FlashLogic DIR-CH8 User manual

REVISION DATE
20180321
DOCUMENT NUMBER
TERMS OF USE: Automotive Data Solutions Inc. (“ADS”) products are strictly intended for installation by
Certified Technicians who are employed by a registered business specialized in the installation of auto-
motive aftermarket electronics products. Prior to beginning installation of an ADS product in a vehicle,
it is the Certified Technician’s responsibility to review the most current Product Guide, Install Guide
and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever,
including but not limited to any consequential damages, incidental damages, damages for loss of time,
loss of earnings, loss of profit, commercial loss, loss of economic opportunity and the like that may or
may not have resulted from the use, misuse, improper installation or operation of its products. ADS
reserves itself the right to suspend any Weblink® account without notice and decline to offer technical
support to non-Certified Technicians, non-compliant Certified Technicians or end users.
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
U.S. Patent No. 8,856,780
INSTALL GUIDE
DIRCHRSCH8FLRSCH10EN
HARDWARE
FLRSCH10
ACCESSORIES
FLPROG REQUIRED
DIRECTED XL202 RFKIT & ADSHRNRSXL02 OPTIONAL
DIRECTED SMARTSTART & ADSHRNRSSM01 OPTIONAL
FIRMWARE
DIRCHRSCH8FLRSCH10
www.flashlogic.comAutomotive Data Solutions Inc. © 2018
48370

U.S. Patent No. 8,856,780
VEHICLE LIST - 1 OF 1
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS 3X LOCK START/STANDALONE MOD. DOOR LOCK DOOR UNLOCK ARM OEM ALARM DISARM OEM ALARM TRUNK/HATCH RELEASE DOOR STATUS OUTPUT TRUNK STATUS OUTPUT BRAKE PEDAL STATUS OUTPUT TACHOMETER OUTPUT SECURE TAKEOVER GLOW PLUGS STATUS RAP SHUTDOWN CTRL
DODGE
Dart STD key (Tip-Start) AT 13-16 1 • • • • • • • • • • • •
RAM
1500 / 2500 / 3500 STD key (Tip-Start) AT 13-17 2 • • • • • • • • • • •
1500 / 2500 / 3500 STD key (Tip-Start) AT 18 3 • • • • • • • • • • •
1500 / 2500 / 3500 Diesel STD key (Tip-Start) AT 14-17 2 • • • • • • • • • • • •
1500 / 2500 / 3500 Diesel STD key (Tip-Start) AT 18 3 • • • • • • • • • • • •
NOTE
I WARNING: All vehicle doors must be
closed and locked prior to remote start
sequence.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 2 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
BOX CONTENTS - 1 OF 1
3
6
4
1
2
5
C
B
A
F
G
E
D
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
2
1
3
7
9
3
10
8
6
4
12
5
2
1
3
4
2
1
3
4
MS1MS1
MS2MS2 VS2VS2
VS1VS1
VS7
VS8
VS3
VS4
VS6
VS5
BOX CONTENTS
T-HARNESS 1
AFTERMARKET HOOD SWITCH AND CABLE
WARNING STICKER
10 PIN CONNECTOR
12 PIN CONNECTOR
BLUE
PROGRAMMING
BUTTON
LED 2
LED 1
MODULE
BLACK
BLACK
BLACK
RF PORT/
WEBLINK PORT
BLACK
BLUE
TELEMATIC
PORT
WHITE
T-HARNESS 1
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 3 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 4 OF 23
• 20180321
COMPATIBLE ACCESSORIES - 1 OF 1
RF KIT (accessories sold separately)
DIRECTED XL202 RF KIT
ADS-HRN(RS)-XL02
XL202 RF DECODER XL202 ANTENNA
MODULE
RF PORT
TELEMATIC KIT (accessories sold separately)
(NC)
(NC)
(NC)
DIRECTED SMARTSTART
ADS-HRN(RS)-SM01
MODULE
TELEMATIC PORT
DOC.: #48370

U.S. Patent No. 8,856,780
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
OBDII
A
VS2VS2
VS1VS1
PTS
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
VS7
VS8
VS3
VS4
VS6
VS5
NC
NC
15
18
TYPE 1 - WIRING DIAGRAM - 1 OF 2
HORN (-)
IGNITION NODE
OBDII CONNECTOR
PARKING LIGHT SWITCHPARKING LIGHT SWITCH
MODULE
11 GRAY/GREEN - HORN (-) OUTPUT
PURPLE (NC)
OPTIONAL
IGNITION CONNECTOR
IGNITION HARNESS
OBDII HARNESS
LIGHT SWITCH CONNECTOR
LIGHT SWITCH HARNESS
OBDII HOLDER
04 GRAY/WHITE - HOOD STATUS (-) INPUT
TELEMATIC PORT
RF PORT/WEBLINK PORT
AFTERMARKET HOOD SWITCH (-)
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
15 BROWN
18 PURPLE
ONLY FOR
ADS-HRN(RS)-CHR10
VER1.20
NOTE 1
(SEE NEXT PAGE)
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 5 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
NOTE 1
TYPE 1 - WIRING DIAGRAM - 2 OF 2
STEP 1:
-IDENTIFY THE PURPLE (PIN 18) AND BROWN (PIN 15) WIRES FROM THE 20 PIN BLACK CONNECTOR OF THE T‐HARNESS.
