FlashLogic FLC-CH(RS)-CH5-[FLRSCH5]-EN User manual

REVISION DATE
20151222
DOCUMENT NUMBER
NOTICE The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
U.S. Patent No. 8,856,780
INSTALL GUIDE
FLCCHRSCH5FLRSCH5EN
HARDWARE
FLRSCH5
ACCESSORIES
FLPROG REQUIRED
FLRF1/2/4 OPTIONAL
CARLINK ASCL2 OPTIONAL
FIRMWARE
FLCCHRSCH5FLRSCH5
www.flashlogic.comAutomotive Data Solutions Inc. © 2015
25395

U.S. Patent No. 8,856,780
VEHICLE LIST - 1 OF 1
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS 3X LOCK START/STANDALONE MOD. PRIORITY UNLOCK DOOR LOCK DOOR UNLOCK ARM OEM ALARM DISARM OEM ALARM TRUNK/HATCH RELEASE DATA/MUX STARTER CTRL DOOR STATUS BRAKE PEDAL STATUS TACHOMETER STATUS PARKING LIGHT CTRL* RAP SHUTDOWN CTRL
CHRYSLER
200 AT 11-14 2 • • • • • • • • • • • • • •
300 / 300C AT 05-07 1 or 3 • • • • • • • • • • • • • •
Aspen AT 07-10 2 • • • • • • • • • • • • • •
PT Cruiser AT 06-10 1 or 3 • • • • • • • • • • • • • •
Sebring AT 07-10 2 • • • • • • • • • • • • • •
DODGE
Avenger AT 08-14 2 • • • • • • • • • • • • • •
Caliber (with start wire) AT 07 1 or 3 • • • • • • • • • • • • • •
Caliber AT 07-12 2 • • • • • • • • • • • • • •
Charger AT 06-07 1 or 3 • • • • • • • • • • • • • •
Durango AT 07-10 2 • • • • • • • • • • • • • •
Magnum AT 05-07 1 or 3 • • • • • • • • • • • • • •
Nitro AT 07-11 2 • • • • • • • • • • • • •
Ram 1500 AT 07-08 2 • • • • • • • • • • • • •
Ram 2500 AT 07-09 2 • • • • • • • • • • • • •
Ram 3500 AT 07-09 2 • • • • • • • • • • • • •
Ram 3500 chassis cab AT 07-09 2 • • • • • • • • • • • • •
Ram 4500 chassis cab AT 08-10 2 • • • • • • • • • • • • •
Ram 5500 chassis cab AT 08-10 2 • • • • • • • • • • • • •
JEEP
Commander AT 06-07 1 or 3 • • • • • • • • • • • • • •
Compass AT 07-16 2 • • • • • • • • • • • • • •
Grand Cherokee AT 05-07 1 or 3 • • • • • • • • • • • • • •
Liberty AT 08-12 2 • • • • • • • • • • • • •
Patriot AT 07-16 2 • • • • • • • • • •••••
Wrangler AT 07-16 2 • • • • • • • • • • • • •
RAM
4500 chassis cab AT 10 2 • • • • • • • • • • • • •
5500 chassis cab AT 10 2 • • • • • • • • • • • • •
* May require additional parts.
