INTRODUCTION
Welcome to your new condenser dryer
Thank you for purchasing a Fisher & Paykel clothes dryer. Your new dryer gives you the
convenience of tumble drying and your clothes the advantage of not being subjected to
the harsh overdrying effects of the sun. Your clothes will feel softer, retain their shape
better and require less ironing.
At Fisher & Paykel we aim to provide innovative products that are simple to use,
ergonomic, energy efficient and kind to the environment. Thousands of tons of laundry
and 75years of laundry experience have been programmed into your dryer to help give
you the best possible performance.
Your dryer has the benefit of not needing to be vented outside, instead it condenses the
moisture from the clothes and collects this in a water tank, or can pump it directly into
adrain.
This dryer has been specifically designed to complement our front loading Fisher & Paykel
WashSmart™ and FabricSmart™ washers. We are proud of this dryer and trust it will serve
you well for many years.
Your condensing dryer has numerous cycles and options so you can perform every
drying task (including flat drying) with ease, allowing you to spend less time in the
laundry. With the ability to automatically sense when your clothes are dry, your dryer is
more efficient, making it kinder on your wallet and the environment.
Please take the time to read these instructions carefully before you begin using your
dryer. Following the advice in this User guide will ensure you get the performance
you expect from your dryer and that you get the best possible results. Keep these
instructions for future reference and pass them on with your dryer, if it changes hands.
We hope you enjoy your new dryer. We have certainly enjoyed designing it for you.
Condenser clothes dryer
EN

4
SAFETY AND WARNINGS
Read all instructions before using the appliance.
!WARNING!
Electric Shock Hazard
Follow the safety precautions outlined in this User guide
Failure to do so can result in death or electric shock.
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
To reduce the risk of fire, explosion, electric shock, or injury to persons when using
your appliance, follow basic precautions, including the following:
 Read all instructions before using the appliance.
 This dryer, when installed, must be electrically grounded in accordance with local
codes, or in the absence of local codes, with the National Electrical Code,
ANSI/NFPA70, or the Canadian Electrical Code, CSA C22.1.
 DO NOT dry articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning solvents, or other flammable or explosive
substances, as they give off vapors that could ignite or explode.
 DO NOT place items exposed to cooking oils in your dryer. Items contaminated with
cooking oils may contribute to a chemical reaction that could cause a load to catch
fire. To reduce the risk of fire due to contaminated loads, the final part of the tumble
dryer cycle occurs without heat (cool down period). Avoid stopping a tumble dryer
before the end of the drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
 DO NOT allow children to play on or in this appliance. Close supervision of children is
necessary when this appliance is used near children.
 Before the appliance is removed from service or discarded, remove the door to the
drying compartment.
 DO NOT reach into the appliance if the drum is moving.
 DO NOT install or store this appliance where it will be exposed to the weather.
 DO NOT tamper with controls.
 DO NOT repair or replace any part of this appliance or attempt any servicing unless
specifically recommended in the user-maintenance instructions or in published user-
repair instructions that you understand and have the skills to carry out.
 DO NOT use fabric softeners or products to eliminate static unless recommended by
the manufacturer of the fabric softener or product.
 DO NOT dry articles containing foam rubber or similarly textured rubber-like materials.
 Clean lint screen before or after each load.
 DO NOT operate the dryer without the lint filter and condenser in place.
 DO NOT store combustible materials, gasoline or other flammable liquids near the
dryer. Keep area around the air intake vent on the front of the dryer and adjacent
surrounding areas free from the accumulation of lint, dust and dirt.
 The interior of the appliance should be cleaned periodically by qualified service
personnel.

5
SAFETY AND WARNINGS
 Unplug the appliance or turn off the circuit breaker before servicing. Pressing the
‘POWER’ or button DOES NOT disconnect power.
 DO NOT operate this appliance if it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts, including a damaged cord or plug.
 DO NOT spray any type of aerosol into, on or near dryer at any time. DO NOT use
any type of spray cleaner when cleaning dryer interior. Hazardous fumes or electrical
shock could occur.
 See ‘Electrical connection information for electric dryers’ located in the Installation
Instructions for grounding instructions.
EN

