Flexa 1477900 User manual

Triple Bunk bed - Natural
Dimensions
Length - 196cm
Depth - 151cm
Height - 149cm
Weight - 46kg
Issue 3 - 02/11/15
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@flexa.dk
Assembly Instructions - Please keep for future reference 1477900

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit. Only use hand
screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
IMPORTANT - READ CAREFULLY -RETAIN FOR FUTURE REFERENCE
ASSEMBLY:
Always follow the instruction. Current legislation requires that the high bed / bunk bed must be fitted with 4
safety-rails and a ladder or platform for the upper bunk. The high bed / bunk bed meets the European EN
747:2012 A1:2015 standards for security and durability.
MATTRESS:
This bed is designed to use a mattress size 190 cm long and 90 cm wide. The total thickness must not
exceed 16,1 cm. The mattress top must not pass the marking on the ladder / the post for the safety-rail.
WARNING:
High beds and the upper bed of bunk beds are not suitable for children under six years due to the risk of
injury from falls. Bunk beds and high beds can present a serious risk of injury from strangulation if not used
correctly. Never attach or hang items to any part of the bunk bed that are not designed to be used with the
bed, for example, but not limited to ropes, strings, cords, hooks, belts and bags. Children can be become
trapped between the bed and the wall, a roof pitch, the ceiling, adjoining pieces of furniture (e.g. cupboards)
and the like. To avoid risk of serious injury the distance between the top safety barrier and the adjoining
structure shall not exceed 75 mm or shall be more than 230 mm.
Do not use the high bed / bunk bed if any structural part is broken or missing.
MAINTENANCE INSTRUCTIONS:
Check regulary that all assembly fastenings are properly tightened. Ventilation of the room is necessary in
order to keep the humidity low and to prevent mould in and around the bed.

Components - Parts
Please check you have all the parts listed below
2
Slat x15 (89.7x6.5x1.5cm)
4Endrail x2 (87.7x8.9x2.0cm)
5Endrail x6 (87.7x6.5x2.0cm)
6
Leg x2 (149x4.3x4.3cm)
1No. 12-04314902 Slat x15 (134.7x6.5x1.5cm)
3No. 12-01513471
Leg x2 (124.5x4.3x4.3cm)
2No. 12-04312452
Leg x2 (29x4.3x4.3cm)
7No. 12-04302901 Leg x1 (20x4.3x4.3cm)
8No. 12-04302001 List f.safety rails x2
(31.8x2.8x1.2cm)
9
No. 12-01203181
Ladder side x2
(121x8.9x2.0cm)
10
No. 12-02012101
Endrail x2 (132.7x8.9x2.0cm)
11 No. 12-02013271 Tread x3 (31.8x6.0x2.6cm)
12 No. 12-02603181
If you have damaged or missing components,
call the Customer Helpline: 0045 7668 8055
No. 12-01508971 No. 12-020087715
No. 12-020087714

Components - Parts
Please check you have all the parts listed below
3
Midsupport x1
(187.5x8.9x2.0cm)
13
No. 12-02018751
Bedside x4
(186.7x8.9x2.0cm)
14
No. 1305-18673
Safety rail 1/1 x2
(186.7x6.5x2.0cm)
15
No. 12-02018673
Safety rail 3/4 x2
(148.9x6.5x2.0cm)
16
No. 12-02014892
Short post x1
(36.8x8.9x2.0cm)
17
No. 12-02003681

Please check you have all the fittings listed below
M6x90mm Connecting bolt x8
Tools required
A
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
M6 Ø10x14mm Barrel nut x8
B
E
4,0x30mm Chipboard screw x80
C
10x45mm Dowel x38
D
Components - Fittings
Phillips
screwdriver
(medium)
Small
hammer
Ruler/tape
measure
4,5x60mm Chipboard screw x3
Allen key
4mm incl.
Flatblade
screwdriver
(medium)
6,3x50mm Assembly screw x15
F
ø10mm Cover cap plastic x22
i
H
ø7mm Cover cap plastic x36,3x90mm Assembly screw x30
G
ø12mm Cover cap wood x2
J
4
Angle 48x48x40x2,5mm x2
P
O
Bracket for slanting ladder 26° x4
4.5x40mm Chipboard screw x2
MNo. 4008-013
No. 4007-029
No. 3901-45040
7x50mm Confirmat screw x1
NNo. 3908-70050
4,0x20mm Chipboard screw x12
L
K
3,0x20mm Chipboard screw x4
No. 3903-40020
No. 3901-30020
No. 3901-40030
No. 3930-10045 No. 3901-45060
No. 3922-06014
No. 3913-06090
No. 4033-004
No. 3909-63050
No. 3938-00010-1
No. 3938-00007-1
No. 3909-63090
No. 3939-00012

