Flextone Rx-8000 User manual

1
FlexTone Rx-8000 User Manual
FlexTone
Rx-8000
User Manual

2 3
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
TABLE OF CONTENTS TABLE OF CONTENTS
Pg. 4-5 Quick Start Guide .............................................
Connecting Electrodes and Leads....................
Starting & Stopping a session ..........................
Pg. 6 Rx-8000 Diagram...................................................
Pg .7 LCD Display............................................................
Battery ..............................................................
Body IQ Display................................................
Time Indicator..................................................
Pg. 8 Battery & Charging...............................................
Pg. 9 Setting The Intensity ............................................
Intensity For EMS Training...............................
Intensity For TENS Pain Relief ........................
Pg. 10 Program Guide .....................................................
Knee / Elbow ...................................................
Hip (Sciatica Nerve Treatment) ........................
Pg. 11 Program Guide .....................................................
Back.................................................................
Arm / Leg.........................................................
Shoulder ..........................................................
Foot / Sole .......................................................
Pg. 12 EMS Programs (Muscle toning)
Abdominal Toning ............................................
StimRx.com | 800-573-8171
Pg. 13 Strength Training .................................................
Pg. 14 Active Recovery....................................................
Pg. 15-17 Pad Placement Chart.......................................
Pg. 18 Electrode Care......................................................
Pg. 19-22 Indications For Use .........................................

4 5
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
1
2
3
4
QUICK START
GUIDE
QUICK START
GUIDE
Connect the lead wire to the channel port
marked Ch 1 A and then connect 2 electrodes
to that lead wire.
Place the electrodes on the desired muscle
group.
Press the green ON button and select the
desired program.
Set the Timer and slowly increase the
intensity until the desired level of stimulation
is achieved.
Note: To STOP a session, briey press the ON/OFF button.
You can change a program without ending the session. All
you have to do is press the program you desire.

6 7
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
1
2
3
5
6
7
4
Rx-8000 Diagram LCD Display
1. On/Off Button Press for 1 Second to turn unit On or Off.
2. Power Indicator LCD The Power LCD indicator illuminates
green when the unit is on.
3. LCD Display Window The LCD window will remain lighted
Blue for the entire session. The Blue LCD window displays the
selected program, time and indicates battery life.
4. TENS Body IQ The Purple Buttons are for Body IQ.
5. Channel Intensity Knob The four knobs located across the
bottom of the unit control the intensity of each channel.
6. Channel Status Indicator LCD When illuminated, the channel
is on.
7. EMS Programs The 3 blue buttons on the bottom panel of
the unit are the EMS programs - Abdominal training, Strength
training and Active Recovery.
8. Timer Adjustable between 10-60 Minutes.
9. Channel Indicator Each channel has an A or B setting port.
Choose either A or B to stimulate all ports are the same.
8
1
3
2
4
1. Battery Indicator Indicates remaining battery life.
2. Body IQ Display The human body gure will highlight the exact
spot selected from the Body IQ wheel.
3. Time Indicator This allows you to set the time of your session.
4. EMS or TENS Program indicator.
9
EMS Abdominal Workout Active Recovery Program
EMS Strength Training Workout Body IQ TENS Treatment
The human body gure will indicate
your selection from the Body IQ Wheel
Your unit will automatically start on this
EMS setting.

