23 5/8” (600)
R
Inside depth of cavity min. 22 1/16” (560) min. 22 1/16” (560)
S
Recommended height of adjacent cabinet space 30” (762) 30” (762)
T
Height of toekick space*
2 3/8 - 4 3/4” (60-120) 3 15/16” - 6 5/16” (100-160)
* depending on adjustment of leveling feet
Inches & MM Inches & MM

14
2 SPECIFICATIONS
2.2.4 US, TW Single Models
6
5 CABINETRY DIMENSIONS
Minimum clearances from adjacent cabinetry
min. 1/2” (13 mm)
clearance from a
corner cupboard
min. 1/16” (2 mm)
clearance
to adjacent
cupboard door
R
Q
PS
T
PROFILE
PLAN
DD24DA DD24DCT
CABINETRY DIMENSIONS MM MM
P
Inside height of cavity* min. 32 5/16” (820) min. 34” (864)
Q
Inside width of cavity 23 5/8” (600) 23 5/8” (600)
R
Inside depth of cavity min. 22 1/16” (560) min. 22 1/16” (560)
S
Recommended height of adjacent cabinet space 30” (762) 30” (762)
T
Height of toekick space*
2 3/8 - 4 3/4” (60-120) 3 15/16” - 6 5/16” (100-160)
* depending on adjustment of leveling feet
6
5 CABINETRY DIMENSIONS
DD24SA DD24SCT
CABINETRY DIMENSIONS MM MM
KInside height of cavity min. 16 1/4” (412) min. 18” (456)
LInside width of cavity 23 5/8” (600) 23 5/8” (600)
MInside depth of cavity min. 22 1/16” (560) min. 22 1/16” (560)
DD60S(H)I7 DD60SC(H)TM7
min.
16 1/4”
(412mm)
min.
18”
(456mm)
KK
Dishwasher Dishwasher
DD24SA
(Standard height models)
DD24SCT
(Tall height models)
Oven
Cavity height options allow you to match dishwasher with your cabinetry or companion products
M
L
K
PROFILE
PLAN
Minimum clearances from adjacent cabinetry
min. 1/2” (13 mm)
clearance from a
corner cupboard
min. 1/16” (2 mm)
clearance
to adjacent
cupboard door
6
5 CABINETRY DIMENSIONS
DD24SA DD24SCT
CABINETRY DIMENSIONS MM MM
KInside height of cavity min. 16 1/4”
(412) min. 18” (456)
L
Inside width of cavity 23 5/8” (600) 23 5/8” (600)
M
Inside depth of cavity min. 22 1/16” (560) min. 22 1/16” (560)
DD60S(H)I7 DD60SC(H)TM7
min.
16 1/4”
(412mm)
min.
18”
(456mm)
KK
Dishwasher Dishwasher
DD24SA
(Standard height models)
DD24SCT
(Tall height models)
Oven
Cavity height options allow you to match dishwasher with your cabinetry or companion products
M
L
K
PROFILE
PLAN
Minimum clearances from adjacent cabinetry
min. 1/2” (13 mm)
clearance from a
corner cupboard
min. 1/16” (2 mm)
clearance
to adjacent
cupboard door
Inches & MM Inches & MM

15
2 SPECIFICATIONS
2.3 Plumbing Requirements
2.3.1 AA, GB, EU, DK, PF, SG Double Models
14
!5
THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE.
1
2
1
23
If space is limited
for fixing, push
hose through drain
hose support
to required height
If space is limited
for fixing, push
hose through drain
hose support
to required height
Dishwasher using drain hose joiner onto sink trap/waste tee
min. radius 200 mm
750 - 882.5 mm
750 - 882.5 mm
min. 500 mm
min. 500 mm
min. radius 200 mm
step 16
step 16
Supplied drain hose joiner to suit 19 mm waste tee
Ensure drain hose is routed straight to joiner. Remove excess drain hose material if necessary. Do not shorten the inlet hose.
Dishwasher and Ø 38 mm Standpipe
IMPORTANT! Do not connect the drain hoses to a Waste Disposal Unit, as this type of connection may lead to a blockage in the drain hoses.
750-882.5 mm
38mm
max.
120mm

