Fluidwell F011-A User manual

F011-A
TOTALIZER
Signal input flowmeter: (0)4-20mA
Options: Intrinsically Safe
F-Series - Field mounted indicators for safe and hazardous areas.
More info: www.fluidwell.com/fseries

Page 2
FW-F011-A-M_v0404_01_EN.docx
SAFETY INSTRUCTIONS
•Any responsibility is lapsed if the instructions and procedures as described in this manual
are not followed.
•LIFE SUPPORT APPLICATIONS: The F011-A is not designed for use in life support
appliances, devices, or systems where malfunction of the product can reasonably be
expected to result in a personal injury. Customers using or selling these products for use
in such applications do so at their own risk and agree to fully indemnify the manufacturer
and supplier for any damages resulting from such improper use or sale.
•Electro static discharge does inflict irreparable damage to electronics! Before installing or
opening the F011-A, the installer has to discharge himself by touching a well-grounded
object.
•The F011-A must be installed in accordance with the EMC guidelines (Electro Magnetic
Compatibility).
•Connect a proper grounding to the metal enclosure as indicated if the F011-A has an
incoming power or signal line which carries a hazardous live voltage.
The Protective Earth (PE) wire may never be disconnected or removed.
•Intrinsically Safe applications: follow the instructions as mentioned in Chapter 5.
Certificates and related documents are available on our website or from your distributor.
DISPOSAL OF ELECTRONIC WASTE
•The WEEE Directive requires the recycling of disposed electrical and electronic
equipment in the European Union. When the WEEE Directive does not apply to your
region, we support its policy and ask you to be aware on how to dispose of this product.
•The crossed out wheelie bin symbol as illustrated and found on our products tells that this
product shall not be disposed of into the general waste system or into a landfill.
•At the end of its life, equipment shall be disposed of according to the local regulations
regarding waste of the electrical and the electronic equipment.
•
helpdesk for information on the product disposal.
SAFETY RULES AND PRECAUTIONARY MEASURES
•The manufacturer accepts no responsibility whatsoever if the following safety rules and
precautions, instructions and the procedures as described in this manual are not
followed.
•Modifications of the F011-A implemented without preceding written consent from the
manufacturer, will result in the immediate termination of product liability and warranty
period.
•Mounting, electrical installation, start-up and maintenance of this device may only be
carried out by trained persons authorized by the operator of the facility. Persons must
read and understand this manual before carrying out its instructions.
•This device may only be operated by persons who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
•Check the mains voltage and information on the manufacturer's plate before installing the
F011-A.
•Check all connections, settings and technical specifications of the various peripheral
devices with the F011-A supplied.
•Open the enclosure only if all leads are free of potential.
•Never touch the electronic components (ESD sensitivity).
•Never expose the system to heavier conditions than allowed according to the
classification of the enclosure (see manufacture's plate and chapter 4).
•If the operator detects errors or dangers, or disagrees with the safety precautions taken,
he should inform the owner or principal responsible.
•The local labor and safety laws and regulations must be adhered to.

Page 3
FW-F011-A-M_v0404_01_EN.docx
ABOUT THE MANUAL
This operation manual is divided into two main sections:
•The daily use of the F011-A is described in chapter 2 
meant for users.
•The following chapters and appendices are exclusively meant for electricians/technicians. These
provide a detailed description of all software settings and hardware installation guidance.
This operation manual describes the standard F011-A as well as most of the options available. For
additional information, please contact your supplier.
A hazardous situation may occur if the F011-A is not used for the purpose it was designed
for or is used incorrectly. Please carefully note the information in this operating manual
indicated by the pictograms:
A "warning !" indicates actions or procedures which, if not performed correctly, may lead to
personal injury, a safety hazard or damage of the F011-A or connected instruments.
A "caution !" indicates actions or procedures which, if not performed correctly, may lead to
personal injury or incorrect functioning of the F011-A or connected instruments.
A "note !" indicates actions or procedures which, if not performed correctly, may indirectly
affect operation or may lead to an instrument response which is not planned.
WARRANTY AND TECHNICAL SUPPORT
For warranty and technical support for your Fluidwell products,
visit our internet site www.fluidwell.com or contact us at [e-mail].
Hardware version : 03.03.xx
Software version : 03.03.xx
Manual : FW-F011-A-M_v0404_01_EN.docx
© Copyright 2022 : Fluidwell B.V. - the Netherlands
Information in this manual is subject to change without prior notice. The
manufacturer is not responsible for mistakes in this material or for incidental
damage caused as a direct or indirect result of the delivery, performance or
use of this material.
© All rights reserved. No parts of this publication may be reproduced or used
in any form or by any means without written permission of your supplier.