6
INSTALLATION INSTRUCTIONS
Before you begin
Read these instructions completely and carefully.
IMPORTANT!
Save these instructions for local electrical inspector’s use.
IMPORTANT!
Observe all governing codes and ordinances.
 Install the clothes dryer according to the manufacturer’s instructions and local codes.
 Note to Installer – Be sure to leave these instructions with the Consumer.
 Note to Consumer – Keep these instructions for future reference.
 Clothes dryer installation must be performed by a properly trained installer.
 Before the old dryer is removed from service or discarded, remove the dryer door.
 Service information and the wiring diagram are located in the control console.
 Do not allow children on or in the appliance. Close supervision of children is necessary
when the appliance is used near children.
 Proper installation is the responsibility of the installer.
 Product failure due to improper installation is not covered under the limited warranty.
 Install the dryer where the temperature is above 50°F (10°C) for satisfactory operation
of the dryer control system.
!WARNING!
Fire Hazard
 Clothes dryer installation must be performed by a properly trained
installer.
 Install the clothes dryer according to these instructions and local codes.
 DO NOT install or store this appliance in any location where it could be
exposed to water or weather.
 To reduce the risk of severe injury or death, follow all installation
instructions.
 Save these instructions. (Installers: Be sure to leave these instructions
with the customer.)
If you are planning to stack the washer and dryer, order a Stacking Kit separately for
thisdryer.
Unpacking your dryer
Tilt the dryer sideways and remove the
foam shipping pads by pulling at the
sides and breaking them away from the
dryer legs. Besure to remove all of the
foam pieces fromaround the legs.
Remove and retain the bag containing
the literature.

7
INSTALLATION INSTRUCTIONS
Product dimensions
DE4024P
PRODUCT DIMENSIONS inches (mm)
AOverall height of product* 331/4” (845)
BOverall width of product 237/16” (595)
COverall depth of product
(including dial and door whenclosed)
251/4” (640)
DDepth to door open 42” (1067)
MAXIMUM CAPACITY† kg
8.0
* Note:
With leveling legs retracted: 331/4” (84.5cm).
With leveling legs fully extended: 335/8” (85.4cm).
Stacked: 661/2” (168.9cm).
† Capacity refers to the maximum dry weight of items the machine can dry at any one time.
Note: some cycles have a lower maximum capacity (see the ‘Drying cycles’ section).
Electrical connection dimensions
Power cords
Fisher & Paykel Appliances strongly
recommends the use of factory
specified parts. Select the power cord
to fit your installation requirements.
A
B C
D
201/2” (52.1cm)
30”
(76.2cm)
Back view
EN

8
INSTALLATION INSTRUCTIONS
Requirements for alcove or closet installation
!WARNING!
Explosion Hazard
 Keep flammable materials and vapors, such as gasoline, away from dryer.
 Place dryer at least 18” (46cm) above the floor for a garage installation.
 Failure to do so can result in death, explosion, or fire.
 Minimum clearance between dryer cabinet and adjacent walls or other surfaces is:
3/4” (20mm) sides, front, and top
1” (25.4mm) rear
 Consideration must be given to provide adequate clearance for installation and service.
 Closet doors must be louvered or otherwise ventilated and have at least 60 square
inches (387cm2) of open area. If the closet contains both a washer and a dryer, doors
must contain a minimum of 120 square inches (774cm2) of open area.
Minimum clearance other than alcove or closet installation
 Minimum clearance to combustible surfaces and for air opening are:
3/4” (20mm) sides and top
1” (25.4mm) rear
 Consideration must be given to provide adequate clearance for installation and service.
Mobile or manufactured home installation
 Installation MUST conform to the MANUFACTURED HOME CONSTRUCTION AND
SAFETY STANDARD, TITLE 24, PART 3280 or STANDARD FOR MOBILE HOMES
CAN/CSA-Z240 MH, or, when such standards are not applicable, with AMERICAN
NATIONAL STANDARD FOR MOBILE HOME, ANSI/NFPA NO. 501B.
 Provide an opening with a free area of at least 25 square inches (161cm2)for introduction
of outside air into the dryer room.
 See the sections for electrical connection information.
Bathroom or bedroom installation
The installation must conform with local codes or, in the absence of local codes, with
the NATIONAL ELECTRICAL CODE, ANSI/NFPA NO. 70 (for electric dryers).

9
INSTALLATION INSTRUCTIONS
Undercounter installation
If an undercounter installation is desired:
 No special dryer installation kit is required.
 If the dryer is installed alone, a minimum of 60 square inches (387cm2) of open area is
required. If a washer and dryer are installed together, a minimum of 120 square inches
(774cm2) of open area is required.
Door fully open
1113/16” (300mm)
25” (635mm)
Dryer installed alone
Washer and dryer installed together
Door fully open
1113/16” (300mm)
Door fully open
1113/16” (300mm)
493/16” (1250mm)
163/4”
(427mm)
min 1”
(25.4mm)
34” (865mm)
min clear space required
263/16” (665mm)
43” (1090.4mm)
163/4”
(427mm)
min 1”
(25.4mm)
34” (865mm)
min clear space required
263/16” (665mm)
43” (1090.4mm)
EN

10
INSTALLATION INSTRUCTIONS
Connecting an electric dryer
Tools you will need:
Slip-joint pliers Phillips
screwdriver
Flat-blade
screwdriver
Level
Materials you will need:
Safety glasses Gloves 3/4” Strain relief
(UL recognized)
Dryer power cord kit (not provided with dryer)
UL rated 120/240V, 30A with 3 or 4 prongs. Identify the
plug type as per the house receptacle before purchasing
line cord. Stacking installations may require a power cord
up to 6feet (1.8m) in length.
Before making the electrical connection, turn off the
circuit breaker(s) or remove the dryer’s circuit fuse(s) at
the electrical box. Be sure the dryer cord is unplugged
from the wall.
IMPORTANT!
Never leave the access cover off the terminal block.

