QSI COVER PLATE TRANSMITTER
For FLOMEC® G2 Meters
01/2022 920905-03 Rev. B
Product Owner’s Manua EN
NN

2
Please save these instructions for future reference. Read carefully before
attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to
comply with instructions could result in personal injury and/or property
damage.
Please refer to back cover for information regarding this product’s warranty
and other important information.
DO NOT RETURN THIS PRODUCT TO THE STORE!
Please contact Great Plains Industries, Inc.® before returning any product.
If you are missing parts, or experience problems with your installation,
contact our Customer Support Department. We will be happy to assist you.
Ca : 888-996-3837 or 316-686-7361
Emai : meters@gp ains.com
SAVE FOR YOUR RECORDS
Model #: ______________________
Serial #: ______________________
Purch. Date: ___________________

3
TABLE OF CONTENTS
Getting Started ----------------------------------------------- 4
Introduction ---------------------------------------------------- 4
General Information ------------------------------------ 4
Important Notice ---------------------------------------- 4
Safety ------------------------------------------------------ 4
Installation ----------------------------------------------------- 5
Wiring ------------------------------------------------------ 5
Strain Reliefs -------------------------------------------- 5
NPT Adapters ------------------------------------------- 5
Terminal Connections Chart ------------------------- 6
QSI1 Wiring ---------------------------------------------- 7
QSI2 Wiring ---------------------------------------------- 8
QSI3 Wiring ---------------------------------------------- 9
FLOMEC App for Android -------------------------------- 11
Temperature Probes -------------------------------------- 11
Installation & Wiring ---------------------------------- 11
Maintenance ------------------------------------------------- 12
Replacing Battery ------------------------------------- 12
Specifications ----------------------------------------------- 14
Approval Ratings ------------------------------------------- 15
Service -------------------------------------------------------- 15
Returning Parts ---------------------------------------- 15
Warranty ------------------------------------------------------ 16

4
UNPACKING/INSPECTION
Inspect
• After unpacking the unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing or damaged
parts. Shipping damage claims must be filed withcarrier.
• See General Safety Instructions, and all Cautions, Warnings, and
Dangers as shown.
INTRODUCTION
The QSI communications module is a multiple capability electronics package. For
the G2 meter, the module is available with the plain cover plate only. The QSI
module has three versions (QSI1, QSI2 or QSI3) available; each with its own mix
of capabilities to better serve the customer (See Versions below).
• QSI1 is equipped with Bluetooth®, coil/digital pulse input, pulse output (flow or
energy & scalable), RS485 (Modbus® RTU), temperature inputs, BTU
calculator.
• QSI2 is equipped with Bluetooth, coil/digital pulse input, pulse output (flow or
energy & scalable), temperature inputs, BTU calculator.
• QSI3 is equipped with Bluetooth, coil/digital pulse input, pulse output (flow
scalable), 4-20mA output.
This manual contains information and meter wiring diagrams for the three different
QSI electronics modules.
IMPORTANT NOTICE
QSI module electronics are very sensitive to electric noise if operated within 6
inches of some electric motors, relays, transformers or other sources of electronic
noise.
If the QSI electronics are used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
GENERAL INFORMATION
QSI electronics are mounted into the cover plate of the meter you ordered. The
QSI electronics converts the voltage (or pulses) from the meter into usable
information.
The QSI module electronics is powered by customer supplied external power.
SAFETY
•This product is not approved for use in hazardous locations.
•Be sure O-rings and seals are kept in good repair.
•When applying power, adhere to specifications in this manual.
•Disconnect external power before attaching or detaching input or output wires.