Page 4
FW-F011-A-M_v0404_01_EN.docx
CONTENTS MANUAL
SAFETY INSTRUCTIONS.................................................................................................................... 2
DISPOSAL OF ELECTRONIC WASTE............................................................................................... 2
SAFETY RULES AND PRECAUTIONARY MEASURES ................................................................... 2
ABOUT THE MANUAL ........................................................................................................................ 3
WARRANTY AND TECHNICAL SUPPORT........................................................................................ 3
CONTENTS MANUAL ......................................................................................................................... 4
1INTRODUCTION ..................................................................................................................... 6
1.1 System description of the F011-A............................................................................................6
2OPERATIONAL....................................................................................................................... 7
2.1 General information .................................................................................................................7
2.2 Control panel............................................................................................................................7
2.3 Operator information and functions .........................................................................................7
3CONFIGURATION................................................................................................................... 9
3.1 Introduction ..............................................................................................................................9
3.2 Programming SETUP-level......................................................................................................9
3.2.1 Entering SETUP-level..............................................................................................................9
3.2.2 Navigating through SETUP-level.............................................................................................9
3.2.3 Programming sequence.........................................................................................................10
3.2.4 Returning to OPERATOR-level .............................................................................................11
3.3 Configuration Settings............................................................................................................11
3.3.1 Overview functions SETUP level...........................................................................................11
3.3.2 Explanation of SETUP-menu 1 - Total...................................................................................12
3.3.3 Explanation of SETUP-menu 2 - Display...............................................................................12
3.3.4 Explanation of SETUP-menu 3 - Power management..........................................................13
3.3.5 Explanation of SETUP-menu 4 - Flowmeter..........................................................................13
3.3.6 Explanation of SETUP-menu 5 - Others................................................................................14
4INSTALLATION..................................................................................................................... 15
4.1 General directions..................................................................................................................15
4.2 Installation / surrounding conditions ......................................................................................15
4.3 Handling the F-Series enclosure ...........................................................................................16
4.3.1 Identification...........................................................................................................................16
4.3.2 Opening / Removing the cover ..............................................................................................18
4.3.3 Closing / Replacing the cover................................................................................................18
4.4 Mechanical installation...........................................................................................................19
4.4.1 Dimensions Aluminum and stainless steel enclosures.......................................................19
4.4.2 Dimensions Non-metallic enclosures..................................................................................20
4.4.3 Mounting ................................................................................................................................21
4.5 Electrical installation ..............................................................................................................22
4.5.1 Electrical safety......................................................................................................................22
4.5.2 Protective Earth (PE) connections.........................................................................................22
4.5.3 Field wiring connections.........................................................................................................23
4.5.4 Power supply wiring...............................................................................................................24
4.5.5 Sensor supply ........................................................................................................................24
4.6 Terminal connectors safe area applications Type PB / PD / PL / PX.................................25
4.6.1 Terminals 1-2: Flowmeter input .............................................................................................25
4.6.2 Terminal 4-5: Power supply - type PX (default) and PD (option) ..........................................26
4.6.3 Terminal 9-10: Power supply backlight - type ZB (option).....................................................26
4.7 Terminal connectors safe area applications Type PF / PM................................................26
4.7.1 Terminal GND-1-2: Power Supply .........................................................................................26
4.7.2 Terminals 5-7: Flowmeter input .............................................................................................27
5INTRINSICALLY SAFE APPLICATIONS............................................................................. 28
5.1 Identification...........................................................................................................................28
5.2 Electrical installation in hazardous area ................................................................................29
5.2.1 General information and instructions.....................................................................................29
5.2.2 Installations based on FM or CSA certificate.........................................................................29
5.2.3 Electrical data - Control drawing............................................................................................30
5.2.4 Installations based on ATEX or IECEx certificate..................................................................32
5.2.5 Electrical data Annex 1.......................................................................................................33
5.3 Terminal connectors Intrinsically Safe applications...............................................................34

Page 5
FW-F011-A-M_v0404_01_EN.docx
5.3.1 Power supply wiring............................................................................................................... 34
5.3.2 Terminal 6 - Type PD: Sensor supply ................................................................................... 34
5.4 Configuration examples Intrinsically Safe applications ......................................................... 35
5.4.1 F011-A-PX-XI-ZB - Ex ia IIC/IIIC........................................................................................... 35
5.4.2 F011-A-PD-XI-ZB - Ex ia IIC/IIIC........................................................................................... 35
5.4.3 F011-A-PL-XI-ZB - Ex ia IIC/IIIC ........................................................................................... 36
6MAINTENANCE.....................................................................................................................37
6.1 General directions ................................................................................................................. 37
6.2 Instructions for repair............................................................................................................. 37
6.3 Battery replacement .............................................................................................................. 38
6.3.1 Safety instructions ................................................................................................................. 38
6.3.2 Replace the battery ............................................................................................................... 39
6.3.3 Disposal of batteries.............................................................................................................. 39
TECHNICAL SPECIFICATION.................................................................................40
PROBLEM SOLVING ...............................................................................................43
DECLARATION OF CONFORMITY .........................................................................44
INDEX OF THIS MANUAL..................................................................................................................45
LIST OF FIGURES..............................................................................................................................46