-CUT THE PURPLE WIRE.
-CAREFULLY STRIP THE BROWN WIRE USING A WIRE STRIPPER.
STEP 2:
-CONNECT AND SOLDER THE PURPLE WIRE TO THE BROWN WIRE.
STEP 3:
-INSULATE THE CONNECTIONS WITH ELECTRICAL TAPE.
WARNING
FAILURE TO PROPERLY SOLDER
CAN RESULT IN
FAULTY CONNECTIONS AND
PRODUCT MALFUNCTION
ONLY FOR
ADS-HRN(RS)-CHR10
VER1.20
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 6 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
OBDII
A
VS2VS2
VS1VS1
PTS
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
VS3
VS4
VS6
VS5
NC
NC
VS7
VS8
15
18
TYPE 2 - WIRING DIAGRAM - 1 OF 2
HORN (-)
IGNITION NODE
OBDII CONNECTOR
PARKING LIGHT SWITCHPARKING LIGHT SWITCH
MODULE
11 GRAY/GREEN - HORN (-) OUTPUT
02 GRAY (NC)
PURPLE (NC)
OPTIONAL
IGNITION CONNECTOR
IGNITION HARNESS
OBDII HARNESS
LIGHT SWITCH CONNECTOR
LIGHT SWITCH HARNESS
OBDII HOLDER
04 GRAY/WHITE - HOOD STATUS (-) INPUT
TELEMATIC PORT
RF PORT/WEBLINK PORT
AFTERMARKET HOOD SWITCH (-)
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
15 BROWN
18 PURPLE
ONLY FOR
ADS-HRN(RS)-CHR10
VER1.20
NOTE 1
(SEE NEXT PAGE)
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 7 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
NOTE 1
TYPE 2 - WIRING DIAGRAM - 2 OF 2
STEP 1:
-IDENTIFY THE PURPLE (PIN 18) AND BROWN (PIN 15) WIRES FROM THE 20 PIN BLACK CONNECTOR OF THE T‐HARNESS.
-CUT THE PURPLE WIRE.
-CAREFULLY STRIP THE BROWN WIRE USING A WIRE STRIPPER.
STEP 2:
-CONNECT AND SOLDER THE PURPLE WIRE TO THE BROWN WIRE.
STEP 3:
-INSULATE THE CONNECTIONS WITH ELECTRICAL TAPE.
WARNING
FAILURE TO PROPERLY SOLDER
CAN RESULT IN
FAULTY CONNECTIONS AND
PRODUCT MALFUNCTION
ONLY FOR
ADS-HRN(RS)-CHR10
VER1.20
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 8 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
TYPE 3 - WIRE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
RAM
1500 / 2500 / 3500
STD key AT 18 CanH ~ Gray 10 pin 02 Orange (DATA) Trailer module, right of steering column ~
CanL ~ Gray 10 pin 01 Yellow (DATA) Trailer module, right of steering column ~
1500 Diesel / 2500 Diesel /
3500 Diesel
STD key AT
18
CanH ~ Gray 10 pin 02 Orange (DATA) Trailer module, right of steering column ~
CanL ~ Gray 10 pin 01 Yellow (DATA) Trailer module, right of steering column ~
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 9 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
A
1
6
2
7
3
8
4
9
5
10
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
OBDII
B
VS2VS2
VS1VS1
PTS
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
VS3
VS4
VS6
VS5
NC
NC
VS7
VS8
15
18
TRAILER PACK CONNECTORTRAILER PACK CONNECTOR
GRAY
TYPE 3 - WIRING DIAGRAM - 1 OF 2
HORN (-)
IGNITION NODE
OBDII CONNECTOR
PARKING LIGHT SWITCHPARKING LIGHT SWITCH
MODULE
11 GRAY/GREEN - HORN (-) OUTPUT
02 GRAY (NC)
PURPLE (NC)
OPTIONAL
IGNITION CONNECTOR
IGNITION HARNESS
OBDII HARNESS
LIGHT SWITCH CONNECTOR
LIGHT SWITCH HARNESS
OBDII HOLDER
04 GRAY/WHITE - HOOD STATUS (-) INPUT
TELEMATIC PORT
RF PORT/WEBLINK PORT
AFTERMARKET HOOD SWITCH (-)
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
15 BROWN
18 PURPLE
ONLY FOR
ADS-HRN(RS)-CHR10
VER1.20
NOTE 1
(SEE NEXT PAGE)
BROWN/YELLOW
BROWN/RED
CUT THE BROWN/RED AND BROWN/YELLOW WIRES.
