FLORA LJ3208P User manual
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~1~
Flora
LJ3208P USER GUIDE
2011-7-18
Shenzhen Runtianzhi Image Technology Co.,Ltd
www.floradigital.com.cn
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~2~
FLORA.....................................................................................................................................................................1
LJ3208P USER GUIDE.............................................................................................................................................1
FLORADIGITALPRINTINGSYSTEM............................................................................................................................................5
DISCLAIMER.........................................................................................................................................................................5
MANUALUSEGECONDITIONSANDLIMITATIONS.........................................................................................................................5
CONTENTSOFPACKAGE..........................................................................................................................................................6
PRINTERINTRODUCTION.........................................................................................................................................................6
TABLE1GENERALFEATURES...................................................................................................................................................6
TABLE2TECHNICALSPECIFICATION...........................................................................................................................................6
TABLE3FLORALJ3208PPRINTERMODELCODING....................................................................................................................7
ABOUTTHEMANUAL............................................................................................................................................................7
CHAPTER1SAFETYOPERATINGINSTRUCTIONS...........................................................................................................................8
1.1BriefIntroduction...............................................................................................................................................8
1.2SafetyInformation.............................................................................................................................................8
1.2.1SolventandInkProperties.........................................................................................................................................8
1.2.2DangerofFireandExplosion.....................................................................................................................................8
1.2.3Anti‐ultravioletRadiation...........................................................................................................................................8
1.2.4ProperVentilationandExhaustSystem.....................................................................................................................8
1.2.5InkandSolventspillage,apotentialriskofFireandexplosion..................................................................................8
1.2.6Highvoltagemayshockpeopleortriggerafire.........................................................................................................8
1.2.7Printingmediarollsarebulkyandveryheavy............................................................................................................9
1.3Fireproofing.......................................................................................................................................................9
1.4ExhaustSystem..................................................................................................................................................9
1.5HandlingPrecautions.........................................................................................................................................9
1.5.1PowerSupply.............................................................................................................................................................9
1.5.2Printer........................................................................................................................................................................9
1.6RegularInspectionandMaintenance................................................................................................................9
1.7Consumables......................................................................................................................................................9
CHAPTER2PREINSTALLREQUIREMENT....................................................................................................................................11
2.1GettingStarted.................................................................................................................................................11
2.2OperatingConditions.......................................................................................................................................11
2.2.1InstallationSpace.....................................................................................................................................................11
2.2.2EnvironmentConditions...........................................................................................................................................11
2.3ConfigurationofComputer..............................................................................................................................12
2.4PowerSpecification..........................................................................................................................................12
2.5SuggestInventoryList......................................................................................................................................12
2.6AvailableMediaTypes.....................................................................................................................................13
CHAPTER3EXTERNALVIEWS,PARTNAMESANDFUNCTIONS......................................................................................................14
3.1ComputerStation.............................................................................................................................................15
3.2MaintenanceStation........................................................................................................................................15
3.3Carriage&BeamAssembly..............................................................................................................................15
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~3~
3.4InkSupplyCompartment.................................................................................................................................16
3.5ElectricalCompartment...................................................................................................................................16
3.6DryingSystem..................................................................................................................................................16
3.7Take‐upSystem&FeedingSystem...................................................................................................................17
3.8PowerControlPanel.........................................................................................................................................17
CHAPTER4WORKINGSYSTEMOFFLORALJ3208P...................................................................................................................18
4.1SystemBlockDiagram.....................................................................................................................................18
4.2PolarisPrintheadIntroduce.............................................................................................................................19
4.3PrintingControlSystem....................................................................................................................................20
4.3.1PrintingControlBoard(116‐0401‐132)....................................................................................................................20
4.3.2USBBoard(116‐0417‐011).......................................................................................................................................21
4.3.3ServoCard
（
116‐0385‐022
）
..................................................................................................................................22
4.3.4HPPBoard
（
116‐0396‐081
）
..................................................................................................................................23
4.3.5ConnectorBoard(116‐0402‐020).............................................................................................................................24
4.3.6RTZ‐16UVMediaBoard‐V1.3(116‐0030‐041)...........................................................................................................24
4.4MechanicalMovementSystem........................................................................................................................24
4.4.1X‐axisMovement(CarriageMotionSystem)............................................................................................................25
