Flamerite Fires Gotham Series User manual

1 | Page
Installation, Precautions & Servicing
Gotham
600 750 900 1300
OmniGlide
600 900 1300
IMPORTANT
This product is only suitable for well insulated spaces or occasional use
Carefully remove the fire from the packing checking neither the heater nor the power
cable has been damaged during transport. Do not operate the fire if damaged. Please
bear in mind the weight of the fire before removal from the packaging and installation.
Consider if help is required. Always read this manual first before attempting to install
or use and keep in a safe place. Any alteration to the power cable should only be done
by a qualified electrician.
Your fire is guaranteed for one year from the date of purchase. In the unlikely event of
a breakdown you have access to our customer services team, simply call 01543 251122
during office hours, 9am – 5pm or e-mail on [e-mail] The accessories
are found in a box that is packed at the side of the fire.

2 | Page
•For indoor use only.
•Do not use the fire in the vicinity of a bath, shower or swimming pool.
•Never use the fire to dry laundry.
•Never install the fire directly underneath a fixed main socket.
•Never cover the appliance.
•The use of an extension lead is not recommended.
•This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children without supervision.
•Children of less than 3 years should be kept away unless continuously supervised
•Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it
has been placed or installed in its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
•Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.
•Some parts of this product can become very hot and cause burns. Particular attention has to be given
where children and vulnerable people are present
•Caution should be applied to ensure that children do not play with the fuel effects.
•As with any electrical appliance whilst the instructions aim to cover as many eventualities as possible,
caution and common sense should be applied when operating your appliance, particularly in the
vicinity of small children.
•CAUTION: The heater is fitted with an automatic cut out to prevent any damage due to overheating.
The element will continually and automatically cut out if the airflow is obstructed. Never cover the air
outlets. To reset, switch the fire off, disconnect from the mains supply, remove the cause of the
overheating, where fitted check the OmniGlide micro switches. Allow to cool for a suitable period
then switch the fire back on.
•CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut out, the
appliance must not be supplied through an external switching device, such as a timer, or connected to
circuit regularly switched on and off by a utility.
Important Safety Information and Warnings
Where a chimney is not blocked off completely, any draw will cause the heater to cut
out during use. Care should also be taken when fitting into a cavity wall in case of
damp or draft with external air vents fully sealed

3 | Page
Electrical connections. Your appliance comes fitted with a plug that incorporates a 13A fuse. The replacement
fuses must be 13A and ASTA approved. If the fuse cover is lost the plug must not be used until a replacement
cover, of the same colour, is obtained from an electrical retailer. The appliance is fitted with a moulded plug if
it is necessary cut off the plug, for any reason, it must be discarded immediately with the fuse removed.
Under no circumstances should any attempt be made to reuse the plug, do not insert into any 13A socket as
this could cause a hazard. If the mains cable is damaged it must be replaced by the manufacturer or an
authorised technical service centre.
WARNING THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code.
Green and yellow:
EARTH
Blue:
NEUTRAL
Red:
LIVE
As the colours of the wires in the mains lead of this appliance may not correspond with the colour markings in
your plug proceed as follows: -
•The wire which is coloured green and yellow must be connected to the terminal in the plug
which is marked with the letter E, or coloured green or coloured green and yellow, or marked
with the earth symbol
•The wire which is coloured blue must be connected to the terminal in the plug which is marked
with the letter N, or coloured black.
•The wire which is coloured brown must be connected to the terminal in the plug which is marked
with the letter L, or coloured red.
RECYCLING
Please recycle responsibly. Take your item to your local recycling
centre. You can easily locate your nearest centre on
the www.recyclenow.com website or check with your retailer for
details on either a collection service or a store take-back scheme (some
may apply charges). Councils may offer a household recycling
collection service for small electrical items; contact your local authority
for more details.
Electrical Connections
Insert the plug tightly into its IEC connector underneath the fire if not already done
so. If the removal of the plug is absolutely necessary for installation, cut off in an
area within 100mm only of the plug itself. Any further will affect your warranty.

