KOBE SR375 User manual

DECLARATION OF CONFORMITY
We hereby certify that KOBE 3/8” SQUARE DRIVE RATCHET SPEED WRENCH
(ORDER CODE: KBE-270-2375K)
complies with all the relevant provisions of the
Machinery Directive: 2006/42/EC
Standards Applied:
EN ISO 12100:2010, EN ISO 11148-6:2010, EN ISO 28927-2:2009, EN ISO 15744:2008
RoHS2 Restriction of Hazardous Substances Directive 2011/65/EU
Standards Applied:
EN 50581-1:2012
Signed:
Date: 14th December 2021
Name: Toni Johonson
Position: Compliance Director
OPERATOR’S MANUAL
3/8” SQUARE DRIVE
RATCHET SPEED WRENCH
Please retain this information for future reference.
WARNING: THE SAFETY INFORMATION GIVEN INSIDE MUST BE
READ AND UNDERSTOOD BY ANY PERSON USING, INSTALLING,
REPAIRING OR MAINTAINING THESE PRODUCTS.
ORDER CODE:
KBE-270-2375K
MODEL
SR375
KOBE
PROFESSIONAL
AIR TOOLS
THE ENVIRONMENT
Always dispose of unwanted tools, accessories and packaging materials in an environmentally
friendly manner.
In observance of European Directive 2012/19/EU on Waste Electrical and Electronic Equipment
(WEEE) and its implementation in accordance with national law, electrical goods that have reached
the end of their life must be collected separately and returned to an environmentally compatible
recycling facility.
Do not dispose of electrical goods with domestic waste materials as inappropriate disposal may
cause potential hazards to the environment and human health.
For further information, please contact your local authority or the retailer from whom you purchased
the product.
This product does not contain any restricted substances in concentrations and applications which
are banned by the European RoHS2 Directive.
QUALITY GUARANTEE & WARRANTY
KOBE INDUSTRIAL POWER TOOLS carry a one year manufacturer’s warranty.
KOBE INDUSTRIAL POWER TOOLS are designed & manufactured
to the highest standards & specifications
Assuring the quality and performance required by all sectors of industry.
KOBE INDUSTRIAL POWER TOOLS are fully guaranteed against
faulty materials & workmanship.
Should they be found to be defective, they will either be repaired or replaced
free of charge (fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
• Ball Type Retainer
• Disc Type Reversing Action
• Compact, Lightweight Design
• Front Exhaust
• Ideal for Automotive Work
KOBE TOOLS
Cromwell Group (Holdings) Limited.
65 Chartwell Drive, Wigston, Leicestershire,
England, LE18 2FS
Contact Us: [email protected]
Country of Origin :Taiwan
Cromwell Group (Holdings) Limited.
65 Chartwell Drive, Wigston, Leicestershire, England, LE18 2FS
© The Kennedy Group Ltd. 12/21

