FiT 500956 User manual

INSTRUCTION MANUAL
Biketec GmbH
Luzernstrasse 84
CH-4950Huttwil
T [phone]
[e-mail]
fit-ebike.com
MOTOR BROSE S MAG FIT
NETWORKED
CUSTOMISED
INTELLIGENT
500956 | 500952

INSTRUCTION MANUAL BROSE S MAG FIT
TABLE OF CONTENTS
1 PREFACE 3
2 ABOUT THESE OPERATING INSTRUCTIONS 4
2.1 MANUFACTURER................................................. 4
2.2 LANGUAGE..................................................... 4
2.3 DECLARATIONOFCONFORMITY ........................................ 4
2.4 ONINFORMATION ................................................ 4
2.5 WARNINGS IN THESE OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 SAFETY INSTRUCTIONS 5
3.1 GENERALINFORMATION............................................. 5
3.2 DRIVEUNITS.................................................... 5
3.3 WHATTODOINANEMERGENCY........................................ 5
3.3.1 DANGEROUS SITUATION IN ROAD TRAFFIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 PRODUCT AND TECHNICAL SPECIFICATIONS 6
4.1 BROSESMAGFIT................................................. 6
4.2 PROPERUSE ................................................... 6
4.3 IMPROPERUSE.................................................. 6
4.4 TECHNICALDATA................................................. 6
4.4.1 BROSESMAGFITVERTICAL ...................................... 6
4.4.2 BROSESMAGFITHORIZONTAL .................................... 7
5 CLEANING AND SERVICING 8
5.1 CLEANINGTHEMOTOR ............................................. 8
6 TROUBLESHOOTING, FAULT CLEARANCE AND REPAIR 9
6.1 TROUBLESHOOTING AND FAULT CLEARANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.1.1 DRIVE SYSTEM OR DISPLAY DOES NOT START UP . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.1.2 ERRORS IN THE ASSISTANCE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.2 REPAIR....................................................... 10
6.2.1 ORIGINALPART ............................................. 10
6.2.2 REPLACINGTHELIGHTS ........................................ 10
6.2.3 ADJUSTINGTHEHEADLIGHT...................................... 10
7 RECYCLING AND DISPOSAL 11
7.1 DISPOSAL ..................................................... 11
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 2

INSTRUCTION MANUAL BROSE S MAG FIT
1 PREFACE
Dear FIT customer,
The FIT system offers many useful functions and options and we are pleased that you have decided to choose our
system.
Please read through the operating instructions carefully to ensure you use the system safely and get off to a quick
start.
We hope you enjoy discovering the FIT’s functions and have a fun ride every time you use it.
Thank you for placing your trust in FIT.
Your FIT Team
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 3

INSTRUCTION MANUAL BROSE S MAG FIT
2 ABOUT THESE OPERATING INSTRUCTIONS
2.1 MANUFACTURER
Biketec GmbH
Luzernstrasse 84
CH-4950 Huttwil
fit-ebike.com/en-en/
2.2 LANGUAGE
The original operating instructions are written in German. A translation is invalid without the original operating in-
structions.
2.3 DECLARATION OF CONFORMITY
Biketec GmbH hereby declares that the products described in these operating instructions comply with EU directives.
The complete EU Declaration of Conformity is available online at: fit-ebike.com/en-en/service/declaration/
2.4 ON INFORMATION
Different markings are used in the operating instructions to make them easier to read.
2.5 WARNINGS IN THESE OPERATING INSTRUCTIONS
Warnings indicate hazardous situations and actions. You will find the following warnings in the operating instructions:
DANGER
May lead to serious or even fatal injuries if ignored. Medium-risk hazard.
CAUTION
May lead to minor or moderate injuries if ignored. Low-risk hazard.
NOTICE
May lead to material damage if ignored.
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 4