4.4.2Y‐axisMovement(MediaFeedingSystem)...............................................................................................................26
4.5InkSupply&NegativePressureSystem...........................................................................................................28
4.5.1InkSupplySystem....................................................................................................................................................28
4.5.2LackofInkWarningFunction...................................................................................................................................28
4.5.3PurgeandFlushindividually.....................................................................................................................................29
4.5.4NegativePressureSystem........................................................................................................................................29
4.5.5OverflowProtectionFunction..................................................................................................................................29
4.5.6Otherpartsintro......................................................................................................................................................30
4.6FlushingSystem...............................................................................................................................................31
4.7DryingSystem..................................................................................................................................................32
4.8Take‐upandfeedingSystem............................................................................................................................32
CHAPTER5INSTALLATIONMANUALOFFLORALJ3208P............................................................................................................34
5.1MachinePre‐installation..................................................................................................................................34
5.2InstallationofSoftware....................................................................................................................................34
5.3.1InstallPhotoPRINTServerFloraEdition6.1v2..........................................................................................................35
5.3.2InstallFloraDriver....................................................................................................................................................37
5.3.3InstallUSBDriver......................................................................................................................................................38
5.3.4Addsetup.................................................................................................................................................................39
5.3InstallPrintHeads............................................................................................................................................40
5.4InkandSolventPreparation.............................................................................................................................43
5.5HeadAlignment...............................................................................................................................................43
5.5.1TestPrintToolBar.....................................................................................................................................................43
5.5.2SetParameter&NozzleCheck.................................................................................................................................43
5.5.3PrintheadYAlignment.............................................................................................................................................44
5.5.4VerticalAlignment....................................................................................................................................................47
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~4~
5.5.5InternalRightAlign...................................................................................................................................................47
5.5.6InternalLeftAlign.....................................................................................................................................................49
5.5.7RightAlign................................................................................................................................................................49
5.5.8XAlignment..............................................................................................................................................................51
5.5.9StepAlignment.........................................................................................................................................................52
CHAPTER6OPERATIONMANUALOFFLORALJ3208P...............................................................................................................54
6.1BriefIntroduction.............................................................................................................................................54
6.2Starting‐upActivities........................................................................................................................................54
6.3PrintheadJettingCheck..................................................................................................................................54
6.4OperationalApproachofPhotoPRINTServerFloraEdition6.1v2....................................................................54
6.4.1JobFolder.................................................................................................................................................................54
6.4.2LayoutTag................................................................................................................................................................55
6.4.3WorkFlowTag..........................................................................................................................................................56
6.4.4ColorManagementTag............................................................................................................................................56
6.4.5PrintOptionTag .......................................................................................................................................................57
6.5Shut‐offprocedure...........................................................................................................................................62
6.5.1Over‐nightprotection...............................................................................................................................................62
6.5.2Longtermprotection...............................................................................................................................................62
CHAPTER7SERVICEANDMAINTENANCEMANUALOFFLORALJ3208P........................................................................................63
7.1BriefIntroduction.............................................................................................................................................63
7.2Maintenanceofprintheads.............................................................................................................................63
7.2.1FlushingPrinthead...................................................................................................................................................63
7.2.2PrimePrinthead......................................................................................................................................................63
7.2.3ReplacingPrinthead................................................................................................................................................63
7.3MaintenanceofInkSupplyandVacuumLineSystem......................................................................................64
7.3.1ChangingDefectiveInkPumpandFilter..................................................................................................................64
7.4MaintenanceofPrinterMovingPart...............................................................................................................64
7.5AdjustTimingBeltTension...............................................................................................................................65
APPENDIXATROUBLESHOOTINGGUIDE................................................................................................................................67
APPENDIXBHOWTOSETNEGATIVEPRESSURESENSOR(CKD)DISPLAY........................................................................70
APPENDIXCGLOSSARY......................................................................................................................................................72
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~5~
Flora Digital Printing System
Flora Digital Printing System, reserves the right to make changes without prior notice to the specifications and
materials contained herein and shall not be responsible for any damages (including consequential) caused by
reliance on the materials presented, including but not limited to typographical, arithmetic, or listing errors.