5
INSTALLATION
CAUTION: Installation near high electromagnetic fields and high current fields is
not recommended and may result in inaccurate readings.
NOTE: There is no external visual difference between QSI1, QSI2, or QSI3
communications suites when they are installed.
NOTE: If you ordered a QSI communications suite with your meter, it was installed
at the factory. Please review and thoroughly understand all manuals and
installation instructions before proceeding.
WIRING
All electronic options are associated with a flat style of meter cover plate. This
cover plate has four threaded ports, compatible with PG7 threads, for gaining
wiring access to the electronics inside the cover plate.
The meter is shipped with the ports environmentally sealed with a threaded plug
and seal. Remove one or more of these plugs as required to install the supplied
port fittings below.
Each meter is supplied with cable gland strain reliefs with O-rings and 1/2 NPT
adapters with seals for use in the threaded ports of the meter cover plate.
Select the port fittings that fit your process and replace the threaded plugs in the
cover plate with the fittings as required.
NOTE: The threaded plugs installed at the factory may be left in any unused cover
plate port indefinitely.
It is recommended that a “removable” thread-locker (fluid, stick, tape, spray, etc.)
be used when installing the strain reliefs or adapters into the cover plate ports.
STRAIN RELIEFS
The cable gland strain reliefs will accommodate a cable diameter of 0.11 - 0.26
inches (2.79 - 6.6mm) and provide an environmental seal around the cable when
the dome-nut is tightened.
NPT ADAPTERS
The 1/2 NPT adapter fittings are used for attaching flex conduit to the meter, for
those applications that require cable runs to be enclosed in conduit.
NOTE: Cable to be provided by customer to accommodate job requirements.
Cable is not included with meter.

6
INSTALLATION – (continued)
TERMINAL CONNECTIONS CHART
Figure 1
TEMP SENSOR
PT100-Red Sensor VCC Output
PT100-White Input High Side
PT100-Blue Input Return
RS-485 (Galvanically Isolated)
RS485 (+) Positive Signal
RS485 (-) Negative Signal
RS485 GND Circuit Ground*
PULSE INPUT
+5V 5VDC output to power
external sensor
(+) Digital Pulse Frequency
Input, up to 3kHz
(-) Digital Pulse Return
4-20mA (Galvanically Isolated)
(+) 4 to 20mA current loop-
current in to transmitter
(-) 4 to 20mA current loop-
current out of transmitter*
*NOTE: It is not recommended to connect
isolated ground connections together or to
board common.
Coil A Low level sine wave input
Coil B Low level sine wave input
GPI SENSOR
Ribbon cable connection to GPI custom
sensor designs
PULSE OUTPUT
(Galvanically Isolated)
(-) Pulse Output return
current*
(+)
Pulse Output frequency
output. This is a “current
sinking open collector”
output ***
POWER INPUT
-) 12-36VDC Input A**
(+) 12-36VDC Input B**
**NOTE: Polarity of voltage for DC is not
important. However, an earth ground
isolated power supply is required to
prevent earth ground loop currents and
ground fault conditions.
***NOTE: This output may require an
external pull up resistor if interfacing
equipment does not include one.

7
QSI1 WIRING
QSI VERSION 1 – PC BOARD
RS-485
BTU
Figure 2
QSI VERSION 1 - WIRING DIAGRAM
Inputs: Temperature Sensors, Variable Reluctance, Pickup Coil
Outputs: RS-485, Pulse Output
Figure 3

8
QSI2 WIRING
QSI VERSION 2 – PC BOARD
Pulse In
BTU
Figure 4
QSI VERSION 2 - WIRING DIAGRAM
Inputs: Temperature Sensors, Variable Reluctance, Pickup Coil
Output: Pulse Output
Figure 5

9
QSI3 WIRING
QSI VERSION 3 – PC BOARD
4-20mA
Figure 6
QSI VERSION 3 - WIRING DIAGRAM
Customer Equipment with Built-in Power Supply
Inputs: Standard Remote Sensor (Variable Reluctance Pickup Coil)
Outputs: Customer Equipment, 4-20mA Sensing, Built-in Loop Power Supply
Minimum signal amplitude required for
normal operation is approximately 15mV P-
P. Recommended cable type - twisted pair
with shield. Recommended maximum cable
length - 20ft.
CAUTION: When reassembling the cover plate, make sure the enclosure seal is not crimped or twisted.
Do not over-tighten screws (hand-tighten only).
Figure 7

10
QSI3 WIRING - (continued)
QSI VERSION 3 - WIRING DIAGRAM
Customer Equipment without Built-in Power Supply
Inputs: Standard Remote Sensor (Variable Reluctance Pickup Coil)
Outputs: 4-20mA with Separate Power Supply
Note: Either of the wiring diagrams below (Low Side Negative Wiring-Figure 8A) or
(High Side Positive Wiring-Figure 8B) are valid, as long as the current direction arrows
and the (+) and (-) connections on all of the equipment in the loop are correct.
Figure 8A
Low Side (Negative) Wiring
Figure 8B
High Side (Positive) Wiring