8 9
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
The StimRx® Rx-8000 has a built-in, rechargeable, lithium
battery, and will fully charge within 30-45 minutes. Check
battery indicator to conrm that battery is fully charged.
The battery can be charged with a USB connection, or the
adapter provided with your unit.
DO NOT USE THE UNIT WHILE CHARGING.
The battery icon symbol will appear on the Blue LCD display
at all times during operation. As the battery power decreases,
the 3 bars on the battery symbol disappear one by one. The
outline of the battery symbol will ash to indicate when the
batteries need to be charged.
PRO
TIP
1. In order to preserve battery longevity
you should fully charge the unit at least
once a month.
2. You cannot use the unit plugged in.
Setting the Intensity
When rst beginning the treatment session make sure all
of the channel intensity knobs are in the OFF position by
twisting them all the way left until they click and the channel
indicator LCD is no longer illuminated.
Begin by slowly increasing the intensity until you feel a
tingling sensation. Depending on the desired effect, the
intensity plays a major role in the effectiveness of the
session:
For EMS (Abdominal Training / Strength
Training / Active Recovery)
For EMS training and active recovery you need to ensure
that the muscles are optimally contracting. In order to do so,
increase the intensity of the stimulation until you can feel and
see the muscles contract. A setting between 5-10 typically
works best.
For TENS (Pain Relief)
For TENS therapy the goal is to achieve immediate pain
relief. Adjust the intensity as needed to alleviate pain.
Channel intesity knob indicating a
power level of 2.5. You can see the
channel is active when the green
light above the knob is on and lit.

10 11
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
TENS Programs
For Pain
Body IQ Programs
The Rx-8000 offers 6 unique Body IQ
programs designed for individual body
parts which are located in the purple
button bank.
KNEE & ELBOW
This program is a combination of
rapid pulses followed by a series of
slower more deliberate contractions.
The mixture is very effective in
eliminating knee and elbow pain
because of high cartilage and bone
density. Recommended stimulation
time is 20-30 minutes.
Placeholder
SCIATIC
The Sciatic program produces
a strong, steady and deeply
penetrating frequency that is critical
in preventing hip pain. The Sciatic
frequency is designed for people
who suffer from sciatic nerve pain.
Recommended time 20-40 minutes.
BACK
ARM & LEG
SHOULDER
FOOT & HAND
The Back program offers a combi-
nation of deep penetrating therapy,
coupled with soft and gentle pulses
allowing you to treat a variety of back
pain from tightness, to sore or strained
muscles. This program works best when
used with the Back & Ab Belt Pro.
Recommended time 20-30 minutes.
The Arm & Leg program uses a
series of 4 unique cycles that are
designed to reach deeply into the
muscles. Beginning with a series
of rapid pulses, followed by smooth
powerful contractions, and nishing
with short, deep, deliberate pulses.
Recommended time 20-40 minutes.
The Shoulder program is designed
for all areas related to the shoulder
muscles in order to prevent pain in
the upper back, neck, and shoulder
area. The program cycles throughout
multiple frequencies. Recommended
time 20-30 minutes.
The Foot & Hand program is designed
to increase blood ow to the ankle,
foot, and toes. It can be used on foot,
ankle or hands. It is recommended to
use this frequency with our therapy
sandals or the smaller 2”x2” electrodes.
Recommended time 15-30 minutes.

12 13
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
EMS Programs
Abdominal Toning Strength Training Active Recovery
Abdominal Toning
Strength Training
Since the Early 1970’s athletes have turned to EMS, or
electrical muscle stimulation, to push their strength to
another level. By incorporating EMS into your workout
routine, or even by itself, you can increase your muscle
performance, strength, and tone.
The Strength Training Program on the Rx-8000 utilizes state-
of-the-art Russian Stim (2500hz Packets) adapted to include
proper rest time between contractions, allowing the muscle
bers to contract and increase strength, while remaining
comfortble.
The Strength Training Program is more effective the higher
the intensity is turned up. We recommend a level just
below your maximum threshold in order to get the most
efcient results. USE THE PAD PLACEMENT CHART FOR
GUIDELINES ON ELECTRODE PLACEMENT.
Recommended Time: 30 Minutes
Core Muscle Strength is the most important factor for
overall body mechanics. A strong core is crucial for injury
prevention. The abdominal muscles are one of the most
important muscle groups for tness and wellness.
The Abdominal Toning Frequency with the Rx-8000 utilizes
cutting edge research to deliver the most effective and
comfortable workout. The Abdominal Toning Frequency relies
on a deep penetrating and rhythmic frequency in order to
stimulate a thorough contraction.
The Abdominal Toning frequency works best when used with
the FLEXTONE Ab Belt Pro. Recommended Time: 30-45 minutes.