Page 6
FW-F011-A-M_v0404_01_EN.docx
1 INTRODUCTION
1.1 SYSTEM DESCRIPTION OF THE F011-A
Functions and features
The Totalizer model F011-A is a microprocessor driven instrument designed to display a resettable
total and non-resettable accumulated total.
This product has been designed with a focus on:
▪ultra-low power consumption to allow long-life battery powered applications (type PB / PC),
▪intrinsic safety for use in hazardous applications (type XI),
▪several mounting possibilities with GRP, aluminum or stainless steel 316L enclosures for
industrial surroundings,
▪ability to process all types of flowmeter signals.
Flowmeter input
This manual describes the unit with an analog (0)4-20mA input type from the flowmeter "-A version".
Other versions are available to process pulse or 0-10V flowmeter signals.
One flowmeter with a passive or active (0)4-20mA signal output can be connected to the F011-A. To
power the sensor, several options are available.
Fig. 1: Typical application for the F011-A.
Configuration of the F011-A
The F011-A has been designed to be implemented in many types of applications. For that reason, a
SETUP-level is available to configure your F011-A according to your specific requirements.
It includes several important features, such as span, measurement units, signal selection etc. All
setting are stored in EEPROM memory and will not be lost in the event of power failure. To extend
the battery-life time, please use of the power-management functions as described in chapter 3.3.4.
Display information
The F011-A has a large transflective LCD with all kinds of symbols and digits to display measuring
units, status information, trend-indication and key-word messages.
Running and accumulated totals can be displayed with the 8mm and 17mm digits.
A backup of the total and accumulated total in EEPROM memory is made every minute.
Options
The following options are available: intrinsic safety, power- and sensor-supply options, panel-mount,
wall-mount and weather-proof enclosures, flame proof enclosure and LED backlight.
Overview typical application F011

Page 7
FW-F011-A-M_v0404_01_EN.docx
2 OPERATIONAL
2.1 GENERAL INFORMATION
This chapter describes the daily use of the F011-A. This instruction is meant for users / operators.
•The F011-A may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed
•Take careful notice of the "Safety rules, instructions and precautionary measures" in the
front of this manual.
2.2 CONTROL PANEL
The control panel has three keys. The following keys are available:
Fig. 2: Control panel.
Functions of the keys
PROG-key
This key is used to program and save new values or settings.
The PROG-key is also used to gain access to SETUP-level; please read chapter 3.
SELECT-key
This key is used to SELECT the displayed information, like accumulated total and flow
rate.
CLEAR-key
This key is used to CLEAR the value of total.
2.3 OPERATOR INFORMATION AND FUNCTIONS
In general, the F011-A will always function at Operator level. The information displayed is dependent
upon the SETUP-settings. The signal from the connected sensor is processed by the F011-A in the
background, whichever screen refresh rate setting is chosen. After pressing a key, the display will be
updated very quickly during a 30 second period, after which it will slow-down again.
Fig. 3: Example of display information during process.
For the Operator, the following functions are available:
•Display total and accumulated total
This is the main display information of the F011-P. After selecting any other information, it will
always return to this main display automatically.
The resettable total is displayed on the upper-line of the display and the non-resettable
accumulated total on the bottom line.
RUN

Page 8
FW-F011-A-M_v0404_01_EN.docx
•Clear total
The value for total can be re-initialized. To do so, press CLEAR twice. After pressing CLEAR
once, the flashing text "PUSH CLEAR" is displayed. To avoid re-initialization at this stage,
press another key than CLEAR or wait for 20 seconds.
Re-initialization of total DOES NOT influence the accumulated total.
The accumulated total cannot be re-initialized. The value will count up to 99,999,999,999. The
unit and number of decimals are displayed according to the configuration settings for total.
•Low-battery alarm
When the battery voltage drops, it must be replaced. At first "" will flash, but as
soon as it is displayed continuously, the battery MUST be replaced shortly after!
The remaining lifetime after the first moment of indication is generally several days up to some
weeks. See paragraph 6.3 for further information on battery replacement.
Fig. 4: Example of low-battery alarm.
•Range error
As soon as the input value is 5% outside the calibrated measurement range, 
will be displayed. Meanwhile, the calibrated value will be displayed.


