FLI Audio INTEGRATOR 4 Parts list manual
Models: INTEGRATOR 4, 5, 6, 9, 9P F-2
Introduction
This instruction manual is for your safety and must be adhered to at all times. Please read and ensure that you fully
understand the installation and set up procedures as explained. If you are unclear on the installation or set up of your
FLI INTEGRATOR speakers please contact your nearest authorised FLI dealer.
Contents
2 x FLI Integrator speakers.
2 x Grills.
8 x Fixing screws.
1 x Cut out template.
2 Lengths of speaker cable.
Warranty card
WARNING
DO NOT EXPOSE THIS PRODUCT TO DAMP OR MOISTURE - doing so may result in fire, shock or damage to the product.
BEFORE WIRING DISCONNECT THE CABLE FROM THE POSITIVE BATTERY TERMINAL - failure to do so may result in electric
shock or injury.
ENSURE GOOD AND CORRECT CONNECTIONS - failure to make the correct connections may result in fire or damage to the product.
DO NOT USE ANY FUNCTIONS OF THIS EQUIPMENT THAT MAY TAKE YOUR CONCENTRATION AWAY FROM DRIVING YOUR
VEHICLE - do not set up your amplifier whilst driving, doing so may result in an accident. For prolonged setting up, make sure that your
vehicle is stationary and in a safe location.
KEEP THE VOLUME AT A LEVEL SO YOU CAN STILL HEAR OUTSIDE NOISE - failure to do this may result in an accident. FLI
equipment is capable of producing sound levels that can permanently damage your hearing. FLI recommends caution when listening at
high volume. For safe and enjoyable listening the sound should be comfortable and clear without distortion.
CAUTION
Never connect any speaker lead to the car chassis. This can cause severe damage to your speaker /car radio /amplifier.
Before drilling or cutting any holes, investigate the layout of your vehicle thoroughly.
Use caution when working near the fuel / hydraulic lines and electrical wiring.
Observe the correct polarity when wiring, improper phasing may cause a loss of bass response.
Ensure that no moving parts catch on the speaker or grill (e.g. window or door handles, or window glass inside the door)
Installation
The quality of the installation will affect the system performance and reliability.
Contact your nearest authorised FLI dealer if you are unsure about the installation of this product.
Please mount this unit away from any potential hazards.
Minimising the length of wires will provide higher audio output from the system.
The speaker should be securely fastened to the mounting position using the screws provided.
Pre drill your mounting holes using a drill and position with the template provided.
Be sure to investigate your mounting area thoroughly for electrical wires, brake or fuel lines or fuel tank to prevent causing any damage.
Thank you for purchasing these FLI coaxial speakers. They will provide you with
years of trouble free usage providing you follow a few simple guidelines.
Speaker Installation
Ifnecessarycutanymaterialawaytoallowthespeakertositcorrectly.
Cutoutthemountingholeandpre-drillanyotherfixingholes.
Ifthegrillistobefitted,screwthroughbothgasketandspeakerusingthescrewprovideduntilthespeakerissecurelyfastened.
Grill removal
TheFLIintegratorspeakersfeaturearemovablemeshgrill.Pleasefollowtheinstructions
belowtoremovethegrill.
* Peeltherubbergasketawayfromthebasket
* Removethemeshgrill
* Refittherubbergasket.
Firstly,makesurethatthespeakerswillfitinyourchosenlocation.Thismayinvolvetheremovalofthestandardvehiclespeakers.Pleaseusethe
mountingdepthandholecutdimensionsasdetailedinthismanualforguidance.
