Flamerite Fires Luma Series User manual

1 | Page
Installation, Precautions & Servicing
Ador – Luma – Valentino - Jaeger
IMPORTANT
This product is only suitable for well insulated spaces or occasional use
Carefully remove the fire from the packing checking neither the heater nor the power
cable has been damaged during transport. Do not operate the fire if damaged. Please
bear in mind the weight of the fire before removal from the packaging and installation.
Consider if help is required. Always read this manual first before attempting to install
or use and keep in a safe place. Any alteration to the power cable should only be done
by a qualified electrician.
Your fire is guaranteed for one year from the date of purchase. In the unlikely event of
a breakdown you have access to our customer services team, simply call 01543 251122
during office hours, 9am – 5pm or e-mail on [e-mail] The accessories
are found in a box that is packed at the side of the fire.

2 | Page
•WARNING: In order to avoid overheating, do not cover the heater.
•For indoor use only.
•Do not use the fire in the vicinity of a bath, shower or swimming pool.
•Never use the fire to dry laundry.
•The heater must not be located immediately below a socket outlet.
•The use of an extension lead is not recommended.
•This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
•Children of less than 3 years should be kept away unless continuously supervised
•Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it
has been placed or installed in its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
•Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.
•Some parts of this product can become very hot and cause burns. Particular attention must be given
where children and vulnerable people are present
•Caution should be applied to ensure that children do not play with the fuel effects.
•As with any electrical appliance whilst the instructions aim to cover as many eventualities as possible,
caution and common sense should be applied when operating your appliance, particularly in the
vicinity of small children.
•CAUTION: The heater is fitted with an automatic cut out to prevent any damage due to overheating.
The element will continually and automatically cut out if the airflow is obstructed. Never cover the air
outlets. To reset, switch the fire off, disconnect from the mains supply, remove the cause of the
overheating. Allow to cool for a suitable period then switch the fire back on.
•CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut out, the
appliance must not be supplied through an external switching device, such as a timer, or connected to
a circuit regularly switched on and off by a utility.
Important Safety Information and Warnings
Where a chimney is not blocked off completely, any draw will cause the heater to cut
out during use. Care should also be taken when fitting into a cavity wall in case of
damp or draft with external air vents fully sealed

3 | Page
Electrical connections. Your appliance comes fitted with a plug that incorporates a 13A fuse. The replacement
fuses must be 13A and ASTA approved. If the fuse cover is lost the plug must not be used until a replacement
cover, of the same colour, is obtained from an electrical retailer. The appliance is fitted with a moulded plug if
it is necessary cut off the plug, for any reason, it must be discarded immediately with the fuse removed.
Under no circumstances should any attempt be made to reuse the plug, do not insert into any 13A socket as
this could cause a hazard. If the mains cable is damaged it must be replaced by the manufacturer or an
authorised technical service centre.
WARNING THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code.
Green and yellow:
EARTH
Blue:
NEUTRAL
Red:
LIVE
As the colours of the wires in the mains lead of this appliance may not correspond with the colour markings in
your plug proceed as follows: -
•The wire which is coloured green and yellow must be connected to the terminal in the plug
which is marked with the letter E, or coloured green or coloured green and yellow, or marked
with the earth symbol
•The wire which is coloured blue must be connected to the terminal in the plug which is marked
with the letter N, or coloured black.
•The wire which is coloured brown must be connected to the terminal in the plug which is marked
with the letter L, or coloured red.
RECYCLING
Please recycle responsibly. Take your item to your local recycling
centre. You can easily locate your nearest centre on
the www.recyclenow.com website or check with your retailer for
details on either a collection service or a store take-back scheme (some
may apply charges). Councils may offer a household recycling
collection service for small electrical items; contact your local authority
for more details.
Electrical Connections
Insert the plug tightly into its IEC connector underneath the fire if not already done
so. If the removal of the plug is absolutely necessary for installation, cut off in an
area within 100mm only of the plug itself. Any further will affect your warranty.

4 | Page
Wall mounting
Suite Screws Rawl Plugs
Luma 3x 60mm 2x 35mm 2x 16mm 3x 50mm 2x 35mm
Ador 3x 60mm 2x 35mm 2x 16mm 3x 50mm 2x 35mm
Jaeger
4x 60mm 2x 35mm 2x 16mm
4x 50mm 2x 35mm
The height at which you may wish to fix the fire in the wall is up to you, though we recommend anywhere
from 350-450mm from the floor to the bottom of the fire opening (not the bottom of the fire).
•The top MDF fixing rail should be fixed to the wall with the highest edge facing forward and the lowest
against the wall using the 3x 60m screws and 3x 50mm rawl plugs.
•The corresponding edge where the suite is to be hung on the top fixing rail can be found on the back,
at the top and across the suites centre.
•Once the top fixing rail is secured to the wall, lift and hook the suite onto it.
•The lower MDF rail should then be added to the underside of the suite. A channel in the underside will
be visible, the bottom rail will slot into this.
•With the suite in place, mark off the holes to be drilled, remove the suite and secure the lower rail to
the wall using the 2x 35mm screws and 2x 35mm rawl plugs. Refit the suite, lift and hook onto the
brackets.
•Finally fit the metal bracket to the lower rail and to the underside of the suite using the 16mm wood
screws. This will prevent the suite from being lifted off the fixing rails.
Valentino suite
•Your Valentino Suite is a freestanding and flat wall fix. Mirror clips are provided so you may secure it to
the wall
Installation Instructions