•Alarm 01-03
When "alarm" is displayed, please consult Appendix B: problem solving.

Page 9
FW-F011-A-M_v0404_01_EN.docx
3 CONFIGURATION
3.1 INTRODUCTION
This and the following chapters are exclusively meant for electricians and non-operators. In these,
an extensive description of all software settings and hardware connections are provided.
•Mounting, electrical installation, start-up and maintenance of the instrument may only be
carried out by trained personnel authorized by the operator of the facility. Personnel must
read and understand this Operating Manual before carrying out its instructions.
•The F011-A may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
•Ensure that the measuring system is correctly wired up according to the wiring diagrams.
The housing may only be opened by trained personnel.
•Take careful notice of the "Safety rules, instructions and precautionary measures" in the
front of this manual.
3.2 PROGRAMMING SETUP-LEVEL
Changing the settings of the F011-A may have an influence on the current operation of the
device, even when SETUP-level is still active.
Make sure that the unit is not being used for any application when altering the settings.
3.2.1 ENTERING SETUP-LEVEL
Configuration of the F011-A is done at SETUP-level, which can be reached at all times while the
F011-A remains fully operational. At SETUP-level the display will deactivate the RUN indicator and
activate the SETUP indicator.
Use the control panel to access SETUP-level
PROG-key
To enter SETUP-level, press the PROG-key for 7 seconds at OPERATOR-level.
During this time, the symbols  will be displayed.
When SETUP-level is entered, a password might be required to continue. You can
enter the password by following the procedure for programming values as described in
the following paragraphs.
A password may be required to enter SETUP.
Without this password access to SETUP is denied.
3.2.2 NAVIGATING THROUGH SETUP-LEVEL
Each function has a unique menu-number, which is displayed near the SETUP indicator at the
bottom of the display. The menu-number is a combination of two figures, e.g. 1.2. The first number
indicates the function-group and the second number indicates the function. Additionally, each
function and function-group is expressed with a keyword.
Fig. 5: SETUP matrix structure
1.1
1.2
2.1.
2.1
1.3
2.2
3.1
3.
FUNCTION GROUP
FUNCTION
FW-4100-000001-001-EN

Page 10
FW-F011-A-M_v0404_01_EN.docx
Use the control panel to navigate through SETUP-level
PROG-key
When a function is selected, this key is used to start the programming sequence.
When only a function group is selected (and no function), this key is used to scroll back
a function group (e.g. 3 →2 →1 →3).
SELECT-key
This key is used to select the next function in the list (e.g. 1 →1.1 →1.2 →1). When
the top of the list is reached, it will wrap around and return to the function group
selection.
CLEAR-key
This key is used to select the previous function in the list (e.g. 1.2 →1.1 →1 →2).
When the bottom of the list is reached, it will return to the function group selection.
When only a function group is selected (and no function), this key is used to scroll to
the next function group. (e.g. 1 →2 →3 →1).
3.2.3 PROGRAMMING SEQUENCE
After selecting a function at SETUP-level, a new value can be programmed using the control panel.
A function either contains a value (a number with optionally a decimal point, e.g. 123.45) or a list
with items (e.g. Disable Enable).
For each function that needs to change, navigate to that function and follow the steps indicated
below. During the programming sequence, the display will deactivate the SETUP indicator and
activate the PROGRAM indicator.
When programming new values, alterations will only be set after the PROG-key has been
pressed to confirm the new value! (STEP 3)
Step 1: Starting the programming sequence
PROG-key
When a function is selected at SETUP-level, this key is used to start the programming
sequence.
Step 2a: Changing a value
SELECT-key
This key is used to increment the selected digit.
When the entered value is out of range, the increase sign or decrease-sign will
be displayed while you are programming. If this value is confirmed by pressing the
PROG-key, the value will be brought within a valid range automatically.
CLEAR-key
This key is used to select the next digit. If a decimal point can be set, this will be
included in the sequence as well (e.g. [decimal point] →digit 1 →digit 2→digit 3 →
[decimal point].
SELECT-key + CLEAR-key
The combination of the SELECT-key and CLEAR-key is used to select a negative
value. When a value can also be entered as a negative number, pressing the SELECT-
key and CLEAR-