11
INSTALLATION INSTRUCTIONS
Electrical connection information for electric dryers
For electrical connections using a power cord:
!WARNING!
Fire Hazard
 Use a new UL-listed 240V 30 amp dryer power supply cord with closed
ring terminals or spade terminals with upturned ends.
 Use a UL-listed strain relief.
 Disconnect power before making electrical connections.
 Connect neutral wire (white or center wire) to center terminal.
 Ground wire (green or bare wire) must be connected to green ground
connector.
 Connect remaining two supply wires to remaining two terminals.
 Securely tighten all electrical connections.
 Replace the terminal block cover.
 Failure to do so can result in death, fire or electrical shock.
Grounding instructions
For a grounded, cord-connected dryer:
This dryer must be grounded. In the event of a malfunction or breakdown, grounding
will reduce the risk of electric shock by providing a path of least resistance for electric
current. This dryer uses a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
WARNING!
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician, or service representative or
personnel, if you are in doubt as to whether the appliance is properly grounded.
DO NOT modify the plug on the power supply cord. If it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
SAVE THESE INSTRUCTIONS
EN

12
INSTALLATION INSTRUCTIONS
Electrical connection information for electric dryers
For direct wire connections:
!WARNING!
Fire Hazard
 Use 10 gauge copper wire.
 Use a UL-listed strain relief.
 Disconnect power before making electrical connections.
 Connect neutral wire (white or center wire) to center terminal.
 Ground wire (green or bare wire) must be connected to green ground
connector.
 Connect remaining two supply wires to remaining two terminals.
 Securely tighten all electrical connections.
 Replace the terminal block cover.
 Failure to do so can result in death, fire or electrical shock.
Grounding instructions
For a permanently connected dryer:
This dryer must be connected to a grounded metal, permanent wiring system, or an
equipment-grounding conductor must be run with the circuit conductors and connected
to the equipment-grounding terminal on the appliance.
WARNING!
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician, or service representative or
personnel, if you are in doubt as to whether the appliance is properly grounded.
SAVE THESE INSTRUCTIONS

13
INSTALLATION INSTRUCTIONS
Connecting dryer using 4-wire connection (must be used for mobile home installation)
Note: since January 1, 1996, the National Electrical Code requires that new constructions
use a 4-wire connection to an electric dryer. A 4-wire cord must also be used where
local codes do not permit grounding through the neutral. 3-wire connection is NOT for
use on new construction.
L1 NL2
Cover
Green wire from
power cord
3/4” Strain relief
and bracket
4 #10 AWG minimum copper conductors or 120/240V 30A power supply cord kit
marked for use with dryers and provided with closed loop or spade terminals with
upturned ends (not supplied)
1Turn off the circuit breaker(s) (30 amp) or remove the dryer’s circuit fuse at the
electrical box.
2Be sure the dryer cord is unplugged from the wall receptacle.
3Remove the power cord cover located at the upper back.
4Remove green ground screw and retain for use in Step 7. Remove center screw
(markedN) in terminal block. Remove and discard ground strap.
5Install 3/4 in. UL-recognized strain relief to power cord entry hole. Bring power cord
through strain relief and bracket.
6Connect power cord as follows:
A. Connect the 2 hot lines to the outer screws of the terminal block (marked L1 and L2).
B. Connect the neutral (white) line to the center of the terminal block (marked N).
7Attach ground wire of power cord with the green ground screw (hole above strain relief
bracket). Tighten all terminal block screws (3) securely.
8Properly secure power cord to strain relief and bracket.
9Reinstall the cover.
IMPORTANT!
Never leave the cover off of the terminal block.
EN

