fluidra ASTRALPOOL Viron CL Series User manual

26/08/2015
INSTALLATION AND
OPERATING INSTRUCTIONS
Melbourne: 03 8796 8600 Gold Coast: 07 5552 2600 Perth: 08 9350 2600
Sydney Nth: 02 9853 2100 Sydney Sth: 02 8778 9500 Townsville: 07 4750 3100
Brisbane: 07 3308 5400 Adelaide: 08 8152 7600 [email protected]
www.astralpool.com.au
Bolero ND Cleaner
Viron Cartridge Filter
INSTALLATION AND OPERATING INSTRUCTIONS I INSTALLATION AND OPERATING INSTRUCTIONS
Viron CL Series
Cartridge Filter

INST 249 - Viron CL Series Cartridge Filter V08-15
2
INSTALLATION OF VIRON CL SERIES
Install Cartridge filter on a clean, stable and level
base on which the circulation pump is located.
1. The CL Cartridge Filter has two 50mm water
connections. The 2 inlet ports (from pump) are located
at the bottom of the filter. The 2 outlet ports are
located on the opposite side of the filter. The inlets and
outlets are marked on the tank. The un-used inlet and
outlet ports should be capped using the caps provided.
For installations where the flow rate is above 350 litres
per minute, both Inlet and outlet ports may be used.
The PVC pipe can be manifolded together to achieve a
maximum flow rate of 700 litres per minute.
2. Allow a minimum on one hour for glue to dry.
3. Using Teflon tape, screw pressure gauge into lid.
4. If the filter is installed below water level, isolation valves must be installed on the inlet and outlet to enable the
filter to be dismantled for cleaning without the loss of water from the pool or spa.
5. It is also recommended that a three way valve be installed on the return line to allow draining of water from the
pool or spa when necessary.
CL 400 A Dimension –734mm,B dimension 586mm
CL 600 1034mm 586mm
START UP INSTRUCTIONS
Warning: Never Start Pump while lid or lock ring is loose. Never stand above filter while pump is running –danger of
lid coming off under pressure could cause serious injury or death.
1. Before start up make sure the elements are in the filter and the lid lock ring is tightened until the safety catch locks
–do not over tighten.
2. Open the suction and return line valves (where fitted).
3. Loosen the air release valve on the filter lid, start pump until water escapes the air release valve. Tighten the air
release valve and check there is a good flow of water back in the pool.
4. Clean the cartridges when the flow to the pool reduces or the pressure gauge increases by 20 kPa.
Outlets
Inlets

INST 249 - Viron CL Series Cartridge Filter V08-15
3
PUMP PRIMING
1. With the pump OFF, remove the lid from the pump strainer and pour in approximately 4 litres of water.
2. Replace lid.
3. If valve has been installed on the pump suction line, close before filling strainer. Open again after lid has been
securely fastened in place. Any valves on the return lines should be open. The pump should not need to be re-
primed unless the pump has been drained for servicing, or winterizing (refer to complete pump operations manual
provided with pump).
TO CLEAN FILTER CARTRIDGE
1. Stop pump - close valves on the suction and return lines.
2. Open the air bleed valve on the lid.
3. Loosen lock ring and remove cartridges.
4. Lift out cartridges. Clean the cartridge by soaking it in a mild solution of chlorine and warm water for 15 minutes
and then hose off with high pressure water.
5. Replace the cartridges –carefully locating it on the bottom spigot.
6. Clean the lid ‘o’ ring. Apply a small amount of water based lubricant.
7. Place the lid onto the filter body, ensuring it is located centrally. Do not try to force lid down into place.
8. Place locking ring onto filter.
9. Tighten the lock ring to pull the lid into the filter body. Approximately 3 ½ turns are required until safety catch
engages –do not over tighten.
10. Check locking ring will not loosen without releasing the locking mechanism.
11. Open the valves –start the pump.

INST 249 - Viron CL Series Cartridge Filter V08-15
4
CLEANING FREQUENCY
The Viron CL 400 and CL 600 have been designed to minimise cleaning. On average sized residential pools it is likely
cleaning will only be required once a year. However, after storms causing severe ingress of dust and debris into the pool, or
in times where earthworks and construction are taking place nearby, cleaning may be required as often as once per month.
NEVER LOOSEN THE LOCK RING WHEN THE PUMP
IS WORKING!!!
MODEL
PART
NO.
ELEMENT
PART
NO.
FILTER
AREA
MAX
FLOW
RATE
L/Hr
MAX
FLOW
RATE
L/M
4 HR
TURN
OVER
6 HR
TURN
OVER
PUMP
SIZE
SHIP
KG’S
CUBIC
MEASURE
CL400
10055
78083
400 sq ft
38.0 m2
42,000
700
168,000
252,000
750w
2200w
37.0
kg
0.63m2
CL600
10056
78084
600 sq ft
57.00m2
42,000
700
168,000
252,000
750w
3000w
38.0
kg
0.63m3

