Fisher & Paykel DishDrawer User manual

Controls and Displays
Details many of the various controls and their respective descriptions for your DishDrawer.
Single models
Double models
Controls Description
A. Off/On
Press
to turn the dishdrawer on or off.
• Opening the drawer will automatically turn the dishwasher on.
https://producthelp.fisherpaykel.com/us/Clean/DishDrawer%E2%84%A2/Double/DD24DAX9/Quick_Start_Guide_DD24DAX9/…
Updated: Wed, 14 Oct 2020 22:58:21 GMT
Powered by
1

B. Drawer selector
(Double models
only)
Press
to scroll between drawers.
C. Wash program
selector
Press
to scroll through wash program options.
D. Start / Delay
Start
Press
to start the wash.
To pause:
Press
again. The wash stage indicator Wash and
(Double models) will flash.
• Wait for the 3 short and one long tone before opening the drawer.
Forcing it open mid cycle may cause damage or injury.
• If the drawer is not restarted within 7 minutes it will tone intermittently
until it is restarted.
To Delay start
1. Press and hold
until
appears on the display, then release. You are now in Delay start
mode.
2. Press
https://producthelp.fisherpaykel.com/us/Clean/DishDrawer%E2%84%A2/Double/DD24DAX9/Quick_Start_Guide_DD24DAX9/…
Updated: Wed, 14 Oct 2020 22:58:21 GMT
Powered by
2

until the display shows the number of hours you want to delay the
start of a wash by (1 to 12 hours).
If you scroll past 12 hours the dishwasher will exit Delay
start mode. To re-enter delay start follow step 1 above.
• The wash will start once the delay time is over, provided the drawer
is closed.
DD24 models only
If the drawer is opened after delay start has been set (for example if you
need to load more dishes), delay start will be paused after the drawer is
closed.
To restart delay start:
Close the drawer.
•Single models:
will flash.
•Double models:
and
will flash.
• Press
to resume.
Cancel wash / Cancel Delay start
Press
to cancel a wash that has already started or to cancel the Delay start
setting.
https://producthelp.fisherpaykel.com/us/Clean/DishDrawer%E2%84%A2/Double/DD24DAX9/Quick_Start_Guide_DD24DAX9/…
Updated: Wed, 14 Oct 2020 22:58:21 GMT
Powered by
3

• If there is any water in the drawer, it will automatically drain before the
dishwasher turns off.
E. Keylock /
Childlock
Keylock:
Keylock disables all the buttons – helpful when cleaning the dishwasher.
Single models
To activate:
Press and hold
until you hear one tone. The keylock indicator
will come on.
To cancel:
Press and hold
until you hear another tone and the keylock indicator stops flashing and
goes out.
Double models
To activate:
Press and hold
and
together until you hear one tone. The keylock indicator
will come on.
To cancel:
Press and hold
https://producthelp.fisherpaykel.com/us/Clean/DishDrawer%E2%84%A2/Double/DD24DAX9/Quick_Start_Guide_DD24DAX9/…
Updated: Wed, 14 Oct 2020 22:58:21 GMT
Powered by
4

and
together until you hear another tone and the keylock indicator stops
flashing and goes out.
Childlock:
Disables all the buttons and locks the drawer closed, preventing unauthorized use
by children.
Single models
To activate:
Press and hold
until you hear a second tone. The keylock indicator
will come on.
To cancel:
Press and hold
until you hear another tone and the keylock indicator stops flashing and
goes out.
Double models
To activate:
Press and hold
and
together until you hear a second tone. The keylock indicator
will come on.
https://producthelp.fisherpaykel.com/us/Clean/DishDrawer%E2%84%A2/Double/DD24DAX9/Quick_Start_Guide_DD24DAX9/…
Updated: Wed, 14 Oct 2020 22:58:21 GMT
Powered by
5

To cancel:
Press and hold
and
together until you hear another tone and the keylock indicator stops
flashing and goes out.
F. Wash program
indicators These show which program is selected.
G. Drawer indicator
(Double models
only)
White:drawer is running and selected.
Dim:drawer is running but not selected.
Flashing:drawer is paused
H. Display • Time remaining (minutes)
• Fault code numbers (see ‘If there is a fault’ in User guide).
I. Wash stage
indicators (See ‘During and after the wash cycle’).
J. Keylock/
Childlock
indicator
If lit: keylock or childlock is activated.
K. Delayed start
indicator If lit: delayed start is set.
https://producthelp.fisherpaykel.com/us/Clean/DishDrawer%E2%84%A2/Double/DD24DAX9/Quick_Start_Guide_DD24DAX9/…
Updated: Wed, 14 Oct 2020 22:58:21 GMT
Powered by
6

L. Salt indicator (Water softener models only)
If lit: salt reservoir is empty.