4 | Page
DO NOT TWIST, FORCE OR SQUEEZE THE FIRE DURING THE INSTALLATION PROCESS.
The height at which you may wish to fix the fire in the wall is up to you, though we recommend anywhere
from 350-450mm from the floor to the bottom of the fire opening (not the bottom of the fire).
Using the OnmiGlide 900 as a Hang on the Wall.
•The fixing rail should be fixed to the wall using the 4 x 60mm screws and rawl plugs with the hooks
facing upward and outwards.
•At the back of the case (bottom/centre) is a fold down tag. Fold this down to expose it under the fire.
•Once the rail is fixed in place, lift and hook the fire onto the rail.
•Mark off through the hole in the fold down tag. Remove fire and drill hole.
•Hang the fire back on the wall and secure in place using the 35mm screw and rawl plug. This will
prevent the fire from being lifted off the hooks on the fixing rail.
Situ
Screws
Rawl Plugs
OnmiGlide 900
4 x 60mm
10mm x 50mm
Hang on wall
1 x 35mm
5.5mm x 34mm
Using in a Flamerite suite, chimney breast, fireplace or an internal studwork and plaster board wall.
Always ensure the fire is well supported in a structure when mounting above the floor. A header or Lintel
should be fitted at the required height to ensure the appliance does not support the weight of the finished
wall or chimney breast.
The minimum opening size to inset your fire
Model
H
W
D
600
730mm
610mm
170mm
900
875mm
760mm
170mm
750
510mm
920mm
170mm
1300
510mm
1320mm
170mm
•There must be enough clearance for the fire to comfortably fit into the hole. DO NOT SQUEEZE INTO
THE OPENING this may deform the case and stop the glass from moving correctly.
•Prior to sealing/plastering the wall, the must be secured into place using the fixings provided.
•If not already done so fitting a Gotham into a Flamerite Suite, this will be done from the back.
•If not already done so fitting an OnmiGlide into a Flamerite Suite, this will be done from the front.
Situ
Screws
Rawl Plugs
Stud Wall
4 x 35mm
N/A
Chimney
4 x 35mm
5.5mm x 34mm
Fireplace
4 x 35mm
5.5mm x 34mm
Suite
4 x 15mm
N/A
Installation Instructions

5 | Page
Four larger counter sunk holes will be visible at each corner of the fire.
The OnmiGlide Front
The front is held on by four keyhole slots, one in each corner. Corresponding screws are attached to the case,
they should be adjusted for a tight fit. Lift the front over the screws, insert into the keyhole slots and push
down.
Please now test the fire and follow the rest of the instructions below before
permanently boarding/sealing/plastering in place.

6 | Page
The log effects must be positioned according to the images below. Care must be taken to ensure there is
enough room between the front of the logs and the glass channel at the front of the opening so the glass may
tilt open freely into the fire and trigger the micro switch.
Visit www.flameritefires.com/downloads if you require clearer downloadable images.
600
750
Log Effect

7 | Page
900
1300

8 | Page
WARNING: The glass used is toughened, if mishandled it is designed to shatter. Extra care should be taken
during this procedure. Make sure the fire is turned off and the heater allowed to cool.
Insert
•AHold the glass panel in each bottom corner
•BTilt the top of the glass into the fire
•CPlace the bottom on the glass panel into the channel
•Adjust the glass panel side to side for a smooth forward and backwards action
Glass Fitting & Removal

9 | Page
Opening & Closing
To open and close the front glass panel, place your index finger on the handle as shown in the picture.
Remove
•AHold the glass panel across the top either side of the heater
•BPull up and outward of the channel toward you C. Do not rest on a hard surface
Gotham (600 & 900) Dresser Rail
Simply fit the rear of the channel in front of the glass whilst the front hangs over covering the join from wall to
fire.

10 | Page
WARNING: Before any maintenance/cleaning is undertaken, always disconnect the fire from the mains
power supply.
Replacing Lamps
Dimmable 240V 6W 3000k E14 LED lamps
Allow a suitable time for the lamps to cool then remove the glass & fuel effect (see Installation). Remove the
two screws from either side of the fuel bed and lift out of place. Remove and replace the lamps, fuel bed, fuel
effect and glass. Please note that replacement Lamps are only covered from purchase by a 2-year warranty.
Replacements are available from Flamerite Fires Ltd
Cleaning
The fire can be cleaned with a soft cloth and nonabrasive glass cleaner.
•No power to the fire: Check the wall socket, plug, fuse and lamps.
•Heat turns off quickly after turn on: Set thermostat on app after turning heat on, not before.
•No illumination: Make sure fire is turned on. Check heater is working, if so check lamps.
•Heater blowing cold air:The safety cut out may have operated. Check for obstruction around the
heater. If continually a problem and fitted into a cavity wall or chimney breast check with installer the
inset opening has been 100% fully sealed from drawn air and draft.
•Noise when illuminated: Due to moving parts, the electric fire will make a noise.
•Noise from the heater when in use: The sound of rushing air is normal.
Maintenance
Trouble Shooting

11 | Page
Information requirement for electric local space heaters
Model identifier (s)
600
900
750
1300
Item
Symbol
Value
Value
Value
Value
Unit
Heat
output
Nominal heat output
Pnom
1.5
1.5
1.5
1.5
kW
Minimum heat output (indicative)
Pmin
0.75
0.75
0.75
0.75
kW
Maximum continuous heat output
Pmax,c
1.5
1.5
1.5
1.5
kW
Auxiliary electricity consumption
At nominal heat
elmax
17.5
35
25.8
43.8
W
At minimum heat
elmin
28.5
46
36.8
54.8
W
Instandby
elSB
.5
.5
.5
.5
W
Type of heat output/room temperature control
With distance control option
Room temperature control, with open window detection
Adaptive Start
With electronic room temperature control plus week timer
Yes
Contact details:
Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs.
WS137AU
Information Requirements
Wiring Diagram
