FLIGHT DESIGN CT2K User manual
CT2K/CTSW
Parts & Assembly
Manual
Copyright © 2008 Flight Design GmbH. All Rights reserved
Release 5
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Disclaimer Notice
FLIGHT DESIGN DISCLAIMS ALL WARRANTIES WITH
REGARD TO THIS CATALOGUE, INCLUDING ALL IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS, IN
NO EVENT SHALL FLIGHT DESIGN BE LIABLE FOR ANY
SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR
ANY DAMAGES WHATSOEVER RESULTING FROM LOSS
OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF
CONTRACT OF THIS CATALOGUE.
3
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Contents ............................................................................................................................... 3
Introduction ......................................................................................................................... 10
Plane ..................................................................................................................................... 11
Chapter 1: Fuselage .......................................................................................................... 12
Designs ................................................................................................................................ 12
Snow Design ..................................................................................................................... 13
Swing Design ................................................................................................................... 14
Up Design ......................................................................................................................... 16
Fuselage ........................................................................................................................... 17
Curtain Mounting ............................................................................................................... 18
KB1000440 Curtain, Frame N2 ......................................................................................... 19
KB1000440 Curtain, Frame N2_2 ..................................................................................... 20
KB1000520 Frame 3 Curtain ............................................................................................ 21
Tunnel & Pyramid Hatches ............................................................................................... 22
KA1000902 Tunnel Hatch 180x152 Mounting .................................................................. 23
KA1000903 Tunnel Hatch 315x148 Mounting .................................................................. 24
Pyramid Hatches Mounting ............................................................................................... 26
Cowlings .............................................................................................................................. 27
KA1010100 Upper Cowling ............................................................................................... 28
KA1010000 - Cowlings ..................................................................................................... 29
KA1010210-01 - Lower Cowlings For Landing Light ........................................................ 30
Upper Cowling Hatch ........................................................................................................ 31
Windows .............................................................................................................................. 32
KB1020000 - Windows, German Version ......................................................................... 32
KS1020000 - Windows, English Version ........................................................................... 33
Doors .................................................................................................................................... 34
KA1030100 - Door With Small Window ............................................................................ 35
KA1030140 Handle ........................................................................................................... 36
KA1040100 Baggage Hatches .......................................................................................... 37
KA1040303 Handle ........................................................................................................... 38
KA1040300 Lock ............................................................................................................... 39
Seats ..................................................................................................................................... 40
WA1060200 - Seat, Sport With Headrest ......................................................................... 42
KA1060001 Rail ................................................................................................................ 44
KA1060004 Belt Eyes ....................................................................................................... 45
Roller Installation .............................................................................................................. 46
Seat Pivots Installation ...................................................................................................... 47
KA1060101 Belt Eye ......................................................................................................... 48
KA1070000 - Safety Belts ................................................................................................. 49
Safety Belts Mounting, Lower .......................................................................................... 50
Safety Belts Mounting, Upper ........................................................................................... 51
KA1090000 - Underfin ...................................................................................................... 52
KA6070000 - Tow Device .................................................................................................. 53
WS1080000, KB1080000 - Instrument Panel ..................................................................... 55
KS1080000, English Version ............................................................................................ 55
KB1080000, German Version ........................................................................................... 57
WA1081000 - Instrument Board ........................................................................................ 59
Panel CTSW Classic ......................................................................................................... 60
Panel CTSW Advanced .................................................................................................... 60
Contents
4
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA1081010 Map Shelf, Big (Left) ..................................................................................... 62
KA1081020 Map Shelf, Small(Right) ................................................................................ 62
KS1081100 Panel Left Section, KS (English Versiion) ..................................................... 63
KB1081100 Panel Left Section, KB (German Version) ..................................................... 64
KS1081300 Panel Lower Section (English Version) ......................................................... 65
KB1081300 Panel Lower Section (German Version) ........................................................ 66
WS1081305 Panel Right Section (English Version) ......................................................... 67
KB1081200 Panel Right Section (German Version) ......................................................... 68
Pocket for maps .................................................................................................................. 69
KA1000470 - Map Pocket Mounting ................................................................................. 69
KA1030160 - Pocket, Door ............................................................................................... 70
Chapter 2: Wing .................................................................................................................. 71
Mounting of Wing Consoles .............................................................................................. 71
KA2010000 Wing Console, Right ..................................................................................... 72
KA2010001 Cap ................................................................................................................ 73
KA2010010R Wing Pivot No1, Right ................................................................................ 74
KA2010020R Wing Pivot No2, Right ................................................................................ 75