INSTRUCTION MANUAL BROSE S MAG FIT
3 SAFETY INSTRUCTIONS
3.1 GENERAL INFORMATION
Please read all safety instructions carefully. Failure to comply with the warnings or to take residual risks into ac-
count may result in electric shock, fire and/or serious injury.
Keep the operating instructions in a safe place and have them readily available to consult. Pass these instructions
on if you provide your e-bike for someone else’s use.
When used in these operating instructions, the word “battery” refers to all original FIT e-bike batteries.
3.2 DRIVE UNITS
Do not make any changes that affect the power or the maximum speed that the drive supports, especially to increase
it. You may endanger yourself and others and you may be using your e-bike illegally in public spaces.
Do not open up the drive unit yourself. Only qualified technical staff may repair the drive unit and only with original
spare parts. This ensures that the drive unit remains safe. Unauthorised opening of the drive unit will void the war-
ranty.
All components fitted to the drive unit and all other e-bike drive components may only be replaced with components
of an identical design or ones specifically approved by your e-bike’s manufacturer. This protects the drive unit from
overloading and damage.
When the push assist system is switched on, the pedals may possibly turn as well. When the push assist system is
activated, make sure that you are at a sufficient distance from the rotating pedals. There is a risk of injury.
The brakes and the motor may become very hot during operation. There is a risk of burns or fire in case of contact.
Never touch the brakes or the motor directly after a ride. Never place the e-bike on a flammable surface, such as
grass or wood, or near flammable objects directly after use.
3.3 WHAT TO DO IN AN EMERGENCY
3.3.1 DANGEROUS SITUATION IN ROAD TRAFFIC
If you encounter any hazards or dangers in road traffic, apply the brake until the e-bike comes to a halt. The brake
acts as an emergency stop system in such cases.
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 5

INSTRUCTION MANUAL BROSE S MAG FIT
4 PRODUCT AND TECHNICAL SPECIFICATIONS
4.1 BROSE S MAG FIT
The S Mag provides a detailed pedalling frequency measurement. This brings clear advantages and guarantees a
natural ride performance, especially during technically difficult climbs.
4.2 PROPER USE
All check lists and instructions for actions in these operating instructions met. The drive unit is designed to supply
power to the e-bike only and must not be used for other purposes.
4.3 IMPROPER USE
Improper use refers to use which is not described under proper use or goes beyond proper use.
4.4 TECHNICAL DATA
4.4.1 BROSE S MAG FIT VERTICAL
Electric drive Brose S Mag FIT Eco vertical
Brose S Mag FIT Pro vertical
Part nos. 500952 (Eco)
500952 & Upgrade 501061 (Pro)
Max. torque Nm 75 (Eco)
95 (Pro)
Nominal voltage V 36
Operating temperature °C -10 to +40
Storage temperature °C -20 to +50
Weight about kg 2.9
Protection class IP 56
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 6

INSTRUCTION MANUAL BROSE S MAG FIT
4.4.2 BROSE S MAG FIT HORIZONTAL
Electric drive Brose S Mag FIT Eco horizontal
Brose S Mag FIT Pro horizontal
Part nos. 500956 (Eco)
500956 & Upgrade 501061 (Pro)
Max. torque Nm 75 (Eco)
95 (Pro)
Nominal voltage V 36
Operating temperature °C -10 to +40
Storage temperature °C -20 to +50
Weight about kg 2.9
Protection class IP 56
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 7

INSTRUCTION MANUAL BROSE S MAG FIT
5 CLEANING AND SERVICING
5.1 CLEANING THE MOTOR
CAUTION
If water enters the motor, it will be permanently damaged.
Never immerse the motor in water.
Never clean with a pressure washer, water jet or compressed air.
Never use cleaning agents.
Carefully clean the motor with a soft, damp cloth.
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 8

