Fisher & Paykel DishDrawer DS605 User manual

599464
Diagnostic Manual
DishDrawer™
MODELS:
DD605 DS605
Fisher & Paykel Appliances © 2007 - All Rights Reserved

599464 - September 2007
CONTENTS
1DIMENSIONS & SPECIFICATIONS....................................3
1.1 Product Size (mm)........................................................3
1.2 Specifications...............................................................3
2OPTION ADJUSTMENT......................................................5
2.1 Changing Setup Options..............................................5
2.1.1 Rinse Aid Setup (rA) ...........................................................5
2.1.2 Water Supply Hardness Setup (hd) (Where Fitted).............6
2.1.3 Auto Power Option (AP)......................................................6
2.1.4 End of Cycle Beeps (EC)....................................................6
2.1.5 Closed Drawer Option (Ld) .................................................7
2.1.6 Clean/Dirty Dish Symbol (dS) .............................................7
3DIAGNOSTICS ....................................................................8
3.1 DishDrawer™ Diagnostics ...........................................8
3.2 Display/Download Mode...............................................8
3.3 Optical LED Download/Fault Display ...........................8
3.4 Clearing Fault Logs......................................................8
3.5 Hardware Output Diagnostic Test Mode......................9
3.6 Fast Test Cycle ..........................................................11
3.7 Continuous Cycle Test Mode.....................................11
3.8 Temperature & Voltage Display Mode .......................13
3.9 Show Off/Showroom Wash Mode..............................13
3.10 Playing Tunes.............................................................14
4DIAGNOSTICS QUICK REFERENCE CHARTS ..............14
4.1 Fault Display/Download Mode....................................14
4.2 Hardware Output Test Mode......................................15
4.3 Fast Test Cycle ..........................................................16
4.4 Continuous Cycle.......................................................16
4.5 Temperature & Voltage Display Mode .......................16
4.6 Fault Codes................................................................17
4.7 Fault Code Description Chart.....................................18
4.8 Fault Code Problem Solving Charts...........................22
4.8.1 Poor Dry Performance ......................................................32
4.8.2 Poor Wash Performance...................................................33
5WIRING DIAGRAM............................................................38
5.1 Power Distribution Concept........................................38
5.2 Wiring Diagram...........................................................39

599464
3
1 DIMENSIONS & SPECIFICATIONS
1.1 Product Size (mm)
Height (double) 819.5 – 879.5mm
Height (single) 409mm
Width 595mm
Depth 570mm
Drawer Open
(including cabinet) 1090mm
1.2 Specifications
Electrical
NZ/AUS/UK/UE 230-240Volt AC 50Hz 10 amp/5 amp max.
USA 110-120Volt AC 60Hz 10.6 amp/5.3 amp max.
JAP 90-110Volt AC 50/60Hz 11.6 amp/5.3 amp max.
Water Inlet Valves 24Volt DC
65 ± 10 Ohms
2.5 Lt/min (0.65 US gal/min)
Japan only 4 Lt/min
Chassis P.C.B.
NZ/AUS/UK/UE 230 Volt AC
USA/JAP 120 Volt AC
Temperature Sensor 12000 Ohms @ 20oC (68oF)
(On Heater Plate) 8300 Ohms @ 30oC (86oF)
3000 Ohms @ 60oC (140oF)
Drying Fan 2 to 3 Meg Ohms
Motor 80 Volt DC 3 Phase Brushless
Drain 4200 RPM
Wash 2300 – 2850 RPM
Stator 8 ± .5 Ohms per winding
Inlet Hose 1.56m (61 inches)
1000Kpa (145 PSI)

599464
4
Drain Hose 2.01m (78 inches) from rear of cabinet
2.5m (98 inches) bottom tub
2.9m (114 inches) top tub
Detergent Dispenser 24 Volt DC
65 ± 10 Ohms
Rinse Aid Dispenser 24 Volt DC
65± 10 Ohms
Heater Plate (NZ/AUS/UK/UE) 230 Volt AC
Heater Track 50 ± 4 Ohms
Power Supply Resistor 98 + 7 Ohms
Heater Plate (USA) 120 Volt AC
Heater Track 24 ± 3 Ohms
Power Supply Resistor 24 + 3 Ohms
Heater Plate (JAP) 100 Volt AC
Heater Track 20 ± 2 Ohms
Power Supply Resistor 19 + 3 Ohms
Diverter Valve Softener Assy 24 Volt DC
65 + 10 Ohms
Brine Pump 24 Volt DC
65 + 10 Ohms