11
FLOMEC APP FOR ANDROID
To learn how to get started using the FLOMEC App, visit:
flomecmeters.com/downloads/flomec-app-quickstart.pdf
FLOMEC APP QUICKSTART
TEMPERATURE PROBES
If you ordered a QSI1 or QSI2 electronic module and intend to use the BTU
calculator function in your process, you will need to provide temperature probes
and cables suitable for your process. The cables are not connected to the QSI PC
board.
If the cables used with your probes has a smaller diameter than the standard strain
reliefs (black) provided with your meter, reduced fit strain reliefs (gray) are
available as a kit from the factory.
NOTE: PN 145500-13, Kit, strain relief, temperature sensor. Includes: (2) PG7
thread strain reliefs (reduced fit), .08 - .20 cable diameter range.
INSTALLATION & WIRING
NOTE: The meter should be installed in the system return line for accurate BTU
calculations.
Typically, a temperature probe is installed in the process piping, initially near each
end of the meter to calculate the differential between the two probes (inlet vs
outlet), if any. The differential is captured and shown in the Android application as
“Temp 1” and “Temp 2” and is used in the BTU calculations to ensure an accurate
calculation.
For clarity, one probe is considered PT100 #1 and is connected to the meter PC
board in that location. It is shown as “Temp 1” in the Android application.
The other probe is then considered PT100 #2 and is connected to the meter PC
board in that location. It is shown as “Temp 2” in the Android application.
To perform the differential check, the probe installed near the meter outlet end
should be considered PT100 #1.
The probe installed near the meter inlet end should be considered PT100 #2.
After wiring the probes to the correct terminal of the PC board, perform the
differential check.

12
TEMPERATURE PROBES
INSTALLATION & WIRING - (continued)
After performing the differential check, remove the PT100 #2 probe near the inlet
end of the meter and install the removed probe in the system supply line.
During normal system operation, probe PT100 #1 is installed near the meter outlet
end and probe PT100 #2 is installed in the system supply line. Accurate system
BTU usage is calculated between the (2) probes.
Typically, the probe cables are the same length. Excess cable from the PT100 #1
probe (near the meter outlet) to the cover plate may be coiled and secured using
plastic quick ties.
MAINTENANCE
Check cable-entry seals periodically. Tighten and/or apply sealant if needed. This
is especially important in environments containing heavy concentrations of dust,
oil mist, or other residue.
Check all wiring connections occasionally for oxidation or corrosion. Clean and re-
seat if such conditions are noted.
If necessary, check and re-seat any connections that may have been subjected to
strain (during rework or construction, for example).
REPLACING BATTERY
NOTE: The QSI2 and QSI3 communications module has a 3V lithium coin cell
battery installed on the PC board. In case of power failure, the battery functions
as power backup to maintain the internal system time. Any QSI2 or QSI3 feature
that uses a time reference as part of its functionality will be immediately accurate
to the current time when power is restored.
•DISCONNECT POWER TO METER
•Remove (6) screws retaining the cover plate to the base and lift the cover plate
free of the meter body (see Figure 9).
•Flip the cover plate over and remove (4) screws retaining the PC board
assembly (see Figure 10).
•Remove and replace the coin cell battery (CR2032) on the backside of PC
board (see Figure 11).
•Reverse the procedure to reassemble the cover plate to the base. Make sure
the cover plate seal is seated before tightening the (6) cover plate screws.

13
MAINTENANCE – (continued)
REPLACING BATTERY – (continued)
Figure 9 Figure 10
Figure 11

14
SPECIFICATIONS
MECHANICAL
Cover Plate
Port Threads
Female 1/2-20 UNF-
2B (Compatible with
PG7 thread)
Port Strain
Relief Hubble PG7
Grip Range 0.11”-0.26”
(2.79 - 6.6mm)
Port Conduit
Adapter
GPI PG7 x 1/2 in.
NPT Male
Recommended
Cable
Belden #9501
(2-Conductor
w/Drain Wire,
Shielded)
TEMPERATURES
Operation
Temperature
+32
°
F to +140
°
F
(0°C to +60°C)
Ambient Air
Operation
Temp
0°F to +140°F
(-18°C to +60°C)
POWER SUPPLY
Voltage
Requirement
Min. 12 VDC
(voltages below 12V
will result in meter
accuracy issues)
Max. 36 VDC
(higher voltage may
damage unit)
Battery Backup
(QSI2, QSI3
Only)
Coin cell lithium, 3V
(CR2032)
UL APPROVED
MAX POWER CONSUMPTION
G2 Meter with
QSI
170mA
4 watts @ 24VDC
6 watts @ 36VDC
ELECTRICAL
PollutionDegree 2
Installation
Category 1
Altitude 2000m Max.
Indoor use only
OUTPUTS
&
COMMUNICATION
QSI Version 1:
Bluetooth
Coil/Digital Pulse Input
Pulse Output
RS485
Temperature Inputs
BTU Calculator
QSI Version 2:
Bluetooth
Coil/Digital Pulse Input
Pulse Output
Temperature Inputs
BTU Calculator
QSI Version 3:
Bluetooth
Coil/Digital Pulse Input
Pulse Output
4-20mA output

