Fisher & Paykel DH9060H1 User manual

USER GUIDE
NZ AU
HEAT PUMP CLOTHES DRYER
DH9060H1 & DH9060HG1 models

3
CONTENTS
Safety and warnings 4
First use 8
Setting a cycle 11
Loading suggestions 14
Dry cycles 16
Cycle settings 18
Cycle options 19
W-Fi connection and Remote Mode 21
Cleaning 23
Cleaning the lint filter 24
Emptying the water tank 25
Cleaning the condenser filter 26
Troubleshooting 29
Fault codes 34
Manufacturer’s Warranty and Service Guide 35
Registration
To register your product visit our website: fisherpaykel.com/register

4
SAFETY AND WARNINGS
WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• If you are using an extension cord or a portable
electrical outlet device (eg multi-socket outlet
box), ensure that it is positioned so that it does
not come into contact with water or moisture.
WARNING!
Fire Hazard
• Only dry fabrics that have been washed
with water.
• Do not use heat to dry articles containing
foam rubber or similarly textured rubber–like
materials, dry on COOL AIR.
• Never stop a tumble clothes dryer before the
end of the drying cycleunless all items are
removed and spread out in order to dissipate
the heat.
• A clothes dryer produces combustible lint;
the lint filter must be cleaned before each
drying cycle.
• Failure to follow the warnings outlined in these
user instructions can cause a fire hazard.
• Failure to follow these instructions can result in
death or personal injury.

5
SAFETY AND WARNINGS
READ AND SAVE THIS GUIDE
WARNING!
Read Safety Guide. Failure to follow all guides and rules could cause personal injury or
property damage. Use this appliance only for the intended purpose as described in the
user guide and installation guide of this appliance. When using this appliance, always
exercise basic safety precautions including the following:
General
zDo not touch or operate the appliance with wet hands or with bare feet.
zA damaged power cord must be replaced by a Fisher & Paykel trained and supported
service technician or similarly qualified person in order to avoid a hazard. Do not use
the machine until it has been repaired to avoid a risk of electric shock.
zDo not operate this appliance if it has been damaged during transport. Contact your
Fisher&Paykel dealer or Fisher & Paykel trained and supported service technician.
zThis product has been designed for personal, family or household use. This product is
not designed for any commercial use. Any commercial use will terminate this products
manufacturer’s warranty.
zThis appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,unless
they are supervised or given instructions on how to use the applianceby someone
responsible for their safety.
zSupervise children to ensure they do not play with the appliance or climb inside
thedrum.
zDo not swing on or put weight on the door.
zUndergarments that contain metal reinforcements should not be placed in the dryer.
Damage to the dryer can result if the metal reinforcements come loose during drying. If
you wish to dry these items use a drying rack or place in a garment bag.
zCheck and remove all objects from pockets, eg lighters and matches.
zItems should go through the cooling phase in the final part of the cycle. This ensures
items are left at a temperature where they will not be damaged. Ifforany reason the
cycle is stopped before it has finished, dry clothes should be removed immediately and
not left in the appliance. Items should be quickly spread out flat to cool so heat can
dissipate, not left bunched up, eg in a clothes basket or in a pile.
zIn the event of a power outage the cycle will be paused when power is restored. Press
start to resume the cycle.
zThe only user-removable parts of the dryer are the filters, water tank and drying rack.
No other parts are designed to be removed by anyone other than aFisher & Paykel
trained and supported service technician.
zFor problems that cannot be solved from information in the user guide, turn off
and unplug your appliance and contact a Fisher & Paykel trained and supported
service technician.
zNever attempt to repair the appliance yourself.
zNever put dripping wet clothes in or on top of the dryer as excess water may cause an
electrical hazard.
zDo not under any circumstances place an electric blanket or any other electrical, plastic
or rubber items in the appliance, unless the care label specifically states it is safe to
do so.