14
INSTALLATION INSTRUCTIONS
Connecting dryer using 3-wire connection
If required, by local code, install external ground (not provided) to grounded metal, cold
water pipe, or other established ground determined by a qualified electrician.
L1 NL2
Cover
Ground strap
3/4” Strain relief
and bracket
3 #10 AWG minimum copper conductors or 120/240V 30A power supply cord kit
marked for use with dryers and provided with closed loop or spade terminals with
upturned ends (not supplied)
3-wire connection
 Not for use in Canada.
 DO NOT use for Mobile Home Installations.
 NOT for use on new construction.
 NOT for use on recreational vehicles.
 NOT for use in areas where local codes prohibit grounding through the neutral
conduction.
1
Turn off the circuit breaker(s) (30 amp) or remove the dryer’s circuit fuse at the
electrical box.
2
Be sure the dryer cord is unplugged from the wall receptacle.
3
Remove the power cord cover located at the upper back.
4
Install 3/4 in. UL-recognized strain relief to power cord entry hole. Bring power cord
through strain relief and bracket.
5
Connect power cord as follows:
A. Connect the 2 hot lines to the outer screws of the terminal block (marked L1 and L2).
B. Connect the neutral (white) line to the center of the terminal block (marked N).
6
Be sure ground strap is connected to green ground screw on cabinet rear. Tighten all
terminal block screws (3) securely.
7
Properly secure power cord to strain relief and bracket.
8
Reinstall the cover.
IMPORTANT!
Never leave the cover off of the terminal block.

15
INSTALLATION INSTRUCTIONS
Connecting the drain hose
Draining water without using the water tank
You can use the dryer without using the water
tank by following the procedures below.
To connect the drain hose:
1
Disconnect the drain hose A.
2
Connect the drain hose Ato the other hole.
3
Connect accessory hose B(long drain hose)
adjacent to hose A.
 When connecting hose B, take care that
the height of the hose does not exceed
58”(147cm).
 After connecting the drain hose, you can
now directly drain the condensed water to
a standpipe or washstand.
4
Over the edge of a wash basin: The
drain hose must be placed lower than
58” (147cm). To keep the drain hose
spout bent, use the plastic hose guide
as supplied with the washer. Secure the
guide to the wall with a hook or to the
tap with a piece of string to prevent the
drain hose from moving.
5
Assemble the drain hose and the hose
guide and fix them with the cable-tie.
Do not push the drain hose in the
standpipe any further than 4” (10cm).
Pushing the drain hose further in the
standpipe can cause leaking.
Back view
A
A
B
Drain hose Hose guide
Cable ties
58”
(147cm)
Max.
EN

16
INSTALLATION INSTRUCTIONS
Final setup
1Level the dryer
Stand the dryer upright near the final location
and adjust the four leveling legs at the corners to
ensurethat the dryer is level from side to side and
front to rear.
2Plug dryer in
Note: stacking installations may require a power
cord up to 6feet (1.8m) in length.
3Dryer startup
Press the ‘POWER’ button.
Note: if the dryer has been exposed to temperatures
below freezing for an extended period of time, allow
it to warm up before pressing ‘POWER’. Otherwise,
the display will not come on.
The dryer is now ready for use.
49-90571 19
Ensure proper
ground exists
before use.
Levelling the feet

17
INSTALLATION INSTRUCTIONS
Completing the installation
Installation test cycle
IMPORTANT!
Ensure the installation test cycle is completed before you dry any items in your dryer.
This is to check that your dryer is installed correctly and that it is functioning properly
prior to use.
1Turn your dryer on by pressing the ‘POWER’ button.
2Select the ‘Time Dry’ (30 mins) cycle. Ensure the drum is empty and the door is closed
(you will hear it click shut).
3Touch the button. The drum will start rotating.
 Observe the machine for any problems.
 The dryer will beep and display any faults on the screen if there are any problems.
Refer to pages 28 and 29.
4At the completion of the cycle open the door and check that there is warmth inside the
dryer. This indicates the dryer is operating normally.
IMPORTANT!
If there are any problems, you must address these before proceeding with normal use.
The dryer will automatically turn off at the end of the cycle if there are no problems.
Before you start, it is a good idea to go through the following checklist:
1Has the packaging been removed?
2Is the machine correctly levelled, and the cabinet corners clear of the floor and walls?
3Are the water tank, condenser and lint filter correctly in place?
4Has the power cord been connected to an appropriate power supply and the power
turned on?
5Have you performed the installation test cycle?
6If external draining is preferred, is the drain hose attached to the correct outlet and
hooked into a standpipe or tub?
EN

18
GETTING STARTED
WARNING!
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT
SAFETY INSTRUCTIONS before operating this appliance.
 Check the lint filter is clean and the water tank is empty before every load. Ensure
both are replaced correctly before using your dryer.
 Sort and load items into the dryer drum, ensuring no items are in the way of the door.
Close the door (you will hear it click shut).
1Press ‘POWER’ to activate your dryer.
2Your dryer will default to the ‘Everyday’ cycle. Select your desired drying cycle by
turning the SmartTouch™ Control Dial.
3Select your preferred drying options, using the SmartTouch™ buttons on the right hand
side of the panel (if you wish to select options different from the default options for
thecycle).
4Touch the button to start the cycle.
Condenser dryer control panel
1 2
