Fisher & Paykel DH9060FS User manual

USER GUIDE
NZ AU
HEAT PUMP CLOTHES DRYER
DH9060FS

3
Safety and warnings 5
Control panel 9
WiFi connection & remote mode 12
Dry cycles 14
Dry preparation 16
Getting started quickly 19
Dry cycle options 21
Customising a dry cycle 23
Dryer settings 27
Caring for your dryer 29
Before you call for service 36
Fault codes 37
Troubleshooting 38
Manufacturer’s warranty 44
Customer care 46
CONTENTS
Registration
To register your product visit our website: fisherpaykel.com/register

5
SAFETY AND WARNINGS
!WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• If you are using an extension cord or a portable
electrical outlet device (eg multi-socket outlet
box), ensure that it is positioned so that it does
not come into contact with water or moisture.
!WARNING!
Fire Hazard
• Only dry fabrics that have been washed
with water.
• Do not use heat to dry articles containing foam
rubber or similarly textured rubber–like materials,
dry on ‘Cool Dry’.
• Never stop a tumble clothes dryer before the end
of the drying cycleunless all items are removed
and spread out in order to dissipate the heat.
• A clothes dryer produces combustible lint;
the lint filter must be cleaned before each
drying cycle.
• Failure to follow the warnings outlined in these
user instructions can cause a fire hazard.
• Failure to follow these instructions can result in
death or personal injury.
READ AND SAVE THIS GUIDE
When using your clothes dryer, follow basic precautions, including thefollowing:
General
zThe appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and off by a utility.
zWe do not recommend the use of extension cords or portable electrical outlet devices
for safety reasons.

6
SAFETY AND WARNINGS
zDo not touch or operate the machine with wet hands or with bare-feet.
zA damaged power cord must be replaced by a Fisher & Paykel trained and supported
service technician, its service agent or similarly qualified persons in order to avoid
a hazard. The appliance must not be operated until it is repaired, as there is risk of
electric shock.
zDo not operate this machine if it has been damaged during transport. Contact your
Fisher&Paykel dealer or Fisher & Paykel trained and supported service technician.
zThis dryer has been designed for domestic use only, not for commercial applications,
such as massage/beauty clinics where there may be increased lint accumulation or
flammable materials in the atmosphere or load.
zThe tumble dryer is intended only for drying textile material washed in water.
zUndergarments that contain metal reinforcements should not be placed in the dryer.
Damage to the dryer can result if the metal reinforcements come loose during drying. If
you wish to dry these items use a drying rack or place in a garment bag.
zCheck and remove all objects from pockets, eg lighters and matches.
zNever dry rubber articles, or any plastic items or film, eg plastic lined
tablecloths andbaby bibs.
zClothes should go through the cool down/airing phase in the final part of the cycle.
This ensures items are left at a temperature where they will not be damaged. Ifforany
reason the dryer is stopped before the cycle has finished, dry clothes should be
removed immediately and not left in the dryer. Clothes should be quickly spread out
flat to cool so heat can dissipate, not left bunched up, eg in a clothes basket.
zDo not operate this product without the lint filter in place or allow lint to accumulate in
or around the dryer.
zThis dryer is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless given
supervision or instruction concerning the use of the dryer by a person responsible
for their safety.
zChildren should be supervised to ensure they do not play with the dryer.
zUnplug the machine from the power supply when it is not in use.
zDo not swing on or put weight on the door.
zIn the event of a power outage your dryer will resume automatically when
power is restored.
zNever attempt to repair the dryer yourself.
zThe only user-removable parts of the dryer are the filters and drying rack. No other
parts are designed to be removed by anyone other than aFisher & Paykel trained and
supported service technician.
zFor problems that cannot be solved from information in this user guide, turn off and
unplug your dryer and contact a Fisher & Paykel trained and supported service technician.
zDo not overload your dryer beyond its rated capacity:
MODEL MAXIMUM CAPACITY (KG)
DH9060FS 9
*Capacity refers to the maximum dry weight of items the dryer can dry at any one time
zNever put dripping wet clothes in or on top of the dryer as excess water may cause an
electrical hazard.
zDo not under any circumstances dry an electric blanket or any other electrical, plastic
or rubber items in your dryer, unless the care label specifically states it is safe to do so.
Never dry these items at high temperatures.