599464
5
2 OPTIONADJUSTMENT
2.1 Changing Setup Options
To enter the option adjustment mode, press POWER to turn the LCD on, then
hold the ECO button and KEYLOCK button simultaneously for 5 seconds,
ensuring that ECO is pressed first. Once the option adjustment mode is
entered, a beep is emitted and the LCD displays the letters rA. Pressing the
START/PAUSE button scrolls through the options and allows changes as
follows:-
Rinse Aid Setup (rA).
Water Supply Hardness Setup (hd). (Water softener models only)
Auto Power Option (AP).
End of Cycle Beeps (EC).
Closed Drawer Option (Ld).
Clean/Dirty Dish Symbol (dS).
Integrated and flat door models:- On an integrated or flat door
DishDrawer™ where there is no display, the option chosen is indicated by the
lights showing on the integrated badge as follows:-
Rinse Aid Setup (red light above START/PAUSE button).
Water Supply Hardness (green light above START/PAUSE button).
Auto Power Option (orange light above START/PAUSE button).
End of Cycle Beeps (green light above START/PAUSE button and ECO light
is red).
Closed Drawer Option (red light above START/PAUSE and ECO light is red).
Clean/Dirty Dish Symbol (not available on Integrated or flat door models).
Dry Enhancement Option (no light above buttons, ECO light is red).
Press POWER at any time to exit this setup mode.
2.1.1 Rinse Aid Setup (rA)
The current rinse aid setting is shown using the red LED’s on the touch switch
panel.
The amount of rinse aid dispensed into a rinse cycle can be varied to suit the
level of hardness of the local water supply. It is adjusted for 1 - 5 dispensing
levels.
(1 = approx 0.5mls (1/10) teaspoon of rinse aid, 5 = approx. 2.5mls (1½)
teaspoon of rinse aid).

599464
6
Press KEYLOCK to advance the rinse aid setting. Once the desired setting is
achieved, press POWER to exit. The rinse aid index is stored in EE memory,
so even with the power removed, the rinse aid level is retained.
2.1.2 Water Supply Hardness Setup (hd) (Where Fitted)
The current supply hardness setting is shown using the red LED’s on the
touch switch panel. One of 5 settings should be selected according to the
known hardness of the supply water. Each setting is appropriate for the
following water supply hardness:
No LED Water Softener turned off, continuous bypass of softener.
1 LED 150-250 ppm water supply hardness.
2 LEDs 250-350 ppm water supply hardness.
3 LEDs 350-450 ppm water supply hardness.
4 LEDs 450-550 ppm water supply hardness.
5 LEDs 550-625 ppm water supply hardness.
Press KEYLOCK to advance the Water Softener setting. Once the desired
setting has been achieved, press POWER to exit.
Selection of a setting affects how the Electronic Controller diverts supply
water, how much water is treated, and how much salt is used in regeneration,
in a manner that optimises the performance of the Water Softener.
2.1.3 Auto Power Option (AP)
The automatic power up sequence that occurs when the tub is opened can be
turned on or off using the KEYLOCK button. If the scrubbing brush symbol is
showing on the LCD, then the auto power up sequence will occur when the
tub is opened. If the scrubbing brush symbol is not showing, then the
DishDrawer™ will not automatically power up when the tub is opened (the
customer will need to press the power button each time they wish to use the
DishDrawer™). Press POWER to exit when the desired setting has been
selected.
2.1.4 End of Cycle Beeps (EC)
The six beeps that occur at the end of the cycle can be turned on or off using
the KEYLOCK button. If the scrubbing brush symbol is showing on the LCD,
then the end of cycle beeps are activated. If the scrubbing brush symbol is
not showing, then the end of cycle beeps are deactivated. Press POWER to
exit when the desired setting has been selected.