INST 249 - Viron CL Series Cartridge Filter V08-15
5
Maintenance of your filter
Maintenance Schedule: Your new product incorporates moving parts and withstands high velocity water with
chemicals in it. Some of these parts will wear in the normal course of use and require regular checks and
maintenance. Performing these checks and maintenance will identify parts that have worn and require
repair/replacement before further serious damage is sustained. A small amount of regular care and attention to your
pool equipment will help ensure long life and trouble free performance.
Timing
Maintenance Check
Service action (if required)
Fortnightly
Check pressure gauge. If pressure increase is
greater than 20kPa cleaning may be required
In accordance with instructions, clean
elements with a high pressure cleaner or
purpose made element cleaner
Three Monthly
Check inlet/outlet o’rings for leaks
Check operation of pressure gauge –salt water
can prematurely reduce the life of a gauge
Isolate Pump, turn power off, clean and
grease O rings or replace if necessary
Replace gauge if required
Annually
Compare operating pressure of a cleaned filter
to initial pressure (when new). Also check for
signs of damage to elements
If pressure is more than 30 –40 kPa different
from cleaned elements to new filter, replace
elements
Important note: Regular maintenance is important to ensure long life and trouble free performance of your pool
equipment. If unable to perform the maintenance yourself, contact your local AstralPool office who will arrange a trained
service technician to perform the maintenance for you.
Record your Equipment details here for quick reference:
Model No.: ____________________________
Serial No.: ____________________________
Initial Pressure (kPa): _______________________

INST 249 - Viron CL Series Cartridge Filter V08-15
6
WARRANTY
AstralPool Australia Pty Ltd (ABN 97 007 284 504) ("AstralPool") provides the following warranty in relation to its CL series
cartridge filters ("Product").
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
The benefits of this warranty are in addition to any rights and remedies imposed by Australian State and Federal legislation
that cannot be excluded. Nothing in this warranty is to be interpreted as excluding, restricting or modifying any State or
Federal legislation applicable to the supply of goods and services which cannot be excluded, restricted or modified.
WARRANTY
AstralPool warrants that, subject to the exclusions and limitations below, the Product will be free from defects in materials
and workmanship during the warranty period. The warranty periods are set out below and commence 30 days after the
date of purchase (to allow for installation). The warranty period may vary for different parts of the Product.
Parts
Warranty Period
Filter body, lid and locking ring
5 years
Filter Element
12 months
‘O’rings and gasket seals
12 months
If a defect appears in the Product before the end of the warranty period and AstralPool finds the Product to be defective in
materials or workmanship, AstralPool will, in its sole discretion, either:
(a) Replace or repair the Product or the defective part of the Product free of charge; or
(b) Cause the Product or the defective part of the Product to be replaced or repaired by an Authorised
AstralPool Service Agent free of charge.
AstralPool reserves the right to replace defective parts of the Product with parts and components of similar quality, grade
and composition where an identical part or component is not available.
Goods presented for repair may be replaced by refurbished goods of the same type rather than being repaired. Refurbished
parts may be used to repair the goods.
WARRANTY CLAIMS
1. If a fault covered by warranty occurs, the customer must first contact AstralPool at the contact address listed
below, or an Authorised AstralPool Service Agent.
2. Any warranty claim must be accompanied by:
(a) Proof of purchase;
(b) Full details of the alleged defect; and
(c) Appropriate documentation (such as historical and maintenance records).
3. The customer must make the Product available to AstralPool or its Authorised AstralPool Service Agent for
inspection and testing. AstralPool or its Authorised AstralPool Service Agent will attend the premises where the Product is
installed for inspection and testing. If the Product is installed:
(a) Outside a capital city metropolitan area; and
(b) is not within a 20 km radius of an Authorised AstralPool Service Agent;
Then the customer may have to pay a travel fee.
4. If such inspection and testing finds no defect in the Product, the customer must pay AstralPool's usual costs of
service work and testing. If such inspection and testing finds a defect that is not covered by this warranty, the customer

INST 249 - Viron CL Series Cartridge Filter V08-15
7
must pay AstralPool's usual costs of service work plus any parts and labour required to repair the Product, unless
recoverable from AstralPool on the failure of any statutory guarantee under the ACL.
Exclusions
The warranty will not apply where:
(a) The customer is in breach of the Terms and Conditions of Sale;
(b) The Product was used for a purpose other than one it was intended for;
(c) The Product was repaired, modified or altered by any person other than AstralPool;
(d) The Product has not been installed, maintained and/or operated in complete compliance with the
installation and operating instructions and any instructions by AstralPool;
(e) The Product has been subject to accident, negligence, alteration, abuse or misuse.
The warranty does not extend to:
a) Normal wear and tear;
b) Weather and other environmental conditions including but not limited to storm, flood, and/or heat wave damage; or
c) Service and maintenance items.
Examples of exclusions include but are not limited to:
Over tightening of locking ring or union fittings
Damage to element caused by use of high pressure water cleaners
Commercial Installations
On commercial installations, such as health clubs, motels/hotels and hydrotherapy facilities, the warranty is limited to parts
and in field labour (within capital city metropolitan areas or 20 km radius of Authorised AstralPool Service Agents) for a
period of 12 months from the date of purchase plus 30 days to allow for installation.
LIMITATIONS
AstralPool makes no express warranties or representations other than set out in this warranty.
The repair or replacement of the Product or part of the Product is the absolute limit of AstralPool's liability under this
express warranty.