Assembly Instructions
Step 1
Step 2
Attach the dowels to
endrail and and to
bedside and to safety
rail and
It may be necessary
to tap the dowels in
very gently with a small
hammer.
Attach leg 1to endrail
5, 6and 11 with
screws Gusing the allen
key.
Repeat same procedure
for both headboard and
footboard
Attach leg 2to endrail
5and 6with screws
Gusing the allen key.
Attach leg 2to endrail
11 with the screws C.
Attach leg 7to endrail
11 with screws Gusing
the allen key.
Repeat same procedure
for both headboard and
footboard G
16
14
5
6
16
15
6
5
D
x2
x2
D
D
D
D
14 x4
x6
x2
G
G
G
G
5
CG
C
6
6
5
1
1
6
6
5
6
6
11
11
2
7
Step 3
15
C

6
Assembly Instructions
Step 4
Attach bedsides 14 and
safety rails 15 to end
boards firstly by placing
the dowels into the holes
in endboards.The thin rail
attached to the bedside
should face inwards.
Push barrel nut Binto
the small hole in the
bedside 14 , the groove
on barrel nut Bshould
be horizontal.
Push connecting bolt A
through each leg 1to
meet barrel nut Band
then fasten with the allen
key.
Attach safety rails 15
through the leg 1with
the screws G
a: Attach bedsides 14
to the legs 2and 7
by pushing the barrel
nuts Binto the small
holes in the bedside 14
Push connecting bolts A
through the legs 2and
7to meet the barrel
nuts B.
Attach safety rails 16
to the leg 2with the
screws G.
Fasten with the allen key.
Ladder can be
positioned left or right
b:Attach the short post
17 to the safety rails 16
with assembly screws F
and confirmat screw N.
c:Attach the short post
17 to the bed side 14
with chipboard screws E
and cover with cover cap
J.
Step 5
B
A
A
A
Ladder can be positioned left or right!!
G
A
14
14
14
15
G B
A
A
G
B
B
B
B
1
1
A
G
B
2
2
B
B
B
B
7
7
A
A
A
A
G
14
14
16
15
16
b: c:
17
17
17
E
F
N
a:
J
F
E
N
J
14
16
16

Assembly Instructions
Step 6
Attach the treads 12 to
the the ladder sides 10
with the screws F.
Attach the bracket Oto
the ladder side 10 with
the screws C.
Attach ladder sides 10
with the brackets Oto
the bedsides 14 with
screw K.
Attach the ladder sides
10 to the leg 2and to
the short post 17 with the
chipboard screws M.
Step 7
F
7
C
F
F
F
C
C
C
C
F
F
F
10
10
12
12
12
O
O
O
OO
M
K
M
K
K
K
14
2
10
10
O
O
O
O
14
K
17
O
11,5 mm
16,5 mm
Front edge
12
Front edge

Assembly Instructions
Angle Pshould be
attached to the endrail
11 663,5 mm from the
leg 1and 2 mm from
the bottom of the endrail
11 .
Follow the
measurements.
Attach angle Pto the
endrails 11 with the
screws L.
Follow the
measurements.
Step 9
Step 8
8
1.
2.
1.
2.
1
11 P
1
11
P
11
P
P
L
P
L
11
11
11
663,5 mm
663,5 mm
2 mm
2
7
7
2

Assembly Instructions
9
Step 10
Place midsupport 13
onto the angles Pand
attach it with the screws
L.
Attach the leg 8to the
midsupport 13 with the
screw E.
Follow the measurement.
Step 11
L
P
11
13
L
11
11
13
E
E
13 8
937,5 mm

10
Assembly Instructions
Step 12
Place 1 slat 4(slat 3
is for the bottom bed) in
the center of the bed and
two slats 4in both ends
of the bed, 16mm from
bed ends. Follow the
measurements.
Push the bedsides 14
together whilst attaching
slat 4to the bed with 2
chipboard screws C
Repeat same procedure
for the bottom bed.
Position the remaining
12 slats 4(slat 3is
for the bottom bed) in the
bed with a distance of 63
mm between each.
Fasten each slat 4with
2x chipboard screws C
Repeat same procedure
for the bottom bed.
Step 13
14
C
C
C
63 mm
832 mm 832 mm
PUSH
PUSH
4
14
4 4 4 4 4 4 4 4 4 4 4 4 4 4
16 mm

Step 14
If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055
E-mail: order@flexa.dk
Ref.no. 44-01357 C Stand: 021115 Page 12 (80-12414)
71 mm
71 mm
Attach the safety list 9
inside the bed, on the
front safety rails 16 .
Should be in the center
of the front guards 16
between the slats 4.
Attach it 9to the safety
rails 16 and bedside 14
with chipboard screws C
Follow the measurement.
Attach the safety list 9
on the outside of the bed,
on the back safety rails
15 .
Should be in the center
of the back guards 15 .
Attach it 9to the safety
rails 15 and bedside 14
with chipboard screws
C.
Follow the measurement.
Max. mattress height !
Assembly is complete.
Max. mattress height !
16 16
9
14
15 15
C
C
CC
9
14
71 mm
71 mm
Assembly Instructions
11
9
C
14
9
16
16
15
15
4
