Flextool Mikasa MTX-85DYC User manual

OPERATING INSTRUCTIONS
FOR MORE INFORMATION
CONTACT US ON 1300 353 986 OR VISIT flextool.com.au EXCLUSIVE TO
Version 2.0 (March 2022)
MIKASA TAMPING RAMMER
MTX-85DYC

MTX-85DY
302-06401
*302-06401*
http://www.mikasas.com
en
TAMPINGRAMMER
INSTRUCTIONMANUAL
WethankyouforselectingMikasaTampingRammer.
Foryoursafeandproperoperation,pleasereadthismanualand
bealwayssuretokeepitreadyforreference.

Table of contents
1
1
2
2
2
3
3
3
4
4
5
6
6
7
8
8
8
9
9
10
11
12
12
12
13
13
13
14
14
14
16
General Cautions
Precautions When Adding Fuel
Precautions About Where To Use The Machine
Precautions Before Starting Work
Precautions While Lifting
Transportation And Storage Precautions
Maintenance Precautions
Label Position
Label List
Descriptions Of The Symbols On The Warning Decals
Body
Engine
Appearance Dimension
Control Unit Positions And Names
Starting
Operation
Table Of Scheduled Checks
Inspection And Maintenance Work Contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
6.1
6.2
8.1
8.2
12.1
12.2
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
4.10
5.1
5.2
INTRODUCTION ......................................................................................
APPLICATION, STRUCTURE AND POWER TRANSMISSION ..............
WARNING SIGNS ....................................................................................
CAUTIONS FOR SAFETY........................................................................
SPECIFICATION......................................................................................
APPEARANCE ........................................................................................
INSPECTION BEFORE OPERATION .....................................................
OPERATION ............................................................................................
STOPPING THE MACHINE......................................................................
TRANSPORTATION
STORAGE.................................................................................................
PERIODIC CHECKS AND ADJUSTMENTS.............................................
TROUBLESHOOTING..............................................................................

1
1．INTRODUCTION
2．APPLICATION, STRUCTURE AND POWER TRANSMISSION
●
●
●
●
Application
Warning About Incorrect Applications And Techniques
Structure
Power Transmission
The illustrations in this manual might slightly differ in part from the machine you actually
purchased due to design changes.
This instruction manual describes the proper methods for using the tamping rammer, as well as simple checks and
maintenance. Be sure to read this instruction manual before using the rammer, in order to get full use of the excellent
performance of this machine, to improve your operation and to perform work effectively.
After reading this manual, store it in a handy location for easy reference.
For details about the engine in this machine, see the separate instruction manual for the engine.
For inquiries about repair parts, parts lists, service manuals, and repair of the machine, please contact the shop
where you purchased it, or the Mikasa Website. In addition, parts lists are available on the
MIKASA website at: http://www.mikasas.com/english/
This rammer is small size and lightweight, but it has strong impact force. Therefore, it will get the strong compaction
effect to the ground.
There is the strong compaction effect to the most soils except soft soil containing too much moisture.
Use the rammer to the construction works of roads, embankments and foundation works, and backfill works of gas
lines, water lines and other pipe lines.
Do not use the rammer for the pile driving work, and compacting work on the rock and hard ground that is over
compacted more than compaction ability of the rammer. Furthermore, in case of using the rammer on sloping ground
such as the side of embankments, it may cause an accident and machine trouble like an abnormal wear due to
unstable operation.
The upper section of the rammer that functioned as a weight consists of the engine section, gear reducer section,
reciprocating section. And handle and the fuel tank section are fitted to the upper section with shock absorber.
The lower section of the rammer that compact the ground consists of the spring cylinder section to generate sliding
motion, the sloping section to tilt machine forward, foot section to compact the ground, and bellows and protect
sleeve to cover the sliding section.
The rammer has the air-cooled, 4-cycle, single-cylinder diesel engine as power unit. And it is equipped the drive
shaft of engine with the centrifugal clutch.
With increasing engine speed, the centrifugal clutch expands and engages with the clutch drum integrated with the
pinion gear. The engine speed is reduced to the speed required for tamping by the reduction ratio of the pinion gear
and crank gear.
The rotary motion of crank gear is converted to the reciprocating motion through the connecting rod. This reciprocat-
ing motion generates jumping motion of the foot up and down through the strong coil spring of spring cylinder. The
rammer generates strong impact force to the ground by its own weight and the jumping motion of foot.