599464
7
2.1.5 Closed Drawer Option (Ld)
The closed drawer option can be turned on or off using the KEYLOCK button.
If the scrubbing brush symbol is showing on the LCD, then the closed drawer
option is selected and it will keep the DishDrawer™ locked at all times by
bringing the lid down. When this mode is selected, the customer needs to
press the POWER button to lift the lid whenever they want to open the
drawer. When they close the drawer again, the lid comes down automatically
after 30 seconds and locks the tub. If the scrubbing brush symbol is not
showing, then the closed drawer option is deactivated. Press POWER to exit
when the desired setting has been selected.
2.1.6 Clean/Dirty Dish Symbol (dS)
(Not available on integrated or flat door models)
The clean/dirty dish symbol can be turned on or off using the KEYLOCK
button. If the scrubbing brush symbol is showing on the LCD, then the
clean/dirty dish option is selected. This means that the end of cycle clean
dishes symbol will remain in the LCD display until the power button is pressed
to clear it. If the scrubbing brush symbol is not showing, then the clean/dirty
dish symbol will disappear when the drawer is first opened at the end of a
cycle (factory setting). Press POWER to exit when the desired setting has
been selected.

599464
8
3 DIAGNOSTICS
3.1 DishDrawer™ Diagnostics
Dishwasher Diagnostics can only be entered in Power Off mode, i.e. when
there is no display on the LCD or the badge LED’s are off. Diagnostics is
entered by holding the KEYLOCK and START/PAUSE buttons
simultaneously for 5 seconds. Ensure that KEYLOCK is pressed first.
There are currently four levels of diagnostics. To move to the next level,
press POWER. To enter a level, press START/PAUSE. Once a level has
been entered, pressing POWER will exit diagnostics completely. If no level is
entered, then the display will cycle through the four levels and exit after the
last. On entering diagnostic mode, the first level is the Display/Download
Mode.
3.2 Display/Download Mode
In this mode, all LED’s and LCD segments (except keylock) are illuminated.
3.3 Optical LED Download/Fault Display
An optical data download is available here to download all EE data to a PC or
Palm PC via the lower tub-home sensor light pipe. Hold the reader pen over
the lower tub-home sensor light pipe and press START/PAUSE to initiate the
download. A short beep indicates the start and finish of download.
The last two faults are displayed on the LCD (secondary control panel LEDs
for integrated and flat door models) during the optical download. The Current
Fault code is displayed first followed by the Previous Fault Code. To read the
Fault Code on the secondary display, refer to Section 4.7 on Fault Codes.
3.4 Clearing Fault Logs
To clear the current fault code, press the KEYLOCK button until a beep is
sounded. This action moves the current fault into the previous fault while
clearing the current fault. To clear the previous fault code, press KEYLOCK
once more until the beep is sounded.
Warning: Once a fault code has been cleared, it is permanently removed
from memory and cannot be recovered.
Press POWER to advance to the next level.

599464
9
3.5 Hardware Output Diagnostic Test Mode
This level tests all the hardware outputs and inputs. The LCD display shows
“HO”.
Press POWER to skip hardware diagnostics and advance to the next level.
Press START/PAUSE to enter hardware diagnostics.
Once hardware diagnostics has been entered, the current hardware output
being tested is indicated by letters in the LCD display, and for integrated and
flat door models the LEDs on the touch switch panel using binary encoding,
as shown in the table on the next page.
Different combinations of outputs can be switched on or off together, but the
controller will prevent higher current drawing components such as the wash
pump and the lid motors being turned on together.
Press START/PAUSE to advance to the next hardware output.
Press KEYLOCK to turn the currently displayed output on or off. If the
scrubbing brush symbol (green LED above start/pause button on integrated
and flat door models) is displayed, then that output has been switched on,
and if it is not displayed then that output is off.
Press POWER to exit at any time (all outputs will be switched off on exit).