KA2010030R Wing Pivot No3, Right ................................................................................ 76
KA2010040R Wing Pivot No4, Right ................................................................................ 77
WA2010000 - Wing Console, Right .................................................................................. 78
WA2010010 - Pivot, Wing No1, Right ............................................................................... 79
WA2010020 - Pivot, Wing No2, Right ............................................................................... 80
WA2010030 - Pivot, Wing No3, Right ............................................................................... 81
WA2010040 - Pivot, Wing No4, Right ............................................................................... 82
Aileron .................................................................................................................................. 83
KA2030020 Pivot No2 ....................................................................................................... 84
KA2030010 Pivot No1 ....................................................................................................... 84
Flap ....................................................................................................................................... 85
KA2040010 Flap Pivot No1 ............................................................................................... 86
KA2040020 Flap Pivot No2 ............................................................................................... 87
KA2040030 Flap Pivot No3 ............................................................................................... 87
Chapter 3: Stabilizer & Rudder ...................................................................................... 88
Stabilizer .............................................................................................................................. 88
KA3010200 Stabilizer ....................................................................................................... 89
WA3010200 Stabilizer CTSW 2006 .................................................................................. 90
KA3010010 Bearing .......................................................................................................... 91
KA3011000 Stabilizer with Trim Tab .................................................................................. 92
WA3011010 Trim Tab, Assembly ...................................................................................... 93
Rod, Trim Tab Control, Mounting ...................................................................................... 94
Rudder .................................................................................................................................. 95
KA3020020, KA3020030 - Rudder Lower Support & Pivot .............................................. 96
KA3020010 Pivot Upper ................................................................................................... 97
Chapter 4: Landing Gear .................................................................................................. 98
Nose Landing Gear ............................................................................................................. 98
KA4010008 Leather Cap .................................................................................................. 100
Nose Strut Steering Rod & Fork Stopper .......................................................................... 101
KA4010010 Nose Wheel Fairing ....................................................................................... 102
KA4010200_1 Nose Wheel ............................................................................................... 103
Nose Wheel Installation_1 ................................................................................................ 104
5
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4010100 Nose Wheel Rotation Unit ............................................................................. 105
KA4010100 Nose Wheel Rotation Unit_1 ......................................................................... 106
Spring Unit ........................................................................................................................ 107
Spring Unit_1 .................................................................................................................... 108
KA4010200-04 - Nose Wheel Mounting, Tundra .............................................................. 109
KA4010100-04 - Strut, Nose Gear .................................................................................... 111
Main Landing Gear .............................................................................................................. 112
KA4020200 Upper Mounting Unit ..................................................................................... 114
KA4020300 Bracket for Main Gear Fairing ....................................................................... 114
KA4020200_1 Upper Mounting Unit ................................................................................. 115
KA4020001 Main Spring Bar ............................................................................................ 116
KA4020100 Main Wheel Attachment ................................................................................ 117
KA4020400 Main Strut Fairing .......................................................................................... 118
KA4020010 Main Wheel Fairing, Detailed View ............................................................... 119
Main Wheel, Detailed View ............................................................................................... 120
KA4020500 - Main Wheel Assembly ................................................................................. 121
KA4020500_1 - Main Wheel Assembly ............................................................................. 122
KA4020500-01 - Wheel, Main, Light ................................................................................. 123
KA4020500-02 - Wheel, Main, Tundra .............................................................................. 124
Chapter 5: Power Plant ..................................................................................................... 125
Engine .................................................................................................................................. 125
KA5010200 Engine Frame, Small ..................................................................................... 127
KB5010100 Engine Mount ................................................................................................ 128
Big & Small Engine Mount ................................................................................................ 129
KA5010103 Bracket .......................................................................................................... 131
Muffler .................................................................................................................................. 132
Muffler Mounting, Right Side............................................................................................. 133
Muffler Mounting, Left Side ............................................................................................... 133
Carburetor ....................................................................................................................... 134
KS5030000 Carburetor, English Version .......................................................................... 134
KB5030000 Carburetor, German Version ......................................................................... 135
Air Filter Mounting, English Version .................................................................................. 136
Air Filter Mounting, German Version ................................................................................. 135
Handle ............................................................................................................................... 138
C9997701P Compression Spring ..................................................................................... 138
KA5030001 Protection Plate, Left ..................................................................................... 139
KA5030002 Protection Plate, Right .................................................................................. 140
C9993188A Tubes ............................................................................................................ 141
Water Cooling ...................................................................................................................... 142