14 15
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
Active Recovery
Active recovery, as opposed to passive recovery, is the
stimulation and exercise of muscles in the off-day of training.
The purpose of active recovery is to stimulate muscles,
decrease recovery time, increase strength, and reduce pain
associated with DOMS, or Delayed Onset Muscle Soreness.
Active recovery works by:
• Removing waste build-up
• Bringing nourishment to muscles
• Enhancing blood ow
What are some benets of active recovery
with Electronic Muscle Stimulation?
Electronic muscle stimulation provides one of the best forms of
active recovery because of its low-impact deployment, coupled
with convenience and control. Electronic Muscle Stimulation
allows the user to pinpoint specic muscles for treatment,
while using very little amounts of energy. Active recovery with
EMS is comfortable, convenient, and highly effective.
StimRx - Active Recovery Perfected
The StimRx Active Recovery Program is a unique blend of
frequencies including both TENS and EMS, which provide
the most efcient and effective Electronic Active Recovery on
the market.
There is no exact science or industry standard for electrode
platecement. These images serve as a guideline. You have
to experiement to get the best results but the positions shown
are highly recommended after 30 years of our own research.
PRO
TIP
Use th pad placement chart for guide-
lines on electrode placement.
Pad Placement Chart

16 17
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
Advanced Pad
Placement

18 19
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
Electrode Care & Life
To get the most benet from your electrodes, be sure your
skin is free from dirt, oil and body lotion. The electrodes will
disperse stimulation more effectively with little or no hair in
the desired treatment area, so we recommend removing any
hair in the area to be treated. The lifespan of the electrode
pads will vary depending on how often you use them and
how you care for them. Keeping electrode pads clean and
stored on the original sheet, and sealed in the zip lock bag
after each use will extend their lifespan. If your electrodes are
no longer able to adhere to the skin properly, make sure to
replace them in order to maximize stimulation and comfort.
EXTENDING ELECTRODE LIFE
The electrodes typically have a cloth or foam backing, and
a sticky gel coating that conducts electricity. The gel is the
“middle man” between the wire and the skin. Our electrodes
are hypo-allergenic, and constructed with water-based
material. Keep adhesive electrodes away from heat and cold.
Electrode life is prolonged when they are stored at room
temperature.
PRO
TIP
PRO
TIP
INDICATIONS FOR USE
Please read the contra-indications, precautions and warnings
carefully to determine whether any of them apply to you.
The Rx-8000 stimulates motor nerves that supply the muscle.
There are nine (9) different programs with varying times and
intensities which can be used for warm-up, strength training, and
recovery after exercise.
CONTRA-INDICATIONS, PRECAUTIONS &
WARNINGS
The Rx-8000 can be used by all healthy adults; however some
care should be taken during use. Read the Manual and follow
the guidelines prior to use. The signal strength can be adjusted
to a high intensity and caution should be taken when setting the
intensity. If there is any doubt whether you should use TENS &
EMS see your doctor for an opinion.
KEY GUIDELINES
• EMS/TENS use is for healthy adults. Keep out of reach of
children.
• Never apply electrodes to any part of the head, face, neck,
throat, or directly over the heart.
• Never use the device in ways other than those directed in the
user manual.
CONTRA-INDICATIONS
• You have an electronic implant, or if you suffer from any other
heart problem because it may interfere with the functioning of
the implant.
To revive the adhesive gel, pass your nger
under running water and wipe a few drops
on the sticky side of the pad. The water will
soak in and rehydrate the surface, giving the
electrode pad additional longevity.