599464
10
As mentioned on the previous page, the LCD display and touch switch panel
LEDs are illuminated to correspond to a particular hardware device. The
following table details the display order of the test.
LCD Norm LED Fast LED Deli LED Rinse
LED Hardware Output
bL Off Off Off On Backlight
Er Off Off
On Off Element Relay
Ld Off Off On On Lid Motors (will run for 10 seconds)
dd Off
On Off Off Detergent Diverter Valve
FU Off
On Off On Fill Water Valve
P1 Off
On On Off Motor Wash direction (2300-2850
rpm)
P2 Off
On On On Motor Drain direction (4200 rpm)
rd On Off Off Off Rinse Aid Dispenser (dispenses
current setting)
dF On Off Off On Drying fan
LE On Off On Off Rinse Aid LED
C1 On Off On On Water Softener Diverter Valve
C2 On On Off Off Water Softener Brine Pump
C3 On On Off On Water Softener Brine Valve
°C On On On Off Displays current water temperature.
°E On On On On Displays controller rail voltage
(C3 is used in the Factory to empty the Water Softener before the Product is
packed.)
WARNING: In diagnostic mode there is no component protection. Therefore
take care when running individual components not to overload them. It is
advisable to avoid turning the element on without placing some water in the
tub first.
NB : No fault codes will come up while in diagnostics mode.
Tub Home Sensor Test: At any time during HO test mode, the Keylock
symbol on the LCD display (Keylock LED on integrated badge) indicates the
tub position. On = Closed, Off = Open.

599464
11
3.6 Fast Test Cycle
WARNING: Only run this cycle if the DishDrawer™ is connected to the water
supply.
This level runs an 8 minute fast test cycle.
Press POWER to skip Fast Test Cycle and advance to the next level.
Press START/PAUSE to enter Fast Test cycle.
Once Fast Test Cycle is selected the DishDrawer™ goes into standby mode
and 8 minutes will be showing on the display. The test cycle is started by
pressing START/PAUSE, and the following components are run during the 8
minute cycle that follows:- Lid motors, fill valve, wash motor, element, drain
motor, drying fan.
Press POWER to exit at any time.
3.7 Continuous Cycle Test Mode
In this level the DishDrawer™ can be run continuously in any wash cycle.
Once the cycle has finished, the DishDrawer™ automatically restarts the
same wash cycle.
Press POWER to skip Continuous Cycle. As this is the last level, doing this
will exit diagnostics.
Press START/PAUSE to enter Continuous Cycle.
Once selected, the LCD backlight flashes on and off to indicate the
DishDrawer™ is in continuous cycle and the cycle starts straight away (for
integrated and flat door models the LED above the start/pause button will be
orange instead of green to indicate the DishDrawer™ is running in continuous
cycle). It will run the last cycle that had been selected prior to going into
diagnostics mode.
If it is desired to run a different cycle, exit diagnostics, turn the DishDrawer™
on as normal and select the cycle required. Then turn the DishDrawer™ off
again, re-enter diagnostics and restart the Continuous Cycle as above.
Press POWER to Exit at any time.