This equipment has been tested and found to comply with the limits for a class Adigital device. Pursuant to part
15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which the user will be required to correct the
interference at his own expense.
This printer is a color inkjet printer that uses a Solvent ink, supports up to 3200mm of media width, and has one
built-in USB interfaces.
This manual, the LJ3208P User's Guide, describes the features of the printer, names of components,
information needed before use, and basic operations, such as how to turn the power ON and OFF, loading and
setting of the media and loading of ink.
The following items should be read before proceeding to Section 1;
−Contents of the package
−Safety precautions
−Handling precautions
−Notion
Notice: Read these items to use the printer safely and properly. Keep this manual in a place where you can
quickly access it any time.
Disclaimer
This is an alpha release of the User's Guide for Flora LJ3208P printer. We have made every effort to guarantee
the accuracy and integrity of the information in this manual. If you find some errors or omissions, please bring
them to our attention so we can check and correct them accordingly.
This manual can be used as a reference for operation and routine maintenance of the Flora LJ3208P printers.
It can’t be a replacement for the formal training provided by Shenzhen Runtianzhi Image Technology Co., Ltd,
regarding on how to operate the printers properly. Shenzhen Runtianzhi Image Technology Co., Ltd will not
take any responsibility for the consequences of misusing this manual and appendix.
Manual Usege Conditions and Limitations
The manual includes patent information, which belongs to Shenzhen Runtianzhi Image Technology Co., Ltd.,
the purpose of which is to help the authorized customers. Without the written permission from RTZ Company
and the public declaration, any content of this manual should not be used for other purposes.
The text and images are subject to change without prior notice. Any software mentioned in this manual is
provided by permission. Use or copy of these softwares must be according and to follow prior regulations. If the
information in this manual has changed, there will be no further notice unless it is specified.
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~6~
Contents of Package
The internal printer components, including the options, are installed on the main unit on delivery. The print
heads and extension table assembly are included on a separated box within the main crate.
If any parts are missing or damaged, please contact the shop or dealership where you have purchased the
product or the nearest service center.
Printer Introduction
The Flora LJ3208P printer is a wide format digital printer suitable for small up to medium size business use. It
uses a Solvent ink. It provides high productivity and is capable to replace traditional silkscreen printing. This
type of printer is widely used in the fields such as advertisement, packing, printing, interior decoration, flexible
packaging, etc.
Flora LJ3208P series printers use drop-on-demand and Piezo-electric technology. It can print colorful and wide
image by using the highest 1200x1200 dpi resolution. It can output any size of images with “tile” feature in the
software.