Page 11
FW-F011-A-M_v0404_01_EN.docx
Step 2b: Changing the selected item in a list
SELECT-key
This key is used to select the next item in the list (e.g. Disable →Enable).
At the end of the list, the selection will wrap around to the first selection.
CLEAR-key
This key is used to select the previous item in the list (e.g. Enable →Disable ).
At the bottom of the list, the selection will wrap around to the last selection.
Step 3: Finishing the programming sequence
PROG-key
During the programming sequence, this key is used to confirm the new value and
return to SETUP-level. To cancel the operation, either press the PROG-key for 3
seconds or wait for 20 seconds: the programming sequence is cancelled and the
former value is reinstated.
3.2.4 RETURNING TO OPERATOR-LEVEL
When all settings are configured correctly, the unit can be returned to OPERATE-level.
Please keep a record of all settings for later reference.
Use the control panel to return to OPERATE-level
PROG-key
In order to return to the operator level, press the PROG-key for three seconds.
When no keys are pressed for 2 minutes, SETUP-level will be left automatically.
3.3 CONFIGURATION SETTINGS
All settings of the F011-A can be set via the control panel.
The following paragraphs give a detailed description of each setting.
3.3.1 OVERVIEW FUNCTIONS SETUP LEVEL
SETUP FUNCTIONS AND VARIABLES
1
TOTAL
1.1
UNIT
L - m3 - kg - lb - GAL - USGAL - bbl - no unit
1.2
DECIMALS
0 - 1 - 2 - 3 (Ref: displayed value)
1.3
SPAN
0.000001 - 999,999 unit / second
1.4
DECIMALS SPAN
0 - 6
2
DISPLAY
2.1
BACKLIGHT (optional)
off - on
2.2
BL. BRIGHTNESS (optional)
1 - 5
3
POWER MANAGEMENT
3.1
LCD UPDATE
fast - 1 sec - 3 sec - 15 sec - 30 sec - off
3.2
BATTERY MODE
operational - shelf
4
FLOWMETER
4.1
FORMULA
interpolation, square root
4.2
FILTER
00 - 99
4.3
CUT-OFF
0.0 - 99.9%
4.4
CALIBRATE LOW
default - calibrate - calibrate set
4.5
CALIBRATE HIGH
default - calibrate - calibrate set
5
OTHERS
5.1
TYPE / MODEL
F011-A
5.2
SOFTWARE VERSION
03.xx.xx
5.3
SERIAL NO.
xxxxxxx
5.4
PASS CODE
0000 - 9999
5.5
TAGNUMBER
0000000 - 9999999

Page 12
FW-F011-A-M_v0404_01_EN.docx
3.3.2 EXPLANATION OF SETUP-MENU 1 - TOTAL
SETUP FUNCTIONS AND VARIABLES
1
TOTAL
1.1
UNIT
SETUP - 11 determines the measurement unit for total and
accumulated total. The following units can be selected:
L - m3 - kg - lb. - GAL - USGAL - bbl - _ (no unit).
Alteration of the measurement unit will have consequences for
operator and SETUP-level values.
Please note that the Span has to be adapted as well; the calculation
is not done automatically.
1.2
DECIMALS
The decimal point determines for total and accumulated total the
number of digits following the decimal point.
The following can be selected:
0000000 - 111111.1 - 22222.22 - 3333.333
1.3
SPAN
With the span, the flowmeter signal is converted to a quantity. The
span for Total is determined on the basis of the selected
measurement unit (SETUP 1.1), and the flow rate per second at
20mA. Enter the span in whole numbers; decimals are set with
SETUP 1.4. The more accurate the span, the more accurate the
functioning of the system will be.
Example 1 Calculating the span
Let us assume that the flowmeter generates 20mA at a rate of 652.31
USGAL per hour, the selected unit is barrels. There are 42 gallons in
one barrel; so the rate is 652.31/42 is 15.53119 barrels/hour.
This is 0.0043142 barrels/second, which is the span.
Enter for SETUP 1.3: "004314" and for SETUP 1.4: "6".
Example 2 Calculating the span
Let us assume that the flowmeter generates 20mA at a flow rate of
2,481.3 Liters/minute and the selected unit is m3".
The rate per second is 2,481.3÷60 is 41.355 L/sec. This is 0.041355
m3/sec., which is the span.
Enter for SETUP 1.3: "041355" and for SETUP 1.4: "6".
1.4
DECIMALS SPAN
This setting determines the number of decimals for the Span
(SETUP 1.3). The following can be selected:
0 - 1 - 2 - 3 - 4 - 5 - 6
Please note that this function influences the accuracy of the Span
indirectly. This setting has NO influence on the displayed number of
digits for total (SETUP 1.2)!
3.3.3 EXPLANATION OF SETUP-MENU 2 - DISPLAY
SETUP FUNCTIONS AND VARIABLES
2
DISPLAY
The functions below will only affect the optional LED-backlight.
2.1
BACKLIGHT (optional)
If a LED backlight has been supplied, it can be turned on or off.
2.2
BL. BRIGHTNESS
(optional)
The backlight brightness is adjustable. The following can be selected:
1 5 (where 1 is minimum and 5 is maximum brightness)

