Ch. 2 Limitations
Dear client,
Congratulations on your purchase of this FLOTEC product. Like all FLOTEC products, it has been developed with the help
of the latest technologies and manufactured with the most advanced electrical/electronic parts.
Take the time to read the instructions carefully before using this appliance.
Thank you!
GB
GB 15
Contents
Ch. 1 Features ............................................................................................
Ch. 2 Limitations..........................................................................................
Ch. 3 Installation ..........................................................................................
Ch. 4 Electric Connection - Start-up ...........................................................
Ch. 5 Maintenance and troubleshooting ....................................................
Appendix Figures ...............................................................................................
GB 1
GB 1
GB 2
GB 3
GB 3
pg. 73
Warnings for the safety of individuals and objects.
Carefully follow the instructions marked with the following symbols.
Warns that the failure to follow the directions given may cause electric shock.
This sign warns the operator that the failure to follow an instruction may
damage the pump and/or the system.
DANGER Warns that the failure to follow the directions given could cause serious risk
to individuals or objects.
DANGER
Electric shock
risk
WARNING
DANGER Keep the technical equipment out of the reach of children!
WARNING: Read this manual carefully before installing this pump.
This sign warns the operator that the failure to follow an instruction may damage the pump and/or the system.
Carefully store this manual. If problems arise, contact the Customer Assistance Service. Please verify that the pump
has been used correctly and that the cause of the problem is not imputable to its operation.
Every electropump is carefully tested and packed during its assembly.
On receiving the pump, check that the pump has not been damaged during transportation. If the pump is damaged,
immediately inform the dealer within 8 days from the date of purchase.
Ch. 1 Features
The pump cannot be used for sea water and inflammable, corrosive, explosive or
dangerous liquids.
Verify that the electropump never runs without liquids.
WARNING
WARNING
FLOTEC VIPVORT, FP14 KVX, FP7 KV series electropumps are suitable to pump dirty water containing suspended solid
particles. These pumps can be used both for permanent and temporary installations and in particular to empty collection
basins containing dirty or waste waters.

The pumps of this series are not suitable for table fountains or aquariums. If these pumps are used in continuous mode
for ponds with fish, it is necessary to check them at regular intervals of 6 months (if the water contains aggressive
substances). It is also advisable to check the maximum dimension of particles recommended for the pump and take
the necessary measures to prevent the fish from being sucked into the pump.
6
(*) These data refer to Fig. 1. Measurements are expressed in millimetres.
The minimum priming level corresponds to a condition in which the delivery mouth is completely submersed.
(See Fig. 1 - Reference A)
GB
Ch. 3 Installation (see Fig. 1)
Electric shock
risk
DANGER
To prevent possible injuries to people, avoid inserting hands into the mouth of the pump if this
is connected to the mains.
DANGER
Use the handle provided to transport or lift the pump.
To use the pump in permanent installations with rigid pipes, to install a check valve to avoid the fluid being re-circulated
once the pump is stopped. The installation of a quick closing fitting in a convenient position facilitates cleaning and
maintenance operations.
The dimensions of the collection container should reduce to the minimum the number of starts per hour (see LIMITATIONS
- Technical data).
To use the pump for temporary applications, install a flexible pipe and connect it to the pump using a pipe holder. To
immerse the pump, use a rope and fix it to the handle.
FLOTEC VIPVORT, FP14 KVX, FP7 KV pumps have a pre-set floating switch. To change the setting, it is necessary to
increase or reduce the length of the floating switch cable by sliding it in the slot on the handle (See Fig. 1).
GB 2
WARNING
WARNING
Verify that the floating switch stops the pump as soon as the minimum level is reached.
Make sure that the floating switch is free to move.
(see also Fig. 7 and 8)
The pumps used in ponds, small lakes, fountains or similar installations or close to them should have a cut-out switch.
Contact a specialised electrician.
When installing, please ensure electropump is disconnected from electrical
supply. Pumps in this series are not suitable for use in a swimming pool and
the relevant cleaning and servicing operations.
Sound pressure level (Lpa) equal to or less than 70 dB(A)
Sound emission values obtained in conformity with the EN 12639 standard
Technical Data VIPVORT 130/5 VIPVORT 180/6 FP14KVX FP7KV
Mains voltage / frequency 230 V ~ 50 Hz 230 V ~ 50 Hz 230 V ~ 50 Hz 230 V ~ 50 Hz
Absorbed power 370 Watt 480 Watt 600 Watt 350 Watt
Type of protection / Insulation class IP 68 / F IP 68 / F IPX8 / B IP68 / F
Suction fitting 41,90 mm (1"1/4 M) 41,90 mm (1"1/4 M) 41,90mm(1"1/4M) 41,90mm(1"1/4M)
Maximum flow rate 7.800 l/h 10.800 l/h 14.000 l/h 7.800 l/h
Maximum head 5 m 6 m 8 m 5 m
Maximum depth of Maximum depth
of immersion 7 m 7 m 5 m 7 m
Power cable 10mH05RNF 10 m H07 RN8-F 10 m H05 RNF 10mH05RNF
Weight 3,9 Kg 4,2 Kg 5 Kg 2,9 Kg
Maximum dimension of pumped
solid particles 25 mm 25 mm 22 mm 25 mm
Maximum temperature of the pumped fluid 35° C 35° C 35° C 35° C
Maximum number of starts per hour 30 30 30 30
Minimum priming level (A)* 150 mm 150 mm 94 mm 150 mm
Minimum suction level (B)* 30 mm 30 mm 37 mm 30 mm
Connection level (C)* 330 mm 330 mm 370 mm 330 mm
Stop level (D)* 150 mm 150 mm 190 mm 150 mm
DANGER
This appliance can be used by children aged 8 years or over and by persons with limited physical,
sensory or intellectual capabilities, or with limited experience and knowledge, provided that they are
supervised or have been instructed in the safe use of the appliance and are aware of the dangers
involved. Children must not be allowed to play with the appliance. Cleaning and user maintenance
must not be carried out by children unless they are supervised
WARNING Pollution of the liquid could occur due to the leakage of lubricants

