Flame PANMIX User manual

PANMIX - Dual Panning Recorder
MANUAL
Version 1.00
FLAME

MANUAL FLAME PANMIX Version 1.00
Contents
1. Short description ................................................................ 3
2. Hardware / Connections ..................................................... 3
2.1 Connection to the modular system (Doepfer bus) 3
2.2 Module overview 4
2.3 Module backside 5
3. Handling ............................................................................. 6
3.1 Manual mix mode (Stop) 6
3.2 Record 6
3.3 Play back 6
3.4 Play funktion Speed 7
3.5 External reset 7
3.6 Inputs CV-Pan 7
3.7 Direct inputs 7
4. Appendix and technical informations .............................. 8
4.1 Technical details 8
4.2 Warrenty 8
4.3 Terms of production 8
4.4 Disposal 8
4.5 Support 8
4.6 Acknowledgment 8
2

1. Short description
2. Hardware / Connections
The FLAME "PANMIX" module includes two independent panning mixers with one input on two
left / right outputs and is designed for audio or CV sources in the voltage range of + -5v (audio
modular level). In addition, the 2 inputs Aand B can be separately switched to + 6db audio via
the rear slide switch (for external audio line level sources).
The movements of the two mix controls can be recorded. The recording time per channel is over
two minutes. The playback speed is adjustable in the playback. The recorded track is played by
pressing the Play button once (one shot) or by a longer press in the loop. The track data remains
permanently stored (battery-backed memory).
Both panning channels have a separate reset input and a separate CV input (+ -5V) for control-
ling the mix e.g. by an LFO. In addition, there are three other audio / CV signal inputs (one mono
and stereo left + right), which are routed directly to the output and mixed together with the two
PAN channels. So you can directly mix other sources and e.g. connect two or more "PANMIX"
modules together.
3
2.1 Connection to the modular system (Doepfer bus)
The module is delivered with a connected
ribbon cable for the Doepfer bus. The red
lead marks -12 volt. Connecting the module
please note the right polarity!
If the module is poled accidentally wrong
safety diodes avoid the immediate destruc-
tion of the module but further damages can-
not be excepted.
So please pay attention: Check the connec-
tion various times before switching on!
-12V
Ground
Ground
Ground
+12V

4
2.2 Modul overview
Key RECORD
Mode LED
Key PLAY
Key STOP
Panning Mix pot
RESET input (0/5v)
Channel Audio/Signal input (+/-5v)
CV Panning input (+/-5v)
Audio/Signal direct inputs (+/-5v)
Audio/Signal stereo output (+/-5v)
u
w
v
x
y
z
{
|
}
u
w
x
y
z
{
v
|
}
~
~

Insert the backup battery before connecting the unit to your modular rack
The PANMIX module uses a standard 3v lithium backup battery, type CR2032. Insert the provided
battery or a comparable battery into the battery compartment as shown below. The battery is needed
to keep recordings and settings stored when the Eurorack case is turned off.
Make sure the anode (+) points outwards ! Otherwise you destroy the SRAM !
2.3 Module backside
5
Socket for backup battery
3V Typ CR2032
Switches for input levels
- Modular level CV or Audio (default)
- Position AUDIO: +6db Audio line level (only audio!)
At the bottom of the module there are two slide switches for setting the input level of the panning
mixer inputs (A + B). The switch position AUDIO means that the input can be used as an audio input
with + 6dB gain for external line level. In this case, the input can not be used as a CV input. In the
other switch position, the module CV or Audio processes levels of +/- 5v (modular level).
In addition there are the socket for the backup battery of the memory.
Please note the information below!
channel A
channel B

6
3. Handling
For beginning the record sequence please push the REC button (blinking LED). You can record
the movements of the ruler until you push again the button REC or until up to the maximal
record time. Now the record sequence stops and jumps automatically in the Play loop mode
(LED on). The sample rate is about 250Hz.
From mode STOP or PLAYyou can start a record sequence anytime.
The maximum recording time per channel is about 2 minutes.
Please note: not the signal at the inputs is recorded, but only the volume control of the poten-
tiometers!
After switching on, the module is in STOP mode. All LEDs are off. With the respective panning
potentiometer of the track you can now control the applied signal of the channel between left
and right of the stereo output. If the potentiometer is at left stop, the signal appears left, at right
stop at output right.
In this mode, the module behaves like an ordinary dual Panningmixer with one input per chan-
nel to a stereo output left / right.
Since the mixer is internally equipped with VCAs, the mix control per channel can be recorded
separately for up to two minutes and played back later.
After a record sequence the play back of the track starts automatically in loop (LED on). If you
are in mode STOP (LED off) then you can start the play back with pushing the button PLAY.
Please note the both versions of pushing (short or long):
ONE SHOT - Track plays once only: Push the button shortly (< 0,5sec)
PLAYLOOP - Track plays in loop: Push the button longer (> 0,5 sec)
ATTENTION:
Reset can start the track (or tracks) while Play mode is activated (LED on).
3.2 Record
3.1 Manual mix mode (Stop)
3.3 Play back