+
+
-
-
Wiring connections
Connection to amplifier
+
+
-
-
Connection to HEAD UNIT
FI5-F2
Revc = 3.4 Ohm
Fo = 83.008 Hz
Sd = 8.659 M
Md = 9.970 g
BL = 3.521 T
Qms = 4.555
Qes = 1.244
Qts = 0.977
No = 0.200 %
SPLo = 85.0 dB
Vas = 4.500 m
Cms = 422.612 u M/N
Krm = 405.635 u Ohm
Erm = 0.892
Mms = 8.699 g
Mmd = 8.235 m Kg
Kxm = 4.057 m H
Exm = 0.704
180 watts peak
60 watts RMS
MIN.input 30 watts RMS
Mount depht 44mm
Mount DIA 100mm
FI9-F2
Revc = 3.4 Ohm
Fo = 65.102 Hz
Sd = 21.253 M
Md = 23.350 g
BL = 4.592 T
Qms = 3.148
Qes = 1.051
Qts = 0.788
No = 0.611 %
SPLo = 89.9 dB
Vas = 24.064 m
Cms = 375.185 u M/N
Krm = 1.800 m Ohm
Erm = 0.795
Mms = 15.930 g
Mmd = 14.98 m Kg
Kxm = 11.722 m H
Exm = 0.637
375 watts peak
125 watts RMS
MIN.input 60 watts RMS
Mount depht 78mm
Mount DIA 220x150mm
FI6-F2
Revc = 3.4 Ohm
Fo = 69.782 Hz
Sd = 13.070 M
Md = 12.340 g
BL = 3.979 T
Qms = 4.111
Qes = 1.339
Qts = 1.010
No = 0.218 %
SPLo = 85.4 dB
Vas = 8.875 m
Cms = 365.859 u M/N
Krm = 623.276 u Ohm
Erm = 0.861
Mms = 14.218 g
Mmd = 13.359 m Kg
Kxm = 8.805 m H
Exm = 0.629
210 watts peak
70 watts RMS
MIN.input 35 watts RMS
Mount depht 48mm
Mount DIA 144mm
Parameters
FI4 -F2
Revc = 3.4 Ohm
Fo = 88.976 Hz
Sd = 5.153 M
Md = 6.410 g
BL = 3.405 T
Qms = 4.377
Qes = 1.211
Qts = 0.949
No = 0.092 %
SPLo = 81.7 dB
Vas = 1.634 m
Cms = 433.228 u M/N
Krm = 298.890 u Ohm
Erm = 0.919
Mms = 7.386 g
Mmd = 7.173 m Kg
Kxm = 3.925 m H
Exm = 0.706
150 watts peak
50 watts RMS
MIN.input 25 watts RMS
Mount depht 40mm
Mount DIA 85mm
In order to protect your purchase and aid your
warranty please fill in the following form and
keep it safe for your future reference:
Model Number:
Serial Number:
Purchased From:
Date of Purchase:
KEEP IT SAFE
Staple your receipt here:
FI9P-F2
Revc = 3.4 Ohm
Fo = 65.102 Hz
Sd = 21.253 M
Md = 23.350 g
BL = 4.592 T
Qms = 3.148
Qes = 1.051
Qts = 0.788
No = 0.611 %
SPLo = 89.9 dB
Vas = 24.064 m
Cms = 375.185 u M/N
Krm = 1.800 m Ohm
Erm = 0.795
Mms = 15.930 g
Mmd = 14.98 m Kg
Kxm = 11.722 m H
Exm = 0.637
375 watts peak
125 watts RMS
MIN.input 60 watts RMS
Mount depht 78mm
Mount DIA 220x150mm
We reserve the right to make needed changes or improvements to the produc and
this manualt , without informing the customer about this in advance.
Copyright
All content included in this manual such as text, graphics, logos, icons, images data, the selection and arrangement
thereof, are the property of FLI Audio (herein referred to as "FLI", "us" or "we") and its affiliate or their content and
technology providers, and are protected by United Kingdom and International copyright laws. All rights reserved.
Trademarks
FLI FrequencyTM, FLI IntegratorTM , FLI LoadedTM , FLI Trap PassiveTM, FLI Trap ActiveTM , and FLI Trap TwinTM and all
stylised representations of product names, or the abbreviations of product names, as logos are all trademarks of FLI.
Graphics and logos are trademarks or trade dress of FLI Audio or its subsidiaries.