Table 1 General Features
Item
No Description Specification
1 Printing Method Drop-on-demand Piezo-electric
2 No. of colors 4 (CMYK)
3 Ink Solvent
4 Ink reservoir capacity (volume) 4 Li/color (refillable while printing is on progress)
5 Outdoor Durability 1 years for Flora Solvent ink
6 Media handling system Roll-to-Roll with vacuum
7 Drying system Dual Drying System
8 Media types Roll-to-roll including paper, vinyl, adhesive back
vinyl, fabrics, banners, PVC, etc
9 Maximum printing size 3.2 m width
10 Rip software PhotoPRINT V6.1 Flora edition (Windows 7)
11 Driver software Flora Driver
12 Color management ICC based color, density adjustment curves
13 File format Bitmaps, Tiffs, Jpeg, Postcripts3, Eps, Pdf, etc.
14 Work Flow Rip and Print
15 Warranty 1 year (please consult your local dealer for details)
Table 2 Technical Specification
Item No D e s c r i p t i o n Specification
1 Model Flora LJ3208P
2 Print Head Binary Drop-on-demand Piezo-electric
3 No. of print heads 8 (CMYK, 2 print heads/color)
4 No of colors 4 colors
5 Printing resolution option 300x200, 300x400, 300x600, 600x400,600x600,
600x800, 1200x1200 dpi
6 Printing quality option Standard, High and Ultra
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~7~
7 Printing Speed Draft Quality: 185 m
2
/hr
Standard Quality: 125 m2/hr
High Quality: 92 m2/hr
8 Media maximum width 3.3 m
9 PC minimum operating requirement. Intel Core 2 Duo, Q6600 @2.40GHz
3GB RAM, 250GB HDD, Windows 7 or XP
11 Operating environment 220VAC/50/60Hz/Single Phase, Distortion<
0.5% Heating:3000W, System:3500W
12 Room temperature 23~33 ºC
13 Humidity 40~70%
14 Dimensions 4.83.m x 1.37m x 1.38m
15 Weight 700 Kg
Table 3 Flora LJ3208P Printer Model Coding
Code Explanation
Flora Brand Name
LJ Light Jet
3208P 320: maximum width 320cm
8: 8 print heads
P: Polaris head
About The Manual
The manual provides the end user all the information related to the machine basic functions, software
installation, machine parameter calibration, maintenance and troubleshooting of Flora LJ3208P.
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~8~
Chapter 1 Safety Operating Instructions
1.1 Brief Introduction
This chapter introduces the important safety information. Please read and understand the safety
information carefully before operating the printer.
1.2 Safety Information
FLORA printer uses the following chemical substances
zAll kinds of printing media
zSolvent Ink
zCleaning liquid (Solvent Flush)
1.2.1 Solvent and Ink Properties
Solvent and Ink are flammable.
Eye contact with the ink and Solvent will break the cornea and weaken the eyesight.
Contact lens should not be worn when operating printer or when there is no proper
ventilation.
Wear safety glasses and gloves while flushing print heads, ink tube or moving the ink
bottles or containers.
Solvent and ink can be irritating to eyes, throat and skin. Inhaling the ink fumes would
result in swoon or other symptoms.
Solvent vapors are heavier than air and may flow and gather in low spot.
1.2.2 Danger of Fire and Explosion
Open flames, heat energy or spark around the printer can trigger fire and explosion.
No smoking, pilot lights, open flames, stoves, heaters or halogen lights should be
turned on within 5m distance from any edge of the printer.
No portable spark-producing equipment (static, electrical or Mechanical) within 5m
distance from any edge of the printer.
1.2.3 Anti-ultraviolet Radiation
Wear solvent protection glasses and gloves when operating the machine and avoid
being too closer to solvent lights.
When doing maintenance task or being close to the flatbed machine, solvent lights
must be shut off or close all solvent protection doors.
1.2.4 Proper Ventilation and Exhaust System
The vacuum exhaust system must be functioning before the printer operates.
Do not ignore this safety warning sign to avoid accumulation of flammable fumes in the
area.
1.2.5 Ink and Solvent spillage, a potential risk of Fire and explosion
Store ink and Solvent in proper cabinet for flammable liquid storage.
Keep ink and Solvent containers tightly closed at all times. If a container has sign of
damage/leakage, fix or replace it immediately.
Clean ink or Solvent spillages as soon as possible.
Only use dry powder, or carbon dioxide type of fire extinguishers.
1.2.6 High voltage may shock people or trigger a fire
If there’s no emergency power switch which can shut down all the power, do not
connect the printer to main-power supply.
When the machine’s power is on, do not open the back cover of machine, or avoid
touching electrical parts.
The printer or other equipments should be grounded, according to the local safety
This caution symbol represents danger. If this sign is ignored it
may lead to serious injury or damage to the printer.
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~9~
electrical connection regulation. The ground voltage should be less than 3 V.