599464
12
The test sequence in fast cycle mode performs 33 tests. The number of any
failed test is displayed on the touch switch panel LEDs. The test sequence
continues even if a test fails. If there are multiple failures the LEDs will
change during the test.
0 = LED off, X = LED on.
LED Display
HNFDRE Test ID Test Description / Probable Cause
0 0 0 0 0X 1 Uncontrolled load on PSU (PSU volts < 30 with PSU on and no devices
turned on)
0 0 0 0 X0 2 Unrealistic zero crossing time, mains frequency non standard
0 0 0 0 XX 3 Uncontrolled load on PSU (volts dropped when PSU turned off and no
devices on)
4 Unused
0 0 0 X0 X 5 Detergent diverter not connected
0 0 0 XX 0 Fill valve not connected
0 0 0 XXX Water softener bypass valve not connected
0 0X 0 0 0 Rinse Aid pump not connected
0 0X 0 0 X Water softener brine pump not connected
0 0X 0X 0 Fan not connected
0 0X 0XX 11 Detergent diverter solenoid low resistance (shorted?)
0 0XX 0 0 Fill valve solenoid low resistance (shorted?)
0 0XX 0X Water softener bypass valve solenoid low resistance (shorted?)
0 0XXX 0 Rinse Aid pump solenoid low resistance (shorted?)
0 0XXXX Water softener brine pump solenoid low resistance (shorted?)
0 X0 0 0 0 16 Fan low resistance (shorted?)
0 X0 0 0 X 17 Lid motor 1 no current (not connected?) in down direction
0 X0 0X 0 Lid motor 1 no current (not connected?) in up direction
0 X0 0XX Lid motor 2 no current (not connected?) in down direction
0 X0 X0 0 Lid motor 2 no current (not connected?) in up direction
0 X0 X0 X 21 Lid motor 1 excessive current in down direction
0 X0 XX 0 Lid motor 1 excessive current in up direction
0 X0 XXX Lid motor 2 excessive current in down direction
0 XX 0 0 0 24 Lid motor 2 excessive current in up direction
25-29 Unused
0 XXXX 0 30 Motor FET A phase high side “shorted”
0 XXXXX Motor FET B phase high side “shorted”
X0 0 0 0 0 Motor FET C phase high side “shorted”
X0 0 0 0 X Motor FET A phase low side “shorted”
X0 0 0 X0 Motor FET B phase low side “shorted”
X0 0 0 XX 35 Motor FET C phase low side “shorted”
X0 0X 0 0 36 Motor phases AB no current (not connected?)
X0 0X 0X Motor phases BC no current (not connected?)
X0 0XX 0 38 Motor phases CA no current (not connected?)
X0 0XXX 39 Motor phases AB current excessive (shorted winding?)
X0 X0 0 0 Motor phases BC current excessive (shorted winding?)
X0 X0 0X 41 Motor phases CA current excessive (shorted winding?)

599464
13
3.8 Temperature & Voltage Display Mode
(Not available on integrated or flat door models)
During a wash cycle, the current water temperature or the power supply rail
voltage of the controller can be displayed on the LCD instead of the time
remaining. To enter temperature/voltage display mode, start a wash cycle as
normal. Initiate a keylock by pressing and holding the KEYLOCK button for 4
seconds.
Once in keylock mode, press and hold START/PAUSE for 8 seconds to enter
temperature display mode. The display now alternates between a °C symbol
and the water temperature. Pressing the START/PAUSE again changes the
display to alternate between an °E symbol and the power supply rail voltage
of the controller.
To cancel temperature/voltage display mode, press the POWER button.
3.9 Show Off/Showroom Wash Mode
This mode initiates a shop show off display and wash operation
demonstration.
With the DishDrawer™ powered up and turned on, the show off mode is
entered by pressing and holding the ECO and POWER buttons
simultaneously for 5 seconds. Ensure that ECO is pressed first.
The DishDrawer™ is now in the show off mode and cycles through all of the
LED & LCD segments.
Pressing the POWER button now puts the DishDrawer™ into the showroom
wash mode. Before running this, mode the tub should be filled with water
until it is just touching the underside of the spray arm. The showroom wash is
started by pressing the START/PAUSE button whereby the following cycle is
run:-
The lid is pulled down.
The wash motor starts and runs for 4 minutes.
The wash motor stops.
The lid is lifted.
The display counts down to zero throughout this cycle.
The DishDrawer™ turns off at the end of this cycle.

599464
14
The DishDrawer™ is still in the Showroom wash mode however, and it can be
re-run by pressing POWER and then START/PAUSE. Once show
off/showroom wash mode has been initiated, the mains power must be
removed to exit out.
3.10 Playing Tunes
Once in showroom mode, pressing the START/PAUSE button for 3 seconds
will start a tune playing. Pressing the START/PAUSE button again will toggle
the tune between Bach and the Star Spangled Banner. This feature is not
widely known about, may not be present in all models and may be removed in
future products.
4 DIAGNOSTICS QUICK REFERENCE CHARTS
4.1 Fault Display/Download Mode
Press and hold KEYLOCK, then START/PAUSE for 5 seconds.
All LEDs & LCD segments except Keylock are illuminated.
Press START/PAUSE.
This initiates pen data download via the lower tub-home light pipe. At the
same time the current and then the previous fault code will be displayed in
the LCD screen and on the secondary control panel LEDs. To read the
fault code on the secondary display, refer to Section 4.7 on fault codes.
Press KEYLOCK.
This will clear current fault code. Note: If Keylock is pressed again, the
previous fault code will be cleared. Pressing Keylock also toggles the wash
icons on the LCD on and off.
Press POWER to exit.

