Fixturlaser ECO D 1-1047 User manual

USER MANUAL Fixturlaser ECO

USER MANUAL FIXTURLASER ECO 1st edition 2017
CONTENT
Welcome to our world
1.1
Declaration of Conformity
2.1
Safety
3.1
Care
4.1
Main Menu
5.1
Shaft Alignment
Horizontal Machines
6.1
Softcheck
7.1
Memory Manager
8.1
Global Settings
9.1
Display Unit ECO D
10.1
Sensors M6 and S6
11.1
Technical Specification ECO D
12.1
Technical Specification
M6 and S6
13.1

1.1
WELCOME TO OUR WORLD
Since the very beginning in 1984, ACOEM AB
(formerly known as ELOS Fixturlaser AB) has
helped industries throughout the world to
achieve more profitable and sustainable
production. We have reached where we are
today by having the courage to think beyond the
norm and follow slightly unconventional paths.
We have had the courage to make mistakes
and find new directions. Through our resolve,
ambition and knowledge we have become a
global player and a leader in innovative, user-
friendly shaft alignment.
SUSTAINABLE INNOVATIONS
During our 30 years in this industry, we
have explored, tweaked and tested more
than anyone. Some might say we are
incurable innovators whereas others might
say that we are highly focused. They both
probably have a point. If we had not been
devoted and ambitious, we would not have
been the first in the industry to have a touch
screen. Nor would we have been pioneers
in the use of visible lasers and dual
measurement heads.
Over the years, we have learnt to never
compromise on quality and we are
constantly in search of new, unexplored
opportunities by combining advanced
technology with design and function. By
doing so, we have become the leading
innovator in our industry. Not only do we
minimize wear, production stoppages and
costs, we also help save the environment.
Natural resources are in short supply and if
we can contribute to a more sustainable

1.2
world by making it a little bit straighter, we
couldn't be happier.
TRUE COMMITMENT
One reason for our success is our solid
commitment. We have ensured that we
remain attentive to constantly pick up on
the needs of the market. Our expert
employees and dedicated dealers in over 70
countries are undoubtedly our most
important asset. Satisfaction and team spirit
are of particular importance to us and are
consistently at the top of our priority list.
With experience from a wide range of
industries and manufacturing processes, we
are fully aware of the problems and needs of
our end-customers. We are passionate
about what we do and we are driven by the
desire to eliminate anything in the industry
worldwide that may be even slightly out of
line.
PURE USABILITY
Our design and user-friendliness are
carefully interwoven. As we develop new
products, they also become cleaner,
smarter, more functional and more robust.
An industrial environment is demanding,
infinitely more difficult to work in and
inevitably subject to time pressure. There is
no place for equipment with unnecessary
functions, complicated interfaces and that is
difficult to assemble.
Usability and user friendliness mean
everything, not only to us but also to our
customers. We have designed products that
are easy to learn and can be incorporated
quickly. By removing non-essential functions,

1.3
we make life less difficult for our users –and
probably a little more difficult for our
competitors.

1.4
END USER LICENSE AGREEMENT
The rights to use the software in this
product are offered only on the conditions
that you agree to all the terms stated below,
i.e. the end user agreement. By using this
product you agree to be bound by this
agreement. If you do not accept this
agreement your sole remedy is to return
the entire unused product, hardware and
software, promptly to your place of
purchase for a refund.
The user is granted a single license to use
the software contained in this product. Use
is only permitted on the hardware it has
been installed on at the time of purchase.
The software may not be removed from the
hardware.
The software contained in the system is the
property of ACOEM AB, any copying or
redistribution is strictly prohibited.
Modifying, disassembling, reverse
engineering or decompiling the system or
any part thereof is strictly prohibited.
Disclaimer of warranties: To the maximum
extent permitted by applicable law, ACOEM
AB and its suppliers provide the software
contained in this product ‘as is’ and with all
faults, and hereby disclaim all other
warranties either expressed, implied or
statutory.
Limited liability: No liability shall exceed the
price of the product, and the sole remedy, if
any, to any claim shall be a right of return
and refund.

1.5
ACOEM AB or its suppliers shall, to the
maximum extent permitted by applicable
law, not be liable to any indirect, special,
incidental, punitive, and consequential
damages arising from the use of the system
or any part thereof, authorized or
unauthorized.
ACOEM AB (formerly known as Elos
Fixturlaser AB) is since mid-2014 a fully
owned subsidiary of ACOEM Group,
headquartered in Lyon, France. Other
brands within ACOEM Group are 01dB,
ONEPROD and METRAVIB. For more
information please visit
www.acoemgroup.com

1.6

2.1
DECLARATION OF
CONFORMITY
In accordance with the EMC Directive
2004/108/EC, the Low Voltage Directive
2006/95/EC, including amendments by the
CE-marking Directive 93/68/EEC & EC
directives RoHS 2011/65/EU.
Type of equipment
Alignment System
Brand name or trade mark
FIXTURLASER ECO
Type designation(s)/Model no(s)
1-1047 FIXTURLASER ECO D
1-1048 FIXTURLASER M6
1-1049 FIXTURLASER S6
Manufacturer’s name, address,
telephone & fax no
ACOEM AB
Box 7
SE-431 21 Mölndal
Sweden
Tel: [phone]
Fax: [phone]
The following standards and/or technical
specifications, which comply with good
engineering practice in safety matters in
force within the EEA, have been applied:
Standard/Test report/Technical
construction file/Normative document
EN 61000-6-3:2007.
EN 61000-6-2:2005, EN 61000-4-2, -3, -4, -
5, -6, -11.