16
2 SPECIFICATIONS
12
!2
THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE.
1
2
3
1
2
If space is limited
for fixing, push
hose through drain
hose support
to required height
If space is limited
for fixing, push
hose through drain
hose support
to required height
Dishwasher using drain hose joiner onto sink trap/waste tee
min. radius 200 mm
750 - 882.5 mm
750 - 882.5 mm
min. 500 mm
min. 500 mm
min. radius 200 mm
step 13
step 13
Supplied drain hose joiner to suit 19 mm waste tee
Ensure drain hose is routed straight to joiner. Remove excess drain hose material if necessary. Do not shorten the inlet hose.
Dishwasher and Ø 38 mm Standpipe
IMPORTANT! Do not connect the drain hoses to a Waste Disposal Unit, as this type of connection may lead to a blockage in the drain hoses.
750-882.5 mm
38mm
max.
120mm
2.3.2 AA, GB, EU, DK,PF, SG Single Models

17
2 SPECIFICATIONS
2.3.3 US, TW Double Models
14
1
2
!5 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE.
DRAINAGE OPTION 1
Dishwasher and Ø 1 1/2” (38 mm) Standpipe
IMPORTANT!
Ensure that drain
connection will comply with
local plumbing regulations.
min. R 8”
(200 mm)
29 1/2”-34 3/4” (750-882.5 mm)
1 1/2po
(38mm)
29 1/2 - 34 3/4” (750-883 mm)
Screw Drain hose
support to back wall
at correct height
If space is limited
for fixing, push
hose through drain
hose support
to required height max.
4 3/4po
(120mm)
step 16
min. 19 11/16” (500 mm)
15
min. R 8”
(200 mm)
IMPORTANT!
Ensure that drain
connection will comply with
local plumbing regulations.
DRAINAGE OPTION 2
Dishwasher using Air Break with Drain Hose Joiner
37 3/8” (950 mm)
Max. height to top
of Air Break
(countertop or
wall mounted)
1
2
step 16
Secure both drain
hoses to drain hose
joiner and secure to
Air Break

18
2 SPECIFICATIONS
2.3.4 US Single Models
16
1
23
min. R 8”
(200 mm)
IMPORTANT!
Ensure that drain
connection will comply with
local plumbing regulations.
DRAINAGE OPTION 3
Dishwasher using drain hose joiner onto sink trap/waste tee
29 1/2 - 34 3/4” (750-883 mm)
step 16
Supplied drain
hose joiner to suit
Ø 3/4” (19 mm)
waste tee
Ensure drain hose is routed
straight to joiner. Remove excess
drain hose material if necessary.
Do not shorten the inlet hose.
29 1/2”-34 3/4” (750-882.5 mm)
Screw Drain hose
support to back wall
at correct height
If space is limited
for fixing, push
hose through drain
hose support
to required height
max.
4 3/4po
(120mm)
min. 19 11/16” (500 mm)
13
1
2
!3 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE.
DRAINAGE OPTION 1
Dishwasher and Ø 1 1/2” (38 mm) Standpipe
IMPORTANT!
Ensure that drain
connection will comply with
local plumbing regulations.
min. R 8”
(200mm)
29 1/2” - 34 3/4” (750 - 882.5 mm)
1 1/2”
(38mm)
29 1/2 - 34 3/4” (750 - 883mm)
Screw Drain hose
support to back wall
at correct height
If space is limited
for fixing, push
hose through drain
hose support
to required height
max.
4 3/4“
(120mm)
step 14
min. 19 11/16” (500mm)

19
14
1
2
min. R 8”
(200mm)
IMPORTANT!
Ensure that drain
connection will comply with
local plumbing regulations.
DRAINAGE OPTION 2
Dishwasher using Air Break with Drain Hose Joiner
37 3/8” (950mm)
Max. height to top
of Air Break
(countertop or
wall mounted)
step 14
Secure drain hose to
drain hose joiner and
secure to Air Break
15
3
1
2
min. R 8”
(200mm)
IMPORTANT!
Ensure that drain
connection will comply with
local plumbing regulations.
DRAINAGE OPTION 3
Dishwasher using drain hose joiner onto sink trap/waste tee
29 1/2 - 34 3/4” (750 - 883mm)
step 14
Supplied drain
hose joiner to suit
Ø 3/4” (19 mm)
waste tee
Ensure drain hose is routed
straight to joiner. Remove excess
drain hose material if necessary.
Do not shorten the inlet hose.
29 1/2”- 34 3/4” (750 - 882.5mm)
Screw Drain hose
support to back wall
at correct height
If space is limited
for fixing, push
hose through drain
hose support
to required height max.
4 3/4”
(120mm)
min. 19 11/16” (500mm)
2 SPECIFICATIONS