INSTRUCTION MANUAL BROSE S MAG FIT
6 TROUBLESHOOTING, FAULT CLEARANCE AND REPAIR
6.1 TROUBLESHOOTING AND FAULT CLEARANCE
6.1.1 DRIVE SYSTEM OR DISPLAY DOES NOT START UP
If the display and/or the drive system do not start up, proceed as follows:
1. Check whether the battery is inserted correctly. If it is not, insert the battery correctly.
2. Start the drive system.
3. If the drive system won’t start, remove the battery.
4. Clean all the contacts with a soft cloth.
5. Insert the battery.
6. Start the drive system.
7. If the drive system won’t start, remove the battery.
8. Fully charge the battery.
9. Insert the battery.
10. Start the drive system.
11. If the drive system won’t start, press the on-off button (operating element) for at least 8 seconds.
12. If the drive system does not start after about 6 seconds, press the on-off button (operating element) for at least
2 seconds.
13. Contact your specialist dealer if the drive system does not start.
6.1.2 ERRORS IN THE ASSISTANCE SYSTEM
Symptom Cause Remedy
Assistance is not
available.
Is the speed too high? 1. Check display screen. The motor assistance is
only active up to the maximum speed for which
the e-bike is approved.
Is the battery charged sufficiently? 2. Check battery is charged.
3. Recharge the battery if it is almost flat.
The motor may become too hot
during rides at high temperatures,
up long inclines or when carrying a
heavy load for a long time.
4. Switch off the drive system.
5. Wait a moment and then check again.
The rechargeable battery, display
or operating element may be
connected incorrectly, or one or
more of them may have a problem.
6. Contact your specialist dealer.
Assistance is not
available.
Are the pedals being pushed? 1. Your e-bike is not a motorbike. Push the pedals.
Is the system switched on? 2. Press on-off button (operating element) to
switch on the system.
Is the level of assistance set to
OFF?
3. Set the level of assistance to HIGH,STD,ECO or
AUTO.
4. Contact your specialist dealer if you still feel that
the no assistance is being supplied.
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 9

INSTRUCTION MANUAL BROSE S MAG FIT
Symptom Cause Remedy
The assisted
journey distance
is too short.
The battery does not perform as
well in winter weather.
This does not indicate a problem.
The journey distance can be
shorter depending on the road
conditions, the level of assistance
and the total light usage time.
1. Check battery is charged.
2. Recharge the battery if it is almost flat.
Is the battery fully charged? 3. If the distance covered with a fully charged
battery has become shorter, the battery may be
affected. Replace the battery with a new one.
The battery is a consumable.
Repeated charging and long
periods of use cause the battery to
degrade (loss of power).
4. If the distance you can cover with one single
charge is very short, replace the battery with a
new one.
It is difficult to
pedal.
Are the tyres pumped to an
adequate pressure?
1. Pump up tyres.
Is the level of assistance set to
OFF?
2. Set the level of assistance to HIGH,STD,ECO or
AUTO.
The battery charge might be low. 3. Check battery is charged.
4. Recharge the battery if it is almost flat.
Have you switched on the system
with your foot on the pedal?
5. Switch on the system again without applying
pressure to the pedals.
6. If assistance is still not supplied, contact your
specialist dealer.
6.2 REPAIR
Special expertise and tools are required for many repairs. That is why only a specialist dealer may perform repairs.
6.2.1 ORIGINAL PART
The individual e-bike parts have been carefully selected and matched to one other. Only original parts must be used
for maintenance and repair. Observe the operating instructions for the new components.
6.2.2 REPLACING THE LIGHTS
Replace components with ones in the right power class.
6.2.3 ADJUSTING THE HEADLIGHT
The headlight must be positioned so that its beam hits the road surface 10 m in front of the e-bike.
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 10

INSTRUCTION MANUAL BROSE S MAG FIT
7 RECYCLING AND DISPOSAL
7.1 DISPOSAL
Mechanical and electrical devices, accessories and packaging should be taken for recycling in an environ-
mentally responsible manner. Do not dispose of them in the household waste!
For EU countries only: According to the European Directive 2012/19/EU on waste electrical and electronic
equipment and its implementation in national law, chargers that can no longer be used must be collected
separately and recycled in an environmentally responsible manner.
FIT_Manual_Motor_Brose_S_Mag_V1_en | Version 01 | 04.04.2022 11