With the ruler you can change the speed of the play back. Turn the pot over the middle position
to activate the speed function. In ruler position Zero you have the half speed and in ruler posi-
tion maximal you have the fourth speed. The original record speed is about ruler middle posi-
tion.
Please note:
After the end of the One shot sequence the function SPEED has no effect.
3.4 Play back function Speed
Ahigh pulse at the reset input of the channel sets the track (Play Mode) to the beginning and
starts it. If the track was previously in One Shot Mode, the sequence will also be played only
once (until another reset pulse arrives).
ADVICE:
Reset has no effect while mode RECORD or STOP is activated.
3.5 Reset
7
Use the CV-Pan input of the channel to control mixing with a control voltage (such as an LFO).
The input can handle voltages in the range of +/- 5v. The pot serves as an attenuator. In order
to use the full voltage range, you must therefore turn the potentiometer to the right stop. When
using an LFO, the frequency should not be higher than 125Hz, because the sample rate of the
recorder is about 250 Hz.
ADVICE:
If you use a modulated CV for recording the mix (eg from an LFO), then this also controls the
SPEED during playback. You should then, if necessary, turn the potentiometer to zero, or pull
out the cable.
3.6 Input CV-Pan
In addition, there are three other audio / CV signal inputs (one mono and left + right) routed
directly to the output and mixed together with the two PAN channels. So you can directly mix
other sources (only with modular level) and e.g. connect two or more "PANMIX" modules
together.
ADVICE:
All 5 inputs (Pan A, Pan B and the three "Direct Inputs") share the maximum output gain. Only
when all 5 channels have been maximally controlled, the output level is +/- 5 volts.
3.7 DIRECT INPUTS

4. Appendix
4.1. Technical details
Connections:
Ribbon cable adapter for Doepfer bus +/-12Volt
Inputs: 5x Audio/CV (+/-5v), 1/8th inch mono jacks
2x Reset (0/+5v..10v), 1/8th inch mono jacks
2x Panning mix CV (+/-5v), 1/8th inch mono jacks
Outputs: 2x left and right (+/-5v), 1/8th inch mono jacks
Control elements:
6 push buttons
2 knobs for mix and speed
2 LED’s
Resolutions: AD/DA converter: 12bit, Sample rate: 250Hz
Current consumption: max + 40mA / - 30mA
Size: Euro rack format 3U / 6HP 30x128,5x40 mm
4.2 Warrenty
Beginning from the date of purchase a 2-year warranty is guaranteed for this device in case of
any manufacturing errors or other functional deficiencies during runtime.The warranty does not
apply in case of:
- damage caused by misuse
- mechanical damage arising from careless treatment (dropping, vigorous shaking, mishandling, etc)
- damage caused by liquids penetrating the device
- heat damage caused by overexposure to sunlight or heating
- electric damage caused by improper connecting
(wrong power supply/ jacks/ MIDI connections/ voltage problems).
If you have any complaints please contact your dealer or send an e-mail to:
service@flame-instruments.de
4.3 Terms of production
conformity: CE, RoHS, UL
4.4 Disposal
The device is produced with RoHS-conformity (subject to the regulations of the European Union)
and is free of hazardous substances (like mercury, plumb, cadmium and hexavalent chrome).
But electronical scrap is hazardous waste. Please don't add this to consumer waste. For an
environment friendly disposal of waste please contact your distributor or specialist dealer.
4.3 Support
Updated and additional informations, updates, downloads and more see:
www.flame-instruments.de
4.4 Acknowledgment
For help and assistance big thanks to: Alex4 and Schneiders Büro Berlin, Shawn Cleary
(Analogue haven, Los Angeles), Thomas Wagner, Robert Junge, Anne-Kathrin Metzler, Lena
Bünger and Felix Bergleiter.