599464
15
4.2 Hardware Output Test Mode
Press and hold KEYLOCK, then START/PAUSE for 5 seconds.
All LEDs & LCD segments except Keylock are illuminated.
Press POWER once.
“HO” will show in the display (integrated and flat door models: Heavy,
Normal, Fast, Delicate, Rinse LEDs showing).
Press START/PAUSE.
Scroll through the following outputs using Start/Pause. Turn the outputs on
& off using Keylock button.
Press POWER to exit.
Note: Scrubbing brush symbol = output on, no scrubbing brush = output off
(on integrated and flat door models a green LED above the start/pause
button is used in place of the scrubbing brush).
LCD Norm Fast Deli Rinse Hardware Output
Display LED LED LED LED
bL Off Off Off
On Backlight
Er Off Off
On Off Element Relay
Ld Off Off On On Lid Motors (will run for 10
seconds)
dd Off On Off Off Detergent Diverter Valve
FU Off
On Off On Fill Water Valve
P1 Off
On On Off Motor Wash direction (2300-
2850 rpm)
P2 Off
On On On Motor Drain direction (4200
rpm)
rd On Off Off Off
Rinse Aid Dispenser
(dispenses current setting)
dF On Off Off On Drying fan
LE On Off On Off Rinse Aid LED
C1 On Off On On Water Softener Diverter
Valve
C2 On On Off Off Water Softener Brine Pump
C3 On On Off On Water Softener Brine Valve
°COn On On Off Displays current water
temperature.
°EOn On On On Displays controller rail
voltage
Tub Home Sensor test:- Keylock symbol on = tub closed, off = tub open

599464
16
4.3 Fast Test Cycle
Press and hold KEYLOCK, then START/PAUSE for 5 seconds.
All LEDs & LCD segments except Keylock are illuminated.
Press POWER twice.
“FC” will show in the display (integrated and flat door models: Heavy,
Normal, Delicate, Rinse LEDs showing).
Press START/PAUSE twice.
The 8 minute fast test cycle will start.
Press POWER to exit.
4.4 Continuous Cycle
Press and hold KEYLOCK, then START/PAUSE for 5 seconds.
All LEDs & LCD segments except Keylock are illuminated.
Press POWER three times.
“CC” will show in the display (integrated and flat door models: Heavy,
Normal, Rinse LEDs showing).
Press START/PAUSE.
The last cycle that had been selected prior to going into diagnostics mode
will be run continuously.
Press POWER to exit.
4.5 Temperature & Voltage Display Mode
(Not available on integrated or flat door models.)
Start a wash cycle running.
Press & hold KEYLOCK for 4 seconds.
Keylock will be activated.
Press & hold START/PAUSE for 8 seconds.
LCD will now alternate between °C symbol and the water temperature.
Press START/PAUSE.
LCD will now alternate between °E symbol and the controller’s rail voltage.
Press & hold KEYLOCK for 4 seconds.
Keylock is deactivated.
Press POWER to exit.

599464
17
4.6 Fault Codes
There are 10 F (fatal) faults, which are displayed in the LCD along with the
symbol of a spanner (not on integrated or flat door models). A fatal fault will
usually require the assistance of a qualified service person.
In addition, there are 4 U (user) faults.
U1 indicates the machine had failed to prime within a certain length of time
usually because the tap has not been turned on. For this reason, at the same
time a U1 comes up in the display we also show the symbol of a tap.
U2 indicates restricted lid travel. The customer can usually rectify a U1 or U2
fault.
A U3 fault is not displayed to the customer, but is recorded in the fault history
and displayed in Smart Tool. It is logged if the motor senses prime in less
than 20 seconds because water was left in the tub from a previous fill, or
because it has filled too quickly. The product will drain and refill up to 5 times
before logging the fault and continuing on with the cycle.
On a double drawer model, a U4 fault indicates an F fault with the other tub
that has disabled the power supply.
In the Integrated and flat door models, an LCD is not available, and the
presence of a fault is indicated by a red centre (start/pause) LED, with the
fault number indicated by the red LEDs on the touch switch panel.
Once a fault is repaired, it can be cleared by pressing the POWER button. If
the fault is still present, then it will not clear.
A fatal or user fault is accompanied by a continuous pulsating beep, which
can be turned off by pressing either the POWER, START/PAUSE, or KEY
LOCK button. This also stops the drain pump running for an F1 fault.
The last two faults are logged into EE memory.
If a tub is forced open, the product simply pauses as if someone had pressed
the start/pause button.
Except for U4, F1, F3, F8 and F9 faults, the other tub can still be used on a
double drawer model.