2.2
EN 61010-1:2010
ISO9001:2008 Ref. No/ Issued by: DNV
Certification AB Certification No. 2009-
SKM-AQ-2704/2009-SKM-AE-1419.
The laser is classified in accordance with the
International Standard IEC-60825-1:2014,
USA FDA Standard 21 CFR, Ch 1, Part
1040.10 and 1040.11 except for deviations
pursuant to laser notice No. 50, dated June
24, 2007.
The wireless device complies with Part 15 of
the FCC Rules. Operation is subject to the
following two conditions;
(1) this device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Additional information
The product was CE-marked in 2017.
As manufacturer, we declare under our sole
responsibility that the equipment follows the
provisions of the Directives stated above.
Date and place of issue
Mölndal 2017-05-30
Signature of authorized person
Hans Svensson, Managing Director

3.1
SAFETY
Retain and follow all product safety and
operating instructions. Observe all warnings
on the product and in the operating
instructions.
Failure to observe the safety pre-cautions
and operating instructions can cause bodily
injury, fire, and damage to the equipment.
Do not disassemble, modify or use the
equipment in other ways than explained in
the operating instructions. ACOEM AB will
not accept any liability for such use.
WARNING!
Do not mount equipment on
running machines and take all
appropriate measures to
prevent unintentional start-up
of machines. Make sure to fully
comply with all appropriate
shut down procedures, safety
measures and regulations at
worksite and local regulations
regarding safety in a machine
environment.

3.2
LASER PRECAUTIONS
FIXTURLASER ECO uses laser diodes with
a power output of < 1.0 mW. The laser
classification is Class 2.
Class 2 is considered safe for its intended
use with only minor precautions required.
These are:
Never stare directly into the laser
transmitter.
Never shine the laser directly into
anyone else’s eyes.
CAUTION!
USE OF CONTROLS OR
ADJUSTMENTS OR
PERFORMANCE OF
PROCEDURES OTHER
THAN THOSE SPECIFIED
HEREIN MAY RESULT IN
HAZARDOUS RADIATION
EXPOSURE.

3.3
Your system complies with the
requirements in:
IEC-60825-1:2007
British Standard BS EN 60825-1
DIN EN 60825-1
USA FDA Standard 21 CFR, Ch 1, Part
1040.10 and 1040.11

3.4
POWER SUPPLY
FIXTURLASER ECO display unit is powered
by a rechargeable Li-Ion battery mounted in
the display unit or by the external power
unit.
The measurement units (M6 and S6) are
powered by a rechargeable Li-Ion battery
mounted in the units or by the external
power unit.
Both the display unit and the measurement
units (M6 and S6) can be connected to the
charger and charged while lying in the case.
It is important that the lid of the case is
open during the charging or else the system
will not be charged properly and might be
damaged.
Do not expose the power adapter to rain
or wet conditions.
Always unplug the charger from the
electrical outlet after charging.
Leaving a display unit or a measurement unit
with an empty battery for a prolonged time
can reduce the capacity of the battery or
even damage the battery.
If the system is not used for a long time,
charge the batteries to approximately 50-
75% before storing the system, if kept in
storage repeat this every 3-4 month (if
needed).

3.5
When used in typical conditions the battery
will sustain good capacity for approximately
2-3 years before needing replacement.
Contact your sales representative for
battery replacement.
The batteries contain safety circuitry to
operate safely with the display unit. The unit
can therefore only be used with the Li-Ion
batteries supplied by FIXTURLASER.
Improper replacement of batteries can
cause damage and risk for personal injury.
WARNING!
BATTERY REPLACEMENT
SHALL ONLY BE
PERFORMED BY
AUTHORIZED FIXTURLASER
REPRESENTATIVES.
USE OF ANY OTHER
BATTERIES THAN THOSE
SUPPLIED BY FIXTURLASER
WILL CAUSE SEVERE
DAMAGE TO THE DISPLAY
UNIT AND CAN CAUSE
RISK FOR PERSONAL
INJURY!

3.6
Handle any batteries with care. Batteries
pose a burn hazard if handled improperly.
Do not disassemble and keep away from
heat sources. Handle damaged or leaking
batteries with extreme care. Please keep in
mind that batteries can harm the
environment. Dispose of batteries in
accordance with local regulatory guidelines,
if in doubt contact your local sales
representative.
Only use the external power adapter
supplied by FIXTURLASER for use with the
display unit and the measurement units.
Using other power adapters can cause
damage to the unit and personal injury.

3.7
WIRELESS TRANSCEIVER
The FIXTURLASER ECO system is fitted
with a Bluetooth wireless transceiver.
Make sure that there are no restrictions on
the use of radio transceivers at the site of
operation before using the wireless
transceivers.
WARNING!
Before using the wireless
transceivers make sure that
there are no restrictions on
the use of radio transceivers at
the site. Do not use on
aircraft.

3.8