7
SAFETY AND WARNINGS
zDo not dry curtains in your dryer. Sunlight makes them brittle and they may
disintegrate during drying.
zDo not use the water collected in the water tank for drinking or food processing.
zNever run the dryer without the water tank in place.
zIf the water tank becomes full, the tumble dryer will pause drying and will sound an
alarm. You must empty the water tank before the dryer can continue drying. Empty the
tank, replace it back in the housing then press to resume the cycle.
Lint
zAccumulated lint in the dryer can become a fire hazard; it also reduces the efficiency of
the dryer by causing longer drying times and increased power consumption.
zClean the lint filter before every load.
zEnsure the area around the dryer is clear of lint.
zAt regular intervals have the interior of the dryer cleaned of any accumulated lint.
This must be done by a Fisher & Paykel trained and supported service technician.
This must be done when the dryer installation is changed from free standing.
zIf the lint filter becomes damaged, contact your Fisher & Paykel trained and supported
service technician to arrange getting a new filter. Do not operate your dryer with a
damaged lint filter or without the filter in place, as this will cause damage to your dryer.
Spontaneous combustion
To reduce the risk of fire in a tumble dryer the following should be observed:
zItems that have been spotted or soaked with vegetable oil or cooking oil are a fire
hazard and should not be placed in a tumble dryer.
zOil-affected items can ignite spontaneously, especially when exposed to heat sources
such as a tumble dryer. The items become warm causing an oxidation reaction in the
oil. This oxidation creates heat. If the heat cannot escape the items can become hot
enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat from
escaping creating a fire hazard.
zIf it is unavoidable that fabrics that contain vegetable oil, cooking oil or have been
contaminated by hair care products be placed in a tumble dryer, they should first be
washed in hot water with extra detergent — this will reduce, but not eliminate the fire
hazard. The cool down cycle of the dryer should be used to reduce the temperature
ofthese items. They should not be removed from the tumble dryer and piled or
stacked while hot.
zItems that have previously been cleaned in, washed in, soaked in or spotted with
flammable liquids or solids, eg petrol/gasoline, kerosene, dry cleaning solvents,
vegetable or cooking oil, acetone, denatured alcohol, some brands of spot removers,
turpentine, waxes and wax removers or other flammable or explosive substances should
not be placed in a tumble dryer.
zDo not dry unwashed items in the tumble dryer.
zThe dryer is not to be used if industrial chemicals have been used for cleaning.
zFabric Softeners or similar products should not be used in a tumble dryer to
eliminate the effects of static electricity, unless this practice is specifically
recommended by the manufacturer of the fabric softener product.
zRubber backed articles, foam rubber (latex foam), clothes or pillows fitted with
foam rubber pads, fibreglass, shoes containing rubber, shower caps, babies waterproof
napkin covers and waterproof textiles should not be dried in the dryer. These materials
can when heated produce fire by spontaneous combustion.
zWhen using STREAM REFRESH on unwashed clothing ensure there are no flammable
substances on them.

8
Disposal
zExtreme care must be taken when disposing of your old appliance to avoid hazards.
zWhen disposing of the dryer, it is recommended that the door is removed to avoid
children getting trapped inside, and that the electrical cable is cut off close to the dryer.
SAFETY AND WARNINGS

9
CONTROL PANEL
1Power Press to turn the dryer ON/OFF.
2Keylock Press to disable all buttons on the control panel, except the
POWER button. This prevents accidental button presses.
3SmartTouch™
Control Dial
Rotate to select your desired drying cycle.
zRed LED illuminates to indicate the selected dry cycle.
4Digital display
screen
Shows the following:
zDry cycle icons and information based on dial selection.
zDry cycle options and machine settings.
zDry progress.
zDelayed start time of drying cycle.
zNotifications if an error is detected or a warning is necessary.
5Adjust Press to navigate through the dry cycles, dry cycle options and
settings, andtoincrease or decrease the delay start time.
6Options Press to access dry cycle options and dryer settings.
7Select Press to accept the selected option or any changes made, and
thenreturn to the main screen.
8Back Press to exit current display and return to the main screen.
9Optimise dry Press to select SPEED, ECO or QUIET.
!0 Dryness level Press to select the level of dryness for your load.
!1 Start/Pause Press to start or pause the selected dry cycle.
Hold for three seconds to enable REMOTE (WiFi) mode.
2
1 4 8 !17
3 6 95 !0