2
3．WARNING SIGNS
4．CAUTIONS FOR SAFETY
The triangle shaped marks used in this manual and on the decals stuck on the machine
indicate common hazards. Be sure to read and observe the cautions described.
Do not work with this machine, when
you are tired or sick and not feeling well.
you have taken medicine or drug.
you have had a drink alchol.
4.1 General Cautions
●
●
●
●
●
●
●
●
●
●
●
○
○
○
Warning labels indicating hazards to humans and to equipment.
DANGER
！
WARNING
！
CAUTION
！
CAUTION
！
Denotes an extreme hazard. It calls attention to a procedure, practice,
condition or the like, which, if not correctly performed or adhered to, is
likely to result in serious injury or death.
Denotes a hazard. It callsattention to a procedure, practice, condition
or the like, which, if not correctly performed or adhered to, could
result in serious injury or death.
Denotes a hazard. It callsattention to a procedure, practice, condition
or the like, which, if not correctly performed or adhered to, could
result in injury to people and may damage or destroy the product.
Failure to follow the instructions may result in damage to property.
！
(without at )
WARNING
！
CAUTION
！
Please read the operation manual well and work safely by using the machine properly.
For handling of the engine, please read to the attached engine operation manual.
Please understand of the structure of this machine well.
Make sure to do the inspection and check the machine conditions before starting operation.
Please use protective equipment such as helmet, protective shoes, protective gloves, etc., and wear
appropriate work clothes for making your work safe.
Always wear noise protection equipment such as ear muffs or ear plugs and protective eyeglasses.
The decals shown operation method, warning and etc. stuck on the machine are very important for your
safety. Clean the machine so that the decals can be read easily. If it is difficult to read the decals, please
replace with new ones.
It is dangerous if children touch the machine. Please be careful about storage location and storage
method for the machine.
Stop the engine before maintenance work.
We are not responsible for any accidents occurred due to the fixing without using genuine parts (foot and
etc.) and equipment modifications.

When adding fuel.■
■
■
■
■
■
■
■
■
■
■
■
Be sure to work in a well ventilated location.
Be sure to work in a clear and flat location without any combustibles nearby.
Be sure to stop the engine and wait until it has cooled down.
Do not use any flames (smoking and etc.) while adding fuel.
Do not overfill tank. If you spill some diesel fuel, wipe it all up.
Tighten the tank cap securely after adding fuel.
-
-
-
-
4.2 Precautions When Adding Fuel
4.3 Precautions About Where To Use The Machine
4.4 Precautions Before Starting Work
CAUTION
！
DANGER
！
DANGER
！
3
① Crack of
shock absorber ② Peeling of steel plate and rubber part
of shock absorber
CRACK PEELING OFF
A
If you use the machine for a long time, be careful to watch for signs of vibration
syndrome. Since this machine vibrates, work for a long time may have a negative
effect on your body. Take sufficient brakes while working.
Before starting to operate the machine, check the safety for people around and
obstacles nearby.
When starting the engine, the rammer may jump suddenly. Hold the handle firmly
and then pull the recoil starter.
Always be careful around ground condition at job site. Operate the rammer in stable
position and balance.
Keep your foot away from the foot of the rammer during work. The foot of the rammer
may crush your foot.
Do not touch the muffler, muffler cover and main body of the engine during work or
soon after work, because they are very hot.
If you find trouble or damage of the machine during work, stop work immediately.
Before leaving or moving the machine, be sure to stop the engine.
When lifting the rammer with the handle, be careful not to pinch your fingers between
the handle and main body.
Push down the rear end of the handle as shown in the left figure (A) and check that
there is no damage on the shock absorbers. If it found the damaged shock absorb-
ers, replace them with new ones by left and right set.
-
-
Do not run the engine in any enclosed or narrow area, such as indoors or in a
tunnel. Engine exhaust gases contain poisonous carbon monoxide. This gas is
colorless and odorless, and can cause death if inhaled.
Do not operate the machine near flames.

