FKI TL 5417 Troubleshooting guide
Operating instructions and service manual
TL 5417
ROTO Toaster
Version 2.0 –Jan 2017
2
1. Table of content
1. Table of content ..........................................................................2
2. Introduction................................................................................3
3. In general...................................................................................3
3.1. Manufacturer...........................................................................................................3
3.2. Full name of the machine........................................................................................3
3.3. Machine tag ............................................................................................................4
4. Overview and application ..............................................................4
4.1. Purpose and intended use......................................................................................4
4.2. Foreseen misuse.....................................................................................................4
4.3. Technical specifications and consumption..............................................................4
4.4. Placement...............................................................................................................5
4.5. Safety precautions to be taken by the user.............................................................5
4.5.1. Personal safety equipment..................................................................................5
5. Operation...................................................................................5
6. Maintenance and repair.................................................................5
6.1. Cleaning and order..................................................................................................5
6.2. Repair .....................................................................................................................6
7. End of use..................................................................................6
7.1. Destruction..............................................................................................................6
8. Appendix ...................................................................................6
8.1. Signs, symbols and pictograms...............................................................................6
8.1.1. Spare parts .........................................................................................................7
9. EU Declaration of conformity..........................................................9
10. El-diagram ................................................................................10
3
2. Introduction
Original instruction manual
This manual is a translation of the original manual for the ROTO Toaster TL 5417. In the
following mentioned as the toaster.
Purpose
The purpose of this manual is to ensure proper installation, use, handling and mainte-
nance of the toaster.
Accessibility
The manual shall be kept in a –to the staff –well known place which is easy to access for
electricians and other personnel who maintain.
Knowledge
The employer is obligated to ensure that people who operate, serve and/or maintain the
roller grill, has read this instruction manual or as a minimum are familiar with parts which
are relevant to their job.
Furthermore everybody who operates, serve and/maintain the roller grill is obligated to
seek information in this operation instructions manual.
3. In general
3.1. Manufacturer
Roto toaster TL 5417 is manufactured by
Company name: FKI Fast Food Teknik A/S
Address: Byghøjvej 5, Verninge
DK-5690 Tommerup
3.2. Full name of the machine
The full name of the toaster is ROTO Toaster TL 5417
4
3.3. Machine tag
The machine tag is placed on the back.
4. Overview and application
4.1. Purpose and intended use
Roto toaster TL 5417 for heating and caramelizing of burger buns.
Max. size of burger buns diameter = 240mm
Distance between heat elements and burger bun leader = minimum 10 mm,
maximum 34 mm
4.2. Foreseen misuse
The toaster shall not be used for burgers, sausages, pizzas, baguettes or other products
containing fat, oil or similar.
4.3. Technical specifications and consumption
Overall dimensions
Height x width x depth: 530 x 380 x 270 mm
Weight: 18 kg
Electricity
Connection power: 230 V AC
Frequency: 50 Hz
Current absorbed: 9,1 A
Power absorbed: Max. 2,1 kW
Noise
Airborne noise coming from the toaster:
5
Measured sound pressure level : < 45 dB(A)
4.4. Placement
The toaster is designed for placement on a table top of a suitable height and is feed from
the top. De toasted buns is picked up from the drawer at the bottom front.
4.5. Safety precautions to be taken by the user
4.5.1. Personal safety equipment
It is recommended to use gloves since the toaster is hot especially on the top surfaces.
5. Operation
The red switch on the front turns on the toaster. A red lamp is
indicating that the toaster is on.
The toaster is with fixed band speed and the distance between
band and heat surface can be adjusted by the two turning knobs.
Tempeature on the heating surface is thermostatic controlled and
can be adjustes from 50-300°C by turning the knob.
The burger bun are placed with one-half on each side of the bread
slicer at the top, with the cut face towards the heat surface.
The bun halves are automatically taken through the
toaster and down in the bun tray. Depending of the size of
the buns halves the distance between band and heat sur-
face shall be adjusted in a way so the buns are kept to the
heat surface without being pressed.
The temperature is adjusted to reach desired toast level.
6. Maintenance and repair
6.1. Cleaning and order
It is important to keep the band clean of bread crumbs and residues. Use a shafted brush
for the cleaning.
Daily cleaning shall be carried out when the toaster has cooled down. The bread tray is
emptied and washed with a damp cloth. The surfaces of the toaster are cleaning by wiping
with a damp cloth.
The heat surface is covered by a Teflon sheet, which can be taken out by lifting the bread
slicer, and remove the sheet. The sheet can be washed or brushed.
Temperature
adjustment
Switch
Distance
adjustment
6
6.2. Repair
Authorized personnel with knowledge of electrical equipment shall always carry out repair.
7. End of use
7.1. Destruction
The toaster is marked with the above recycling symbol (EC Directive 2002/96/EC) and
must be disposed in accordance with your country order. This means that when the prod-
uct becomes obsolete, you should dispose it after the local municipality’s rules,
e.g. in unsorted waste stream.
8. Appendix
8.1. Signs, symbols and pictograms
The toaster is marked with the following symbol and pictograms:
Recycling Symbol according to EU Directive
Hot surface –use protection gloves
7
8.1.1. Spare parts
8
Pos.
Part number
Pcs.
Description
1
83-07890
2
Bearing, bronze Ø6/10x10
2
83-07906
1
Thermostat 50-320°C 1-pole
3
78-04590
2
Nut M6
4
74-00050
2
Ball screw
5
83-07926
2
Band ROTO L
6
83-08002
1
Outer cabinet
7
74-00056
1
Switch, Blue with light
8
83-08003
1
Cabinet part top/back
9
76-00000
2
Turning knob ROTO L
10
74-00005
1
Knob
11
81-06027
4
Leg, black ø22
12
83-07946
1
Bread tray TL5410
13
72-03570
1
Cable glance
14
03-70511
1
Bread slicer
14a
01-10082
1
Teflon sheet TL5410
15
83-08010
1
Gear motor, right
16
83-08011
1
Gear motor, left
17
83-08391
1
Heating plate lower
18
72-03684
1
Heating element 230V –2000W
19
78-00655
5
Screw M5 x 16 US
20
83-08392
1
Heating plate upper
9
9. EU Declaration of conformity
EF-overensstemmelseserklæring
2006/42/EF bilag II A
Fabrikant:
Navn
FKI Fast Food Teknik
Adresse
Byghøjvej 5, Verninge
Postnr. og by
5690 Tommerup
Erklærer hermed at maskine type:
-ROTO toaster TL 5417
Er fremstillet i overensstemmelse med følgende EF direktiver:
-2006/42/EF Maskindirektivet
-
under anvendelse af følgende harmoniserede standarder:
-EN 60204-1 Elektrisk Materiel på Maskiner
-
og følgende nationale standarder og tekniske specifikationer:
-
-
Søren Poulsen
Direktør
Verninge
05.06.2011
Underskriver
Stilling
Sted
Dato
10
10. El-diagram
Pos.
Part no.
Pcs.
Description
1
72-03659
1
Power cord 3 x 1,5 mm²
2
83-08156
1
Connector 2-polet
3
74-00056
1
Switch, Blue with light
4
83-08156
1
Connector 4-polet
5
83-07906
1
Thermostat 50-320°C 1-pole
6
83-08010
1
Gear motor, left
7
83-08011
1
Gear motor, right
8
72-03684
1
Heat element 2,0 kW 230V
M M
11
12
Byghøjvej 5, Verninge –DK-5690 Tommerup –Danmark