WARNING
I Install Type 1 requires a T-harness manufactured before 2013/11/04
Install Type 3 requires a T-harness manufactured after 2013/11/05
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 2 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
BOX CONTENTS - 1 OF 1
VS2VS2
VS1VS1
MS1MS1
MS2MS2
3
6
4
1
2
5
C
B
A
F
G
E
D
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
2
1
3
7
9
3
10
8
6
4
12
5
2
1
3
4
2
1
3
4
BOX CONTENTS
T-HARNESS 1
AFTERMARKET HOOD SWITCH AND CABLE
WARNING STICKER
10 PIN CONNECTOR
12 PIN CONNECTOR
BLUE
PROGRAMMING
BUTTON
LED 2
LED 1
MODULE
BLACK
BLACK
BLACK
RF PORT/
WEBLINK PORT
BLACK
BLUE
TELEMATIC
PORT
WHITE
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 3 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 4 OF 24
• 20151222
COMPATIBLE ACCESSORIES - 1 OF 1
FLRF1/2/4 RF KIT
RF KIT (accessories sold separately)
(NC)
ANTENNA
MODULE
RF PORT
FLHRNTM
TELEMATIC KIT (accessories sold separately)
(NC)
CARLINK
MODULE
TELEMATIC PORT
10 11 12 13 14 15 16
12345678
9
FLHRNTM
TELEMATIC KIT (accessories sold separately)
MODULE
TELEMATIC PORT
CAR CONNECTIONPN 4120260 OBDII CONNECTOR
VEHICLE
OBDII PORT
(NC)
DOC.: #25395

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHRYSLER
300/300C 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Passenger kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
PT Cruiser 06-10
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/LtBlue (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Brown/Tan (-) Switch ~
DODGE
Caliber
(with start wire) 07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Charger 06-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Passenger kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Magnum 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Passenger kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
JEEP
Commander 06-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/Orange (+) Ignition switch ~
Parking Light* ~ ~ ~ 85 ~ (-) Parking light relay, engine compartment. ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Grand Cherokee 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/Orange (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (-) Parking light relay, engine compartment. ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 5 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
86
30
87
87A
85
10 AMPS
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
MS1MS1
MS2MS2
B1
A1
B1
12345 24
VS2VS2
VS1VS1
A1
A2
D
7
9
3
10
8
6
4
1
2
5
6
2
17
19
NOTE 1
NOTE 2
2013/11/04
C
B
A
F
G
E
D
DRIVER DOOR PIN (-)
WHITE/BROWN (NC)
PARKING LIGHT (-)
PARKING LIGHT (+)
12V (+)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (-)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (+)
OR
PARKING LIGHT CONNECTION
HORN (-)
OPTIONAL
CONTROL (MUX) - 02
STARTER (+) - 04
WHITE/RED
WHITE/GREEN
WHITE/YELLOW - CONTROL (MUX) OUTPUT
PURPLE - STARTER (+) OUTPUT
CUT AND INSULATE
THE WHITE/YELLOW WIRE
(NEXT TO WHITE/GRAY WIRE)
INSULATE WIRE
REMOVE THE WHITE/GREEN WIRE FROM THE BLUE
CONNECTOR AND RE-INSERT IT IN PIN 6 (AS SHOWN)
(SEE DETAILED INSTRUCTIONS ON THE NEXT PAGE)
CONNECT THE WHITE/GREEN WIRE TO THE PINK WIRE
AND CONNECT THE WHITE/RED WIRE TO THE RED WIRE
(SEE DETAILED INSTRUCTIONS ON THE NEXT PAGE)
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 WHITE/RED
06 WHITE/GREEN
02 PINK
06 RED
02 GRAY - RAP SHUTDOWN (-) OUTPUT
TYPE 1 - WIRING DIAGRAM - 1 OF 2
VEHICLE IGNITION SWITCHMODULE
11 GRAY/GREEN - HORN (-) OUTPUT
VEHICLE
SKIM CONNECTOR
SKIM HARNESS
AFTERMARKET HOOD SWITCH (-)
04 GRAY/WHITE - HOOD STATUS (-) INPUT
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
WARNING
THIS WIRING DIAGRAM IS APPLICABLE
ONLY IF THE REVISION DATE
OF THE T-HARSNESS IS BEFORE:
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 6 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
NOTE 1 NOTE 2
3
6 4
1
2
5
4 2
3
6 4
1
2
5
6 2
WHITE/RED
WHITE/GREEN
WHITE/RED
WHITE/GREEN
STEP 1:
-REMOVE THE WHITE/GREEN WIRE FROM THE BLUE CONNECTOR CAREFULLY.
-USE A UTILITY KNIFE TO PUSH GENTLY AGAINST THE LOCKING TAB.
-DO NOT DAMAGE THE LOCKING TAB IN THE PROCESS.