FLI's trademarks and trade dress may not be used in connection with any product or service that is not FLI's, in any
manner that is likely to cause confusion among customers or in any manner that disparages or discredits FLI. All other
trademarks not owned by FLI or its subsidiaries that appear in this manual are the property of their respective owners,
who may or may not be affiliated with, connected to, or sponsored by FLI or its subsidiaries.
Limited Warranty
All FLI goods are covered by a full 12 months manufacturers warranty. Valid from
the date of the original receipt and proof of purchase. In order to
validate this warranty, the warranty card should be returned to FLI
within seven days of the original purchase date. The original receipt
and packaging should also be kept for this 12 month period.
If at any stage during the warranty period you have a problem with the
product then it should be returned to the point of purchase in its
original packaging, complete and with no items missing.
If the store is unable to fix the product it may have to be returned to
FLI this process takes around 7 working days.
A full description of FLI's warranty information can be found on our
website:
www.fliaudio.co.uk/warranty
A written version can also be obtained from
FLI warranty department
PO Box 11000
B75 7WG
FLI Line Level Convertor
If your current head unit has no amplifier pre
outputs this FLI Line Level Convertor can be
connected directly to your rear speaker wires to
provide a stereo set of RCA connectors which
can be connected directly to an amplifier.
FLI Loaded In dash remote control
Allows 18db gain adjustment
of the bass boost feature which is present on all
FLI Loaded amplifiers. Comes complete with 5m
cable. Control can be mounted in-dash or
anywhere suitable.
dimensions: H:20mm
W:40mm D:45mm
FIREFLI 5/1 metre LED RCA
interconnect
High quality 2 Channel RCA interconnect
featuring FIREFLI mega brite LED RCA end
plugs
available in 1 metre and 5metre lengths
FLI RCA-Y interconnect
High quality RCA Y-lead interconnect
Converts stereo RCA output to 4channel output
2 female RCA plugs to 4 male RCA plugs
FLEECE
Black pull over fleece with front zip and arm
pocket features white FLI embroidery logos on
front and back
FLI Tshirts
Our heavy weight FLI T-shirts are a must have!
Featuring small FLI logo on front and big logo on
back. All sizes available
FLI Stickers
FLI stickers available in white or silver 5” 10”
15”
FLI Power Capacitor
The FLI powercap, a 1 farad, high
specification power capacitor is another great
addition to our range. This is an essential item
for maximum power delivery.
10 Gauge FLI Wiring Kit
For use with Car audio systems up to 1000
watts. Kitcontents:
5 metre 10 AWG power cable
1 metre 10AWG ground cable
5 metre RCA interconnect
5 metre remote turn on cable
8 metre speaker cable
Inline ATC fuse holder, 30 amp ATC blade
fuse, Fitment pack,
AK8 – 8 AWG amplifier wiring kit
For use with Car audio systems up to 1500
watts Kit contents:
5 metre 8 AWG power cable
1 metre 8AWG ground cable
5 metre FIREFLI LED RCA interconnect
5 metre remote turn on cable
8 metre speaker cable
AGU glass fuse holder, 60 amp AGU glass
fuse, Fitment pack
AK4 – 4 AWG amplifier wiring kit
For use with Car audio systems up to 2000
watts Kit contents:
5 metre 4 AWG power cable
1 metre 4AWG ground cable
5 metre FIREFLI LED RCA interconnect
5 metre remote turn on cable
8 metre speaker cable
AGU glass fuse holder, 80 amp AGU glass fuse
Fitment pack
FLI GRILLS FG10, FG12 & FG15
For use with the FLI subwoofers the FLI Sub
Grill is a visually
appealing way to protect your subwoofer from
accidental damage. The FLI
shaped grill protects the cone and rubber
surround from other items in
your boot.
Accessories can be ordered separately from the
FLI website www.fliaudio.co.uk
Only available in the UK If out side uk please contact your dealer or distributer from the FLI website
Order online or call sales on 0870 765 8423 . All items above come with free next day delivery.