15
APPROVAL RATINGS
IP65
SERVICE
For warranty consideration, contact your local distributor. If you need further
assistance, contact the GPI Customer Service Department at:
1-888-996-3837
You will need to:
• Provide information from the decal on your meter.
• Receive a Return Authorization number.
• Flush any fluid from the meter before shipping to the factory.
RETURNING PARTS
Please contact the factory before returning any parts. It may be possible to
diagnose the trouble and identify needed parts in a telephone call. GPI can also
inform you of any special handling requirements you will need to follow covering
the transportation and handling of equipment which has been used to transfer
hazardous or flammable liquids.
CAUTION: Do not return equipment without specific authority from the GPI
Customer Service Department. Due to strict regulations governing transportation,
handling, and disposal of hazardous or flammable liquids, GPI will not accept
equipment for rework unless it is completely free of liquid residue.
RoHS Compliant (2011/65/EU)
This product is in compliance with the
RoHS Directive of the European
Parliament and of the Council on the
Restriction of the Use of Certain
Hazardous Substances in Electrical
and Electronic Equipment.

16
FLOMEC® TWO-YEAR LIMITED WARRANTY
Great Plains Industries, Inc. 5252 E. 36th Street North, Wichita, KS USA 67220-3205, hereby
provides a limited warranty against defects in material and workmanship on all products
manufactured by Great Plains Industries, Inc. This product includes a 2-year warranty.
Manufacturer’s sole obligation under the foregoing warranties will be limited to either, at
Manufacturer’s option, replacing or repairing defective Goods (subject to limitations
hereinafter provided) or refunding the purchase price for such Goods theretofore paid by the
Buyer, and Buyer’s exclusive remedy for breach of any such warranties will be enforcement
of such obligations of Manufacturer. The warranty shall extend to the purchaser of this
product and to any person to whom such product is transferred during the warranty period.
The warranty period shall begin on the date of manufacture or on the date of purchase with
an original sales receipt. This warranty shall not apply if:
A. the product has been altered or modified outside the warrantor’s duly appointed
representative;
B. the product has been subjected to neglect, misuse, abuse or damage or has been
installed or operated other than in accordance with the manufacturer’s operating
instructions.
To make a claim against this warranty, or for technical assistance or repair, contact your
FLOMEC distributor or contact FLOMEC at one of the locations below.
In North or South America contact
Great Plains Industries, Inc.
5252 East 36
th
St. North
Wichita, KS 67220-3205
USA
888-996-3837
www.flomecmeters.com
(North America)
Outside North or South America contact
GPI Australia
(Trimec Industries Pty. Ltd.)
12/7-11 Parraweena Road
Caringbah NSW 2229
Australia
[phone]
www.flomec.com.au
The company will step you through a product troubleshooting process to determine
appropriate corrective actions.
GREAT PLAINS INDUSTRIES, INC., EXCLUDES LIABILITY UNDER THIS WARRANTY
FOR DIRECT, INDIRECT, INCIDENTAL AND CONSEQUENTIAL DAMAGES INCURRED IN
THE USE OR LOSS OF USE OF THE PRODUCT WARRANTED HEREUNDER.
The company herewith expressly disclaims any warranty of merchantability or fitness for any
particular purpose other than for which it was designed.
This warranty gives you specific rights and you may also have other rights which vary from
U.S. state to U.S. state.
NOTE: In compliance with MAGNUSON MOSS CONSUMER WARRANTY ACT – Part 702
(governs the resale availability of the warranty terms).
© 2021 Great Plains Industries, Inc., All Rights Reserved.
Great Plains Industries, Inc. / 888-996-3837 / flomecmeters.com
01/2022 920905-03 Rev. B