KA5040100 Cooling Case ................................................................................................. 144
C9997791G Expansion Tank ............................................................................................ 145
C9997791H Overflow Bottle ............................................................................................. 146
Radiators ........................................................................................................................... 147
Join Brackets .................................................................................................................... 147
Brackets Installation .......................................................................................................... 149
KA5050100_1 Radiators ................................................................................................... 150
KA5050100_2 Radiators .................................................................................................. 151
KA5050100 — 01 Radiators ............................................................................................ 152
Brackets Installation .......................................................................................................... 153
C9993186A Tube, Left ...................................................................................................... 155
6
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
C9993186A Tube, Right .................................................................................................... 156
C9997794G Thermostat .................................................................................................. 157
Oil cooling ............................................................................................................................ 158
C9997794I Oilthermostat ................................................................................................. 159
C9997791I Oil Tank .......................................................................................................... 160
Oil Hose Connection (1) .................................................................................................... 161
Oil Hose Connection (2) .................................................................................................... 162
Propeller ............................................................................................................................... 163
KA5090100 Spiner Installation .......................................................................................... 164
Propeller Installation ......................................................................................................... 165
Warp Drive Three Blade Propeller .................................................................................... 166
KA5090100-01 Spiner Installation .................................................................................... 167
Propeller Warp Drive Installation ....................................................................................... 168
Neuform Three Blade Propeller ........................................................................................ 169
Spiner Neuform Installation ............................................................................................... 170
Propeller Neuform Installation ........................................................................................... 171
Kaspar Three Bladed Propeller ......................................................................................... 172
Spiner Kaspar Installation ................................................................................................. 173
Propeller Kaspar Installation ............................................................................................. 174
Handle Mounting, Kaspar Propeller Control ..................................................................... 176
KA5090500-03 - Handle Mounting, Neuform Propeller Control ........................................ 177
Chapter 6: Flight Control ......................................................................................... 178
Engine Control .................................................................................................................... 178
Covering Plate Installation ................................................................................................ 179
KA6010001 - Covering Plate ............................................................................................ 180
KA6010001_1 - Covering Plate ........................................................................................ 181
KA6010110 - Choke .......................................................................................................... 182
KA6010100 - Throttle Box (1) ........................................................................................... 183
KA6010100 - Throttle Box (2) ........................................................................................... 184
KA6010001-01 - Covering Plate ....................................................................................... 185
KA6010000-01 - Throttle Box Mounting ............................................................................ 186
KA6010100-01 - Throttle Box .......................................................................................... 187
KA6010130 - Throttle ........................................................................................................ 189
KA6010120 - Trimm .......................................................................................................... 190
KA6010140 - Brake ........................................................................................................... 191
KA6010140_01 - Brake ..................................................................................................... 192
Tross ................................................................................................................................. 193
Aileron Cotrol ...................................................................................................................... 194
KA6020500 - Rod & KA6040103 - Stopper ...................................................................... 196
KA6020210 - H-bracket .................................................................................................... 197
KA6020130 - Rear Fork Rod Support ............................................................................... 198
KA6020200 - Fork Rod ..................................................................................................... 199
KA6020000 - Aileron Cotrol .............................................................................................. 200
KA6020060 - Cable & KA6020400 - Vertical Rod ............................................................. 201
KA6020300 - Rod-Rocker ................................................................................................. 202
KA6020320 - Side Bracket & KA6020300 - Rod-Rocker ................................................ 203
KA6020050R - Aileron Control Rod Rib Box ..................................................................... 204
KA6020010 - Push-pull Rod & KA6020030 - Rod .......................................................... 205
WA6020010 - Rod, Aileron, Long & KA6020030 - Rod ................................................... 206
KA6020000 - Mounting of Rod, Aileron ............................................................................. 207
7
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA6020040 - Rocker ......................................................................................................... 208
KA6020010 - Push-Pull Rod ............................................................................................. 210
WA6020010 - Rod, Aileron, Long ...................................................................................... 211
KA6020030 - Rod ............................................................................................................. 212
KA6020040 - Outer Rocker ............................................................................................... 213
KA6020050 - Rod ............................................................................................................. 214
KA6020060 - Cable ........................................................................................................... 215
KA6020130 - Rear Fork Support ...................................................................................... 216