Set the machine on smooth ceramic tile or cement ground
Use specified anti-static floor mat to minimize harmful static build-up.
1.2.7 Printing media rolls are bulky and very heavy
Wear hand and foot safety protection gear when loading, unloading and handling
media to avoid serious body injuries.
Use proper heavy duty handling equipment if available.
1.3 Fireproofing
Ink and Solvent should be clearly labeled and stored in a specific area for flammable liquid and
should be in accordance with local regulations of fireproof and safety standard. Ensure that the specified
fire extinguisher is always available near the storage area and should be cleared from any obstacle in
case of emergency.
1.4 Exhaust System
The printing area should be equipped with sufficient exhaust system. The exhaust should be installed
in such a way build up of fumes is minimized. Best location for the exhaust should be at lowest level, this
way the fumes build-up is minimized. Solvent fumes are heavier than air, so fumes build-up concentrates
on the lower level of the room.
1.5 Handling Precautions
1.5.1 Power Supply
Install the printer near an easily accessible electrical outlet.
Do not provide power to the printer through the same power line as for other noise
generating devices such as motors.
Use a power supply matched with the printer specification.
Connect the power cable directly to an electrical outlet. Do not plug several devices
into one electrical outlet.
1.5.2 Printer
Do not place anything on top of the printer.
Do not rest you elbows on the printer.
Open and close the top cover gently from the front of the printer with both hands.
Before connecting or disconnecting the interface connector, turn the printer OFF.
Do not clean the surface of the cover with benzene or paint thinner. The coating may
come off or deteriorate. Wipe the cover with a soft cloth, if the cover is very dirty, use a
cloth moistened with a neutral detergent.
Do not touch the ink jet head surface.
1.6 Regular Inspection and Maintenance
The following regular inspection and maintenance must be performed in terms of characteristics of
the solvent ink:
a) Clean the carriage unit and the flat table conveyor surface every day.
b) Make sure that the carriage covers are always replaced.
c) Perform ink supply circuit and print head cleaning when leaving the printer for a long
time (2 weeks or more with no power).
d) Perform head cleaning after leaving the printer idle for a long time.
e) Shut off the solvent lamp whenever the printer is not in use.
1.7 Consumables
zAlways use the recommended consumables (printing media, ink, ink filters). Failure to
follow this instruction may cause poor printing quality and breakdown.
zDo not use ink past the expiration date as this may cause a print head breakdown and poor
printing quality.
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~10~
zPut a used ink bottle into a plastic bag and dispose of it as an industrial waste. Observe
local regulations for disposal of waste ink bottles.
zAvoid spilling ink into your skin or clothes. Wash any ink off immediately with soapy water.
zCheck the waste ink container everyday so as not to permit waste ink to leak from you
printer.
zIf the waste ink container is being installed or removed, spread a stain preventing sheet so
as not to stain the floor with spilled ink.
zStore ink in a dark and cool place. Never store the ink in high temperatures or direct sunlight,
doing so may cause the ink to deteriorate.
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~11~
Chapter 2 Preinstall Requirement
This is a pre-install guide for Flora LJ3208P. Customers are recommended to prepare the room and other
necessary devices before the machine arrived and installation. We have made every effort to guarantee the
accuracy and integrity of the information in this guide. Should you find some errors or omissions, please bring
them to our attention so we can check and correct them accordingly.
2.1 Getting Started
This section provides the necessary information to preinstall the printer. Familiarize yourself with the
basic of the printer before reading Section 2.
Contents of this section：
zOperating conditions
zConsumables
2.2 Operating Conditions
This section describes the operating conditions for the printer.
2.2.1 Installation Space
There must be sufficient space around the printer for the replacement of frequently used parts,
for the output of the printed media and for ventilation. In addition, maintenance space, shown below,
is required to repair the printer or replace components.
There must be at least 1m of space in every side at X-axis, at least 1.5m of space at in every
side Y-axis, at least 1m from the top of the machine.
