Recon®M18
APPLICATIONS
BORDER PATROL
LAW ENFORCEMENT
SEARCH AND RESCUE
SITUATIONAL AWARENESS
SURVEILLANCE
RECONNAISSANCE
FEATURES
640 x 480 FPA
Digital zoom
Lightweight
Simple operation
Covert laser pointer
Multi-use capability
Reliable battery life
Full MIL hardened
It’s all FLIR inside
BENEFITS
High resolution imagery
Capable of E-Zoom up to 4x
Carry in your pocket comfortably
Speeds proficiency for first time users, buttons for
ambidexterous use
Long-distance laser pointer for missions or short distance
for training
Use as a handheld or tripod mount
Over three hours run time
Ruggedized to military standards
FLIR controls the entire supply chain on the critical technology
inside Recon systems ensuring fast service and long term support
Handheld Systems
HIGH PERFORMANCE TACTICAL POCKET SCOPE
INVISIBLE LASER RADIATION
AVOID DIRECT EXPOSURE
TO BEAM
30mW AT 830 nm
CLASS IIIb (ANSI CLASS 3b) LASER PRODUCT
DANGER
IMAGING PERFORMANCE
FPA resolution 640 x 480, 320 x 240 (option)
E-Zoom 2x, 4x digital
Field of view 18.7° x 14° (standard), 13.8° x 10.4° (optional)
Versatility Extender lens option
LASER POINTER
Standard 850 nm at 30 mW and 0.5 mW, Class 3b
Optional Visible, eye safe
DISPLAY & CONTROLS
Image display 640 x 480 color OLED
Image adjustments AGC/ALC, manual, polarity, color, STACETM digital image enhancement
User controls On/off laser, AGC/ALC, manual calibration, NUC, reticle select,
polarity, color palettes, display brightness, image enhancement
modes, digital zoom
Calibration On demand
Reticle Auto-scale with zoom
Video out NTSC, PAL
POWER
Power source Two 3V CR123 batteries
Battery life >3 hours with 640 array)
>3.5 hours with 320 array
INPUTS & OUTPUTS
Inputs USB, sealed jack with dust cover
Outputs USB, status and still imagery
Video (RS-170 or PAL)
DIMENSIONS, WEIGHT & MOUNTING
Weight 14 oz (~400 grams) with batteries
Mounting 1/4-20 tripod mount
Dimensions 5 L x 3.25 W x 2.25 H
ENVIRONMENTAL
Operating temp -32° to +55° C
Environmental MIL-SPEC 810F
Water immersion 66’ for 1 hour
ACCESSORIES
Included Lanyard, carry bag with belt clip, video output cable, laminated
quick reference card, spare batteries
Optional Extender lens, clip on digital video recorder
Recon®M18
1341 San Mateo Avenue,
South San Francisco,
CA 94080, USA
800-910-2862,
650-989-5100,
FAX 650-875-0129
European Office:
44-(0)870-0111286,
FAX 44 (0)845 3349142
The Following Countries can
use our Toll Free Number:
00800 9102-8620
Austria, France, Germany,
Holland, Italy, Spain,
Sweden, Switzerland
www.atncorp.com
AMERICAN
TECHNOLOGIES
NETWORK
CORP.