KA6020210 - H-bracket .................................................................................................... 217
KA6020300 - Rod Rocker ................................................................................................. 218
KA6020400 - Rod ............................................................................................................. 219
KA6020500 - Rod ............................................................................................................. 220
KA6062000 – Aileron Trim Mechanism Mounting ............................................................. 221
KA6062100 - Control Unit, Assembly ................................................................................ 224
KA6020710 - Screen, Aileron Rods, Install ....................................................................... 225
Plexiglass Steering Cover ................................................................................................. 226
Flap Control ......................................................................................................................... 228
KA6030000 - Commutation Unit Installation (1) ................................................................ 229
KA6030000_1 - Commutation Unit Installation (1) ............................................................ 230
KA6030000 - Commutation Unit Installation (2) ................................................................ 231
KA6030310 - Steel Cable Installation ............................................................................... 232
T- bracket Installation ........................................................................................................ 233
KA6030200 - Transverse Rod ........................................................................................... 234
KA6030200_1 - Transverse Rod ....................................................................................... 235
KA6030300 - T-bracket ..................................................................................................... 236
KB6030320 - Support & KA6030303 - Small Angles ........................................................ 238
Beam & Angle .................................................................................................................. 238
KB6030300_4 - T-bracket ................................................................................................. 239
KB6030307 - Beam Lower, T-bracket ............................................................................... 240
KS6030400 - Commutation Unit, English Version ............................................................ 241
KS6030400 - Commutation Unit Assembly, English Version ............................................ 242
KB6030400 - Commutation Unit, German Version ........................................................... 244
KB6030400 - Commutation Unit Assembly, German Version ........................................... 245
KB6030400_1 - Commutation Unit ................................................................................... 247
KB6030400_1 - Commutation Unit Assembly ................................................................... 248
Stabilizer Control ................................................................................................................ 250
KA6040000 - Stabilizer Control (Forward Part) ................................................................ 252
KA6040000 - Stabilizer Control (Forward Part) ................................................................ 253
KA6040000 - Stabilizer Control (Forward Part) ................................................................ 254
KA6040000 - Stabilizer Control (Forward Part) ................................................................ 255
KA6040000 Stabilizer Control (Rear Part) ........................................................................ 257
KA6040050 - Forward Connection .................................................................................... 258
KA6040060 - Rear Connection ......................................................................................... 259
KA6040100 - Control Stick ................................................................................................ 260
Control Stick Covering ...................................................................................................... 261
Rudder Control .................................................................................................................... 262
KA6050000 - Rudder Control ............................................................................................ 264
KA6050000-01 - Rudder Control ...................................................................................... 265
KA6061000 - Rudder Trim Mechanism Mounting ............................................................. 267
KL6061100 - Control Unit .................................................................................................. 268
8
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KL6061030 - Rocker in Assembly ..................................................................................... 269
Trim Tab Control .................................................................................................................. 270
KA6060000-01 Trim Tab Control ....................................................................................... 272
C9997816B Cable Stop .................................................................................................... 274
Chapter 7: Systems ........................................................................................................... 275
Rescue System .................................................................................................................... 275
Rescue Systems Connection ............................................................................................ 277
Parachute Bag .................................................................................................................. 279
KA7010000 - Installation Rescue System BRS1050 ........................................................ 280
KA7010000 - Installation of the Parachute Bag ................................................................ 281
KA7010000 - Installation of a Rocket ................................................................................ 282
KA7010000-02 - Installation Rescue System BRS1350HS .............................................. 283
Installation Rescue System BRS1350HS ......................................................................... 284
Handle Bracket ................................................................................................................. 285
BRS Rescue System Handle Installation .......................................................................... 288
Harness ............................................................................................................................. 289
Squib ................................................................................................................................. 290
Frame ................................................................................................................................ 291
Installation of Support of Rescue System ......................................................................... 292
Fuel System ......................................................................................................................... 293
Fuel System, English Version ........................................................................................... 293
Fuel System, German Version .......................................................................................... 295
Side Wing Cap .................................................................................................................. 297
KA7020052 - Tank Filler .................................................................................................... 298
Fuel Flowmeter & Valve Installation, English Version ....................................................... 299
Fuel Valve Installation, German Version ........................................................................... 300
KB7020020 - Fuel Valve Installation ................................................................................. 301
KB7020020 - Fuel Valve, German Version ....................................................................... 303
KS7020100 - Fuel Valve Drive Rod, English Version ....................................................... 304
KB7020090 - T-connection ............................................................................................... 305