INSULATE THE OBDII SIDE OF THE CUT WIRES AND
CONNECT THE OTHER SIDE TO VEHICLE CANH AND CANL.
CANL - 01
CANH - 02
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 10 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
NOTE 1
TYPE 3 - WIRING DIAGRAM - 2 OF 2
STEP 1:
-IDENTIFY THE PURPLE (PIN 18) AND BROWN (PIN 15) WIRES FROM THE 20 PIN BLACK CONNECTOR OF THE T‐HARNESS.
-CUT THE PURPLE WIRE.
-CAREFULLY STRIP THE BROWN WIRE USING A WIRE STRIPPER.
STEP 2:
-CONNECT AND SOLDER THE PURPLE WIRE TO THE BROWN WIRE.
STEP 3:
-INSULATE THE CONNECTIONS WITH ELECTRICAL TAPE.
WARNING
FAILURE TO PROPERLY SOLDER
CAN RESULT IN
FAULTY CONNECTIONS AND
PRODUCT MALFUNCTION
ONLY FOR
ADS-HRN(RS)-CHR10
VER1.20
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 11 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
01
02
03
04
OFF
ACC ON
START
05
06
OFF
ACC ON
START
07
OFF
ACC ON
START
08
OFF
ACC ON
START
09
OFF
ACC ON
START
10
11
OFF
ACC ON
START
12
13
14
15
OFF
ACC ON
START
16
17
OFF
ACC ON
START
18
OFF
ACC ON
START
MODULE PROGRAMMING PROCEDURE - 1 OF 2
Close driver door. Re-open driver door to wake
up data bus.
Press Unlock on OEM remote. If the vehicle is
not equipped with an OEM remote, press the
module programming button.
Wait, LED will flash GREEN once [1x]. If LED
does not flash GREEN, press Unlock on OEM
remote again.
Turn key to ON position.
Wait, LED will turn solid RED.
Turn key to OFF position.
Remove key.
Insert key into ignition.
Turn key to ON position.
Wait, LED will flash GREEN.
Turn key to OFF position.
WARNING: Disconnect power last. Disconnect
module from vehicle.
Connect module to computer and proceed
with extended programming.
WARNING: Do not press module programming
button. Connect power first. Connect module
to vehicle.
Turn key to ON position.
Wait, LED will turn solid GREEN for 2 seconds.
Turn key to OFF position.
Turn key to START position.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 12 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
19
OFF
ACC ON
START
20
MODULE PROGRAMMING PROCEDURE - 2 OF 2
Turn key to OFF position.
Module Programming Procedure completed.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 13 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
>>
01
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
ENGINE
START
STOP
OFF ACC ON STARTOFF
05
>>
VALET MODE PROGRAMMING PROCEDURE - 1 OF 1
NOTE: In Valet Mode, the Remote starter is not
functional. Keyless entry, Lock and Unlock will
remain functional. See RF kit user manual for
alternate valet mode programming.
Time restriction. Complete next step within 7
seconds.
Cycle ignition ON five times [5x OFF/ON]
rapidly.
Wait, LED 1 will turn solid RED for 2 seconds.
Set ignition to OFF position.
Valet Mode Programming Procedure
completed.
To exit valet mode: repeat steps 1 to 5.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 14 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
AFTERMARKET REMOTE PROGRAMMING - 1 OF 1
AFTERMARKET REMOTE PROGRAMMING:
NOTES
I All aftermarket remotes must be programmed to the
RF-Kit.
Refer to the RF-Kit user guide for aftermarket remote
features and programming procedures.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 15 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
>>
>>
>>
01
ENGINE
START
STOP
OFF ACC ON STARTOFF
02
03 [X]
04
05 [Y]
06
07 [Z]
08 [Z]
09
10
11 [Y]
12
13
14
>>
MODULE NAVIGATION PROCEDURE - 1 OF 1
It is mandatory to exit the Module Navigation
at the end of this procedure. Failure to exit the
Module Navigation will drain vehicle battery.
To exit the Module Navigation at any time:
Follow STEP 13.
Module must be programmed to the vehicle.
Use the Module Navigation Chart on the next
page.
Set ignition to OFF position.
TO ACCESS THE MENUS: Press and hold
programming button until LED 1 turns solid
GREEN.
IN THE MENUS: Press the programming
button as many times as the menu number
indicates. LED 1 will flash GREEN an equal
amount of times continuously.
TO ACCESS THE OPTIONS: Press and hold
programming button until LED 1 turns solid
RED.