6
SAFETY AND WARNINGS
zDo not overload your dryer beyond its rated capacity.
z
MODEL MAXIMUM CAPACITY* (KG)
DH9060H1, DH9060HL1, DH9060HLG1 & DH9060HG1 9
*Capacity refers to the maximum dry weight of items the dryer can dry at any one time
zDo not dry curtains in your dryer.
zFor models with a water tank, never run the dryer without the water tank in place
unless drain hose is connected. For models without a water tank, the drain hose must
be connected.
zDo not use the water collected in the water tank for drinking or food processing.
zIf the water tank becomes full, the appliance will pause and sound an alarm. You must
empty the water tank before the appliance can continue running.
Lint
zDo not operate this appliance without the lint filters in place, or allow lint to accumulate
in or around the appliance.
zAccumulated lint in the appliance can become a fire hazard; it also reduces
the efficiency of the appliance by causing longer drying times and increased
power consumption.
zClean the lint filter before every load.
zEnsure the area around the appliance is clear of lint.
zIf the lint filter becomes damaged, contact your Fisher & Paykel trained and supported
service technician to arrange getting a new filter. Do not operate your appliance
with a damaged lint filter or without the filter in place, as this will cause damage to
your appliance.
Spontaneous combustion
To reduce the risk of fire the following should be observed:
zItems that have been spotted or soaked with vegetable oil or cooking oil are a fire
hazard and should not be placed in the appliance.
zOil-affected items can ignite spontaneously, especially when exposed to heat sources
such as this appliance. The items become warm causing an oxidation reaction in the
oil. This oxidation creates heat. If the heat cannot escape the items can become hot
enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat from
escaping creating a fire hazard.
zIf it is unavoidable that fabrics that contain vegetable oil, cooking oil or have been
contaminated by hair care products be placed in this appliance, they should first be
washed in hot water with extra detergent — this will reduce, but not eliminate the fire
hazard. The cooling cycle should be used to reduce the temperature ofthese items.
They should not be removed from the appliance and piled or stacked while hot.
zItems that have previously been cleaned in, washed in, soaked in or spotted with
flammable liquids or solids, eg petrol/gasoline, kerosene, dry cleaning solvents,
vegetable or cooking oil, acetone, denatured alcohol, some brands of spot removers,
turpentine, waxes and wax removers or other flammable or explosive substances should
not be placed in the appliance.
zThe appliance is not to be used if industrial chemicals have been used for cleaning.
zFabric softeners or similar products should not be used in the appliance to
eliminate the effects of static electricity, unless this practice is specifically
recommended by the manufacturer of the fabric softener product.

7
zItems such as foam rubber (latex foam), shower caps, rubber backed articles, clothes
or pillows fitted with foam rubber pads, waterproof textiles, shoes containing rubber or
plastic items should not be placed in the appliance. These materials can spontaneously
combust when heated.
zDo not dry unwashed items in the appliance.
zWhen using REFRESH BY STEAM cycles on unwashed clothing ensure there are no
flammable substances on them.
Installation
zThe appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and off by a utility.
zWe do not recommend the use of extension cords or portable electrical outlet devices
for safety reasons.
zInstall the appliance on a solid and level floor surface.
zThe appliance must be installed in a well-ventilated, dust-free environment.
zThe appliance must not be installed on any textured floor coverings (eg carpet, rugs).
Ensure that openings at the base of the appliance are not obstructed.
zThe appliance must not be installed behind a lockable door, a sliding door or a door
with the hinge on the opposite side to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
zIf installing behind a cabinetry door, it must be hinged on the same side as the dryer
and there must be a minimum clearance of 40mm from the front of the dryer door to
the internal face of the cabinetry door for the product to operate safely. The enclosed
space must be provided with sufficient ventilation to meet local building code
requirements or the door must be open while the product is operating.
zThis appliance can be installed on a compatible Fisher & Paykel plinth. To ensure
stability, the plinth must be fitted correctly with the appliance. For installation
instructions and compatible plinth models, refer to fisherpaykel.com.
zDo not install or operate this appliance on any other plinth or structure.
zFor more information refer to the installation guide. To access, go to fisherpaykel.com/
specify and search by appliance type, product name or model.
Water supply requirements
zInlet water pressure: Max. 1MPa (145psi), Min. 30kPa (4.5psi)
zInlet water flow rate: Min. 6litres/minute
zThe cold water temperature should not exceed35°C. Temperatures above these may
cause the appliance to fault or cause damage to it.
zA pressure-reducing valve must be installed if pressure is higher than 1Mpa.
zNew hose sets provided should be used to connect the appliance to the water mains.
Old hose sets should not be re-used.
zWe recommend the inlet hose(s) are changed every 5 years. WARNING: Failure to do so
may result in a flood and damage to property.
Disposal
zWhen disposing of this appliance, it is recommended that the door is removed to
avoidchildren getting trapped inside, and that the electrical cable is cut off close to
thedryer.
SAFETY AND WARNINGS