10
Timed cycles
When a timed cycle is selected the machine dries for the selected time regardless of
the level of moisture in the load. It is important to check the items throughout the timed
programmes to avoidover drying.
Select the desired cycle.
Use the ADJUST buttons to adjust the
time up or down.
Press the button to confirm.
CONTROL PANEL
To adjust the length of timed cycles:
Dry progress
For all cycles, the display will show the phase of the cycle that iscurrentlyunderway.
For timed cycles, the display will also show approximately how manyminutesthecycle has
remaining. For automatic cycles, the word AUTO will appear on the screen.
30min
Time Dry
Set Time
Press for three seconds.
When activated, the is illuminated.
Keylock
To turn KEYLOCK ON or OFF when the dryer is powered ON:

11
If KEYLOCK is on and you want to pause your dryer:
If KEYLOCK is ON and you want to power OFF your dryer at any time:
Press POWER .
To pause your dryer at any time during the
cycle, press and hold for threeseconds
then press .
CONTROL PANEL
To turn your dryer on if KEYLOCK is ON and the dryer is powered OFF:
Press POWER , then press and hold
for three seconds. This will activate the
control panel. Dry cycles and options can
now be selected.
If a button is pressed while KEYLOCK is
activated, beeps will be heard and
will flash.

12
Your appliance can be connected to your home wireless network and operated remotely
using the app.
Getting started
zEnsure your home WiFi network is turned on.
zYou will be given step by step guidance on both your appliance and mobile device.
zIt may take up to 10 minutes to connect your appliance.
WIFI CONNECTION & REMOTE MODE
On your mobile device:
1 Download the app from www.fisherpaykel.com/connect
2 Register and create an account.
3 Add your appliance and set up the WiFi connection.
Connecting to your home WiFi
1
2
Press OPTIONS , the screen will show the
default option DAMP DRY SIGNAL.
Scroll to SETTINGS using the ADJUST
buttons, press to confirm.
Press ADJUST to scroll through the list
of SETTINGS to WIFI OFF, press to select
and edit.
Press ADJUST or to select WIFI SETUP and
to confirm to start the setup process.
WiFi
OFF
Settings
Damp Dry
Signal
OFF
Options
WiFi
OFF
Settings
Damp Dry
Signal
OFF
Options

13
Enabling remote mode
WIFI CONNECTION & REMOTE MODE
Press and hold for three seconds.
REMOTE ENABLED will appear in the
display screen.
REMOTE MODE is now enabled. Certain
functions of your washer can now be
accessed via the app.
1
2
Remote
enabled
Remote
disabled
Remote
enabled
Remote
disabled
Remote
enabled
Remote
disabled
Disabling remote mode
Remote
enabled
Remote
disabled
Press and hold for three seconds.
1
REMOTE DISABLED will appear in the
display screen. REMOTE MODE is now disabled.
2
For safety reasons, REMOTE MODE cannot be enabled if the dryer door is open.

14
DRY CYCLES
CYCLE SUB-CYCLE DESIGNED FOR
MAX.
LOAD SIZE
(KG)
DEFAULT
DRYNESS
LEVEL
Everyday
Everyday A high heat cycle designed for
mixed loads. 9 Dry
Heavy A longer, high heat cycle for
durable garments. 8Dry
Extra Dry
Cottons Cotton¹ A high heat cycle designed for
cotton garments. 9 Dry
Towels A high heat cycle for drying towels. 6 Dry
Delicates
Delicate
A low heat cycle for careful
drying of delicate and heat
sensitive garments.
4 Dry
Ultra
Delicate
An extra low heat cycle for careful
drying of ultra delicate and heat
sensitive garments.
1 Dry
Sportswear
Activewear
An extra low heat cycle
designed for special care of light
synthetic garments.
2 Dry
Sports A medium heat cycle designed for
sports garments. 4 Dry
Outdoor
A low heat cycle for high
performance fabrics and
outdoor garments.
2 Dry
Easy Iron n/a
A medium heat cycle that
leaves garments ready to iron.
WRINKLE FREE automatically
selected.
4Damp
Dry
Time Dry n/a A cycle with user selectable
drying times. 9n/a
Bedding
Sheets
A high heat cycle with reversing
to reduce tangling for large
bedding items.
4Dry
Extra Dry
Bulky
A low to medium heat cycle
designed for careful drying of
bulky items.
2Dry
Extra Dry
Utility Rack Dry
A cycle with user selectable drying
times that uses the drying rack for
items that cannot be tumbled.
3n/a
Cool Air 40 minute cool air cycle. 4n/a
Your dryer has a number of dry cycles to suit your laundering needs. Selecting the most
appropriate cycle for each particular dry load will help ensure you get the best dry result.