STEP 1:
-IDENTIFY THE PINK (PIN 17) AND RED (PIN 19) WIRES FROM THE 20 PIN BLACK CONNECTOR OF THE T‐HARNESS.
-CAREFULLY STRIP THE PINK AND RED WIRES USING A WIRE STRIPPER.
-DO NOT CUT THE WIRES IN THE PROCESS.
STEP 2:
-CONNECT AND SOLDER THE WHITE/RED WIRE TO THE RED WIRE.
-CONNECT AND SOLDER THE WHITE/GREEN WIRE TO THE PINK WIRE.
STEP 2:
-USING A UTILITY KNIFE, LIFT THE LOCKING TAB CAREFULLY FOR IT TO BE RE-USED.
STEP 3:
-INSERT THE WIRE IN PIN 6 OF THE CONNECTOR, RIGHT NEXT TO WHERE IT USED TO BE.
STEP 3:
-INSULATE THE CONNECTIONS WITH ELECTRICAL TAPE.
TYPE 1 - WIRING DIAGRAM - 2 OF 2
WARNING
FAILURE TO PROPERLY SOLDER
CAN RESULT IN
FAULTY CONNECTIONS AND
PRODUCT MALFUNCTION
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 7 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 1 OF 3
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHRYSLER
200 11-14
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Aspen 07-10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ Pink/Red (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Violet (-) Driver door module ~
Hood Status ~ ~ ~ ~ Purple/Blue (-) Switch ~
Sebring 07-10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
DODGE
Avenger 08-14
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Caliber 07-12
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Durango 07-10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ Pink/Red (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Violet (-) Driver door module ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
DODGE
Nitro 07-11
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple + White/Green (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 8 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 2 OF 3
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
DODGE
Ram 1500 07-09
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Ram 2500 07-09
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Ram 3500 07-09
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ ~ ~ ~ ~
Driver Door Pin ~ ~ ~ ~ ~ ~ ~ ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Ram 4500 08-10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Ram 5500 08-10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
JEEP
Compass 07-16
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/Blue (-) Switch ~
Liberty 08-12
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 9 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 3 OF 3
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
JEEP
Patriot 07-16
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Wrangler 07-16
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple + White/Orange (+) Passenger kick pad ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
RAM
4500 10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
5500 10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 10 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
VS2VS2
VS1VS1
MS1MS1
MS2MS2
A1
A2
A1
86
30
87
87A
85
10 AMPS
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
SKIM CONNECTOR
SKIM HARNESS
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY - RAP SHUTDOWN (-) OUTPUT
WHITE/BROWN - PARKING LIGHT (MUX) OUTPUT
WHITE/YELLOW (NC)
PURPLE (NC)
TYPE 2 - WIRING DIAGRAM - 1 OF 1
VEHICLE IGNITION SWITCHMODULE
11 GRAY/GREEN - HORN (-) OUTPUT
VEHICLE
DRIVER DOOR PIN (-)
PARKING LIGHT (MUX)
PARKING LIGHT (-)
PARKING LIGHT (+)
12V (+)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (MUX)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (-)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (+)
OR
OR
PARKING LIGHT CONNECTION
HORN (-)
OPTIONAL
AFTERMARKET HOOD SWITCH (-)
04 GRAY/WHITE - HOOD STATUS (-) INPUT
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 11 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
TYPE 3 - WIRE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHRYSLER
300/300C 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Passenger kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
PT Cruiser 06-10
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/LtBlue (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Brown/Tan (-) Switch ~
DODGE
Caliber
(with start wire) 07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Charger 06-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Passenger kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Magnum 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Passenger kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