5 | Page
Your fuel effect may depend on what you have ordered to go with your suite. Pebbles & glass beads come as
standard. A small ember set can be part of this effect, all of which should be arranged randomly across the
fuel bed to suit (not pictured).
The log effect must be positioned according to the images below.
The Jaeger 1360 uses OmniGlide tilting glass, care are must be taken to ensure there is enough room between
the front of the logs and the glass channel at the front of the opening so the glass may tilt open freely into the
fire and trigger the micro switch.
Visit www.flameritefires.com/downloads if you require clearer downloadable images.
Small Cinder
Log Effect

6 | Page
Verada
Large Cinder

7 | Page
WARNING: The glass used is toughened, if mishandled it is designed to shatter. Extra care should be taken
during this procedure. Make sure the fire is turned off and the heater allowed to cool.
Insert
•AHold the glass panel in each bottom corner
•BTilt the top of the glass into the fire
•CPlace the bottom on the glass panel into the channel
•Adjust the glass panel for an even fit, side to side
Opening & Closing
To open and close the front glass panel, place your index finger on the handle as shown in the picture.
Jaeger
1360
Glass Fitting & Removal

8 | Page
Remove
•AHold the glass panel across the top either side of the heater
•BPull up and outward of the channel toward you C.Do not rest on a hard surface
WARNING: Before any maintenance/cleaning is undertaken, always disconnect the fire from the mains
power supply.
Replacing Lamps
Dimmable 240V 6W 3000k E14 LED lamps
Allow a suitable time for the lamps to cool then remove the glass & fuel effect (see Installation). Remove the
two screws from either side of the fuel bed and lift out of place. Remove and replace the lamps, fuel bed, fuel
effect and glass. Please note that replacement Lamps are only covered from purchase by a 2-year warranty.
Replacements are available from Flamerite Fires Ltd
Cleaning
The fire can be cleaned with a soft cloth and nonabrasive glass cleaner.
Maintenance

9 | Page
•No power to the fire: Check the wall socket, plug, fuse and lamps.
•Heat turns off quickly after turn on: Set thermostat on app after turning heat on, not before.
•No illumination: Make sure fire is turned on. Check heater is working, if so check lamps.
•Heater blowing cold air:The safety cut out may have operated. Check for obstruction around the
heater. If continually a problem and fitted into a cavity wall or chimney breast check with installer the
inset opening has been 100% fully sealed from drawn air and draft.
•Noise when illuminated: Due to moving parts, the electric fire will make a noise.
•Noise from the heater when in use: The sound of rushing air is normal.
Information requirement for electric local space heaters
Model identifier (s) Ador Luma 900
Luma
1200
Jaeger
1020
Item Symbol Value Value Value Value Unit
Heat
output
Nominal heat output Pnom 2 2 2 1.5 kW
Minimum heat output (indicative) Pmin 1 1 1 0.75 kW
Maximum continuous heat output Pmax,c 2 2 2 1.5 kW
Auxiliary electricity consumption
At nominal heat elmax 35 43 43 48 W
At minimum heat elmin 35 43 43 48 W
Instandby elSB .5 .5 .5 .5 W
Type of heat output/room temperature control
With distance control option
Room temperature control, with open window detection
Adaptive Start Yes
With electronic room temperature control plus week timer Yes
Contact details: Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs.
WS137AU
Trouble Shooting
Information Requirements

10 | Page
Model identifier (s)
Jaeger
600
Valentino
Luma
1360
Jaeger1360
Item@
240v 50Hz
Symbol Value Value Value Value Unit
Heat
output
Nominal heat output Pnom 1.5 2 1.5 1.5 kW
Minimum heat output (indicative) Pmin 0.75 1 0.75 0.75 kW
Maximum continuous heat output Pmax,c 1.5 2 1.5 1.5 kW
Auxiliary electricity consumption
At nominal heat elmax 0.033 0.043 0.058 0.048 kW
At minimum heat elmin 0.033 0.043 0.058 0.048 kW
Instandby elSB 0.0005 0.0005 0.0005 0.0005 kW
Type of heat output/room temperature control
With distance control option
Room temperature control, with open window detection
Adaptive Start Yes
With electronic room temperature control plus week timer Yes
Contact details: Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs.
WS137AU
Circuit Diagram