Page 13
FW-F011-A-M_v0404_01_EN.docx
3.3.4 EXPLANATION OF SETUP-MENU 3 - POWER MANAGEMENT
When used with the internal battery option, the user can expect reliable measurement over a long
period of time. The F011-A has several smart power management functions to extend the battery life
time significantly. Two of these functions are available.
SETUP FUNCTIONS AND VARIABLES
3
POWER MANAGEMENT
3.1
LCD NEW
The calculation of the display-information influences the power
consumption significantly. When the application does not require a
fast display update, it is strongly advised to select a slow refresh
rate. Please understand that NO information will be lost; every pulse
will be counted and the output signal will be generated in the normal
way. The following can be selected:
Fast - 1 sec - 3 sec - 15 sec - off.
Example battery life-time:
•FAST update: about 3 years.
•1 sec update: about 5 years.
After a button has been pressed by the operator - the display refresh
rate will always switch to FAST for 30 seconds. When "OFF" is
selected, the display will be switched off after 30 seconds and will be
switched on as soon as a button has been pressed.
3.2
BATTERY MODE
The F011-A has two modes: operational or shelf. After "shelf" has
been selected, the F011-A can be stored for several years; it will not
process the sensor signal; the display is switched off but all settings
and totals are stored. In this mode, power consumption is extremely
low. To wake up the F011-A again, press the SELECT/key twice.
3.3.5 EXPLANATION OF SETUP-MENU 4 - FLOWMETER
SETUP FUNCTIONS AND VARIABLES
4
FLOWMETER
4.1
FORMULA
The F011-A can process the (0)4-20mA signal in two ways:
▪Interpolation: the signal is processed linear
R = S x I
▪Square root: for differential pressure
R = S I
where R = the calculated flow rate, S = the maximum flow rate at
20mA (span is programmed with SETUP 1.4) and I = the scaled
analog input value between 0 (zero) for (0)4mA and 1 (one) for 20mA.
4.2
FILTER
The analog output signal of a flowmeter mirrors the actual flow. This
signal is measured several times per second by the F011-A. The
value measured is a "snap-shot" of the real flow as it will be
fluctuating. With the help of this digital filter a stable and accurate
reading can be obtained. The filter level can be set to a desired value.
The filter is based on three input values: the filter level (01-99), the
last measured analog value and the last average value. The higher
the filter level, the longer the response time on a value change will be.
Below, several filter levels with response times are indicated:
Filter value
Response time to step change in analog input value (seconds)
50%
75%
90%
99%
01
filter disabled
filter disabled
filter disabled
filter disabled
02
0.3
0.5
1.0
1.8
03
0.5
1.0
1.5
3.0
05
1.0
1.8
2.8
5.3
10
1.8
3.5
5.6
11
20
3.5
7.0
11
23
30
5.3
10
17
34
50
8.8
17
29
57