JEEP
Commander 06-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/Orange (+) Ignition switch ~
Parking Light* ~ ~ ~ 85 ~ (-) Parking light relay, engine compartment. ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Grand Cherokee 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/Orange (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (-) Parking light relay, engine compartment. ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 12 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
86
30
87
87A
85
10 AMPS
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
MS1MS1
MS2MS2
B1
A1
B1
12345 24
VS2VS2
VS1VS1
A1
A2
D
7
9
3
10
8
6
4
1
2
5
2013/11/05
C
B
A
F
G
E
D
DRIVER DOOR PIN (-)
WHITE/BROWN - PARKING LIGHT (MUX) OUTPUT PARKING LIGHT (MUX)
PARKING LIGHT (-)
PARKING LIGHT (+)
12V (+)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (MUX)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (-)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (+)
OR
OR
PARKING LIGHT CONNECTION
HORN (-)
OPTIONAL
CONTROL (MUX) - 02
STARTER (+) - 04
WHITE/YELLOW - CONTROL (MUX) OUTPUT
PURPLE - STARTER (+) OUTPUT
CUT AND INSULATE
THE WHITE/YELLOW WIRE
(NEXT TO WHITE/GRAY WIRE)
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY - RAP SHUTDOWN (-) OUTPUT
TYPE 3 - WIRING DIAGRAM - 1 OF 1
VEHICLE IGNITION SWITCHMODULE
11 GRAY/GREEN - HORN (-) OUTPUT
VEHICLE
SKIM CONNECTOR
SKIM HARNESS
AFTERMARKET HOOD SWITCH (-)
04 GRAY/WHITE - HOOD STATUS (-) INPUT
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
WARNING
THIS WIRING DIAGRAM IS APPLICABLE
ONLY IF THE REVISION DATE
OF THE T-HARSNESS IS AFTER:
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 13 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
01
02
03
OFF
ACC ON
START
04
OFF
ACC ON
START
05
06
07
OFF
ACC ON
START
08
OFF
ACC ON
START
09
10
11
MODULE PROGRAMMING PROCEDURE - STD KEY - 1 OF 1
Close driver door.
Re-open driver door to wake up data bus.
Insert key into ignition.
Turn key to ON position.
LED will turn solid RED.
Within 5 seconds, LED will flash GREEN
rapidly.
Turn key to OFF position.
Remove key.
Press UNLOCK on the OEM remote. If vehicle
is not equipped with OEM remote, press
module programming button.
Wait, LED will turn solid GREEN for 2 seconds.
Module Programming Procedure completed.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 14 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
>>
01
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
ENGINE
START
STOP
OFF ACC ON STARTOFF
05
>>
VALET MODE PROGRAMMING PROCEDURE - 1 OF 1
NOTE: In Valet Mode, the Remote starter is not
functional. Keyless entry, Lock and Unlock will
remain functional. See RF kit user manual for
alternate valet mode programming.
Time restriction. Complete next step within 7
seconds.
Cycle ignition ON five times [5x OFF/ON]
rapidly.
Wait, LED 1 will turn solid RED for 2 seconds.
Set ignition to OFF position.
Valet Mode Programming Procedure
completed.
To exit valet mode: repeat steps 1 to 5.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 15 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
AFTERMARKET REMOTE PROGRAMMING - 1 OF 1
AFTERMARKET REMOTE PROGRAMMING:
NOTES
I All aftermarket remotes must be programmed to the
RF-Kit.
Refer to the RF-Kit user guide for aftermarket remote
features and programming procedures.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 16 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
>>
>>
>>
01
ENGINE
START
STOP
OFF ACC ON STARTOFF
02
03 [X]
04
05 [Y]
06
07 [Z]
08 [Z]
09
10
11 [Y]
12
13
14
>>
MODULE NAVIGATION PROCEDURE - 1 OF 1
It is mandatory to exit the Module Navigation
at the end of this procedure. Failure to exit the
Module Navigation will drain vehicle battery.
To exit the Module Navigation at any time:
Follow STEP 13.
Module must be programmed to the vehicle.
Use the Module Navigation Chart on the next
page.
Set ignition to OFF position.
TO ACCESS THE MENUS: Press and hold
programming button until LED 1 turns solid
GREEN.
IN THE MENUS: Press the programming
button as many times as the menu number
indicates. LED 1 will flash GREEN an equal
amount of times continuously.
TO ACCESS THE OPTIONS: Press and hold
programming button until LED 1 turns solid
RED.