2 7
KOBE PROFESSIONAL AIR TOOLS have been specifically designed to help you work
SAFELY and EFFICIENTLY. Your care and good judgement are the best protection against injury, but
always ensure that the appropriate safety equipment is worn. All possible hazards cannot be covered here,
but the most important ones have been highlighted.
KOBE
PROFESSIONAL
AIR TOOLS
SAFETY INSTRUCTIONS
You have purchased a quality product that is designed for high performance
and long service life. If correct use, safety and maintenance procedures are
observed this machine will last for many years.
Always adhere to the processes and safety
warnings, which are stated in the instruction
manual.
GENERAL OPERATING HAZARDS
Always ensure the mains power supply
corresponds to the power rating on the
specification label on the machine.
Always plug the battery charger into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances. Check with a qualified electrician
if you are in doubt as to whether the outlet is
properly grounded.
Always ensure the maintenance of electrical
components is carried out by a suitably qualified
person.
Never allow routine to lead to mistakes.
Never operate if any parts are missing or
damaged.
Never allow untrained persons to operate the
tool.
WORKPLACE HAZARDS
Always ensure your working area is clean and
well lit.
When working at height make sure that the tool
is safely secured and be aware of objects falling
below. Make sure that no persons are working
directly below the working area.
Do not operate in explosive atmosphere, for
instance extreme dust, gases and liquids.
Keep children and bystanders away while
operating the tool. Distractions can cause you to
lose control.
Always ensure all users are physically able
and competent to handle the size and weight
of items/components being drilled and have
received appropriate training to perform the task.
 Never run the tool in areas exposed to water or
in damp conditions.
PERSONAL PROTECTION
Always wear approved eye protection during
operation. Use safety glasses or goggles which
conform to BSEN136 or CE equivalent that
provide protection from the front and side. The
operator of the power tool is responsible for
following accepted eye, face, respiratory, hearing
and body protection.
Always ensure that all long hair and loose clothing,
ties, scarves, jewellery, etc., are secured or
removed.
Always consult a doctor if numbness, tingling,
pain or whitening of the skin occurs. Repetitive
work motions, awkward positions and exposure
to vibration can cause “Repetitive Strain
Injuries”.
When operating the tool stay alert and use
common sense, especially when it comes to
working at height. Be aware of what’s below you.
Do not overreach. Keep a proper balance and
footing at all times.
Remove any adjusting key or wrench before
turning the power tool on.
If devices are provided for the collection of dust,
ensure these are connected and properly used.
Do not use the tool if under the influence of
alcohol, drugs or medication.
SPECIFIC SAFETY INSTRUCTIONS
Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate
for which it was designed.
Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the
hands of untrained users.
Maintain power tools. Check for misalignment or
binding of moving parts,breakage of parts and
any other condition that may affect the power
tools operation. If damaged,have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
KOBE
PROFESSIONAL
AIR TOOLS
PARTS BREAKDOWN
1 KBE-298-0001S Housing 1 2 KBE-298-0004S Spring Pin 1 3 KBE-298-0007S Connection 1 4 KBE-298-0010S
Safety Throttle Lever 1
5 KBE-298-0013S Throttle Valve 1 7 KBE-298-0016S O-Ring 1 8 KBE-298-0019S Spring 1 9 KBE-298-0022S O-Ring 1 10 KBE-298-0025S Valve Plug 1 11 KBE-298-0028S End Plate Cap 1 13 CES-298-0627B Bearing 1 14 KBE-298-0034S Rear End Plate 1 15 KBE-298-0037S Rotor 1 16 KBE-298-0040S Vanes 4 17 KBE-298-0043S Pin 1 18 KBE-298-0046S Cylinder 1 19 KBE-298-0049S Front End Plate 1 20 CES-298-0609B Bearing 1 21 KBE-298-0055S Washer 1 22 KBE-298-0058S Thread Ring Gear 1
23 KBE-298-0061S Idler Gear 3
24 KBE-298-0064S Idler Gear Pin 3 25 KBE-298-0067S Idler Gear Plate 1 26 KBE-298-0070S Clamp Nut 1 27 KBE-298-0073S Spacer 1 28 KBE-298-0076S Ratchet Housing 1 29 KBE-298-0079S Needle Bearing 1 30 KBE-298-0082S Crank Shaft 1 31 KBE-298-0085S Drive Bushing 1 32 KBE-298-0088S Yoke 1 33 KBE-298-0091S Reverse Button 1 34 KBE-298-0094S Spring 1 35 KBE-298-0097S Spring Cap 1 36 KBE-298-0100S Washer 1 37 KBE-298-0103S Ratchet Pawl 1 38 KBE-298-0106S
Ratchet Anvil 3/8"1
39 KBE-298-0112S Spring 1 40 KBE-298-0115S Pin 1 41 KBE-298-0118S Thrust Washer 3/8" 1
42 KBE-298-0124S Retainer Ring 1 43 KBE-298-0127S Ball 2
No. Order Code Description Qty No. Order Code Description Qty
Always plug the battery charger into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances. Check with a qualified electrician
if you are in doubt as to whether the outlet is
properly grounded.
Always ensure the maintenance of electrical
components is carried out by a suitably qualified
Never allow routine to lead to mistakes.
Never operate if any parts are missing or
Never allow untrained persons to operate the
WORKPLACE HAZARDS
Always ensure your working area is clean and
When working at height make sure that the tool
is safely secured and be aware of objects falling
below. Make sure that no persons are working
directly below the working area.
Do not operate in explosive atmosphere, for
instance extreme dust, gases and liquids.
Keep children and bystanders away while
operating the tool. Distractions can cause you to
to vibration can cause “Repetitive Strain
Injuries”.

When operating the tool stay alert and use
common sense, especially when it comes to
working at height. Be aware of what’s below you.

Do not overreach. Keep a proper balance and
footing at all times.