Ch. 4 Electric Connection - Start-up
7
Pump anchorage
Use the slots on the filter cap (see Fig. 2, pos. 1) to anchor the pump. Then, remove the inserts from the filter cap. It is also
possible to insert 3 screws in the widest section of the slots (see Fig. 2, pos. 2) and turn the filter cap counterclockwise
so that the screws keep the cap in place in the narrowest section of the slots (Fig. 2, pos. 3). After fixing the filter cap, it is
necessary to insert the pump in the related guides (see Fig. 3, pos. 4) and turn it counterclockwise to fix it in place (Fig. 5).
Instructions for a safe pump start
The power cable should have a minimum section equivalent to that of H05 RN-F. To be able to use the pump outdoors,
it is necessary to use cable with a length of 10 m. The plug and connections should be protected by water splashes.
Before using the pump, always inspect it visually (especially power cable and plug). Do not use the pump if it is damaged.
If the pump is damaged, have it inspected by the specialised assistance service only.
Make sure that electric connections are protected from inundation.
Protect the plug and the power cable from heat, oil or sharp edges.
Grounding
The plug of the power cable has a double grounding contact, so that grounding can be performed by simply inserting
the plug.
GB
The installer must make sure that the electric system is grounded in
accordance with the law in force.
WARNING
Verify that the voltage and frequency of the electropump shown on the nameplate
correspond to those available on the mains.
DANGER
Electric shock
risk
DANGER
Electric shock
risk
Make sure that the electric system has a high-sensitivity circuit
breaker D=30 mA (DIN VDE 0100T739).
DANGER
Electric shock
risk
The power cable must be replaced by qualified personnel only.
Overload protection
FLOTEC VIPVORT series pumps have a built-in thermal protection switch. The pump stops if an overload condition occurs.
The motor restarts automatically after it has cooled down (see point 4 of the Troubleshooting section for information
on causes and corrective actions).
To start the pump, insert the plug in a 230 V alternate current socket.
ATTENTION: the pump runs as soon as the floating switch reaches the start-up level.
GB 3
In ordinary conditions, FLOTEC VIPVORT series electropumps do not require any maintenance.
It may be necessary to clean the hydraulics or replace the impeller.
Hydraulics cleaning VIPVORT (see Fig. 3, Fig. 4, Fig. 5, Fig. 6)
Disassembly of the filter cap: disassemble the filter cap only after removing the safety screw (See Fig. 3, pos. 6). Keep
the pump motionless and turn the filter cap clockwise looking at the pump from the bottom. To assemble the filter cap,
turn it counterclockwise (see Fig. 4).
If the filter cap is fixed on the base with screws, turn the pump clockwise in the direction of the handle to disassemble
it (See Fig. 5).
Ch. 5 Maintenance and troubleshooting
DANGER
Electric shock
risk
Make sure the machine is disconnected from electric power supply,
before performing maintenance operation.

Disassembly of the diffuser filter VIPVORT
Disassembly of the diffuser filter: disassemble the diffuser filter only after removing the safety screw (See Fig. 3, pos. 5).
Keep the pump motionless and turn the diffuser filter clockwise looking at the pump from the bottom. To reassemble
the diffuser filter, lubricate the O-ring with water and turn the filter counterclockwise (see Fig. 6).
1) THE ELECTROPUMP DOES
NOT PUMP WATER, THE
MOTOR DOES NOT RUN
2) THE PUMP DOES NOT SUP-
PLY WATER BUT THE MOTOR
IS RUNNING
3) THE PUMP SUPPLIES A
LIMITED AMOUNT OF WATER
4) INTERMITTENT OPERATION
Pump storage instructions
Store the pump in a dry place and protect it from frost.
8
GB
PROBLEM POSSIBLE CAUSE REMEDY
1) No electricity.
2) Plug inserted incorrectly.
3) Enabled safety switch.
4) Blocked impeller.
5) Damaged motor or condenser.
2) Verify that voltage is present and that the
plug is correctly inserted.
3) Reset the safety switch.If the safety switch
is once more enabled, contact a specialised
electrician.
4) Remove possible obstructions from the
impeller.
5) Contact the Customer Assistance Service.
1) Obstructed suction grid.
2) Blocked check valve.
3) Air in impeller body (air bubbles).
1) Clean the grid.
2) Clean or replace the valve.
3) Perform several start-ups in order to
remove all the air.
1) Partially obstructed suction grid.
2) Obstructed pipe.
3) Worn impeller.
1) Clean the grid.
2) Remove the obstructions
3) Contact the Customer Assistance Service.
1) Solid particles prevent the free rotation
of the impeller.
2) The temperature of the fluid is too high.
3) Voltage out of range.
4) The fluid is too dense.
5) Faulty motor
1) Remove the foreign particles.
3) Supply the pump in accordance with
nameplate data.
4) Dilute the pumped fluid.
5) Contact the Customer Assistance Service.
GB 4
Only for EU countries
Do not dispose of electric tools together with household waste material!
In observance of European Directive 2002/96/EC on waste electrical and electronic equipment
and its implementation in accordance with national law, electric tools that have reached the
end of their life must be collected separately and returned to an environmentally compatible
recycling facility.