599464
18
Once the fault has been cleared for an F3, F8 or F9 fault, the power needs to
be disconnected and reconnected to reset the isolation relay before the
product can be used again.
4.7 Fault Code Description Chart
The following chart is a quick reference guide on fault codes. To read a fault
code off an integrated or flat door model, refer to the LED Display column on
the chart below. The LED that has activated on the secondary display
indicates which fault code has occurred.
To make diagnostics easier, a test handle can be made for use on integrated
or flat door models using a cut down handle and a DD605 PCB LCD. This will
not be able to be used on DD603 products, nor can a DD603 test handle be
used on DD605 products.
Fault
Code LED Display Fault Possible Causes
F1 Rinse LED. The bottom
controller flood
sensor
detector has
been activated
for more than
six seconds.
• Lid not closing.
• Overfilling.
• Foaming.
• Not draining.
• Lid seal damaged.
• Dispenser or water softener or
their seals leaking.
• Damaged water inlet or drain
hoses.
• Leaking heater plate or motor
seals, or drain o-ring seals.
• Yoke jammed or broken.
• Inlet hose to inlet valve
connection loose.
• Inlet valve body leak.
• Heater plate damage (chipped
enamel).
• Dry F1 – PCB mains filter,
harness or connectors,
electronic controller.

599464
19
Fault
Code LED Display Fault Possible Causes
F2 Delicate
LED. The controller has not
sensed the
motor rotating.
• Foreign object has jammed the
rotor.
• The rotor has failed.
• Hall sensor connector or wiring
fault at hall sensor or
controller.
• The hall sensor has failed.
• Motor stator winding or
connection open circuit.
• The electronic controller has
failed.
• PCB mains filter has failed.
F3 Delicate
and Rinse
LEDs.
The water
temperature
has been
sensed as
greater than
85°C (185°F).
• The incoming water is greater
than 85°C (185°F).
• The element has failed closed
circuit.
• The temperature sensor on the
heater plate has failed.
• The electronic controller has
failed.
F4 Fast LED. No
temperature
increase has
been sensed
for about 4
hours while
the element is
on.
• The element is not connected.
• The element has failed open
circuit.
• The temperature sensor has
failed.
• The electronic controller has
failed.
F5 Fast and
Rinse
LEDs.
Lid motor
current too
high during
start.
• Lid jammed up or down.
• The electronic controller has
failed.
F6 Fast and
Delicate
LEDs.
Lid motors ran
but did not
reach stall
current.
• Lid actuator off yoke or slide.
• Yoke off lid.
• Faulty lid actuator.

599464
20
Fault
Code LED Display Fault Possible Causes
F7 Fast,
Delicate
and Rinse
LEDs.
No lid motor
current
detected.
• Lid actuator not connected.
• PCB mains filter and controller
connectors.
• Faulty PCB mains filter.
• Faulty electronic controller.
F8 Normal
LED. Earth leakage fault.
• Test for earth leakage.
• Connectors and earth
connections fitted correctly.
• Damaged harnesses.
• Water damaged harness,
connector, or controller.
F9 Normal and
Rinse LED. Power supply /
controller fault.
• Caused by F3, F8 or F9 faults.
• Check coils and motor
windings.
• Check lid actuators.
• Check controller for signs of
damage.
• Check PCB mains filter and
controller connectors.
• Check heater plate harness
and connectors.
• Replace electronic controller.
• Replace PCB mains filter.
FF Normal,
Fast,
Delicate
and Rinse
LEDs.
Top tub not
responding.
• Chassis harness or
connectors.
• Faulty top controller.
• Faulty PCB mains filter.