2.2.2 Environment Conditions
2.2.2.1 Operating temperature and humidity levels
The printer should be used within the temperature and humidity ranges as shown below;
Temperature: 20 ºC to 30 ºC
Humidity: 40% to 70%
Note: To obtain better print quality, use the printer within temperature of 25 ºC to 30 ºC.
X
Y
Media
Load Area
LJ 3208P Top View
Power
Distribution
Area
1.0m 4.83m
LJ 3208P Printer
Left Back
Right
Front
0.96m
1.5m
1.5m
3.96m
6.83m
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~12~
When the operating temperature is lower than 20 ºC or higher than 40º C, printing speed
should be reduced to two-thirds of normal print speed to maintain good print quality.
2.2.2.2 Places where the printer must not be installed
Do not install the printer in the following places:
A location near a fire
Places exposed to direct sunlight
Places subject to vibration
Places with excessive dust
Places subject to extreme changes in temperature or humidity
Places near an air conditioner or a heater
Places where the printer may get wet
Places near a diazo copier that may generate ammonia gas
Places with poor ventilation
Unstable place
2.3 Configuration of Computer
zIntel Core 2 Duo, Q6600 @2.40GHz
z3G RAM
z250G Hard disk
zDVD-ROM
zUSB 2.0 port(at least 2)
Notice: This is only for reference, which is used to test in our company! Recommend to use
Brand Computer.
2.4 Power Specification
System Power Heating Power
Rated voltage 220VAC (±5%) 220VAC (±5%)
Rated currency 25A 16A
Input power frequency 50/60HZ 50/60HZ
Phase Single-phase Single-phase
Electrical Safety:
zThe machine should be grounded, according to the local safety electrical regulation.
zThe grounding should be less than 3V.
zUse specified anti-static floor matting to minimize the harmful static buildup.
zUse ESD Ground Strap when handling Print heads and any Electronic Boards to avoid any
electric static discharge that may damage these parts.
zDo not open the cover where electrical spare parts are located to avoid possible electrical
shock.
Notice: AVR or UPS is recommended to keep supplying stable power to the machine!
2.5 Suggest Inventory List
PN Part Name Number/Machine Photo
116-0401-132 Printing Control Board 1pcs
116-0417-011 USB Board 1pcs
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~13~
116-0385-022 Servo Card 1pcs
116-0396-081 HPP Board 1pcs
312-0015-233 Ink Pump 9pcs
141-0487-000 Ink Pump Filter 9pcs
141-0428-006 Disc Filter 16pcs
116-0340-020 Raster Reader 1pcs
141-0134-004 Raster Strip 1pcs
2.6 Available Media Types
The following types of media are available:
zPaper
zAdvertising banner
zPVC
zMesh Fabrics
zAdhesive Vinyl
Note: Contact our service center for detail!
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~14~
Chapter 3 External Views, Part Names and Functions
The mechanical design parts/assembly of the
machine are grouped according to its function;
namely, the print head carriage, the x-axis
movement mechanism, the y-axis movement
mechanism, the roll media feeding and take-up
mechanism, the ink supply compartment, the
electrical control cabinet and the printing platform.
The printing system control is a modular control
that has the dedicated controller board for a specific function. Other controller board functions as a stand-alone
control, like the roll media feeding and take-up control board, that has no communication and no interlock with
the other controller board, it needs only the power supply from the machine. The mechanics, the electronics
and the standard electrical parts are harnessed together to form a system for large format printing application.
LJII-series Perspective View
Fig.3-1Top View (Back Side)
(Front Side)
Fig.3-2 Left View
Ink Supply Control
Compartment
Fig.3-4 Right View
Computer
Compartment
Fig.3-3 Front View
Ink Bottle
Compartment Drying Plate
Drying Fans Roll Media
Take-up Roller
Heater Controller
and Roll Media
Control Switches
User Interface
(UI)/Monitor
Maintenance
Station
Fig.3-5 Back View
ELCB and Circuit
Breakers
Roll Media
Feeding Roller
Roll Media
Feeding Motor Roller Wheel
andAdjustable
Footing
Exhaust Fan
Ducting Port
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~15~
3.1 Computer Station
Computer station is control centre, which is located at right side of the machine! It takes charge early
treatment before printing including image ripping and print mode setting. Most function starts to work
when get the command from computer.