Remove any adjusting key or wrench before
turning the power tool on.

If devices are provided for the collection of dust,
ensure these are connected and properly used.

Do not use the tool if under the influence of
alcohol, drugs or medication.
SPECIFIC SAFETY INSTRUCTIONS

Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate
for which it was designed.

Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.

Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the

6 3
KOBE
PROFESSIONAL
AIR TOOLS
SPECIFICATIONS
SUGGESTED AIR SUPPLY
1. For optimal results you should incorporate a regulator, oiler and an inline filter.
2. If you are not using an automatic lubricating system, before operating the tool, add a few drops
of Pneumatic Tool Oil to the air-line connection. Add more after each hour of constant using.
3. Do not exceed maximum air pressure of 90 PSI/ 6.2 bar or as stated on tool nameplate.
KOBE
PROFESSIONAL
AIR TOOLS
LUBRICATION
KOBE
PROFESSIONAL
AIR TOOLS
AIR PRESSURE 90PSI
AIR CONSUMPTION 4CFM*
OVERALL LENGTH 255MM
WEIGHT 1.1 KG
*Based on 15 second cycle per minute average use.
MODEL NUMBER SR375
FREE SPEED 200rpm
BOLT CAPACITY 10mm
AIR INLET THREAD 1/4NPT
AIR HOSE SIZE (ID) 10mm
Air tools require lubrication throughout the life of the tool otherwise moisture in the compressed air will
rust the air motor. Correct lubrication is vital for the maximum performance of the die grinder and an airline
lubricator should be fitted into the system down stream of the filter. Failure tolubricate the tool at the air inlet
will void your warranty.
Either use an air line lubricator with air tool oil adjusted to two drops per
minute, or if an air line lubricator cannot be used, add air motor oil to the
inlet once a day (See fig 1). ISO Grade VG22 oil is recommended.
Any excess oil in the motor is expelled immediately from the exhaust
port. Always direct the exhaust port away from people or objects.
Do not lubricate the die grinder with flammable or volatile liquids such as
kerosene, diesel or jet fuel.
Fig. 1
KOBE
PROFESSIONAL
AIR TOOLS
PARTS BREAKDOWN

4 5
KOBE
PROFESSIONAL
AIR TOOLS
OPERATION
WARNING! BEFORE ATTEMPTING TO USE THIS PRODUCT, MAKE SURE YOU ARE
FAMILIAR WITH ALL OPERATING AND SAFETY INSTRUCTIONS.
OPERATING INSTRUCTIONS
Use accessories recommended by Sunmatch. Check the position of the reversing mechanism before
operating the tool so as to be aware of the direction of rotation when operating. Use only impact sockets
and accessories. Do not use the hand sockets or accessories. Check the drive end of the tool to make
sure that the socket retainer functions correctly and that sockets and drive ends are not excessively worn
which may allow the socket to come off when rotating. Connections requiring specific torque must be
checked with a torque meter after fitting with an ratchet wrench.
LOOSENING
Attach the correct size socket to the anvil. Set the compressor’s pressure regulator to 90PSI. Connect the
tool to the air compressor’s hose. If leakage is detected, disconnect the air hose and fix it correct before
use. Place the socket over the nut to loosen. Grip the tool firmly.
TIGHTENING
Make sure that the nut or bolt you are using the tool to tighten can withstand the rated torque.
Tighten the nut as far as you can by hand. Place the socket on the nut. Press the Reverse valve forward so
it protrudes out the front of the housing. Please the trigger to start the tool.
MAINTENANCE
Disassemble and inspect higher wear parts every three months if the tool is used every day and replace
damaged or worn parts.
Replace as necessary all "O" rings, bearings and rotor blades, see parts break down.
It is recommended that adequate stocks of standard service parts are held for servicing requirements.
The use of other than genuine Kobe replacement parts may result in safety hazards, decreased tool
performance and increased maintenance.
Mineral spirits are recommended when cleaning the tool and its parts. Do not clean with any solvents or
oils containing acids, esters, ketones, chlorinated hydrocarbons or nitro carbons. Do not use chemicals
that have a low flash point.
For spare parts or servicing please contact your nearest agent. Remember to quote tool model number and
spare part number when ordering spares.
When disposing of components, lubricants etc. ensure that relevant environmental procedures are carried
out.
KOBE
PROFESSIONAL
AIR TOOLS
NOTES
