Flamerite Fires Corello User manual

Corello/Yukon
This product is only suitable for well insulated spaces or occasional use
Installation & Precautions
Carefully remove the fire from the packing, checking that neither the heater nor the power cable has been damaged during transport. Do not
operate the fire if either is damaged. Please bear in mind the weight of the fire before removal from the packaging and installation. Consider if
help is required. Any alteration to the power cable should only be done by a qualified electrician and to the Flamerite Fires guidelines stated
below. Your fire is guaranteed for one year from the date of purchase. In the unlikely event of a breakdown you have access to our customer
services team, simply call 01543 251122 during office hours, 9am – 5pm or e-mail on [e-mail] The accessories are found in a
box that is packed at the side of the fire.
INSTALLATION
Where a chimney is not blocked off completely it will cause the heater to cut out during use. ONLY if installing into a chimney and you are
not sure that you have cut off the draw 100% we recommend covering the slots in the rear and at either side.
Automatic safety cut out: The heater is fitted with an automatic cut out to prevent any damage due to overheating. The element will
continually and automatically cut out if the airflow is obstructed. Never cover the air outlets. To reset, switch the fire off, disconnect from the
mains supply, remove the cause of the overheating, check the micro switches and allow to cool for a suitable period then switch the fire back
on. Caution: In order to avoid a hazard due to inadvertent resetting of the thermal cut out, the appliance must not be supplied through an
external switching device, such as a timer, or connected to circuit regularly switched on and off by a utility.
Electrical connections: Your appliance comes fitted with a plug that incorporates a 13A fuse. The replacement fuses must be 13A and ASTA
approved. If the fuse cover is lost the plug must not be used until a replacement cover, of the same colour, is obtained from an electrical
retailer. The appliance is fitted with a moulded plug if it is necessary cut off the plug, for any reason, it must be discarded immediately with the
fuse removed. Under no circumstances should any attempt be made to reuse the plug, do not insert into any 13A socket as this could cause a
hazard. If the mains cable is damaged it must be replaced by the manufacturer or an authorised technical service centre.
WARNING THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code.
Green and yellow:
EARTH
Blue:
NEUTRAL
Red:
LIVE
As the colours of the wires in the mains lead of this appliance may not correspond with the colour markings in your plug proceed as follows: -
•The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked with the letter E,
or coloured green or coloured green and yellow, or marked with the earth symbol
•The wire which is coloured blue must be connected to the terminal in the plug which is marked with the letter N, or coloured
black.
•The wire which is coloured brown must be connected to the terminal in the plug which is marked with the letter L, or
coloured red.
Insert the plug tightly into its IEC connector underneath the fire if not already done so. If the removal of the plug is absolutely necessary for
installation, cut off in an area within 100mm only of the plug itself. Any further will affect your warranty.

Using as a Hole in the Wall:
THE SPACER MUST BE REMOVED (FIG.2)
Fig.1 Fig.2
Removing the decorative front (Fig.1), there are two screws either side of the heater outlet next to the on/off switch and the keypad and two
inside the fire under the fuel bed area beneath the lamps (B). To remove the spacer there are eight screws (A) on the rear of the case (Fig.2).
Four keyhole slots should now be visible, two on each side of the outer return. Place the fire into the hole, mark off at the TOP of the keyhole
slots where the fixing holes are to be drilled. Remove fire and drill the holes. When this is done push the rawl plugs into the drilled holes and
half screw in the fixings. Finally lift and hook the fire back onto the fixings and tighten. The decorative front may be reapplied.
Using as a Hang on the Wall. The rail should be fixed to the wall with the hook facing upward and outward. Once the rail has been fixed in
place, lift and hook the fire onto the rail. Next at the back of the case bottom/centre is a fold out tag. Fold this down as to expose it under the
fire when it is hung in place. Mark off through the hole, remove fire, drill and fit rawl plug. Hang the fire back on the wall and secure in place
using the screw provide.
Fuel effect Pebbles/coal
Once the fire has been installed in the correct position unpack the pebbles/coals from the accessory box and arrange on the fuel bed.
MAINTENANCE
Before any maintenance/cleaning is undertaken, always disconnect the fire from the mains power supply.
Replacing Lamps (Dimmable 240V 7W 3000k E14 LED lamps): Replacements are available from Flamerite Fires [e-mail]
Allow a suitable time for the lamps to cool then remove the glass & fuel effect (see Installation). Remove the two screws from either side of
the fuel bed and lift out of place. Remove and replace the lamps, fuel bed, fuel effect and glass. Please note that replacement Lamps are only
covered from purchase by a 2 year warranty
Cleaning
The fire can be cleaned with a soft damp cloth and none abrasive glass cleaner.
WARNINGS
•Do not open and close the glass repeatedly while the heater is on or the cut out will activate.
•Do not use the fire in the vicinity of a bath shower or swimming pool.
•Never use the fire to dry laundry.
•Never install the fire directly underneath a fixed main socket.
•Never cover the appliance during the operation of the fire.
•The use of an extension lead is not recommended.
•Particular caution should be applied to ensure that children do not play with the fuel effects.
•As with any electrical appliance whilst the instructions aim to cover as many eventualities as possible, caution and common sense
should be applied when operating your appliance, particularly in the vicinity of small children.
Areas around the fire will become hot when activated. We strongly recommend small children be kept away from having any direct
contact with the appliance by means of fitting a fireguard. This appliance is not intended for use by persons (or children) with
reduced physical sensory or mental capabilities or lack of experience or knowledge unless they have been given supervision or
instruction concerning the use of the appliance by the person responsible for their safety. Children should be supervised to ensure
they do not play with this appliance.

PROBLEM SOLVING
•No power to the fire:Check the wall socket, plug, fuse and lamps.
•No illumination: Make sure fire is turned on. Check heater is working, if so check lamps.
•Illumination but heater blowing cold: The safety cut out may have operated. Check for obstruction around the heater. If installed
into a chimney or cavity wall is 100% of drawn air blocked off from the fire.
•Noise when illuminated: Due to moving parts, the electric fire will make a noise.
•Noise from the heater when in use: The sound of rushing air is normal.
RECYCLING
Please recycle responsibly. Take your item to your local recycling centre – you can easily locate your nearest centre on the Recycle
Now website or check with your retailer for details on either a collection service or a store take-back scheme (some may apply charges).
Councils may offer a household recycling collection service for small electrical items; contact your local authority for more details.
Information requirement for electric local space heaters
Model identifier (s)
Corello/Yukon
Item Symbol Value Unit
Heat output
Nominal heat output
Pnom
2.0
kW
Minimum heat output (indicative)
Pmin
1.0
kW
Maximum continuous heat output
Pmax,c
2.0
kW
Auxiliary electricity consumption
At nominal heat
elmax
28.5
W
At minimum heat
elmin
28.5
W
In standby
elSB
0.0015
kW
Type of heat output/room temperature control
With distance control option
Room temperature control, with open window detection
With electronic room temperature control plus week timer
Yes
Contact details:
Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs.
WS13 7AU