3.2 Maintenance Station
Maintenance station is in right compartment. When the carriage stopped working, it will come back to
station.All the maintenance performance should be done here.
3.3 Carriage & Beam Assembly
The print head carriage assembly houses the print heads, secondary ink tanks, print head control
board, raster reader, negative pressure sensor.
Rail guide serves as pathway for carriage moving, and the beam serves as frame for rail guide
mounting.
Fig.3.2-1 Maintenance Panel
Vacuum To
gg
le
Switch
Flush To
gg
le
Switch
A
ir flow Control
Fig.3.2-2 Maintenance Station
Pur
g
e Button
Waste ink Tra
y
Fig.3.3-1 Carriage Assembly
Ink Tank
PH Plate
Fig.3.3-2 Beam&Pinch Roller&Plate
Carria
g
e
Printin
g
Platform
Rail Guide
Pinch Roller
Fig.3.1-1 Monitor&Keyboard&Mouse
Monitor
Ke
y
Board &
Mouse Bracket
Fig.3.1-2 Computer
PC
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~16~
3.4 Ink Supply Compartment
Ink supply station contains two compartments. One is on the right side for ink pumps and filter, while
the other one is on the back right side for ink bottles.
3.5 Electrical Compartment
Electrical compartment is a shelf for mounting USB Board, Servo Card, Media Board, transformer
and DC power supply. It is built in steel frame.
3.6 Drying System
Because of speciality of the ink, one drying system is necessary for output job. This system is fixed in
front of the machine, including Hot drying and Cold drying system.
Fig.3.4-1 Ink Pump Compartment
Buzze
r
Bulk Filte
r
Ink Pump
A
ir Pump
Flush Pump
Fig.3.4-2 Ink Bottle Compartment
Ink Bottle
Waste ink Bottle
Fig.3.6-1 Drying System
Heatin
g
Plate
Hot wind Fans
ColdAir Fans
Power Inlet
Fig.3.6-2 Fan Switch &Temp. Controller
Hot-Fans Switch
Cold-Fans Switch
Temp. Controller
Fig.3.5-1 Electrical Shelf
Media Sensor
Transformer
36VDC Power Suppl
y
24VDC Power Suppl
y
Take-up Media PCB
Feedin
g
Media PCB
USB Board
Servo Card
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~17~
3.7 Take-up System & Feeding System
Take-up system in the front of the machine is used to roll up the output media, while the feeding
system fixed behind the machine used for roll down the media for feeding.
3.8 Power Control Panel
Power control panel is fixed behind the machine on the right side! On this panel, there is one inlet
used for main power input, three built-in outlets two of which are used for computer and monitor.
All the power breakers are also built on this panel!
Fig.3.7-1 Take-up System
Tension Ba
r
Take-up Rolle
r
Motor Box
Fig.3.7-2 Feeding System
Feedin
g
Motor
Feedin
g
Roller
Media Hoop
Fig.3.7-3 Control Panel
Back Heat Controller
Take-up Switch
Transition
Button
Feedin
g
Switch
Fig.3.8-1 Power Control Panel
Main power Breaker
Computer outlet
Main Power Inlet
S
y
stem Breaker
Heatin
g
Breaker
Monitor Outlet
Backup Outlet
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~18~
Chapter 4 Working System of Flora LJ3208P
The Flora LJ3208P large format printer is using raster image technology to process photos stored in computer.
It is one of the most innovative products, which combines photo digital technology with high precision engine
driver. It produces super wide printouts for business use.
It is a high-technology equipment with a user friendly operating system with simple operational and
maintenance procedures. Though simple, it is composed of several precise systems. In this chapter, we will
introduce the system components and operator guide.