■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
4.5 Precautions While Lifting
DANGER
！
4.6 Transportation And Storage Precautions
DANGER
！
4
DANGER
！
Take the utmost care not to fall over the rammer during work, stored or
stopped. Tie down the rammer with cable (wire or rope) when stopped or
stored so that it cannot fall.
If the rammer falls over when children are nearby, they may have a seri-
ous accident.
If the foot of the rammer is worn, the rammer will be especially unstable.
If the foot of the rammer is severe worn, replace it with new one.
If the rammer falls over during work, it will move to forward due to kicking
motion of the foot while falling over. And if the ground is solid, the
rammer will move quickly so it is very dangerous. After ensuring that the
operator and people around are safe, move the throttle lever to the
engine stop position and make sure the rammer stops.
Take careful note of safe especially when working on the public road,
because a serious accident can occur easily.
Before lifting the machine, make sure that there is no damage to parts on
the machine (especially the shock absorber and the hook), loosening or
missing of the bolt, and the machine must be in a safe condition.
Stop the engine before lifting the machine.
Use adequate lifting cable (wire or rope) of sufficient strength for support to the machine.
Do not lift it higher than necessary for safety.
Do not use a damaged lifting cable.
Use one point lifting hook for lifting the machine and lift straight upwards. Do not use any
other points (such as the handle) for lifting.
Never lift or lower the machine rapidly with hydraulic excavator.
Never allow any person or animal to stand underneath the machine while lifting.
Be careful not to an accident when using any lifting equipment. Before using the lifting
equipment, make sure that there is no trouble or damage.
Stop the engine before transporting or storing the machine.
After the engine and main body have cooled down enough,
transport or store the machine.
Drain any fuel before transporting or storing the machine.
Maintain upright position of this rammer on a level floor
during transporting or storing. If it has to lay down the
rammer of necessity, drain the fuel, tighten the tank cap, and
then lay down it with muffler side down. After it lies down,
make sure that there are no oil or fuel leaks.
Tie down the rammer with cable (wire or rope) so that it
cannot move or fall over.
When lifting the rammer with the handle, be careful not to
pinch your fingers between the handle and main body.
When transporting the rammer, use MC-1A of Mikasa Carry
or similar product.
■
■
■
■
■
■

5
■
■
■
■
4.7 Maintenance Precautions
CAUTION
！
Ensure safety for maintenance. It needs appropriate maintenance for
keeping the machine performance. Keep the machine in good condition
with attention to the machine’s condition always.
Be sure to stop the engine before maintenance of the machine.
Do not touch the muffler, muffler cover and main body of the engine until they
have cooled down enough to prevent burn.
Do not touch the lubrication oil and engine oil until they have cooled down
enough to prevent burn.
When maintenance of the machine with disassembling, be sure to refer the
service manual and always work safely.
After maintenance of the machine, check that the parts are assembled properly
and machine conditions for safety.
WARNING
！
■
■

FRONT VIEW
6
4.8 Label Position
LEFT SIDE VIEW
TOP VIEW
9202-21980
9202-10870
9202-10100
9202-11690
9209-00100
9209-00100
9209-00100
9209-00100
9201-09360
9209-00280
9209-00280
REF
No. LABEL No.
PART No. PART NAME Q’ TY REMARK
PLATE, SERIAL NO./MTX-85DY
DECAL,CAUTION/CONBI PL4
DECAL,EC NOISE REQ.LWA108
DECAL,LEVER OPERATION
DEAL,CAUTION ICONS / MT
DECAL,FUEL CAUTION
DECAL,DO NOT LIFTING
DEAL,LIFTING POSITION
DECAL,DO NOT LAY DOWN
DECAL,AIR CLEANER
DECAL,MACHINE STOP
NPA-2198
NPA-1087
NPA-1010
NPA-1169
NPA-1470
NPA-1471
NPA-1473
NPA-1474
NPA-936
NPA-1246
NPA-1248
1
1
1
1
1
1
1
1
1
1
1
1
2
3
4
5
6
7
8
9
10
11
Air
cleaner
7
8
10
6
1
5
3
4
9
2
4.9 Label List
13
12
14
11
9202-15500
9202-11220
9202-20190
DECAL,HUTTER 30 X 140
DECAL,HUTTER MARK D60
DECAL,HUTTER,3ANS GARANTIE
NPA-1550
NPA-1122
NPA-2019
1
1
1
12
13
14