Page 14
FW-F011-A-M_v0404_01_EN.docx
75
13
26
43
86
99
17
34
57
114
4.3
CUT-OFF
To ignore small flows e.g. leakage or vibration, a low-flow cut-off can
be set as percentage of the full range of 16mA (or 20mA). When the
analog value is less than required with this setting, the signal will be
ignored. The cut-off value can be programmed in the range 0.0 -
99.9%. Below two examples are given.
Formula (SETUP 4.1)
Span
(SETUP 1.4)
Required
cut-off
Cut-off (SETUP 4.3)
Required output
Interpolation
450 L/min
25 L/min
(25/450)*100%=5.5%
16mA*5.5%+4mA=4.88mA
Square root
450 L/min
25 L/min
(25/450)2*100%=0.3%
16mA*0.3%+4mA=4.05mA
4.4
TUNE MIN / 4mA
With this setting it is possible to calibrate the input value for (0)4mA
as the signal from the flowmeter might not be exact 4.0mA (or 0.0
mA) at flow rate zero. This function will measure the real output value
at flow zero.
The input loop powered version - type A-PL - requires a signal of at
least 4mA; not lower!
Be very sure that the offered signal is correct before calibration is
executed, as this has major influence on the accuracy of the system
After pressing PROG, three settings can be selected:
▪CALIBRATE: with this setting, the input will be calibrated with the
actual "(0)4mA" value. After pressing enter, CAL SET will be
displayed as soon as the calibration is completed. From that
moment, the analog value must be more than the calibrated value
before the signal will be processed.
▪DEFAULT: with this setting, the factory value is re-installed.
▪CAL SET: to select the last calibrated value.
4.5
TUNE MAX / 20mA
With this setting it is possible to calibrate the input value for 20mA as
the signal from the flowmeter might not be exact 20.0mA at maximum
flow rate. This function will measure the real output value at maximum
flow rate.
Be very sure that the offered signal is correct before calibration is
executed, as this has major influence on the accuracy of the system
After pressing PROG, three settings can be selected:
▪CALIBRATE: with this setting, the input will be calibrated with the
actual "20mA" value. After pressing enter, CAL SET will be
displayed as soon as the calibration is completed. From that
moment, the analog value must be less than the calibrated value
for reliable measurements.
▪DEFAULT: with this setting, the factory value is re-installed.
▪CAL SET: to select the last calibrated value.
3.3.6 EXPLANATION OF SETUP-MENU 5 - OTHERS
SETUP FUNCTIONS AND VARIABLES
5
OTHERS
5.1
TYPE / MODEL
For support and maintenance it is important to have information about
the characteristics of the F011-A.
Your supplier will ask for this information in the case of a serious
breakdown or to assess the suitability of your model for upgrade
considerations.
5.2
SOFTWARE VERSION
5.3
SERIAL NO.
5.4
PASS CODE
All SETUP-values can be pass code protected.
This protection is disabled with value 0000 (zero).
Up to and including 4 digits can be programmed, for example 1234.
5.5
TAGNUMBER
For identification of the F011-A and communication purposes, a
unique tag number of maximum 7 digits can be entered.

Page 15
FW-F011-A-M_v0404_01_EN.docx
4 INSTALLATION
4.1 GENERAL DIRECTIONS
•Mounting, electrical installation, start-up and maintenance of this instrument may only be
carried out by trained personnel authorized by the operator of the facility. Personnel must
read and understand this Operating Manual before carrying out its instructions.
•The F011-A may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
•Make sure that the measuring system is correctly wired up according to the wiring
diagrams. Protection against accidental contact is no longer assured when the enclosure
cover is removed or the panel cabinet has been opened (danger from electrical shock).
The enclosure may only be opened by trained persons authorized by the operator of the
facility.
•Take careful notice of the "Safety rules, instructions and precautionary measures" at the
front of this manual.
The F0-Series can be supplied as suitable for Safe Area or Hazardous Area. This is indicated in the
model code (shown on the product label) by the Type X* designator, with following options:
•Type XX: Suitable for safe area applications only (e.g. F011-A-XX)
Follow the mechanical and electrical installation instructions shown in chapter 4.
•Type XF: Suitable for explosion proof / flame proof applications (e.g. F011-A-XF)
Follow the electrical installation instructions as shown in chapter 4 and
the mechanical installation instructions of the enclosure that are supplied separately.
•Type XI: Suitable for intrinsically safe applications (e.g. F011-A-XI)
Follow the general mechanical and electrical installation instructions of chapter 4
and the specific installation instructions of chapter 5.
4.2 INSTALLATION / SURROUNDING CONDITIONS
Take the relevant IP classification of the
enclosure into account (see identification plate).
Even an enclosure rated for IP67 / TYPE 4(X)
should NEVER be exposed to strongly varying
(weather) conditions.
When used in very cold surroundings or varying
climatic conditions, inside the instrument case,
take the necessary precautions against moisture.
Mount the F-Series onto a solid structure to avoid
vibrations.
For use in Safe and Hazardous Areas (or Locations), the following conditions apply:
Relative humidity:
< 90% RH
Outdoor use:
suitable for outdoor use
IP and NEMA rating:
IP65 (panel mount), IP67 (field mount) and Type 4X
Supply voltage fluctuation:
As indicated by the supply range (e.g. 10V to 30V),
otherwise +/- 10% unless stated otherwise
Means of protection:
Intrinsically safe:
IS
Ordinary locations:
Class I (PE connected metal enclosure)
Class II (non-metallic enclosure)
Over-voltage category:
II (when supplied from mains)
Pollution degree:
2 (internal environment), 3 (external environment)
Ambient:
Intrinsically safe:
-40 °C to +70 °C, -40 °F to +158 °F
(limited to +50 °C, 122 °F for EPL Da)
Ordinary locations:
-40 °C to +80 °C, -40 °F to +176 °F
Altitude:
up to 2000 m

