Flexiheat LEO D S Guide

DESTRATIFICATOR
TECHNICAL DOCUMENTATION OPERATION MANUAL
LEO D S
/ LEO D S BMS / LEO DT S
LEO D L / LEO D L BMS / LEO DT L
LEO D XL / LEO D XL BMS / LEO DT XL

2 |
1. Purpose and Principle of Operation.......................................... 2
2. Technical Data.........................................................................3
3. Wiring diagrams ....................................................................... 4
4. Installation................................................................................5
4.1. Montage distance.................................................................. 5
4.2. Method of installation ............................................................5
5. Start-up and operation .............................................................6
6. Service and warranty terms...................................................... 7
7. Conformity with WEEE directive 2012/19/UE ........................... 9
TABLE OF CONTENTS
1 PURPOSE AND PRINCIPLE OF OPERATION
Destratificator (under ceiling air mixer) co-operates with various devices of the heating system and is used for improving the
efficiency of heating in high objects such as: industrial shops, storehouses, supermarkets, exhibition halls.
The primary function of the under ceiling air mixer is counteracting the accumulation of warm air in upper zones of the room. An axial fan
draws warm air in and forces its flow downwards, i.e. towards the zone occupied by people (the thermal comfort zone). This results in a
reduction of heat losses through the ceiling and causes a faster heating of the building.
Destratificator is designed for installation indoors, in an environment protected against weather conditions and in rooms in which
there is no risk of explosion.

| 3
LEO D S | LEO D S BMS | LEO DT S LEO D L | LEO D L BMS | LEO DT L
LEO D XL | LEO D XL BMS | LEO DT XL
LEO D S LEO D L LEO D XL
Gear III II I III II I III II I
Air flow [m3/h] 2500 2200 1900 5200 4200 2800 7200 6100 3900
Max. current
consumption [A] 0,5 0,4 0,3 1,3 1,0 0,6 2,0 1,5 1,3
Maximum power
consumption [W]
110 80 70 280 200 120 450 350 260
Electric power
supply 230V / 50Hz
Acoustic
pressure level*
[dB(A)]
56,9 55,2 49,4 65,7 58,4 44,9 72,8 66,9 53,7
Motor protection
degree IP 54
Motor insulation
class F
Weight [kg] 8,9 13,9 19,5
*Acoustic pressure level measured in the room of average sound absorption, capacity 1500m
3
, at distance of 5m from the unit.
EN
2 TECHNICAL DATA

4 |
LEO D / LEO DT
Hi / N / Pe - 3rd fan speed
Med. / N / Pe - 2nd fan speed
Low / N / Pe – 1st fan speed
LEO D BMS
3 WIRING DIAGRAMS
T-box – controller with touch screen connection
FAN 3V - 3-step fan connection
SUPPLY – supply connection
When wiring the BMS Leo destratification fans– you ‘Daisy Chain’ them from one DRV module to the next
– maximum cable length in between two units is 50 mtrs – cable size in yellow below

| 5
LEO D / S LEO D / L LEO D / XL
 min. 1m
 min. 6m
 max. 8 m* max. 13 m* max. 15 m*
*with all blades directed downwards
In case of installation on surface which transfer
vibrations is recommended to use vibration isolator.
LEO D S LEO D L LEO D XL
A 415 515 585
B 415 515 665
4 2 METHODS OF INSTALLATION
4 INSTALLATION
4 1 DISTANCE
Under ceiling montage must be done using each (four) U-section profiles.
It is recommended that the mounting to the ceiling be executed keeping similar distance.
Unit can be hanged by pins. Instalation by ropes is not allowed.
Please mind distances of installation listed in paragraph 4.1.

6 |
Start Up
Before connecting the power supply check the
correctness of connection of the fan motor and the
controllers. These connections should be executed in
accordance with their technical documentation.
Before connecting the power supply check whether the
mains voltage is in accordance with the voltage on the
device data plate.
The electrical system supplying the fan motor should be
additionally protected with a circuit breaker against the
effects of a possible short-circuit in the system.
Starting the device without connecting the ground
conductor is forbidden.
Operation
The device is designed for operation inside buildings, at
temperatures above 0
o
C.
The device must be inspected periodically. In the case
of incorrect operation of the device it should be switched
off immediately.
It is forbidden to use a damaged device. The
manufacturer bears no responsibility for damage
resulting from the use of a damaged device.
For the time of performing inspection or cleaning the
device, the electrical power supply should be
disconnected.
5 START-UP AND OPERATION

| 7
Please contact your dealer in order to get acquitted with the
warranty terms and its limitation.
In the case of any irregularities in the device operation, please
contact the manufacturer’s service department.
The manufacturer bears no responsibility for operating the
device in a manner inconsistent with its purpose, by
persons not authorised for this, and for damage resulting
from this!
Made in EU
6 SERVICE AND WARRANTY TERMS

| 9
For information on the collection system of waste electrical
and electronic equipment, please contact the distributor.
R E M E M B E R :
 Do not dispose of used equipment together with other waste!
There are financial penalties for this. Proper handling of used
equipment prevents potential negative consequences for the
environment and human health. At the same time, we save the
Earth's natural resources, reusing resources obtained from the
processing of equipment.
7 CONFORMITY WITH WEEE DIRECTIVE 2012/19/UE
Running a business without harming the environment and observing the rules of proper handling of waste electrical and electronic
equipment is a priority for Flexiheat.
The symbol of the crossed out wheeled bin placed on the equipment, packaging or documents attached means that the product
must not be disposed of with other wastes. It is the responsibility of the user to hand the used equipment to a designated
collection point for proper processing. The symbol means at the same time that the equipment was placed on the market after
August 13, 2005.

10 |

www.flowair.com | 11
•LEO D S / LEO D S BMS / LEO DT S
•LEO D L / LEO D L BMS / LEO DT L
•LEO D XL / LEO D XL BMS / LEO DT XL
Gdynia, 14.01.2019
Product Manager
Declaration Of Conformity
Flexiheat hereby confirms that heating units
were produced in accordance to the following Europeans Directives
1. 2014/30/UE – Electromagnetic Compatibility (EMC)
2. 2006/42/WE – Machinery
3. 2014/35/UE – Low Voltage Electrical Equipment (LVD)
4. 2009/125/WE – Energy-related products (ErP 2015)
and harmonized norms ,with above directives
PN-EN ISO 12100:2012 Safety Of Machinery - General Principles For Design - Risk Assessment And Risk Reduction
PN-EN 60204-1:2018-12
Safety of machinery − Electrical equipment of machines − Part 1: General requirements
PN-EN 60034-1:2011 Rotating electrical machines — Part 1: Rating and performance
PN-EN 61000-6-2:2008 Electromagnetic compatibility (EMC). Generic standards. Immunity for industrial environments