8
FIRST USE
*Located behind filter cover.
2
3
4
5
1
7
6
Features and accessories
1 Water tank
2 Dryer controls
3 Drum light
4 Drying rack
5 Sensors
6 Lint filter
7 Condenser filter*

9
FIRST USE
Control panel
1 Menu Press to access additional features and settings.
2 Touchscreen display Use to navigate and select cycles, features and settings.
3 Start/Pause button Press to start or pause a cycle.
4 Control dial zPress the dial to turn the display on.
zTurn the dial to scroll.
zPress to select or confirm.
zPress and hold to go back or to turn the display off.
3 42
1

10
FIRST USE
Menu
LOCK Lock the controls to prevent accidental use. The controls can be
locked at any time including while a cycle is running.
When locked, the controls will be unresponsive except to pause
a cycle. Press and hold the screen to unlock.
LIGHT Turn the drum light ON/OFF.
SETTINGS Adjust the appliance settings to suit your preferences or set up a
Wi-Fi connection. Refer to ‘Wi-Fi connection & Remote mode’.

11
SETTING A CYCLE
Before you begin
zCheck pockets for items that could damage your clothes or get caught in the dryer.
zCheck and empty the lint filter.
zCheck and empty the water tank (if not set up for automatic draining).
Place items in the dryer.
For best results, dry similar items together
and do not exceed the maximum capacity for
the selected cycle.
2
Fit the drying rack if required. Refer to
‘Loading suggestions’.
1
3Press the dial to turn on the display.
4Select a drying mode then select a cycle.

12
SETTING A CYCLE
5
Adjust the settings as needed or press
OPTIONS to access additional cycle options.
For more information refer to ‘Cycle settings’
and ‘Cycle options.’
6Press to start the cycle.

13
SETTING A CYCLE
Press to pause the cycle.
Press CANCEL.
Pausing a cycle
Cancelling a cycle
If cancelling a cycle partway through, remove items immediately and spread out to cool. Do
not leave hot items in the dryer or in a clothes basket. Take care as the drum and items may
be hot.

14
LOADING SUGGESTIONS
Sorting
zSort itemsintoloads of similar items, and loads that will likely take similar times to
dry. This prevents thepossibility of some items becoming over-dried whilst others are
still damp.
zAlways separate coloured items from whites, especially when they are new.
zColour run could be an issue, especially if using DELAYED START.
zClose zippers, hooks and eyes, and other fastenings (ie fasten the opening of duvet/
doona covers), and remove loose bra wires. These can damage your dryer and clothes.
zItems of clothing with screen-printing should be turned inside out to prevent damage to
the print.
zCare labels on garments provide valuable information about the fabric type and
howthegarment should be dried. Always follow the advice on garment labels.
Loading
zLoading items correctly will help to minimise creasing and wrinkling, and ensure the load
is dried evenly.
zAllow enough room in the dryer for clothes to tumble freely. Load the dryer in terms of
the space the garments take up when dry, rather than when they are wet.
zShake clothes out and load individually to help items dry evenly and reduce tangling.
zDry permanent press items (eg business shirts) together on the EASY IRON cycle with the
WRINKLE FREE option on. This will help reduce wrinkling and the need for ironing.
zHang garments as soon as the drying cycle is complete to reduce the need for ironing.
Drying times
zDrying very small loads is inefficient. Try to dry medium to large loads.
zHeavier items (towels, flannelette sheets) will take longer to dry than light items
(synthetics and polyester cotton sheets and shirts).
zDrying times can be reduced by spinning the wash load at the highest spin speed
suitable for the load type in your washing machine.
zCheck bulky items during the cycle to ensure even drying, pause the dryer and reposition
the item if necessary.
Lint
Some items are lint givers, while others are lint collectors. Always dry lint givers
and collectors separately.
LINT GIVERS LINT COLLECTORS
Towels Synthetics, eg polar fleece
Flannelette sheets Corduroy
Polyester cottons

15
LOADING SUGGESTIONS
Use the drying rack for items that cannot be
tumbled such as sneakers, hats and soft toys.
Use the rack with the following cycles:
zRACK DRY
zSNEAKERS
zSOFT TOYS (optional)
Drying rack
To fit the drying rack, insert the legs into the
slots in lint filter then lower into place.