20 21
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
CONTRA-INDICATIONS Continued:
• You have cancer or cancerous lesions. The effects of
electronic stimulation on cancerous tissue are unknown.
• You suffer from epilepsy.
• The unit is in close proximity to shortwave or microwave
therapy equipment, or you are connected to high-frequency
surgical equipment.
• Ensure the intensity is kept at a low setting for back treatment.
• You have serious injury or illness not mentioned in this manual
• You experience any irritation, skin reaction, hypersensitivity, or
other adverse reaction. Note that some reddening of the skin
under the pad is normal.
Additional Information
• Contact StimRx®, or an authorized dealer, if your unit is
not working correctly, and immediately discontinue use until
resolved.
• An effective session should not cause discomfort.
• For rst time users we recommend you begin in a seated
position with low stimulation intensity settings.
• Keep out of reach of children.
• Leads and electrodes must not be connected to, or used with
other objects.
• Do not use this unit while using any other device that transmits
electrical current into the body.
• Do not use when driving, operating machinery, or cycling.
• Cease usage if you are feeling light headed or faint.
• Do not place pads over jewelry or body piercings.
• StimRx® will not accept responsibility if the instructions
and guidelines supplied with this unit are not followed.
WARNINGS
• Do not use while sleeping, electrodes may become loose.
• User must position the pads and operate unit ONLY as
indicated in this manual. Never place the pads on the front or
sides of neck, across or through the heart (i.e., one pad on the
front of the chest and one on the back), in the genital region or
on the head, because of the risk of stimulating inappropriate
muscles and organs.
• Avoid placing electrodes over any recent scars, broken or
inamed skin, infected areas or areas susceptible to acne,
thrombosis or other vascular problems (varicose veins), or any
part of the body where feeling is limited without rst consulting
your doctor.
• Avoid areas of injury or restricted movement without rst
consulting your doctor.
• Avoid placing the pads over metal implants.
• Wait before using your StimRx® product until:
• At least 6 weeks after the birth of your baby. You must
consult your doctor before use.
• One month after an IUD contraceptive device has been
tted. You must consult your doctor before use.
• At least 3 months after having a caesarian section. You
must consult your doctor before use.
• The heavy days of your period have nished because
vigorous abdominal exercise is not recommended at this
time.
• Do not use in the bath or shower, or in an environment of
elevated humidity (sauna).
• Caution should be used in the following:
• When there is a tendency to bleed internally following a
fracture or injury.
• Following recent surgical procedures when electronic
stimulation may disrupt the healing process.
• Over areas of skin which lack normal sensation.

22 23
FlexTone Rx-8000 User ManualFlexTone Rx-8000 User Manual
Adverse Reactions
• Skin irritations and burns have been reported with the
improper use of electronic muscle stimulators
• On very rare occasions, rst time users of EMS have reported
feeling light-headed or faint. StimRx® recommends you use
the product while seated until you become accustomed to the
sensation.
Pad Precautions
• To reposition pads during a session, always turn off the
program in use, THEN reposition the pads as directed in this
manual. Once you have repositioned the electrodes properly,
you may restart the program.
• Only use pads supplied by StimRx® with your muscle
conditioner. The pads are for single person use only.
• Do not submerge the pads into water.
• Do not apply solvents of any kind to the pads.
• Always ensure the unit is OFF before removing the pads
• Apply the entire surface of the pads rmly to the skin. Do not
use pads which do not adhere properly and completely to the
skin. You can purchase new pads at www.Stimrx.com
• If your skin is red under the pad after a session, do not start
another session on the same area until the redness has
completely disappeared
Rx-8000 REGISTRATION
Register your unit for the 2 Year Warranty
- Free of Charge -
1. Visit StimRx.com
2. Locate the Support tab
3. Click the Registration option below the Support tab
StimRx – 2 Year Warranty
StimRx devices are covered by a no hassle 2 year Warranty.
If your device fails for any reason during the course of normal
use, we will replace it. Our warranty does NOT cover abuse
or water damage.
10% OFF
YOUR NEXT
PURCHASE
CALL IN CODE: VIPFLEX

24
FlexTone Rx-8000 User Manual
StimRx.com | 800-573- 8171