KA7020008 - Gascolator Adapter ..................................................................................... 306
Fuel Line Connection ........................................................................................................ 307
C9997793 - Fuel Filter ...................................................................................................... 308
Fuel Valve Hard Assembly ................................................................................................ 309
Fuel Line & Grommet ........................................................................................................ 310
Back Up Fuel Line ............................................................................................................. 311
Brake System ...................................................................................................................... 312
KA7030100 - Master Brake Cylinder ................................................................................ 314
KA6010010 - Access Panel .............................................................................................. 315
Master Brake Cylinder & Pin Installation ........................................................................... 316
Outlet Branch & Branch Installation in Stream Distributor ................................................ 318
Master Brake Cylinder & Pin Installation-2 ....................................................................... 319
Check Valve, Installation ................................................................................................... 320
C9997793 - Fuel Filter Installation .................................................................................... 321
Branch Installation ............................................................................................................ 322
Heating & Ventilation System ............................................................................................ 323
KS7040000 - Heating & Ventilation System, English Version ........................................... 323
KB7040000 - Heating & Ventilation System, German Version .......................................... 324
KS704010 - Rod Indexing Mechanism, English Version ................................................... 325
KS704010 - Rod Indexing Mechanism, German Version ................................................. 325
9
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA7040100 - Air Heater .................................................................................................... 326
KU7040100 - Air Heater, USA, Canada, Scandinav Version ............................................ 327
C9993111B - Rubber ......................................................................................................... 328
C9993188 - AERODUCT Tube CEET-7 ............................................................................ 329
KA7040003 - Brackets ...................................................................................................... 330
KA7040200 - Thermic Choke Connection ........................................................................ 331
C9997065B - Control Rod ................................................................................................. 332
KA7040300 - Air Mixer ..................................................................................................... 333
KA7040400 - Air Branch Canal ......................................................................................... 334
KB7040400 - Air Terminal Unit .......................................................................................... 335
C9993188 - Hose NW 50mm ............................................................................................ 336
Electric System ................................................................................................................... 337
KS7050000 - Electric System, English Version ................................................................ 338
KB7050000 - Electric System, German Version ............................................................... 338
KA7050200 - Battery Installation ...................................................................................... 343
KB7050200 - Battery Installation ...................................................................................... 344
C9997187B - Capacitor Installation .................................................................................. 345
C9997788A - Control Panel .............................................................................................. 346
Discrete Flap Control, Assembling .................................................................................... 347
Mounting Dynon and Sensors ........................................................................................... 348
KA1081950 - Fans, Dynon, Mounting ............................................................................... 349
Damping, Fuel Pressure Sensor, Mounting ...................................................................... 350
Sensor of Compass and OAT Sensor for Dynon, Installation ........................................... 352
Installation Pitot Tube ....................................................................................................... 354
Generator .......................................................................................................................... 355
C9997791A - Ducati .......................................................................................................... 356
Ground 1 ........................................................................................................................... 357
Ground 2 ........................................................................................................................... 358
C9997494 - Starter Relay ................................................................................................. 359
Strobobox .......................................................................................................................... 360
Loft Wing Position Light Connection ................................................................................. 361
Strobe Light Mountingt ...................................................................................................... 362
KA7053100 - Light, Landing, Mounting ............................................................................. 363
KA7053170 - Lighting of Fuel Indicator ............................................................................. 364
Cockpit Light ..................................................................................................................... 365
Block, Lighting, Instruments .............................................................................................. 366
Air Pressure System ........................................................................................................... 367
KS7070000 - Air Pressure System, English Version ......................................................... 367
KB7070000 - Air Pressure System, German Version ....................................................... 368
KA7070010 - Plate Installation .......................................................................................... 369
C9997417I - Adapter ......................................................................................................... 370
KA7070020 - Flange Installation ....................................................................................... 371
ALPHA MFD Mounting ...................................................................................................... 372
Air Speed Indicator Mounting ............................................................................................ 373
Compass .............................................................................................................................. 374
Added Accessories ............................................................................................................. 375
Chapter 8: Price List .......................................................................................................... 368
Credits .................................................................................................................................... 413
10
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Introduction
Dear Customer,
This is a catalogue of spare parts for the CT2K/CTSW ultra light airplane. We would really
appreciate your co-operation if you find any kind of discrepancies or mistakes.
Our intention is the catalogue to contain comprehensive information on parts and units that the
aircraft consists of and you would probably like to replace.