4.1 System Block Diagram
Fire si
g
nal
HPP Board
USB_IF
Board
C
on
t
ro
l Si
gna
l
Cd
Level, Pressure Si
g
nal
Monitor &
Keyboard Mouse
Host Computer
USB2
.
0
Servo Card
Ink Pumps
(24Vdc)(CMYK) - Buzzer
- Flush Pump
- Air/Vac Pump
Home
Left LS
Right
Switches
& Signal:
- Flush
- Prime
Printing Control
Board
IT Level
Sensors
IPT Level
Sensor
NP
Sensor
Raster
Encoder
O
p
tical
fiber
Image Data,
Clock, DC
Supply & Heater
Control signals
PHdTemp.
Sensor Signal
K2
Y2
C1
M2
Y1
M1
C2
K1
Power Supply
+36Vdc
+36Vdc Supply
Power Supply
+24Vdc
+24Vdc
220Vac
Supply
Temp.
Controller
Solid State
Relay Heaters
- Printing Platform
- Drying Platform
Sensor
Media
Take-Up
PCB
Media
Feeding
PCB
Media
Sensor
Media
Sensor
Y-axis motion
X-axis motion
Dir/Step
si
g
nal
36Vdc
Power
X-axis
Servo
Driver
Servo
Motor
(X-axis
Encode
r
Dir/Step
si
g
nal
36Vdc
Power
Y-axis
Servo
Driver
Servo
Motor
(
Y
-axis
Encode
r
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~19~
4.2 Polaris Print head Introduce
Feature:
35 picoliter nominal drop size
512 individual addressable nozzles
Incorporates versaDropTM binary jetting
capability
Excellent channel-to-channel uniformity
High frequency continuous operation
Designed for long service life
Integral mounting bezel with precision
features
Configurable for single and two-color
operation
Optimized for high viscosity jetting fluids
Built-in heaters and temperature sensors
Operation up to 60°C（140°F）
Simplified field repair with no special tools required
Supports UV-curable, solvent and aqueous-based inks
Technology Specification Table:
Parameter Polaris PQ-512/35AAAPrint head
Number of addressable jets 512
Print width 64.897mm(2.555inches)
NOZZLE SPACING
Single color(4 rows of jets) 127 microns [0.005in.]（200 dpi）
Two color(2 rows of jets/per color) 254 microns [0.01in.](100 dpi)
Jet straightness ,1 sigma* 2.0mrad[0.11°]
Nominal drop velocity 8m/s
Calibrated drop mass 35ng
Compatible jetting fluids solvent-curable, organic solvents, aqueous
BINARY OPERATION
Adjustment for drop size 35-80 picoliters
Productivity Drop size Maximum Frequency
35 pl 30kHz
80 pl 13kHz
Operating temperature range Up to 60°C
Fluid viscosity at jetting 10 to 14 centipoise
Dry weight 160ams
Fig. 4.2-1 Print head
Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~20~
4.3 Printing Control System
4.3.1 Printing Control Board (116-0401-132)
The print head control board controls and drives the jetting parameters of the print heads.（as
below）. Functions of the board are as follow：
Receiving optical signal from USB Board ,change it into electric signal and separate
the image data & control order from the signal ；as the same time，combine level
signal , negative signal , raster signal etc., then change them into optical signal and
send them to USB Board
Supplying power & clock to print head to drive it work
Detecting automatically: detecting level of ink tank is full or not ; detecting negative
pressure is in the range of setting or not ; reading raster signal
Level indicator:
When the tank is full, the responsible indicator will turn on!
Fig.4.3.1-1 Printing Control Board
DC 24V
USB J6
Level Sensor USB J11
NP Sensor
Raster
Reader
HPB J2
Y1 Y2M2M1
C1 C2K1 K2
Linking
indicator
Working
indicato
r
Status
indicator
Level
indicator
Powe
r
indicato
r
Common Port
Indicator
Tanks are full
Fig.4.3-1 Printing Control Board
