Fisher & Paykel 11 Series User manual

INSTALLATION GUIDE
NZ AU
FABRIC CARE SOLUTION
WASHER INSTALLATION
WH1160HG1 and WH1160H1 models

2
COMPONENTS REQUIRED
TOOLS
Supplied
F Spanner
Not supplied
F Box cutter
F Phillips screwdriver
F Level
PARTS
Supplied
F 1x Cold water hose
F 1x Hot water hose
F 1x Blanking cap
F 7x Plugs
Supplied (not required*)
F 1x Communication cable
*Not required for single product installation.

3
ACCESSING YOUR PRODUCT SPECIFICATIONS
For full product, cabinetry and service specifications, refer
to the Planning Guide. To access the Planning Guide, scan
the QR code or visit fisherpaykel.com/specify. Search by
appliance type, product name or model code.
862
665
624

4
PRIOR TO INSTALLATION
3. Ensure power will remain
accessible following install to
allow access for any future
product maintenance.
Service holes should be smooth
with gromets installed where
required.
Refer to the services section
of the Planning Guide for more
details.
2. Ensure floor is level and clear
and a finished return has been
created.
1. Ensure cabinetry and
servicing specifications have
been met and clearances have
been considered.
Refer to the Planning Guide for
details.
fisherpaykel.com/specify

5
UNPACK
3. Protect flooring before
positioning washer as close
to the installation location
as possible, ensuring enough
working room is left available.
1. Cut the straps and the line
printed on the top of the
carton. Lift to remove. Discard
braces and corner posts.
Remove any packaging and
accessories from the drum and
base packer.
2. Dispose of packaging
responsibly.

6
1. Using the supplied spanner,
remove all four transit bolts
from the back of the washer.
2. Pull the rubber grommets
and spacers outwards to
remove.
3. Using a Phillips screwdriver,
remove the two side brackets.
REMOVE TRANSIT BOLTS

7
4. Remove and discard the
braces.
5. Pull the two transit rods
outwards to remove.
Set aside for future use.
6. Cover the transit bolt holes
using the supplied plugs.
REMOVE TRANSIT BOLTS

8
LEVEL
2. Once level, move the washer
into its final position allowing
for required clearances.
Recheck washer is level before
removing from the alcove.
3. Remove the washer from the
alcove and tighten locking nuts.
1. Adjust the feet using the
supplied spanner until the
washer is level front to back
and corner to corner.

9
CONNECT CABLES AND HOSES
2. Connect the angled end of
cold hose to the cold water
inlet on the washer.
3. Connect angled end of hot
water hose to the orange outlet
on the washer. If hot hose is
not required, install a blanking
cap.
1. Refer to the Planning Guide
for full service information.
Supply: 220 - 240V, 50Hz
Service: 10A
Outlet: 3-prong grounding-type
Supply: Hoses provided
Pressure: 50KPa (7psi) - 1MPa
(150psi). Min 6 litres/min.
fisherpaykel.com/specify

10
CONNECT CABLES AND HOSES
5. Route the power cables and
hoses through service holes.
Ensure power will remain
accessible following install to
allow access for any future
product maintenance.
6. Install the drain hose guide
to the back wall.
Refer to the planning guide for
placement details.
4. Partially push products into
the alcove.
Take care not to crush the cables
and hoses.