IN THE OPTIONS: Press the programming
button as many times as the option number
indicates. LED 1 will flash RED an equal
amount of times continuously.
TO ACCESS THE SETTINGS: Press and hold
programming button until LED 1 turns solid
GREEN.
LED 1 will flash GREEN as many times as
the current (or default) setting number,
continuously.
IN THE SETTINGS: Press the programming
button as many times as necessary to access
your setting. LED 1 will flash GREEN an equal
amount of times continuously.
To return to the MENUS: exit the Module
Navigation and redo the Module Navigation
Procedure.
To save and return to the OPTIONS: Press and
hold programming button until LED 1 turns
solid RED.
LED 1 will flash RED as many times as the
current option number continuously.
Configure every other setting and proceed to
step 13.
MANDATORY: EXIT MODULE NAVIGATION.
Press and hold programming button for 7
seconds. LED 1 will flash RED rapidly. Release
programming button. LED 1 will turn OFF.
Module navigation completed.
Failure to exit the Module Navigation will drain
vehicle battery.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 17 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
MODULE NAVIGATION CHART - 1 OF 2
MODULE NAVIGATION CHART:
NOTES
[X] MENUS [Y] OPTIONS [Z] SETTINGS
I Default settings are listed in bold.
01 CONFIGURATION
01 DISARM/UNLOCK BEFORE START 01 OFF
II Make sure the option is covered on the vehicle before
attempting to change the setting.
02 ON
02 RELOCK AFTER START 01 OFF
02 ON
03 RELOCK AFTER SHUTDOWN 01 OFF
02 ON
04 FORCE UNLOCK ALL ON FIRST PRESS 01 OFF
02 ON
05 TAKEOVER 01 ENABLE
02 DISABLE*
06 N/A 01 N/A
07 FACTORY KEYLESS RS SEQUENCE
01 DISABLE
02 N/A
03 LOCK + UNLOCK + LOCK
04 LOCK + LOCK + LOCK
08 MODULE RUN TIME
01 03 MIN
02 05 MIN
03 10 MIN
04 15 MIN
05 25 MIN
06 30 MIN
07 35 MIN
08 15 MIN
09 WAIT TO START DELAY
01 02 SEC
02 05 SEC
03 08 SEC
04 10 SEC
05 15 SEC
06 20 SEC
07 25 SEC
08 30 SEC
10 N/A 01 N/A
11 N/A 01 N/A
12 N/A 01 N/A
13 N/A 01 N/A
*Vehicle will shutdown when a door is opened.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 18 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
MODULE NAVIGATION CHART - 2 OF 2
MODULE NAVIGATION CHART:
NOTES
[X] MENUS [Y] OPTIONS [Z] SETTINGS
01 CONFIGURATION
14 HORN EVENT TRIGGER
01 DOUBLE LOCK
02 LOCK + UNLOCK
03 LOCK + UNLOCK + START
04 DOUBLE LOCK + START
15 HORN CHIRPS WIDTH
01 30 mSEC
02 15 mSec
03 60 mSec
02-07 Technical Support only 01 N/A 01 N/A
*Vehicle will shutdown when a door is opened.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 19 OF 24
• 20151222
DOC.: #25395

U.S. Patent No. 8,856,780
REMOTE STARTER ERROR CODES - 1 OF 1
REMOTE STARTER ERROR CODES:
NOTES
[X] NUMBER OF PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking
lights are connected and supported by the system.
03 Foot brake is ON.
04 Hood is open.
II After a remote starter failure, the parking lights will fl ash
[X] number times to indicate an error code. See table.
05 Engine tach signal is lost.
06 System is in Valet Mode.
07 Vehicle is moving (VSS).
08 Glow plug timeout error.
09 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
10 N/A
11 N/A
12 N/A
13 N/A
14 N/A
15 N/A
16 CAN communication failure during RS sequence.
www.flashlogic.comAutomotive Data Solutions Inc. © 2015 FLCCHRSCH5FLRSCH5EN
PAGE 20 OF 24
• 20151222
DOC.: #25395