7
4.10 Descriptions Of The Symbols On The Warning Decals
①
②
⑤
④
Part code No.9209-00100 DECAL, SET /MT /EXP, EU
⑨
⑥
⑧
⑦
③
72
⑪
① ②
⑤④
⑥
⑧
③
⑨
⑩
⑦
⑩
⑪
NPA-1472
NPA-1473
NPA-1474
NPA-1471
NPA-1470
Part code No.9202-10870 DECAL, COUTION/CONBI PL4
⑧
⑨⑫
⑫
⑦
NOUSE
NOUSE
Lethal exhaust gas hazards.
The exhaust gas contained poisonous carbon
monoxide can cause death if inhaled.
Falling hazards.
Falling hazards.
Take the utmost care not to fall over the
rammer during work, stored or stopped.
Read the manual carefully.
Always read the operation manual and have
good understanding of operation before
working.
Burn hazards.
Never touch the hot exhaust manifold, muffler
or cylinder. Allow these parts to cool before
servicing the machine.
Crush hazards.
During work, keep your foot away from the
foot of the rammer. The foot of the rammer
may crush your foot.
Refueling hazards.
Do not add fuel until the engine has cooled
down after stopping it.
Fire hazards.
Do not use any flames (smoking and etc.)
while adding fuel.
Eye hazards
Always use eye protection during operating
the machine.
Hearing hazards.
Always use ear plugs during operating the
machine.
Lifting position.
Use one point lifting hook for lifting the
machine.
No lifting position.
Do not use any other points (such as the
handle) except one point lifting hook for
lifting the machine.
Read the manual carefully.
Always read the operation manual and have
good understanding of operation before
working.

8
5.1 Body
5.2 Engine
Model
Dimensions
Plate Size
Fuel Tank Capacity
Main Body Oil
Oil Capacity
Number of Blow
Impact Force
Jumping Stroke
Operating weight
Overall height
Overall width
Overall length
Length
Width
MTX-85DY
1063
411
740
340
285
2.6
API Service Categories SE or higher SAE 10W-30
820
10.9～11.6/656～698
15.7/1,600
50～80
93
mm
mm
L
cc
Hz/v.p.m
kN/kgf
mm
kg
Model
Type
Piston Displacement
Max. Output
※
Fuel
Engine Oil
Oil Capacity
Starting System
Setting speed
Yanmar L48N6-SMK2
Air-Cooled 4 Stroke,
diesel engine.
219
3.5 (4.7)/3600
Automotive Diesel Fuel
API Service Categories CD or higher SAE 10W-30
800
Recoil starter
3300
cc
kW(PS)/rpm
ｃｃ
min-1/rpm
5．SPECIFICATIONS
※Based on “SAE J1349”

9
6．APPEARANCE
※
6.1 Appearance Dimensions
411
285
740
340
1063

10
6.2 Control Unit Positions And Names
MUFFLER
ASSY
HANDLE ASSY
ONE POINT LIFTING HOOK
FUEL TANK
CAPASSY
FUEL TANK
ASSY
ENGINE
ASSY
BELLOWS
FOOTASSY
THROTTLE
LEVER ASSY
RECOIL
STARTER
OIL GAUGE
DRAIN
PLUG
AIR CLERNER
COVER
OIL INLET
PLUG
FOOT PLATE

11
7．INSPECTION BEFORE OPERATION
Check the machine while the engine is stopped. You may be caught in a rotating
part and be seriously injured.
Check the machine after it has cooled down. Since the muffler is very hot, you may
be burned.
Fig.2
WARNING
！
●
●
Inspection items
Flaws, deformity, dirt
Dirt, flaws, deformity
Loose or missing
Flaws, deformity, cracks, breaks
Flaws, deformity, cracks, breaks
Leaks,oil level,dirt
Leaks,oil level,dirt
Leaks, fuel level, dirt
Leaks, wear, loose parts
Inspection points
Appearance
Air cleaner
Bolts, nuts
Handle
Rubber damper
Engine oil
Main body oil
Fuel tank
Fuel system
Fig.1
Oil inlet plug
(Check the oil level!!)
Blocking
(Move the engine at vertical position!)
It is extremely important that this section be
read carefully before attempting to operate the
rammer.
Do not use your rammer until this section is
thoroughly understood.
Clean each parts of the machine so that there is no
mud or dirt on them.
Make sure that all bolts and nuts are not loos-
ened. If they are loosened, retighten them to
prevent an accident and trouble.
Replace any missing or damaged safety and operation
decals.
Check the main body oil through the oil gauge on the
protection sleeve on level ground. (Fig.1)
Check the engine oil. For checking the engine
oil level, move the engine to vertical position
and check that the oil is filled at the oil inlet
(800cc). (Fig.2)
Fill the fuel tank with automobile diesel fuel. (Fig.3)
1.
2.
3.
4.
5.
6.
Oil gauge
Oil inlet plug Fuel tank ( Diesel )
Fig.3
Drain plug