15
CYCLE SUB-CYCLE DESIGNED FOR
MAX.
LOAD SIZE
(KG)
DEFAULT
DRYNESS
LEVEL
Hygiene n/a
A longer, high heat cycle
designed to eliminate >99.9% of
household bacteria.
4Extra Dry
Wool² n/a
A low heat cycle designed for
special care of washable woollen
items that complies with Woolmark
Apparel Care criteria.
1n/a
Denim n/a
A medium heat cycle designed
for special care of stretch
denim garments.
3 Dry
Silk n/a An extra low heat cycle designed
for special care of silk garments. 1 Dry
Extra Care
Sneakers
Timed cycle to warm blow dry
sneakers and sports shoes using the
drying rack.
1-2 pairs n/a
Soft Toys
Timed cycle to warm blow dry soft
toys. Do not dry toys with plastic,
metallic or electrical parts.
1-4 items n/a
Steam
Steam
Freshen
A cycle for de-wrinkling
and removing odours from
dry garments.
1-2 items Dry
Pre Iron A quick cycle for de-wrinkling dry
garments before ironing. 1-2 items Damp Dry
¹COTTON with ECO selected is the recommended energy saving cycle for everyday drying.
DRY CYCLES
²Woolmark Apparel Care
The wool drying cycle of this machine has been approved by The Woolmark
Company for the drying of machine washable wool products provided that the
products are washed and dried according to the instructions on the garment
label and those issued by the manufacturer of this machine. M2018.

16
DRY PREPARATION
Sorting
Sort itemsintoloads of similar items, and loads that will likely take similar times to dry. This
prevents thepossibility of some items becoming over-dried whilst others are still damp.
Separate coloured items from white/light items where possible, especially when new. Colour
run may be an issue, especially if you intend to delay the start of the drying cycle.
Care labels on garments provide valuable information about the fabric type and
howthegarment should be dried. Always follow the advice on garment labels.
ITEM/DRYING
REQUIREMENTS
SUGGESTED
CYCLE COMMENTS
Towels Towels Towels produce a lot of lint and are best dried on
their own.
Sheets, pillowcases Sheets Ensure openings are buttoned/domed before
placing in the dryer.
Bulky items — doonas/
duvets, sleeping bags
andblankets
Bulky Dry only one bulky item at a time.
Business shirts,
trousers, other
creasables
Easy Iron WRINKLE FREE is automatically selected to
help minimise creasing once the drying cycle
has finished.
Woollens Wool Designed for machine washable woollen items.
Delicates, fine fabrics Delicate,
Ultra delicate
or Rack Dry
You can further reduce the dryness level to damp
or useRack Dry for very delicate items.
Denim Denim Turn jeans inside out to help maintain their
appearance. Dry separately from other items.
Sports and
casual shoes
Sneakers Check on the item regularly throughout
the drying cycle. Ensure the rack has been
correctly fitted.
Soft toys Soft Toys Check on the item/s regularly throughout the
drying cycle. Use the drying rack for more
delicate soft toys.
Hats and other odd
shaped items
Rack Dry Check on the item regularly throughout
the drying cycle. Ensure the rack has been
correctly fitted.
Jackets Outdoor Turn jackets inside out to help maintain their
appearance. Dry separately from other items.
Bed linen, tea towels,
socks, reusable
face masks
Hygiene Ensure the items can safely withstand heat.