16
DRY CYCLES
Your dryer has a number of cycles to suit your fabric care needs. Selecting the most
appropriate cycle for each particular load will help ensure you get the best results.
DRY BY CYCLE
CYCLE DESIGNED FOR
MAX.
LOAD SIZE
(KG)
MIXED An everyday cycle for mixed fabrics. Ideal for items like
t-shirts and trousers. 9
COTTON¹ A high heat cycle for natural cotton fabrics. 9
DELICATE A gentle cycle for delicate items such as blouses and
dresses. 4
TOWELS Designed for drying thick and absorbent items such
as towels. 6
SHEETS An optimised cycle for bed linen. Ideal for drying sheets,
covers and pillowcases. 4
WOOL²
An extra gentle cycle to care for woollen items. This
cycle meets the Woolmark requirements for machine
washable items.
1
ULTRA DELICATE An extra gentle cycle for very delicate items such as lace. 1
SILK An extra gentle cycle designed specifically for silk items. 1
ACTIVEWEAR An extra low heat cycle optimised for activewear. Ideal for
synthetic and elasticated items. 2
DENIM An everyday cycle to care for denim fabrics. 3
HEAVY A stronger cycle designed for durable fabrics. 8
SANITISE An extra hot cycle designed to eliminate bacteria. Ideal for
sanitising items like towels and sheets. 4
SPORTS A medium heat cycle designed for sportswear. Suitable for
more durable fabrics. 4
SYNTHETICS An everyday cycle for synthetic fabrics. Ideal for synthetic
fabrics and polyester-cotton blends 4
BULKY A gentle cycle for large or bulky items. Ideal for items like
jackets, duvets and quilts. 3
OUTDOOR A low heat cycle designed for outdoor clothing and high
performance fabrics. 2
EASY IRON Designed to minimise creasing in items like shirts. Items are
ready to iron at the end of the cycle. 4
RACK DRY Designed for items that cannot be tumbled. This cycle
requires the drying rack. 3
SOFT TOYS A gentle cycle for looking after soft toys. This cycle can be
used with the drying rack. 4 items

17
DRY CYCLES
DRY BY CYCLE
CYCLE DESIGNED FOR
MAX.
LOAD SIZE
(KG)
SNEAKERS A gentle cycle for drying sneakers and sports shoes. This
cycle requires the drying rack. 2 pairs
COOL AIR A heat free cycle for airing items. 4
REFRESH BY STEAM
CYCLE DESIGNED FOR
MAX.
LOAD SIZE
(ITEMS)
MIXED Designed to refresh dry items by reducing creases and
odours. Ideal for mixed fabrics. 3
SHIRTS Designed to refresh shirts by reducing creases and
odours. 3
DELICATE A gentle cycle to refresh delicate items such as blouses
and dresses. 3
SANITISE A high heat cycle designed for sanitising dry items. 3
²Woolmark Wool Care
The wool drying cycle of this machine has been approved by The Woolmark
Company for the drying of machine washable wool products provided that the
products are washed and dried according to the instructions on the garment
label and those issued by the manufacturer of this machine. M2018.
¹COTTON with ECO, AUTO and DRYNESS: 3 selected is the recommended energy saving cycle
for everyday drying.
REFRESH BY STEAM
All REFRESH BY STEAM cycles are designed for refreshing dry items. To dry wet items select
DRY BY CYCLE.

18
CYCLE SETTINGS
TIME
Set your preferred cycle time. The cycle will end after the set time. If the time is set to AUTO
the cycle will end automatically when the load reaches the selected dryness level.
DRYNESS
Set the level of dryness required. The dryer will sense the remaining moisture in the load to
end the cycle. Level 1 is the dampest setting, while level 5 is the driest. Try a higher or lower
setting if the load dryness is not as expected.
Adjust the default cycle settings to suit your preferences. Tap the setting to select then
adjust as needed.
OPTIMISE
Optimise the cycle as required to reduce noise, save time or save energy. Some optimise
options are not available on certain cycles to ensure optimal results.

19
CYCLE OPTIONS
WRINKLE FREE
After the cycle is complete the load will continue to tumble periodically to help reduce
wrinkles. WRINKLE FREE will remain active for up to 8 hours or until cancelled. To cancel,
touch the screen or open the door.
DAMP DRY ALERT
Set an alert for when the load reaches damp dry level. Pause the cycle to remove items that
do not need further drying. Restart the cycle to continue drying the remaining load.
Select additional cycle options as needed to suit your preferences.
DELAYED START
Set a time for the cycle to start. Avoid using DELAYED START for damp, non-colourfast items
as this may cause dye run to occur.

20
CYCLE OPTIONS
Accessing options
Select a cycle option and adjust as needed.
2
1Select a cycle then press OPTIONS to access.