12
8．OPERATION
Idlingposition
Stopposition
Throttlelever Fig.4
Fig.6
8.1 Starting
Idling
Position
Opetation
Position
Throttle
lever
Recoilstarter
Fig.5
Decompressionlever
(Decompressedposittion)
CAUTION
！
Fig.7
CAUTION
！
Move the throttle lever to idle position. (Fig.4)
Grip the recoil starter handle and pull it slowly
until you feel a strong resistance. (Fig.5)
Slowly return the recoil starter handle to the
original position.
Push the decompression lever down and release
it. (Fig.6)
The decompression lever will return automatical-
ly when the recoil starter handle is pulled.
Grip the recoil starter handle and hold the handle
firmly. Then, pull the recoil starter handle with a
strong and even motion.
1.
2.
3.
4.
5.
Slowly return the recoil starter handle to the
original position.
After starting engine, warm up it for about five
minutes by idling speed and check for fuel
leakage or abnormal sounds in the meantime.
In cold weather, the engine should be started at
operation position of the throttle lever. (Fig.7) In
this case, note that the rammer will jump soon
after starting engine, so move the throttle lever
to idling position quickly.
Do not pull the recoil starter rope all the way to
the end.
Be careful to the snap back of the recoil rope
when pulling it, as this may cause injury.
Move the throttle lever quickly from the idling
position to operation position for starting tamping
action.
Do not move the throttle lever slowly, as this
may cause damage to the clutch or irregular
tamping action.
In cold weather, the rammer can be warmed up
by moving the throttle lever quickly form the
operation position to idling position several times
until the rammer operates smoothly.
6.
7.

13
11．STORAGE
9．STOPPING THE MACHINE
10．TRANSPORTATION
Fig.9
Idlingposition
Stopposition
Throttlelever Fig.8
Movethelever
fromIdling
toStopposition.
Move the throttle lever quickly from the operation
position to idling position.
Run the engine at idling speed for five minutes
for cool down for maximum engine life.
Move the throttle lever quickly from the idling
position to stop position. (Fig.8)
Stop the engine before transporting the machine.
Do not move the machine until the engine and
main body have cooled down enough.
Drain any fuel before transporting the machine.
Maintain upright position of the rammer on a
level floor during transporting. If it has to lay
down the rammer unavoidably when transport-
ing, drain the fuel, tighten the tank cap and then
lay down it with muffler side down. (Fig. 9)
Tie down the rammer with cable (wire or rope)
so that it cannot move or fall over during trans-
porting.
Store the machine the same procedure as [10.
Transportation].
Slowly pull the recoil starter handle until the point
of resistance (the point in the compression
stroke where the intake and exhaust valves are
closed). This helps to prevent rust while the
engine is not in use.
Put a cover on the machine to prevent deposit-
ing dirt.
Store the machine in dry place away from direct
sunlight.
1.
2.
3.
1.
2.
3.
4.
5.
1.
2.
3.
4.