Page 16
FW-F011-A-M_v0404_01_EN.docx
4.3 HANDLING THE F-SERIES ENCLOSURE
4.3.1 IDENTIFICATION
The F0-Series can be supplied as suitable for Safe Area or Hazardous Area.
Suitability for Intrinsic Safety is indicated in the model code by Type XI (e.g. F011-A-XI).
For Intrinsically Safe applications: Installation and identification labels are shown in chapter 5.
Identification label
To identify your F0-Series device, all field mount enclosures have a weatherproof identification label
placed on the outside of the unit.
Fig. 6: Identification Example of F0-Series identification label (safe area)
Installation label
A second label is located on the inside and shows additional installation data. For panel mount
enclosures, the outside label is not available, so the inside label also serves as identification label.
After installation, the inside label is only visible from the rear side of the panel.
Fig. 7: Identification Example of F0-Series installation label (safe area - Type PB, PX or PD)

Page 17
FW-F011-A-M_v0404_01_EN.docx
Fig. 8: Identification Example of F0-Series installation label (safe area - Type PF or PM)
Serial number and year of production
The serial number can be reviewed on the identification label or in
SETUP-menu Others. The production date is either shown separately on
the label or indicated by the first 4 digits of the serial number
representing year and week number (YYWW).

Page 18
FW-F011-A-M_v0404_01_EN.docx
4.3.2 OPENING / REMOVING THE COVER
To open the F-Series enclosure, the front cover needs to be removed. Please follow this procedure:
1. If necessary, clean the enclosure with an anti-static cloth
made damp with a mild soap solution. Wait for the
enclosure to dry before opening.
2. While loosening the screws, hold on to the front cover to
prevent it from falling down.
3. Unscrew all 4 screws from the front of the enclosure and
(if present) mind that the serrated washers are kept with
the screws.
4. Carefully take the front cover away from the rear cover,
minding that the wiring stays intact.
5. Depending on the work to be done, all terminal
connectors can be removed from their mating parts and
the front cover is now completely separate.
4.3.3 CLOSING / REPLACING THE COVER
To replace the cover on the F-Series enclosure, follow this procedure:
1. Re-insert all terminals to their original position.
2. Carefully position the front cover onto the back cover, making sure
that the gasket falls nicely into the gutter of the back cover.
3. Replace all 4 screws into the front cover and mind that the serrated
washers are replaced (metal enclosure only).
4. Fasten all 4 screws in an alternating way so that the front cover is
placed evenly across the edge of the back cover.
Tighten the 4 screws with the torque value for the type of enclosure
as specified in following table:
Plastic enclosure: 1 Nm per screw
Aluminum enclosure: 1 Nm per screw
Aluminum w. extended back enclosure: 1 Nm per screw
Stainless steel enclosure: 2 Nm per screw
5. The F-Series in now ready to be returned to service.

Page 19
FW-F011-A-M_v0404_01_EN.docx
4.4 MECHANICAL INSTALLATION
4.4.1 DIMENSIONS ALUMINUM AND STAINLESS STEEL ENCLOSURES
•When ordering stainless steel enclosures, insert S after H, e.g. HA → HSA).
•
H: HBx).
Fig. 9: Dimensions Aluminum and stainless steel enclosures
75 mm (2.95")
130 mm (5.12") 112 mm (4.40")
60 mm (2.36")
120 mm (4.72")
M20 x 1,5
PG9 PG9
30mm 30mm
22,5mm
M20 x 1,5
M16 x 1,5 M16 x 1,5
30mm 30mm
22,50mm
M20 x 1,5
22,5mm
M20 x 1,5 M20 x 1,5
25mm 25mm
22,5mm
1/2"NPT
0.9"
3x 1/2"NPT
0.12" 0.12"
0.9"
HA
HM
HN
HO
HP
HT
HU
6 x M12
12mm 12mm
24mm24mm
36mm
36mm
14mm 17mm

98 mm (3.86)
HB

31 mm

HZ
4x M20 x 1,5
15 15
15
HV
2323
16
mm

Page 20
FW-F011-A-M_v0404_01_EN.docx
4.4.2 DIMENSIONS NON-METALLIC ENCLOSURES
Fig. 10: Dimensions Non-metallic enclosures
75 mm (2.95")
130 mm (5.12") 112 mm (4.40")
60 mm (2.36")
120 mm (4.72")
HD
HK
HK back box:
(flat bottom)
HE
HF
HG
HH
D=12mm
12mm 12mm
24mm24mm
36mm
36mm
14mm 17mm
22,5mm
30mm 30mm
D=16mm
D=20mm
0.9"
D=22mm (0.866")
22,5mm
25mm 25mm
D=20mm D=20mm
D=16mm
HC
75 mm (2.95") 118 mm (4.65”)
104 mm (4.09”)
HJ
0.9”
0.12” 0.12”
3x D=22mm (0.866”)

98 mm (3.86)

31 mm