17
Before you load
zCheck pockets for items that could damage your clothes or get caught in the dryer.
zClose zippers, hooks and eyes, and other fastenings (ie fasten the openings of duvet/
doona covers), and remove loose bra wires. These may damage both your dryer
and your clothes.
zItems of clothing with screen-printing should be turned inside out toprevent
damage to the print.
zCheck the lint filter is clean and the water tank is empty (if the dryer is not set up
todrain automatically).
Loading
zGarments need to be loaded correctly to minimise creasing and wrinkling, and to
ensurethe load is dried evenly.
zAllow enough room in the dryer for clothes to tumble freely. Load the dryer in terms of
the space the garments take up when dry, rather than when they are wet.
zShake clothes out and load individually to help items dry evenly and reduce tangling.
zDry permanent press garments (business shirts) together on the EASY IRON cyclewith
the WRINKLE FREE option on. This will help reduce wrinkling and the need forironing.
Hang garments as soon as the drying cycle is complete to reduce the need for ironing.
Drying times
zDrying very small loads is inefficient. Try to dry medium to large loads.
zHeavier items (towels, flannelette sheets) will take longer to dry than light items
(synthetics and polyester cotton sheets and shirts).
zDrying times can be reduced by spinning the wash load at the highest spin speed
suitable for the load type in your washing machine.
zCheck bulky items during the cycle to ensure even drying, pause the dryer and reposition
the item if necessary.
Lint
Some items are lint givers, while others are lint collectors. Always dry lint givers
and collectors separately.
LINT GIVERS LINT COLLECTORS
Towels Synthetics, eg polar fleece
Flannelette sheets Corduroy
Polyester cottons
Delicate or easily damaged items (eg nylon stockings, fine fabrics, delicate embroidered
fabrics) should be dried separately, using the DELICATE, ULTRA DELICATE, SILK or WOOL cycle,
or if you do not want them tumbled use the RACK DRY cycle. Sleeping bags and other down
items should be dried on the BULKY cycle.
DRY PREPARATION

18
DRY PREPARATION
Drying rack
The drying rack is installed in your dryer when it leaves the factory. There are many items
that would benefit from being dried on a dryingrack. For example items such as hats,
sneakers anddelicate soft toys are items that may be damaged if they are tumbled.
1
2Toremove the drying rack, detach the legs
fromthe slots in the lint filter and gently
remove from the drum.
SHOW ONE
OPTION SCREEN,
EG DRY RACK
SHOW ONE
OPTION SCREEN,
EG DRY RACK
The drying rack is installed in your dryer
when it leaves the factory.
When you are using the drying rack
you must select an appropriate cycle:
RACK DRY, SNEAKERS or SOFT TOYS.

19
GETTING STARTED QUICKLY
Check the lint and condenser filters are clean and replaced correctly before every load.
Ensure the water tank is empty or drain hose secure before using your dryer.
Sort and load items into the dryer drum, ensuring no items are in the way of the door. Close
the door (you will hear it click shut).
1
2
3
4
Press POWER to activate your dryer.
Select your desired drying cycle by turning
the SmartTouch™ Control Dial.
A red LED will illuminate as you turn the dial
showing which cycle is selected.
Once the dry cycle is selected, the screen will
display NO DELAY, indicating the dry cycle
isready to start.
The screen will display the information
specific to the selected cycle.
To select a sub-cycle use ADJUST or to
scroll through the sub-cycles.
No Delay
Heavy
Auto
Everyday
Everyday
Start in 8hrs
Heavy
Auto
No Delay
Heavy
Auto
Everyday
Everyday
Start in 8hrs
Heavy
Auto
No Delay
Heavy
Auto
Everyday
Everyday
Start in 8hrs
Heavy
Auto
No Delay
Heavy
Auto
Everyday
Everyday
Start in 8hrs
Heavy
Auto

20
GETTING STARTED QUICKLY
5
Press to start the cycle.
If you wish to change a cycle or select a
different option once a drying cycle has
started, press then select the new cycle.
Press to restart thedryer with the new
cycle and/or settings.
When the cycle finishes, your dryer will beep and then turn off automatically. If
theWRINKLE FREE option has been selected the dryer will rotate the drum periodically to
help minimise wrinkling and creasing ofyour load.
If you wish to stop the dryer before the cycle has finished you MUST remove the clothes
IMMEDIATELY and spread them out to cool. DO NOT leave the clothes in the dryer or
bunched up in a clothes basket. Take extreme care as the drum and the load items may be
extremely hot.
If you prefer to start the wash cycle at a later
time, set a delay for the start time by using
the ADJUST .
4
No Delay
Heavy
Auto
Everyday
Everyday
Start in 8hrs
Heavy
Auto
No Delay
Heavy
Auto
Everyday
Everyday
Start in 8hrs
Heavy
Auto