14
12．PERIODIC CHECKS AND ADJUSTMENTS
Check the machine while the engine is stopped. You may be caught in a
rotating part and be seriously injured.
●
●
WARNING
！
12.1 Table Of Scheduled Checks
Regarding the check and maintenance of the engine in details, please refer to the attached engine operation manual.
Every 2 years Replace
Replace
How often? Place to check Item to check Reference
Daily
(before starting
operation)
Flaws, deformity, dirt
Dirt, flaws, deformation
Loose or missing parts
Flaws, deformity, cracks, breaks
Flaws, deformity, cracks, breaks
Leaks, fuel level, dirt
Leaks, wear, loose parts
Engine oil
Engine oil
Diesel Fuel
After first 50 hours Replace Engine oil
Engine oil
Leaks,oil level,dirt
Leaks,oil level,dirt
Fuel hose
Intake pipe
Appearance
Air cleaner
Bolts, nuts
Handle
Rubber damper
Engine oil
Fuel tank
Fuel system
Engine oil / Main body Oil
Main body oil
Engineoil/Main body oil
Oil Filter
Air cleaner element
(Secondary)
Air cleaner element (Primary)
Every 100 to 150
hours
Every 200 hours
Cleaning
Cleaning
Replace, after the first 50 hours
The above table shows the check frequency for standard condition.
The check frequency may vary depending on the condition in which the machine is used.
●
●
CAUTION
！
12.2 Inspection And Maintenance Work Contents
Every 80 to 100
hours
Cleaning
Oil filter
Cleaning, after the first 50 hours
Check the machine after it has cooled down. Since the muffler is very hot, you may be
burned.
Daily inspection
Thoroughly remove dirt and oil from the
engine and control area.
Clean or replace the air cleaner element as
necessary.
Check and retighten all fasteners as neces-
sary.
Check the main body for oil leaks. Repair or
replace as necessary.
50 hours service
Remove and clean the fuel filter, and inspect
the fuel tank condition. (Fig. 10)
1.
●
●
●
●
2.
Fuel tank
Fuel filter
Fig.10

15
Fig.14
Fig.15
Secondary element
INTIAL OIL CHANGE:
After 50 hours of operation.
Fig.11
Oil gauge
Oil inlet plug
Drain plug
SECOUND OIL CHANGE OR LATER:
Every 200 hours of operation.
Change the main body oil.
Remove the drain plug on the foot plate (Fig.
11) and drain the oil. Refill with approximately
820 cc of engine oil of API service categories
SE or higher, SAE 10W-30. The oil level should
be the halfway point of the oil gauge.
Change the engine oil.
Remove the drain plug (Fig. 12) and drain the
oil. Refill with approximately 800 cc of engine
oil of API service categories CD or higher, SAE
10W-30.
Please refer to the engine operation manual
for details of change the engine oil.
Cleaning the air cleaner
Remove the upper air cleaner cover on the
main body. And then remove the air cleaner
cover on the air cleaner assembly.
Primary element(clean every 80 to 100 hours)
If the primary element (Fig. 13) is dirty,
wash it with gasoline or kerosene. Then
dip it in engine oil (SAE 10W-30) and
wring it so that 25 to 30 cc of engine oil
remains on it.
●
●
3.
●
Fig.12
Drain plug
INTIAL OIL CHANGE:
After 50 hours of operation.
SECOUND OIL CHANGE OR LATER:
Every 200 hours of operation.
Secondary element(cleanevery 100 to
150 hours)
If the secondary element (Fig. 14) under the
primary element is dirty, wash it with neutral
detergent and dry it well. Then reuse it. (Fig.15)
Cleaning the oil filter of engine
Clean the oil filter of engine every oil change.
(Fig. 16)
●
4.
Primary element
Fig.13
Fig.16
Oil filter

16
Replace it every 1000 hours of operation.
Please refer to the engine operation manual for
details of cleaning the oil filter of engine.
Checking Fuel line
Check the fuel line for damage or looseness.
Replace it every 2 years, even if it does not
show any abnormality.
Cleaning the machine
If the machine is cleaned by using high
pressure washer, do not spray directly to the
air cleaner, engine and fuel tank. Otherwise
engine trouble may occur.
5.
6.
1. Diesel Engine
13．TRAUBLE SHOOTING
Operating speed of throttle lever too slow.
Main body oil in excess.
Clutch slips.
Spring failure.
Engine Speed improper.
Engine runs normally, but tamping stroke is not stable or it does not tamping.
2. Rammer itself
■
Regarding the troubleshooting of the diesel engine, please refer to the engine operation
manual.
■

PRINTEDINJAPAN
MIKASASANGYOCO.,LTD.
1-4-3,Kanda-Sarugakucho,Chiyoda-ku,Tokyo,101-0064,Japan