IN THE OPTIONS: Press the programming
button as many times as the option number
indicates. LED 1 will flash RED an equal
amount of times continuously.
TO ACCESS THE SETTINGS: Press and hold
programming button until LED 1 turns solid
GREEN.
LED 1 will flash GREEN as many times as
the current (or default) setting number,
continuously.
IN THE SETTINGS: Press the programming
button as many times as necessary to access
your setting. LED 1 will flash GREEN an equal
amount of times continuously.
To return to the MENUS: exit the Module
Navigation and redo the Module Navigation
Procedure.
To save and return to the OPTIONS: Press and
hold programming button until LED 1 turns
solid RED.
LED 1 will flash RED as many times as the
current option number continuously.
Configure every other setting and proceed to
step 13.
MANDATORY: EXIT MODULE NAVIGATION.
Press and hold programming button for 7
seconds. LED 1 will flash RED rapidly. Release
programming button. LED 1 will turn OFF.
Module navigation completed.
Failure to exit the Module Navigation will drain
vehicle battery.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 16 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
MODULE NAVIGATION CHART - 1 OF 2
MODULE NAVIGATION CHART:
NOTES
[X] MENUS [Y] OPTIONS [Z] SETTINGS
I Default settings are listed in bold.
01 CONFIGURATION
01 DISARM/UNLOCK BEFORE START 01 OFF
II Make sure the option is covered on the vehicle before
attempting to change the setting.
02 ON
02 RELOCK AFTER START 01 OFF
02 ON
03 RELOCK AFTER SHUTDOWN 01 OFF
02 ON
04 FORCE UNLOCK ALL ON FIRST PRESS 01 OFF
02 ON
05 TAKEOVER 01 ENABLE
02 DISABLE*
06 N/A 01 N/A
07 N/A 01 N/A
08 MODULE RUN TIME
01 03 MIN
02 05 MIN
03 10 MIN
04 15 MIN
05 25 MIN
06 30 MIN
07 35 MIN
08 15 MIN
09 WAIT TO START DELAY
01 02 SEC
02 05 SEC
03 08 SEC
04 10 SEC
05 15 SEC
06 20 SEC
07 25 SEC
08 30 SEC
10 N/A 01 N/A
11 N/A 01 N/A
12 N/A 01 N/A
13 N/A 01 N/A
*Vehicle will shutdown when a door is opened.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 17 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
MODULE NAVIGATION CHART - 2 OF 2
MODULE NAVIGATION CHART:
NOTES
[X] MENUS [Y] OPTIONS [Z] SETTINGS
01 CONFIGURATION
14 HORN EVENT TRIGGER
01 DOUBLE LOCK
02 LOCK + UNLOCK
03 LOCK + UNLOCK + START
04 DOUBLE LOCK + START
15 HORN CHIRPS WIDTH
01 30 mSEC
02 15 mSec
03 60 mSec
02-07 Technical Support only 01 N/A 01 N/A
*Vehicle will shutdown when a door is opened.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 18 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
REMOTE STARTER ERROR CODES - 1 OF 1
REMOTE STARTER ERROR CODES:
NOTES
[X] NUMBER OF PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking
lights are connected and supported by the system.
03 Foot brake is ON.
04 Hood is open.
II After a remote starter failure, the parking lights will fl ash
[X] number times to indicate an error code. See table.
05 Engine tach signal is lost.
06 System is in Valet Mode.
07 Vehicle is moving (VSS).
08 Glow plug timeout error.
09 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
10 N/A
11 N/A
12 N/A
13 N/A
14 N/A
15 N/A
16 CAN communication failure during RS sequence.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 19 OF 23
• 20180321
DOC.: #48370

U.S. Patent No. 8,856,780
MODULE DIAGNOSTICS - 1 OF 1
TEST MODULE
LED 1 STATUS DIAGNOSTIC
I DURING PROGRAMMING
Flashing RED Missing/wrong information from firmware or vehicle.
Solid RED Module waiting for more vehicle information.
Flashing GREEN Additional steps required to complete module programming.
Solid GREEN then OFF Module correctly programmed.
OFF No activity or module already programmed.
II DURING REMOTE START
Flashing RED Module incorrectly programmed.
Solid RED Module incorrectly programmed.
Flashing GREEN Module correctly programmed and operational.
Solid GREEN then OFF Reset in progress.
OFF Invalid ground when running status from remote starter.
III WITH IGNITION OFF
Flashing RED Module incorrectly programmed or connected.
Solid RED Module not programmed. Waiting for more vehicle information.
Flashing GREEN False ground when running status from remote starter.
Solid GREEN then OFF Reset in progress.
OFF Module at rest and ready for a remote start sequence.
www.flashlogic.comAutomotive Data Solutions Inc. © 2018 DIRCHRSCH8FLRSCH10EN
PAGE 20 OF 23
• 20180321
DOC.: #48370