We plan over the time the catalogue to be available in two forms – CD and Internet.
The catalogue is simple to use. The standard approach of tree structures has been utilized.
On the top of the tree structure you can see the general view of the whole aircraft with arrows
pointing to a certain system or unit and naming them. Clicking on a name you come to the more
detailed next level picture (or pictures) outlining the system or unit and their options if applicable.
The same principle is used on each level of the catalogue from the bottom to the top. On the very
bottom of the catalogue you can find single details. On each level of catalogue the information
about exact identification number (article) and prices is available, regardless whether this is a single
part or a unit or system. To get back to the previous level of the catalogue just click on the button
“
GO TO PREVIOUS VIEW
” located on the
VIEW HISTORY
bar of
Acrobat® Reader®.
Blue links are for Detailed View,
Red links are for view part price.
You could also get to a certain page clicking on an item in the Table of Content.
We hope, our catalogue will give you complete information about parts & assembly units.
All your questions and suggestions please forward to: [email protected].
Chapter 1: Fuselage 12
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
CHAPTER 1: FUSELAGE
Designs
We proposes three additional colour designs for you — Snow Design,
Swing Design & Up Design. Each design has four colour schemes. You can
choose one for your choice. This is an optional, you can choose it or not.
Swing Design
Standard Design
Snow Design
Up Design
Chapter 1: Fuselage 13
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA 0000110-01 SNOW DESIGN 1
KA 0000110-02 SNOW DESIGN 2
KA 0000110-03 SNOW DESIGN 3
KA 0000110-04 SNOW DESIGN 4
The colors reflected on the brochure are only approximations of the original colors.
Chapter 1: Fuselage 14
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA 0000120-01 SWING DESIGN 1
KA 0000120-02 SWING DESIGN 2
The colors reflected on the brochure are only approximations of the original colors.
Chapter 1: Fuselage 15
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA 0000120-03 SWING DESIGN 3
KA 0000120-04 SWING DESIGN 4
The colors reflected on the brochure are only approximations of the original colors.
Chapter 1: Fuselage 16
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA 0000130-01 UP 1
KA 0000130-02 UP 2
KA 0000130-03 UP 3
KA 0000130-04 UP 4
The colors reflected on the brochure are only approximations of the original colors.
Chapter 1: Fuselage 17
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
FUSELAGE
KA1000000
KA1000000-10
Chapter 1: Fuselage 18
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number Description Q-ty per
ASSY Unit
KB1000420 Frame 2 curtain 2 pcs
KB1000520 Frame 3 curtain 1 pcs
C9996040 Bolt DIN 912 M5x35-8.8 2 pcs
C9996283C Bolt DIN 933 M5x20-8.8 4 pcs
C9996333 Self-locking nut DIN 985-M5, regular 2 pcs
C9996563 Washer DIN 9021-5.3mm VZ 12 pcs
C9996836 Blind nut M5-9x15 4 pcs
CURTAIN MOUNTING
KB1000520
KB1000420
Chapter 1: Fuselage 19
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KB1000440 CURTAIN, FRAME N2
Part
Number Description Q-ty per
ASSY Unit
KB1000420 Frame 2 curtain 1 pcs
C9996040 Bolt DIN 912 M5x35-8.8 1 pcs
C9996283C Bolt DIN 933 M5x20-8.8 2 pcs
C9996333 Self-locking nut DIN 985-M5, regular 1 pcs
C9996563 Washer DIN 9021-5.3mm VZ 6 pcs
C9996836 Blind nut M5-9x15 2 pcs
KB1000420
C9996040
C9996333
C9996563
C9996283C
C9996836
Chapter 1: Fuselage 20
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
C9996283C
Part
Number Description Q-ty per
ASSY Unit
KB1000420 Frame 2 curtain 1 pcs
KB1000431 Blind nut M5 4 pcs
KB1000441 Blind nut M5 4 pcs
KB1000442 Bolt 4 pcs
C9996563 Washer DIN 9021-5.3mm VZ 12 pcs
C9996283C Bolt DIN 933 M5x20-8.8 4 pcs
C9996565 Washer DIN 9021-6.4mm VZ 4 pcs
C9996563
KB1000431
KB1000442
KB1000420
C9996563
C9996565
KB1000441
KB1000440 C
URTAIN
, F
RAME
N2_2 F
IRST
S/N 04-07-02
This manual suits for next models
1
Table of contents
